Tronic TRC 4 A1 User manual

BATTERY CHARGER TRC 4 A1
BATTERY CHARGER
Operation and safety notes
IAN 321887_1904

GB / IE / NI Operation and safety notes Page 5

3
1
2

5GB/IE/NI
List of
pictograms used...... Page 7
Introduction................. Page 8
Intended use...................... Page 9
Part description.................. Page 10
Technical data................... Page 10
Included items ................... Page 12
General safety
instructions................... Page 13
Safety instructions for
rechargeable batteries...... Page 18
Initial use ....................... Page 25

6 GB/IE/NI
Handling and
operation....................... Page 26
Charging rechargeable
batteries ............................. Page 26
Charging your USB device ... Page 28
Bad cell / Short circuit
protection........................... Page 30
Cleaning and care... Page 33
Cleaning the housing........ Page 34
Troubleshooting ...... Page 35
Disposal.......................... Page 36
Warranty....................... Page 40
Warranty claim procedure ... Page 42
Service ............................... Page 43

7GB/IE/NI
List of pictograms used
This symbol means that
the operating instructions
must be observed when
using the product.
Only use the product in
dry indoor rooms.
Volt (alternating voltage)
Hertz (frequency)
Protection class II. The
power adaptor has a
double insulation.
Observe the warnings
and safety instructions!
Direct current

8 GB/IE/NI
Battery charger
Introduction
We congratulate you on
the purchase of your new
product. You have chosen
a high quality product. The instructions
for use are part of the product. They
contain important information concern-
ing safety, use and disposal. Before
using the product, please familiarise
yourself with all of the safety information
and instructions for use. Only use the
product as described and for the spec-
ified applications. If you pass the
product on to anyone else, please
ensure that you also pass on all the
documentation with it.

9GB/IE/NI
Intended use
This product is intended exclusively for
non-commercial use in the charging of
rechargeable Ni-MH batteries (AA/
AAA) with standard rated capacities
and charging of battery-operated
products with a USB interface, such
as MP3 Player or smart phone. Any
other use or uses beyond those men-
tioned are considered to be unintended
use. Claims of any kind for damage
resulting from unintended use will not
be accepted. The operator alone bears
the liability.
Only use the product in
dry indoor rooms.

10 GB/IE/NI
Part description
1Loading slots for type AA / AAA
2USB output
3Display
Technical data
Input voltage: 100–240 V∼
(alternating current)
50 / 60 Hz
Power
consumption: 14 W
Protection class: II / (The power
adaptor has a
double insulation.)
Operating
temperature: 0 °–30 °C
Storage
Temperature: -20 °–40 °C

11GB/IE/NI
Humidity
(no condensation): 5–80 %
Output voltages: 4 x 1.5 V (Loading
slots 1–4)
Charge currents: 4 x 450 mA (Type
AA) or 4 x 200mA
(Type AAA)
Maximum
assessment
capacity: AAA: 1000 mAh
AA: 2700 mAh
USB 2.0 output: 5 V, 1000 mA
Measurements
(W x H x D): approx. 67.9 x
68.1 x 121.6mm
Weight: approx. 128 g
(without recharge-
able battery)

12 GB/IE/NI
Included items
1 Battery charger
4 Ni-MH rechargeable batteries
(Type AA Mignon, Ni-MH, 1.2V,
2400 mAh, HR6, HRMR 15/51,
gastight) for Model A
4 Ni-MH rechargeable batteries
(Type AAA Micro, Ni-MH, 1.2V,
900 mAh, HR03, HRMR 11/45,
gastight) for Model B
1 Operating manual

13GB/IE/NI
General safety
instructions
BEFORE USING THE
PRODUCT, PLEASE
FAMILIARISE YOURSELF
WITH ALL OF THE SAFETY
INFORMATION AND
INSTRUCTIONS FOR USE!
WHEN PASSING THIS
PRODUCT ON TO OTHERS,
PLEASE ALSO INCLUDE
ALL THE DOCUMENTS!

14 GB/IE/NI
WARNING! Packag-
ing material should not
be used as a play thing.
There is a risk of suffo-
cation!
Before use check the
product for visible ex-
ternal damage. Do not
put into operation a
product that is dama ged
or has been dropped.
If the power plug is
damaged, it must be

15GB/IE/NI
replaced by a qualified
persons in order to avo id
a hazard.
This product may be
used by children aged
8 over and by persons
with reduced physical,
sensory or mental capa-
bilities or lack of expe-
rience and knowledge,
provided that they are
under supervision or
have been told how to
use of the product safety

16 GB/IE/NI
and are aware of the
potential risks. Children
must not play with the
product. Cleaning and
user maintenance tasks
must not be carried out
by children unless they
are supervised.
Do not make any changes
or modifications to the
product yourself.
Protect the product from
moisture and liquid pen-
e tration. Never subm erge

17GB/IE/NI
the product in water, do
not place the product
in the vicinity of water
and do not stand any
object filled with liquid
(i.e. vases) on the product.
Do not operate the
product in the vicinity
of open flames (e.g.
candles).
Unplug this product
from wall outlet when
not in use.

18 GB/IE/NI
Safety
instructions for
rechargeable
batteries
DANGER TO LIFE!
Keep rechargeable
batteries out of reach
of children. If acciden-
tally swallowed seek
immediate medical at-
tention.
DANGER OF
EXPLOSION!

19GB/IE/NI
Never recharge non-
rechargeable batteries.
Do not short-circuit re-
chargeable batteries
and / or open them.
Overheating, fire or burst-
ing can be the result.
Never throw recharge-
able batteries into fire
or water.
Never burn or
incinerate any
battery / Never pierce,
attempt to disassemble

20 GB/IE/NI
or short-circuit / Always
observe polarity (+/-)
and charging times.
Do not exert mechanical
loads to rechargeable
batteries.
Risk of leakage of re-
chargeable batteries
Avoid extreme environ-
mental conditions and
temperatures, which
could affect rechargeable
