Lightolier Calculite 784 User manual

Ceiling Cutout: 6 1/2” Dia.
Reflector Trims Frame-In Kit Lamp
784CLW Specular Clear finish with white flange. 7784 A23 200W
784CLP Specular Clear finish with polished flange.
784CL Specular Clear finish with molded trim ring (flangless).
784 Add suffix for other finishes (see options).
Molded
Trim Ring
Flush Trim
(Molded
trim ring removed)
White or
Polished Flange
Top View
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
Features
1. Socket Cup: Die-cast aluminum cup effectively dissipates heat and assures
lamps maintain proper optical alignment to reflector. Snaps onto reflector
neck for easy tool-less installation. Contains medium base porcelain socket
with nickel plated screw shell wired and No 18 SF1 leads to J-Box.
2. Mounting Brackets: Adjust vertically from inside of fixture. Durable 16 ga.
steel construction. Use with standard 3/4" or 1 1/2" lathing channels (by oth-
ers), or Lightolier accessory mounting bars.
3. Retaining Springs: Precision tooled springs secure aperture mounting
frame for quick tool-less installation.
4. Reflector: Specular clear Alzak®upper reflector, retained by spring latches
for inspection and maintenance, top relampable.
5. Junction Box: 14 ga. steel, 4" x 3 1/2" x 2" box.
6. Thermal Protector: Meets NEC and UL requirements. Insulation must be
kept 3" away from fixture sides and wiring compartments and must not be
placed above fixture in a manner which will entrap heat.
7. Aperture Cone: 16 ga. Specular Alzak®aluminum,or optical black multi-
groove. Available with white or polished flange or with removable white
molded trim ring (field paintable).
8. Multigroove Baffle: One piece seamless aluminum. Sharply detailed con-
centric rings with "sawtooth" profile, optical black finish. Permanently fas-
tened to specular clear reflector.
9. Mounting Collar: Die-formed steel painted in baked black enamel.
Other Reflector Finish Options
Comfort Clear Diffuse CCD Specular Black BK
Specular Gold GD Multi-Groove Baffle MG
(MG is only availabe w/ molded trim ring)
Flange Options
White W
Polished Flange P
Flangeless Leave Blank (molded trim ring)
Accessories and Options
18" Mounting Bars 1950 (set of 2)
27" Mounting Bars 1951 (set of 2)
T-Bar Anchor Clips 1956 (set of 4, for 1950 & 1951 bars)
Wood Joist Mtg. Bars 7994 (set of 2)
Sloped Ceiling Adapters 7920 (see SCA specification sheet)
Step Down Transformer 7997 (see separate specification sheet)
Chicago Air Plenum LC (add suffix to Frame-in Kit)
Electrical
UL Listed for maximum of 8 No. 12, 75°C through branch circuit conductors, or
60°C supply conductors for end of run.
Labels
UL Listed for damp locations, I.B.E.W.
Alzak®is a registered trademark of ALCOA.
Calculite®Incancescent Open Downlight 784/7784
Page 1 of 2 6” Aperture A23 Ellipsoidal Reflector

This quick calculator chart determines the number and spacing of 150 Watt A-23 units for any desired level of
illumination. For 200 Watt A-23 units, multiply chart values by 1.4.
80% Ceiling; 50% Walls; 20% Floor
Room Surface Reflectances:
150W A-23
2730 Lumens Per Lamp
RCR = 10 (Rm. Width - Mtg. Ht. above work plane)
RCR = 5 (Rm. Width - 2 x Mtg. Ht. above work plane)
RCR = 1 (Rm. Width - 10 x Mtg. Ht. above work plane)
CENTER TO CENTER DISTANCE OF FIXTURES IN FEET
AREA PER FIXTURE IN SQUARE FEET
INITIAL FOOTCANDLES
3 4 5 6 7 8 9 10 11 12
25 50 75 100 125
10
20
30
40
50
60
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50 30 10 0
ROOM CAVITY RATIO
20% FLOOR CAVITY REFLECTANCE
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
.53 .52 .51 .52 .51 .51 .50 .50 .49 .48 .48 .48 .47 .47 .46 .45
.51 .49 .48 .50 .48 .47 .48 .47 .46 .47 .46 .45 .46 .45 .44 .44
.48 .47 .45 .48 .46 .45 .47 .45 .44 .45 .44 .43 .44 .44 .43 .42
.46 .44 .43 .46 .44 .42 .45 .43 .43 .44 .42. 41 .43 .42 .41 .40
.44 .42 .40 .44 .41 .40 .43 .41 .40 .42 .40 .39 .40 .40 .39 .38
.42 .40 38. 42 .40 .38 .41 .39 .38 .40 .39 .38 .40 .38 .37 .37
.40 .38 .36 .40 .38 .36 .39 .37 .36 .39 .37 .36 .38 .37 .36 .35
.38 .36 .34 .38 .36 .34 .37 .35 .34 .37 .35 .34 .36 .35 .34 .33
.36 .34 .32 .36 .34 .32 .36 .34 .32 .35 .34 .32 .35 .33 .32 .32
.35 .32 .31 .35 .32 .31 .34 .32 .31 .34 .32 .31 .34 .32 .31 .30
1
2
3
4
5
6
7
8
9
10
% WALL REFLECTANCE
Conversion Factor:
300
600
90
60
30
900
1200
E.T.L, Inc. report No. 389989
Date: 04-17-64
Efficiency: 47.5%
Spacing Ration = 1.1
150W A23
2700 Lumens Per Lamp
DEG CP ZONAL FLUX
2 1/2 1279 31
7 1/2 1257 90
12 1/2 1249 148
17 1/2 1335 220
22 1/2 1287 270
27 1/2 1097 278
32 1/2 646 190
37 1/2 137 46
42 1/2 25.6 9
47 1/2 5.5 2
52 1/2 0 0
Candlepower Summary
ZONE LUMENS % LAMP
0-30 1037 38.5
0-40 1273 47.0
0-60 1284 47.5
