Tronic TPB 10000 A1 User manual

POWER BANK
TPB 10000 A1
IAN 378647_2101
POWER BANK
Operation and Safety Notes
POWERBANK
Bedienungs- und Sicherheitshinweise

GB/IE/NI
Operation and Safety Notes Page 5
DE/AT/CH
Bedienungs- und Sicherheitshinweise Seite 23

3
4
5
6
7
1 2

A
B
PD enabled power supply and
USB Type C to Type C cable not
included.
PD-fähiges Netzteil und USB-
Typ-C auf Typ-C-Kabel nicht im
Lieferumfang enthalten.
4
QC3.0 enabled or conventional
power supply not included.
QC3.0-fähiges oder
konventionelles Netzteil nicht
enthalten.

GB/IE/NI 5
Warnings and symbols used........................ Page 6
Introduction ......................................................... Page 9
Intended use......................................................... Page 9
Trademark notice.................................................. Page 9
Scope of delivery................................................. Page 10
Parts description................................................... Page 10
Technical specifications ....................................... Page 11
Safety notices ..................................................... Page 12
Before use ............................................................ Page 14
Operation and use............................................ Page 14
Charging the power bank ................................... Page 14
Checking the battery status................................. Page 16
Charging mobile devices with the power bank.. Page 16
Troubleshooting................................................. Page 17
Cleaning and care ............................................. Page 19
Storage during non-use.................................. Page 19
Disposal................................................................. Page 20
Warranty and service ..................................... Page 21
Warranty .............................................................. Page 21
Warranty claim procedure.................................. Page 22
Service.................................................................. Page 22

GB/IE/NI 6
Warnings and symbols used
These instructions for use contain the following warnings:
DANGER! This symbol with the signal word
“DANGER“ indicates a hazard with a high
level of risk which, if not avoided, will result in
serious injury or death.
WARNING! This symbol with the signal
word “WARNING“ indicates a hazard with
a medium level of risk which, if not avoided,
could result in serious injury or death.
CAUTION! This symbol with the signal word
“CAUTION“ indicates a hazard with a low
level of risk which, if not avoided, could result
in minor or moderate injury.
ATTENTION! This symbol with the signal
word “ATTENTION“ indicates a possible
property damage.
NOTE: This symbol with the signal
word “NOTE“ provides additional useful
information.

GB/IE/NI 7
WARNING! EXPLOSION HAZARD!
A warning with this symbol and word
“WARNING! EXPLOSION HAZARD”
indicates the potential threat of explosion.
Failure to observe this warning may result in
serious or fatal injuries and potential property
damage. Follow the instructions in this
warning to prevent serious injuries, a danger
to life or property damage!
This symbol means that the operating
instructions must be observed before using
the product.
Direct current / voltage
Technology to optimize charging time.
The equipment complies Quick Charge 3.0
specifications and agreements issued by
Qualcomm Technologies, Inc.

GB/IE/NI 8
PD: Power Delivery (PD), introducted by
the USB Implementers Forum, Inc., is a
specification for handling higher power
and allows a range of devices to charge
quickly over a USB connection. It operates
by facilitating a conversation between two
devices so they can determine how much
power can be pulled from the charger.
CE mark indicates conformity with relevant EU
directives applicable for this product.
UKCA mark indicates conformity with relevant
Great Britain regulations applicable for this
product.
(The UKCA mark logo is valid in Great Britain
only.)

GB/IE/NI 9
POWER BANK
PIntroduction
We congratulate you on the purchase of your new product.
You have chosen a high quality product. The instructions for
use are part of the product. They contain important information
concerning safety, use and disposal. Before using the product,
please familiarise yourself with all of the safety information and
instructions for use. Only use the product as described and for
the specified applications. If you pass the product on to anyone
else, please ensure that you also pass on all the documentation
with it.
Intended use
This POWER BANK (hereinafter referred to as “product”) is
an Information Technology device which is solely intended to
be used to charge mobile devices which are normally charged
through a USB port.
This product is not intended for commercial use. Manufacturer is
not liable for damages, which result from non-intended use.
Trademark notice
‒ USB®is a registered trademark of USB Implementers Forum,
Inc.
‒ The TRONIC trademark and trade name is the property of
their respective owners.
‒ The Smart Fast Charge trademark and trade name is the
property of their respective owners.
‒ Any other names and products may be trademarks or
registered trademarks of their respective owners.

GB/IE/NI 10
‒ Qualcomm is a trademark of Qualcomm Incorporated,
registered in the United States and other countries.
Qualcomm Quick Charge is a trademark of Qualcomm
Incorporated. All Qualcomm Incorporated trademarks are
used under license.
Scope of delivery
1 Power bank
1 USB type A to USB type C cable
1 Instructions for use
Parts description
Please refer to the fold out page.
1USB type C (PD) input and output port
2USB type A (QC3.0) output port
3Power bank
4USB cable (USB type A to Type C)
5Instructions for use
6ON / OFF button
7LED indicator for battery capacity

GB/IE/NI 11
Technical specifications
Built-in rechargeable battery: 3.7 V , 10,000 mAh,
37Wh (Lithium polymer)
USB type C input voltage /
current (PD): 5 V , 3 A /
9 V , 2 A/
12 V ,1.5 A
USB type C output voltage /
current (PD): 5 V , 3 A /
9 V , 2 A /
12 V , 1.5 A
USB type A output voltage /
current (QC3.0): 5 V , 3 A /
9 V , 2 A /
12 V , 1.5 A
Maximum output power: 15 W*
Maximum output current: 3 A*
Minimum output current: approx. 60 mA
Operating temperature: 5 – 35 °C
Storage temperature: 0 – 45 °C
Humidity (no condensation): 10 –70 %
Dimensions: approx.
132 x 68 x 16 mm
Weight: approx. 216 g
*If All USB output ports are used at the same time, the total
output current will only have 3A (5V 3A, 15W).

GB/IE/NI 12
Safety notices
Please familiarise yourself with all instructions for use and safety
notices before using the product for the first time. When passing
this product on to third parties, please be sure to include all
documentation.
Check the product for visible external damage before use.
Do not use the product if damaged or dropped.
This product may be used by children age 8 years and
up, as well as by persons with physical, sensory or mental
impairments or lacking experience and/or knowledge,
provided they are supervised or instructed in the safe use
of the product and understand the associated risks. Do not
allow children to play with the product. Never allow children
to clean or maintain this product unsupervised.
DANGER! Packaging materials are not toys. Keep all
packaging materials out of the reach of children. Suffocation
hazard!
Always use the product on flat and smooth surface. The
product could be damaged if it falls.
Do not expose the product to direct sunlight or high
temperatures. It may otherwise overheat and be damaged
beyond repair.
Do not operate the product near heat sources such as
radiators or other devices producing heat.
Do not operate the product near open flames.
The product is not designed for use in rooms with high
temperatures or humidity (i.e bathrooms) or those in which a
great amount of dust is generated.
Do not expose the product to extremely high temperatures.
This applies in particular if you are thinking about storing
the product in your car. Over a prolonged period of time,
the car and the glove compartment could become extremely
hot. Remove electric and electronic devices from the car.

GB/IE/NI 13
Do not use the product immediately after it has brought
from a cold room to a warm room. Allow the product to
acclimatise before you switch it on.
WARNING! Never open the product casing. This
product has no internal parts requiring maintenance.
Do not independently convert or modify the product.
Repairs to the product must be performed by authorised
specialised companies or customer service. Improper repairs
may place the user in considerable danger. They will also
void the warranty.
Do not expose the product to dripping water or splashing
water and do not place containers filled with liquids such as
vases or open drinks on top of or beside the product.
Immediately switch the product off and remove the charging
cable from the product if you smell burning or see smoke.
Have the product examined by a qualified technician before
using it again.
If you use a USB power supply, the socket used must always
be easily accessible so that the USB power supply can be
quickly removed from the socket in the case of emergency.
Please also refer to the manufacturer‘s instruction manual.
WARNING! EXPLOSION HAZARD! Improper
handling of lithium polymer batteries can result in fire,
explosions, hazardous substances leaking, or other
dangerous situations! Do not throw the product into the fire,
as this could lead to the built-in battery exploding.
Observe the usage restrictions and prohibitions of use
for battery-operated products in situations which may be
hazardous such as at petrol stations, airports, hospitals, etc.
WARNING! During charging process, please be
noticed that the product must not be covered. Otherwise the
product can be heated.
The product should never be charged at a PC or notebook,
because due to the high power consumption, the PC or
notebook could be damaged.

GB/IE/NI 14
PBefore use
NOTE: Remove all packaging materials from the product.
Please also check the content of delivery inside the
packaging to see if there are any damages. If you notice
any damage or missing parts, please contact the dealer who
sold this product.
POperation and use
Charging the power bank
The built-in rechargeable battery must be fully charged before
using the product.
To charge the power bank 3only use power supplies
with an output voltage and current matching the rated input
voltage and current as stated in “Technical specifications” of
this user manual.
ATTENTION! The power bank should not be charged
from a PC or notebook.
In order to get the fastest charging speed, charge the
powerbank 3via the PD port 1using a USB Type C to
Type C cable (not included) and a USB Power Delivery (PD)
enabled power charger (not included). Connect the USB
Type C plugs of your Type C to Type C cable (not included)
to the PD port 1of the powerbank 3and the PD port of
your USB PD enable power charger (not included) (see fig.
A).
Alternatively, you could charge the powerbank 3via USB
Type C port 1using the included USB Type-A to Type C
cable 4with a conventional USB charger but the charging

GB/IE/NI 15
time will be longer. Connect the USB Type C plug of the USB
cable 4with the PD port 1and connect the USB Type
A plug of the USB cable 4to the USB power supply (not
included) (see fig. B).
The LED indicator for battery capacity 7shows you the
approximate charge level of the internal battery via 4 LED
lights as described below:
LED indicator 7 status Power bank capacity
level
1 LED flash 0 - 25 %
1 LED light up, 1 LED flash 25 - 50 %
2 LED light up, 1 LED flash 50 - 75 %
3 LED light up, 1 LED flash 75 - 100 %
4 LED light up 100%
*This is approx percentage of power bank capacity but not
actual measurement.
NOTE: The 4th LED light will turn green when the power
bank is charged via PD input port 1using a PD-enabled USB
charger. If a conventional USB charger is used for charging,
the 4th LED will still be the original colour of the battery status
indicator.
WARNING! Do not connect any device to be charged to
power bank as long as the power bank is charging. Remove the
charging cable from the power bank when it is fully charged.

GB/IE/NI 16
Checking the battery status
You can check the battery status via the LED indicator 7of the
power bank 3at anytime.
Briefly press the ON / OFF button 6. The LED indicator
7shows the approximate charge status of the internal
battery capacity level for approx. 30 seconds.
Charging mobile devices with the
power bank
You can charge up to two devices at the same time using the
power bank 3. If all outputs are used at the same time, the
sum of the output current may not exceed 3 A.
To charge your QuickCharge 3.0 enabled device, connect
the USB Type A plug of USB cable 4or the original USB
Type A to USB Type C charging cable of the device to
be charged to the USB type A output 2which supports
QuickCharge 3.0. Then connect the USB Type C plug of the
USB cable 4to the USB Type C input port of the device to
be charged. The charging process will start automatically.
NOTE: You could also charge your conventional USB
devices from the USB Type A output port 2of the power bank
using the included USB cable 4or a USB Type A to micro
USB cable (not included).
To charge your USB Power Delivery (PD) enabled device,
connect the USB Type C plugs of your USB Type C to Type
C cable (not included) to the PD port 1of the power bank
and the PD port of the device to be charged. The charging
process will start automatically.
In case if the charging process does not begin immediately,
press the ON / OFF button 6briefly to begin the charging
process. The current battery status of the power bank 3is

GB/IE/NI 17
displayed during the charging process by the LED indicator
for battery capacity 7.
To end the charging process, disconnect the USB charging
cable from the mobile device and the power bank 3. The
power bank will switch OFF after approx. 30 seconds.
Or simply double click with ON / OFF button 6. The
power bank and the LED indicator for battery capacity 7
will switch off.
NOTE:
1. If you use all the USB ports, a voltage of 5 V will output at
the outputs. The maximum output current must not exceed
3.0 A for all outputs. If all USB outputs are used, fast charge
is not possible.
2. If USB type A output 2or PD port 1is in quick charge
or PD mode, and another USB port is connected to another
device for charging, the quick charge mode or PD mode
will be terminated and switched to normal charge mode. All
devices will now be charged at 5 V each.
PTroubleshooting
= Problem
= Cause
= Solution
The power bank 3is not being charged.
It may be that the power bank is not connected properly.
Check that it is connected.

GB/IE/NI 18
In order to charge the power bank, use a power supply
with an output voltage and current matching the rated input
voltage and current as stated in „Technical specifications“ of
this user manual.
A connected device is not being charged.
The battery is drained.
Charge the battery.
The device is not connected.
The device is not connected. Check that it is connected.
Briefly press the ON / OFF button 6to begin the charging
process.
The current consumption of the connected device might be
too low.
Check with your connected device manual and see if your
connected device current consumption comply with this
product. The minimal output current of the power bank is
approx. 60 mA.
The power bank 3does not react when the
button is pressed or when a device is connected,
even though the battery is charged.
The power consumption of the connected devices is too
high. Therefore, the internal overcurrent protection device
was activated.
Reduce the number of devices connected and press the
ON / OFF button 6.

GB/IE/NI 19
PCleaning and care
This product has no internal parts requiring maintenance.
Moisture entering the product may result in damage.
Ensure no moisture enters the product during cleaning to
prevent damaging the product beyond repair.
Do not use abrasive, solvent-based or aggressive cleaners.
These can damage the surface of the product.
Only clean the product with a slightly damp cloth and mild
washing-up liquid.
PStorage during non-use
Store the product in a dry dust-free location, protected from
direct sunlight.
If the product is not used for a long time, the built-in
battery should be fully charged to prolong its operating
life. Regularly charge the built-in battery if you do not use
the product for a long period of time. This is necessary to
preserve the battery.

GB/IE/NI 20
PDisposal
Packaging:
The packaging is made of environmentally friendly materials,
which may be disposed of through your local recycling facilities.
Observe the marking of the packaging materials for
waste separation, which are marked with
abbreviations (a) and numbers (b) with following
meaning: 1–7: plastics / 20–22: paper and
fibreboard / 80–98: composite materials.
Product:
Contact your municipality for information on how to
dispose of your worn-out product.
The adjacent symbol of a crossed out dustbin on
wheels indicates this product is subject to Directive
2012/19/EU. This directive states at the end of the
life this product must not be disposed of through
regular household refuse but must be returned to special
collection sites, recycling depots or waste management
companies.
This disposal is free of charge to you.
Protect the environment and dispose of properly.
The product is recyclable, subject to extended manufacturer
responsibility, and collected separately.an be obtained from
your local authority.
The built-in rechargeable battery cannot be removed for
disposal. Return the product completely to a collection site for
used electronics.
