ORE Offshore 4324C User manual

0009918 RV A
Nov 2011
OPERATION AND MAINTENANCE MANUAL
FOR THE
ORE OFFSHORE MODEL 4324C-V1661
BATTERY CHARGER
(For Model 436XD Series Transponders)
ORE Offshore, 4 Little Brook Road, West Wareham, MA 02576 USA
Phone: [phone] Fax: [phone] http://www.ore.com
Copyright ©2009 ORE Offshore
All Rights Reserved

4324C-V1661 MULTIBEACON CHARGER
i
TABLE OF CONTENTS
1.0 Specifications....................................................................................... 1
2.0 Operation And Maintenance ................................................................... 2
2.1 General......................................................................................... 2
2.2 Configuring Charger For Single Internal Battery Pack Beacons ............. 2
2.3 Maintenance .................................................................................. 2
3.0 Figures
1 - Fuse position and Input Voltage Selection........................................... 3
2 - Charger outline ............................................................................... 4
3 - Pigtail Wiring .................................................................................. 5

4324C-V1661 MULTIBEACON CHARGER
1
1.0 SPECIFICATIONS
Dimensions of enclosure:
6.3" L x 3.6" W x 2.5" H
Input Voltage:
Selectable, 120 or 220 VAC +10% 50/60 Hz
Fused both sides of line, 0.5 Amp
Input current:
32 mA AC @ N.L. (no VAC)
Output current:
Maximum 300 mA (with fully charged battery;
50 mA)
Output:
Short circuit protection
Input connector:
i.e.c. Type enclosure mounted
Output connector:
Two screw terminals mounted on case
Temperature rating:
-10° to 55° c

4324C-V1661 MULTIBEACON CHARGER
2
2.0 OPERATION AND MAINTENANCE
2.1 GENERAL
The Model 4324C-V1661 is a desk top NiCad battery charger. It is designed
to work at 120 or 220 Volts AC 50/60Hz This is manually selected (see
Figure 1).
This V1661 charger is compatible with the 436XD series Multibeacons only.
The 4324C-V1661 is a dual output whose current is limited to 110 mA or
300 mA but will reduce output to about 40 mA as battery Voltage
approaches a full charge. The 4324C-V1661 will fully charge a dual battery
pack (12 Nicad cells in series) in 14-16 hours at the 300 mA switch setting.
The charger can be left trickle charging the battery at this low current (40
mA) almost indefinitely.
The 4324C has internal short circuit protection, however, it is not
recommended to maintain a short for any extended period of time.
2.2 CONFIGURING THE CHARGER FOR SINGLE INTERNAL BATTERY PACK
Select the proper AC input voltage, 100/120/220 VAC, reference Figure 1 for
details.
Connect the pigtail (LPIL7M) to the terminal screw on the charger. The red
lead of the pigtail goes to the plus screw terminal, and the black lead goes to
the minus screw terminal.
Plug the other end of the connector into the Beacon.
2.3 MAINTENANCE
A quick test to see if the charger is operating is to put a (VOM) Volt/Ohm
Meter across the plus and minus output screw terminals and measure
approximately 19 volts +1 volt.
The 4324C-V1661 has two internal in-line fuses. If there is no output as
tested in 2.41, check to see if the fuses are open, reference Figure 1.

4324C-V1661 MULTIBEACON CHARGER
3

4324C-V1661 BEACON CHARGER
4
FIGURE 1
Squeeze Tabs and Pull Out Module to
Select Input Voltage Ranges
120
120
100
120
220
Remove From Outer
Module the Inner
Module and Position
the Proper AC
Voltage Setting to
Appear in the
Modules Window
Model 4324C-V1623
MultiBeacon Battery Charger
