TRONE Zendoro ZETBCDER-12.WH User manual

Zendoro Instruction Manual

TABLE OF CONTENTS
1. Safety precautions ............................................................................... 2
2. Signs and meanings ............................................................................. 2
3. Warnings........................................................................................... 3-6
4. Line drawings
4.1.Remote Control ............................................................................. 7
4.2.Bidet Toilet..................................................................................... 8
5. Automatic Functions............................................................................ 9
6. Getting to know your remote............................................................ 10
7. Getting to know your lid and seat
7.3. Opening and closing the lid ........................................................ 10
7.4. Opening and closing the seat...................................................... 11
7.5. Adjustable Seat temperature...................................................... 11
7.6. Setting automatic lid opening/closing ........................................ 11
8. Getting to know your bidet
8.7. Stop............................................................................................. 12
8.8. Rear Wash................................................................................... 12
8.9. Adjustable Water Pressure ......................................................... 12
8.10. Adjustable Spray Wand Position............................................... 12
8.11. Adjustable Water Temperature................................................ 12
8.12. Front Wash ............................................................................... 13
8.13. Drying........................................................................................ 13
8.14. Adjustable Drying Temperature ............................................... 13
8.15. Eco Mode.................................................................................. 13
9. Getting to know your bowl
9.16. Night Light................................................................................. 13
9.17.Automatic Flush......................................................................... 14
10. Pairing the remote............................................................................. 14
11. Troubleshooting Guide ...................................................................... 15
12. Cleaning and care .............................................................................. 16
13. Product specifications........................................................................ 18

SAFETY PRECAUTIONS
Basic safety precautions must be followed when handling or using
electrical products, especially those within the reach of children.
Please make yourself aware of the following guidelines:
•This product should only be used by children who are 8
years and older or by persons with disabilities who have
received supervision and instructions on the safe use and
the hazards involved when using this product.
•It is unwise to allow children to play with this electronic
bidet, supervised or not.
•It is not recommended that children who are unsupervised
be allowed to clean and perform maintenance for this
product.
SIGNS AND MEANINGS
Improper operations due to ignorance
of the instructions may result in death
or injury
Improper operations due to ignorance
of the instructions may result in body
injury and property loss
Not allowed
Should be followed

WARNINGS
Please do not touch the electrical outlet with wet hands.
•Or it may cause electric shock
Please do not pour liquids such as water or detergent
on top of the electronic outlet and the toilet.
•Or it may cause fire, electric shock, heat or
short circuit
•Or it may cause injury and indoor water
seepage because of the damaged part
Never attempt to disassemble, repair, or alter the
product yourself.
•Or it may cause fire, electric shock, heat or
short circuit
Please do not install the toilet in the car, ship, or any
other moving objects.
•Or it may cause fire, electric shock, short circuit
or fault
•Or the ceramic, seat, and the main part will be
damaged due to fall
Do not use if it is broken. Under the following condition,
please turn off the toilet and the water angle valve.
•Water leakage from the pipe or inner parts of
the toilet
•Smoke
•Unusual heating and smell
•Blockage

Continuous use of the toilet despite of the damages and
above-mentioned conditions may result to fire, electric
shock, heat, short circuit, injury, and indoor water
seepage.
Please don't use seawater and other water except for
tap water or potable well water (underground water)
•Or it may cause skin irritation or inflammation
During thunderstorms, do not touch the electrical plug
•Or it may cause electric shock
Please do not let the water inlet soft pipe connect to the
electrical plug and outlet
•Or it may cause fire, electric shock, heat, and
short circuit because of moisture condensation
Please do not damage the power cable or plug. Do not
strike, yank, twist, bend excessively, or alter the
electrical cords. Also, do not place anything heavy on,
bind or pinch the cords
•Or it may cause fire, electric shock, heat, and
short circuit if it's broken
Please do not use a loose or faulty electrical outlet
•Or it may cause fire or short circuit
Please use the electrical outlet and wire appliance in the
specified outlet
•Or it may cause fire
Please do not put your finger or anything into the warm
air outlet. Do not cover or put objects or clothes on the
air outlet.
•Or it may cause scalding, electric shock, or fire

Pay attention to the low temperature scalding
Improper use of warm seat may cause low temperature
scalding
If you sit for a long time, please turn the temperature
setting to "off level. Please turn the seat temperature
setting to "off level, warm air-dry temperature to "low"
level under the following situations
•Children and elders or those who cannot adjust
the temperature to the proper level
•Persons with disability and patients with
behavioral problems
•People who have taken medicines with side
effects of hypnosis (hypnotics, cold meds, etc.),
orthose who are excessively drinking alcohol, too
tired, and with somnolence
This is an electrical product, please do not install it in a
place where it will get wet easily or in areas with high
humidity. If installed in the bath- ram, please install a
ventilator to maintain the bathroom ventilation.
Or it may cause fire or electric shock
The product must be connected to the cold water
supply
•Or it may cause body burn or machine fault
Please confirm if the electrical outlet is connected to
the ground.
•Or it may cause electric shock because of fault
or short circuit
The outlet for power wire should obey the following
rules or it may cause fire or electric shock.
Please ask the maintenance team or similar
department to replace the power soft wire if it is broken
to avoid danger. Repair work must be done by
professionals.

Please do not throw lighted cigarettes and other
flaming material into the toilet.
•Or it may cause fire
Do not install this product in a room where it may be
frosted. The room temperature can’t be less than 39.2
degree Fahrenheit.
Don’t block the air outlet
Do not use excessive force when closing the cover and
the seat.
Do not intentionally soil, spray, or block the cleaning
nozzle.
Pull out the plug regularly and clean off the dust with a
dry cotton cloth.
Use the new hose parts that come with the product.
The old ones should not be reused.
Keep the product away from the heater.
Close the water supply valve before taking out the
junction block.
If you need to be away for a long time, be sure to plug
it out, turn off the water, and drain the remaining water
inside the bidet. The remaining water may freeze when
the product is transported over long distances or stored
for a long time in cold winter or alpine region.

LINE DRAWINGS
Remote Control

Electronic Bidet

AUTOMATIC FUNCTIONS
Self-Cleaning Wand
The spray wand cleans itself before and after every use by rinsing itself
as it enters and exits.
Deodorizer
The deodorizer starts anytime the seat sensor has been activated. You
can stop the deodorizer by pressing the DEODORIZER button { } in
idle mode. The deodorizer will stop automatically after a user leaves the
seat for around 60 seconds.
Pre-Rinse
The Pre-Rinse starts anytime the seat sensor has been activated. A quick
jet of water covers the bowl to help waste slide down.
Automatic Flush
The toilet will flush automatically when being changed from washing to
drying, or when someone leaves the seat sensor if no washing has
occurred. This setting can be turned on and off.
Automatic Opening/Closing
The lid can be set to automatically open when approaching the toilet.
The factory default has this setting turned off. You can turn on/off this
setting by pressing and holding the OPEN/CLOSE THE LID button [ ].

GETTING TO KNOW YOUR REMOTE
Level Indicator Light
•The Level Indicator Light [ ] will display the
current level.
•The spray wand position adjustment, and the
temperature adjustments have five levels. When you
successfully change from one level to the other the
light indicator changes position and you hear one
beep. If you hear two beeps you have reached the
maximum or minimum level.
•The water pressure adjustment has three levels.
When you successfully change from one level to the
other the light indicator changes position and you
hear one beep
GETTING TO KNOW YOUR LID & SEAT
Opening and Closing the lid
There are four methods to open and close the lid. These methods
include (1) by hand, (2) using the remote, (3) using the foot sensor
and (4) automatically.
•Method 1: Using your hand you can open or close the lid.
oNote: Do not interrupt the lid opening or closing
with your hand if it is moving via another method. This
can cause the gears to break.
•Method 2: Press the OPEN/CLOSE THE LID button { } to
open or close the lid.
oNote: If the seat is also open, it will close the seat
and the lid together.
•Method 3: When the lid is closed, gently tap the location of
the foot sensor.
oNote: You cannot close the lid using the foot sensor.

•Method 4: The lid will automatically open when you are
close to it if the automatic lid function is active. The lid will
automatically close on its own after no motion is detected for
approximately 3 minutes.
oNote: You can activate or deactivate this feature.
See instructions on this feature on page 12.
Opening and Closing the seat
There are three methods to open and close the seat. These methods
include (1) by hand, (2) using the remote, and (3) using the foot
sensor.
•Method 1: Using your hand you can open or close the seat.
oNote: Do not interrupt the lid opening or closing
with your hand if is moving via another method. This
can cause the gears to break.
•Method 2: Press the OPEN/CLOSE THE SEAT button { } to
open or close the seat.
oNote: If the lid is closed, it will open the lid and seat
together.
•Method 3: When the seat is closed, gently tap the location of
the foot sensor.
Adjustable Seat Temperature
•Press the SEAT TEMP. button [ ] until the desired
temperature is selected. Pressing the button cycles through the
5 different levels continually.
Setting Automatic Lid Opening/Closing
Factory Settings: OFF
•Press and hold the OPEN/CLOSE THE LID button [ ]
•When Automatic Lid Opening activates or deactivates you hear
a short beep.

GETTING TO KNOW YOUR BIDET
Stop
•Press the Stop button [ ] to immediately end any of the
following functions: rear wash, front wash, and drying.
Rear Wash
•When the user is seated, press the REAR/MOVE button [ ] to
start rear washing. Press the REAR/MOVE button [ ] again to
start the oscillating function which increases the cleaning area.
•Press the STOP button [ ] to stop Rear Wash.
oNote: It will stop cleaning after continuous cleaning
for about 120 seconds.
Adjustable Water Pressure
•When you are washing, use the Plus or Minus button + / - to
increase or decrease the water pressure. There are three levels
of adjustment which can be seen on the level display.
Adjustable Spray Wand Position
•While washing, press the Up or Down button { } to increase
or decrease the wand position. There are five levels of
adjustment which can be seen on the level indicator light.
Adjustable Water Temperature
•Press the WATER TEMP. button [ ] until the desired
temperature is selected. Pressing the button cycles through the
5 different levels continually.

Front Wash
•When the user is seated, press the FRONT/MOVE button [ ]
to start front washing. Press the FRONT/MOVE button again to
start the oscillating function which increases the cleansing area.
oNote: It will stop cleaning and start the drying
function automatically after continuous cleaning for
about 120 seconds.
Drying
•When the user is seated, press the DRY/DRYER TEMP button [ }
to start the drying function.
•Press the STOP button [ ] to stop drying.
oNote: The dryer will stop automatically after
continuous drying for about 5 minutes.
Adjustable Drying Temperature
•While you are drying, press the DRY/DRYER TEMP button [ ]
until the desired temperature is selected. There are five levels
of temperature adjustment which can be seen on the level
indicator display.
Eco Mode
•Press and hold the STOP button [ ] to turn on/off the Eco
Mode. When Eco Mode is active, the eco icon turns on on the
lcd display. Eco Mode keeps the seat temperature lower when
nobody is on the toilet.
GETTING TO KNOW YOUR BOWL
Night Light
•Press the LIGHT button [ ] to turn on/ the night light.

Automatic Flush
Factory Settings: OFF
•Press and hold the FULL FLUSH button [ ] to turn this function
on/off.
PAIRING THE REMOTE
1) Press and hold the STOP button [ ] and then press the
REAR/MOVE button [ ]. All five level indicator lights being
flashing.
2) Use the PLUS or MINUS button + / - to select a user code (as
shown below). The level indicator light displays the
corresponding user code.
oNote: You can choose any user code for your toilet.
Multiple user codes are provided if you have more than
one toilet in the house and do not want signal
interference.
3) Press and hold the STOP button [ ] and then press the
REAR/MOVE button [ ]. The toilet beeps once, indicating
that the remote control and toilet are successfully paired.

TROUBLESHOOTING GUIDE
Fault
Failure Analysis
Solutions
No Flushing
Check if supply hose is
buckling
Unbuckle supply hose
Angle valve is off
Turn on angle valve
Water supply is cut off
Connect water supply
Poor Flushing
Water supply hose
buckling
Unbuckle the supply
hose
Angle valve is not fully
turned on
Completely open angle
valve
Filter is dirty
Clean the filter
No water coming
out from the wand
Water supply is cut off
Connect water supply
Angle valve is partially or
completely closed
Open the angle valve
Filter is dirty
Clean the filter
No air flow from
dryer
Toilet is in standby mode
or power save mode
Change toilet to
functioning mode

CLEANING AND CARE
Note: Turn off the power, close the water supply angle valve, and
stop the water supply before doing any maintenance work. DO
NOT rinse this product with water during maintenance.
Toilet Bowl Cleaning
•Please ensure that the electrical plug is taken out.
•Wipe any dirt/stains with a soft damp cloth.
Self-Cleaning Nozzle Maintenance
•While not sitting on the unit, press the REAR/MOVE
button { }. The spray wand will then extend.
•After the nozzle extends, it can be disassembled for
cleaning
•Use a soft cloth or soft brush to clean
•Do not use excessive force. Press the STOP [ ] button
to take the nozzle tube back once you’re done cleaning.

Cleaning the Steel Mesh Filter
Note: Turn off the power and close the water supply angle valve.
If your toilet is poorly flushing, please clean filter.
•Unscrew angle valve nut
•Remove filter net
•Use a brush and warm water to clean filter net
•Reinstall filter net and angle valve nut. Turn on water
supply and the power.
Replacing the Battery
•Unplug the DC connector and remove the battery box
•Replace the battery with a new 9V
•Reconnect the battery box and DC connector
oNote: Keep the battery out of reach of children.
Please confirm the positive and negative of battery. Do
not change, disassemble, or burn the battery. Don’t mix
it with old batteries or different types of batteries to
avoid leakage or explosion.

PRODUCT SPECIFICATIONS
Model Number
ZETBCDER-12.WH
Rated Voltage
120V, 60Hz
Rated Power
1170W
Power Cable
7ft
Flush Volume
1.6/1.1 GPF
Rough-in
Distance
12”
Water Pressure
Range
0.09MPa (dynamic water pressure, flow rate
3.96Gal/min or more)
Warm Air Volume
Over .2m³/min
Net Weight
99.2 lbs
Waterproof Level
IPX4
Cleaning Time
Normal cleaning is about 120 seconds
Nozzle Position
Adjustment
5 levels
Heating Mode
Instant Heat
Safety Device
Thermal fuse, Water temperature sensor,
Ground protection, Thermostat, Over
temperature protection, Leakage protection plug
Deodorization
Nano Intelligent Deodorization

[e-mail]
www.troneplumbing.com
