Tronic QI TPBQ 10000 A1 User manual

Qi®WIRELESS CHARGING POWER
BANK / POWERBANK QI®
TPBQ 10000 A1
IAN 387735_2101 IAN 387735_2101
Distributed by/Distribuido por:
LIDL US, LLC, Arlington, VA 22202
Model No./Modelo Núm.: HG08292A-US/HG08292B-US
Version/ Versión: 07/2021
Made in/Hecho en: China
QI®WIRELESS CHARGING POWER BANK
Operation and Safety Notes
POWERBANK QI®
Instrucciones de utilización y de seguridad

US-EN
Operation and Safety Notes Page 3
US-ES
Instrucciones de utilización y de seguridad Página 30

US-EN 3
Description of signal words .......................... Page 4
Customer service............................................... Page 4
List of pictograms used................................... Page 5
Introduction ......................................................... Page 6
Intended use......................................................... Page 6
Trademark notice.................................................. Page 7
Scope of delivery................................................. Page 7
Parts description................................................... Page 8
Technical specifications ....................................... Page 10
Important safety instructions....................... Page 11
Before use ............................................................ Page 16
Operation and use............................................ Page 16
Charging the power bank ................................... Page 16
Checking the battery status................................. Page 18
Qi wireless charging............................................ Page 19
Charging mobile devices with the
power bank via the USB output ports................. Page 21
Charging mobile devices wirelessly
and via USB simultaneously................................ Page 22
Troubleshooting................................................. Page 23
Cleaning and care ............................................. Page 26
Storage during non-use.................................. Page 26
Disposal................................................................. Page 27
Three year limited warranty........................ Page 27

US-EN 4
DESCRIPTION OF SIGNAL WORDS
WARNING indicates a hazardous situation that, if not
avoided, could result in death or serious injury.
CAUTION indicates a hazardous situation that, if not
avoided, could result in minor or moderate injury.
NOTICE indicates information considered important, but
not hazard related (e.g. messages related to property
damage).
CUSTOMER SERVICE
Visit a LIDL store for further assistance.
Please have your IAN number ready.
Call customer service at 1 [phone]
Visit the Website Customer Service Platform at
www.lidl.com/contact-us
IAN 387735_2101

US-EN 5
List of pictograms used
This symbol means that the operating
instructions must be observed before using
the product.
Direct current / voltage
Technology to optimize charging time.
The equipment complies Quick Charge 3.0
specifications and agreements issued by
Qualcomm Technologies, Inc.
PD: Power Delivery (PD), introducted by
the USB Implementers Forum, Inc., is a
specification for handling higher power
and allows a range of devices to charge
quickly over a USB connection. It operates
by facilitating a conversation between two
devices to negotiate a power contract so
they can determine how much power can
be pulled from the charger.

US-EN 6
Qi®WIRELESS CHARGING
POWER BANK
PIntroduction
Congratulations on your purchase. You have selected a quality
product. The instructions for use are a part of the product.
They contain important information about the safety, use and
disposal of the product. Before using the product, please learn
about all the safety information and usage instructions. Only
use the product as described and for the specified applications.
If you lend the product to someone else, please also give all the
instructions.
Intended use
This Qi®WIRELESS CHARGING POWER BANK (hereinafter
referred to as “product”) is an Information Technology device
which is solely intended to be used to charge mobile devices
which have Qi wireless charging technology. Devices that do
not support Qi wireless technology can be charged through a
USB port.
This product is not intended for commercial use. Manufacturer is
not liable for damages, which result from non-intended use.
“Qi“ and the Qi logo mark are trademark of
the Wireless Power Consortium (WPC)

US-EN 7
Trademark notice
‒ USB®is a registered trademark of USB Implementers Forum,
Inc.
‒ “Qi“ and the Qi logo mark are trademark of the Wireless
Power Consortium (WPC).
‒ The TRONIC trademark and trade name is the property of
their respective owners.
‒ The Smart Fast Charge trademark and trade name is the
property of their respective owners.
‒ Qualcomm is a trademark of Qualcomm Incorporated,
registered in the United States and other countries.
Qualcomm Quick Charge is a trademark of Qualcomm
Incorporated. All Qualcomm Incorporated trademarks are
used under license.
‒ Any other names and products may be trademarks or
registered trademarks of their respective owners.
Scope of delivery
1 Qi®wireless charging power bank
1 USB type A to USB type C cable
1 Instructions for use

US-EN 8
Parts description
Please refer to the fold out page.
1Qi Power bank
2Qi charging surface
3On/Off button
4Qi status indicator
5LED display for battery capacity
6USB Type C (PD) input and output port
7USB Type A to Type C cable
8Instructions for use
9Type A (QC3.0) output port

US-EN 9
2
4
3
7
8
9
1
5
6

US-EN 10
Technical specifications
Built-in rechargeable battery: 3.7 V , 10,000 mAh,
37Wh (Lithium polymer)
USB type C input and output
voltage / current (PD): 5 V , 3 A /
9 V , 2 A/
12 V ,1.5 A
USB type A output voltage /
current (QC3.0): 5 V , 3 A /
9 V , 2 A /
12 V , 1.5 A
Wireless charging power: 10 W max
Wireless charging distance: ≤ 5 mm
Charging efficiency: up to 86%
Frequency band: 136.60 - 147.60 kHz
Transmitted maximum radio
frequency power (H-field):
-10.62 dBuA/m at 10m
distance
Maximum output power: 15 W*
Maximal output current: 3 A*
Minimal output current: approx. 100 mA
Operating temperature: 41–95°F (5–35°C)
Storage temperature: 32–113°F (0–45°C)
Humidity (no condensation): 10 –70 %
Dimensions: 5.40 in x 2.72 in x 0.71in
(137 x 69 x 18 mm)
Weight: 8.64 oz (245 g)
*If all outputs are used at the same time, the sum of the output
current must not exceed 3 A (5 V 3 A, 15 W).

US-EN 11
Notes on Qi technology:
This product with Qi wireless charging is designed to comply
with the Qi (Wireless Power Consortium) standard, but no
guarantees are given for its compatibility with all products that
comply with the standard.
IMPORTANT SAFETY
INSTRUCTIONS
READ ALL INSTRUCTIONS. KEEP FOR FUTURE
REFERENCE. INCLUDE ALL DOCUMENTATION
WHEN PASSING THIS PRODUCT ON TO
OTHERS.
DANGER TO LIFE AND RISK OF ACCIDENT FOR
INFANTS AND CHILDREN!
Risk of suffocation!
 Never leave children unsupervised with the packaging
material. The packaging materials pose a suffocation
hazard. Children frequently underestimate the dangers.
The packaging materials are not a toy. This product is
not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction concerning use of the product by
a person responsible for their safety. Children should be
supervised to ensure that they do not play with the product.

US-EN 12
Risk of property damage
 This product does not contain any parts which can be
serviced by the user.
 Keep the product away from moisture, dripping and
splashing water!
 Do not place burning candles or other open fire on or next
to the product.
 Check the product before every use! Discontinue use if any
damage to the product or the charging cable is detected!
 If you notice smoke or an unusual noise or odor, unplug the
product immediately and remove the USB cable.
 Sudden temperature changes may cause condensation
inside the product. In this case, allow the product to
acclimatise for some time before using it again to prevent
short circuits!
 Do not operate the product near heat sources, e.g. radiators
or other devices emitting heat!
Do not try to open the product! It has no internal parts requiring
maintenance.
Radio interference
 Never use the product on airplanes, in hospitals, service
rooms, or near medical electronic systems. The wireless
signals transmitted could impact the functionality of sensitive
electronics.

US-EN 13
 Keep the product at least 0.65 ft / 20 cm from pacemakers
or implantable cardioverter-defibrillators, as the
electromagnetic radiation may impair the functionality of
pacemakers.
 The radio waves transmitted could cause interference in
hearing aids.
 Do not place the product near flammable gases or
potentially explosive areas (e.g. paint shops) with the
wireless components on, as the radio waves emitted can
cause explosions and fire.
 The range of the radio waves varies by environmental
conditions. In the event of wireless data transmission,
unauthorized third parties receiving the data cannot be
excluded.
 Lidl US, LLC is not responsible for interference with radios
or televisions due to unauthorized modification of the
product. Lidl US, LLC further assumes no liability for using
or replacing cables and products not distributed by Lidl
US, LLC. The user of the product id fully responsible for
correcting interference caused by such unauthorized
modification to the product, as well as replacement of such
products.
Ensure that:
 no direct heat sources (e.g. heating) can affect the product.
 the product is not exposed to bright artificial light.
 any contact with splashed and dripping water and corrosive
liquids is avoided and the product are not operated in the
vicinity of water. In particular, the product should never be
submerged in liquid; do not place any vessels filled with
liquid, for example, vases or drinks, on or near the product.

US-EN 14
 the product is not used in the immediate vicinity of magnetic
fields (e.g. speakers).
 no fire sources (e.g.burning candles) are placed on or near
the product.
 no foreign objects penetrate the product.
 the product is never subjected to extreme temperature
fluctuations as this could result in condensation and electrical
short circuits. If the product were subjected to extreme
temperature fluctuations, however, wait (2 hours) until the
product has reached ambient temperature before use.
 the product is never subjected to excessive shocks and
vibrations.
 the connected cables are always laid in such a manner
that nobody can step on or trip over them. There is a risk of
injury.
 no objects are placed on a connected cable and cables
are not connected over sharp edges because this could
otherwise damage the functionality of sensitive electronics.
Changes or modification to this product not expressly approved
by the party responsible for compliance could void the user‘s
authority to operate the product.
This product has been tested and complies with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
product generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with

US-EN 15
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
product causes harmful interference to radio or television
reception, which can be determined by turning the product
off and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and receiver.
• Connect the equipment to an outlet on a different circuit
than the one the receiver is connected to.
• Consult the dealer or an experienced radio / TV technician
for help.
This product complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This product may
not cause harmful interference, and (2) this product must accept
any interference received, including interference that may cause
undesired operation.
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between
the radiator and your body. This transmitter must not be co-
located or operating in conjunction with any other antenna or
transmitter.
SAVE THESE
INSTRUCTIONS

US-EN 16
PBefore use
Remove all packaging materials from the product.
Please also check the content of delivery inside the
packaging to see if there are any damages. If you notice
any damage or missing parts, please contact the dealer who
sold this product.
POperation and use
Charging the power bank
The built-in rechargeable battery must be fully charged before
using the product.
To charge the power bank 1only use power supplies
with an output voltage and current matching the rated input
voltage and current as stated in “Technical specifications” of
this user manual.
ATTENTION! The power bank should not be charged
from a PC or notebook.
In order to get the fastest charging speed, charge the power
bank 1via the PD port 6using a USB Type C to Type
C cable (not included) and a USB Power Delivery (PD)
enabled power charger (not included).
Connect the USB Type C plugs of your Type C to Type C
cable (not included) to the PD port 6of the power bank
1and the PD port of your USB PD enable power charger
(not included) (see fig. A).

US-EN 17
A
PD enabled power supply
and USB Type C to Type C
cable not included.
B
QC3.0 enabled or
conventional power supply
not included.
7

US-EN 18
Alternatively, you could charge the power bank 1via USB
Type C port 6using the included USB Type-A to Type C
cable with a conventional USB charger but the charging
time will be longer. Connect the USB Type C plug of the USB
cable 7with the PD port 6and connect the USB Type
A plug of the USB cable 7to the USB power supply (not
included) (see fig. B).
The Qi wireless charging function of the power bank is disabled
when the power bank is being charged.
During the charging process, the LED display for battery
capacity 5flashes and shows you the appropriate charge
level of the internal battery in percentage.
This is approx percentage of power bank capacity but not
actual measurement.
ATTENTION! Do not connect any device to the power
bank for charging while the power bank itself is charging.
Remove the charging cable from the power bank when it is fully
charged.
Checking the battery status
You can check the battery status on the LED display for battery
capacity 5of the power bank 1at anytime.
Briefly press the On/off button 3. The LED display for
battery capacity 5shows the approximate charge status of
the internal battery for approx. 30 seconds.

US-EN 19
Qi wireless charging
Put your Qi compatible device to be charged on the centre
of the Qi charging surface 2of the power bank 1.
Slightly adjust the charging position of the device to be
charged so that its charging surface is facing down to the
centre of the Qi charging surface 2of the power bank 1.
Briefly press the On/off button 3to switch on the power
bank 1. The wireless charging will then start automatically.
When Qi charging is active, Qi status indicator 4flashes
blue*. The LED display for battery capacity 5shows the
current charge status of the internal battery throughout the
wireless charging process.
If wireless charging does not start, move your device to be
charged more accurately to the centre of the Qi charging
surface 2until the Qi status indicator 4starts flashing.
While in idle status (standby mode), the Qi status indicator
4will light blue*. The Qi status indicator 4will go off if
no Qi compatible device is detected and idle for approx. 30
seconds.
When the charging process has finished (i.e. the mobile
device is fully charged) the Qi status indicator 4will light
blue or flash blue in colour*.
The Qi status indicator 4will go off when errors are
detected on the Qi charging surface 2*. In this case,
remove your device and make sure that there are no
unwanted metallic objects between your device and the Qi
charging surface 2and then try again.
To stop the wireless charging, take your device away from
the Qi charging surface 2. The Qi status indicator 4will
light blue(standby mode)*. If no Qi compatible device is

US-EN 20
detected for approx. 30 seconds, the Qi status indicator 4
will go off.
To switch off the power bank 1during the standby mode,
press the On/off button 3twice. The Qi status indicator 4
and LED display for battery capacity 5will then go off.
*
1) Qi status indicator 4may change back to blue colour
(standby mode) when wireless charging has finished if the
mobile device closed the wireless communication between
the Qi charging surface 2and the mobile device.
2) All devices to be wirelessly charged must comply with Qi
Standard.
3) The different modes of the Qi status indicator are
summarized below:
Qi wireless
charging status
Qi status
indicator 4
Starting process (boot phase),
standby or searching for a Qi
charging device
Light blue
Charging Flash blue
Fully charged
Light blue or flash blue
(depending on the mobile
devices being charged)
Fault/Error condition Indicator off
No Qi compatible device detected Indicator on
