Tronic TLGL 1000 B1 User manual

IAN 274326
UNIVERSAL CHARGER TLGL 1000 B1
UNIVERSAL CHARGER
Operating instructions
UNIVERSAL-LADEGERÄT
Bedienungsanleitung

GB/IE Operating instructions Page 1
DE/AT/CH Bedienungsanleitung Seite 15
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

IAN 274326
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
DEUTSCHLAND/GERMANY
www.kompernass.com
Last Information Update ·
Stand der Informationen: 03/ 2016
Ident.-No.: TLGL1000B1-022016-3

GB│IE │ 1■TLGL 1000 B1
Index
Introduction ..............................................2
Information regarding these operating instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Copyright ..........................................................2
Limited liability ......................................................2
Intended use........................................................2
Warnings used ......................................................3
Safety ...................................................4
Basic Safety Instructions ...............................................4
Interaction with rechargeable batteries (cells) ..............................5
Initial use.................................................5
Items supplied and transport inspection ...................................5
Disposal of the packaging .............................................6
Operating components .....................................6
Handling and operation ....................................6
Switching the appliance on/off .........................................6
Charging Ni-MH/Ni-Cd batteries .......................................7
Charging Li-ion batteries...............................................7
Operating status displays..............................................8
Calculating the average charging time ...................................8
Timer control........................................................9
Charging a USB device ...............................................9
Cleaning .................................................9
Cleaning the housing .................................................9
Troubleshooting ..........................................10
Malfunction causes and remedies ......................................10
Storage/Disposal .........................................10
Storage...........................................................10
Disposal of the device ...............................................11
Disposal of batteries.................................................11
Appendix ...............................................11
Information regarding the EC Declaration of Conformity.....................11
Importer..........................................................11
Technical data .....................................................12
Warranty.........................................................13
Service ...........................................................13

■ 2 │ GB│IE TLGL 1000 B1
Introduction
Information regarding these operating instructions
Congratulations on the purchase of your new device.
You have clearly decided in favour of a quality product. These operating instruc-
tions are a component of the Battery Charger (hereafter referred to as the device
or product). They contain important information in regard to safety, use and
disposal. Before using the product, familiarise yourself with all of these operating
and safety instructions. Use the product only as described and only for the specified
areas of application. In addition, pass these documents on, together with the
product, to any future owner.
Copyright
This documentation is copyright protected. Any copying or reproduction, including
as extracts, as well as the reproduction of images, also in an altered state, is not
permitted without the express written consent of the manufacturer.
Limited liability
All technical information, data and instructions for the connection and opera-
tion contained in these operating instructions correspond to the latest available
at the time of printing and, to the best of our knowledge, take into account our
previous experience and know-how. No claims can be derived from the details,
illustrations and descriptions in these instructions. The manufacturer assumes no
responsibility for damage caused by failure to observe the instructions, improper
use, inappropriate repairs, making unauthorised changes or for using unauthorised
replacement parts.
Intended use
This device is intended exclusively for the non-commercial
— charging of rechargeable Ni-Cd and Ni-MH batteries (sizes AAA/
AA/C/D) with standard-rated capacities,
— charging of fast-rechargeable as well as not-fast-rechargeable batteries,
— charging of 3.6–3.7 V Li-ion batteries for digital cameras, camcorders
and smartphones, and
— charging of battery-operated devices with a USB interface, such as MP3
players
only.
Any other use or uses beyond those mentioned are considered to be unintended
use. Claims of any kind for damage resulting from unintended use will not be
accepted. The operator alone bears the liability.

GB│IE │ 3■TLGL 1000 B1
Warnings used
In these extant operating instructions the following warning notices are used:
DANGER
A warning at this risk level indicates a threatening dangerous
situation.
In the event that the dangerous situation is not avoided it could lead to death
or serious physical injury.
► Comply with the directives in this warning to avoid the risks of death or
serious physical injury.
IMPORTANT
A warning of this risk level indicates possible property
damage.
If the situation is not avoided it could lead to property damage.
► Comply with the directives in this warning to avoid property damage.
NOTICE
► A notice indicates additional information that may assist you in the handling
of the device.

■ 4 │ GB│IE TLGL 1000 B1
Safety
In this section you will receive important safety information regarding the handling
of the device. This device complies with the statutory safety regulations. Incorrect
usage can lead to injuries and property damage.
Basic Safety Instructions
For safe handling of the device observe the following safety
instructions:
■ Before use check the device for visible external damage. Do
not put into operation a device that is damaged or has been
dropped.
■ To avoid possible risks, arrange for damaged cables or con-
nectors to be exchanged by an authorised specialist or the
Customer Service Department.
■ This appliance may be used by children aged 8 over and by
persons with reduced physical, sensory or mental capabili-
ties or lack of experience and knowledge, provided that they
are under supervision or have been told how to use of the
appliance safely and are aware of the potential risks.
Children must not play with the appliance. Cleaning and
user maintenance tasks must not be carried out by children
unless they are supervised.
■ A repair to the device during the warranty period may only
be carried out by a customer service department authorised
by the manufacturer, if it is not, additional warranty claims
cannot be considered for subsequent defects.
■ Do not make any changes or modifications to the appliance
yourself.
■ Protect the device from moisture and liquid penetration.
Never submerge the device in water, do not place the
device in the vicinity of water and do not stand any object
filled with liquid (i.e. vases) on the device.
■ Do not operate the device in the vicinity of open flames (e.g.
candles).
■ Avoid direct sunlight.
■ Charge exclusively rechargeable batteries of the types
"Ni-Cd“, "Ni-MH" and Li-ion.

GB│IE │ 5■TLGL 1000 B1
■ NEVER recharge batteries of other types or non-rechargea-
ble batteries. These are not suitable for recharging. Batteries
not suitable for recharging can overheat and explode. It
could irreparably damage the device and the inserted
batteries.
■ This product is intended exclusively for indoor operation in
dry and enclosed rooms.
Interaction with rechargeable batteries (cells)
■ Do not use damaged or corroded rechargeable batteries in
the device.
■ Rechargeable batteries (cells) can be fatal if swallowed.
Therefore, always keep the device and the rechargeable
batteries out of the reach of children!
■ If a rechargeable battery is swallowed medical assistance
must be sought IMMEDIATELY.
■ Should a battery have leaked, you must avoid contact by the
battery fluid with the skin! The battery liquid can cause acid
burns on the skin!
■ Remove the leaked battery liquid with a dry, absorbent cloth
and avoid contact by it with the skin by wearing, for exam-
ple, a pair of gloves.
Initial use
Items supplied and transport inspection
The device is delivered with the following components as standard:
▯ Universal Charger
▯ This operating manual
NOTICE
► Check the contents to make sure everything is there and for visible damage.
► If the items supplied are incomplete, or damaged due to defective packaging
or transportation, contact the Service Hotline (see section Service).
♦ Remove the device and the operating instructions from the carton.
♦ Remove all packing material.

■ 6 │ GB│IE TLGL 1000 B1
DANGER
► Packaging material should not be used as a play thing. There is a risk of
suffocation!
Disposal of the packaging
The packaging protects the device from transport damage. The packaging
materials are selected from the point of view of their environmental friendliness
and disposal technology and are therefore recyclable.
The recirculation of packaging into the material circuit saves on raw material
and reduces the amount of waste generated. Dispose of packaging material
that is no longer needed as per the regionally established regulations.
NOTICE
► If possible preserve the device's original packaging during the warranty
period so that, in the event of a warranty claim, you can package the
device ideally for its return.
Operating components
Display
2Operating status display (charging slots 1 to 4)
3USB Output
4Operating status display (Li-ion batteries)
5Charging contact for Li-ion batteries
6Holder for Li-ion batteries
7Charging slots for types AAA/AA/C/D (charging slots 1 to 4)
Handling and operation
In this chapter you will receive important information for the handling and
operation of the device.
Switching the appliance on/off
♦ Place the appliance on a smooth, level and slip resistant surface.
♦ Compare the technical details with those of your power supplier. If they
match, connect the mains cable to an easily accessible mains power socket.
The LEDs light up red three times. The battery charger is now ready for use.
♦ To switch off the battery charger, unplug the appliance from the mains
socket.

GB│IE │ 7■TLGL 1000 B1
NOTE
► Between 1 and 7 batteries can be charged individually:
- 4 x type C or type D batteries in the charging slots 1 to 4 7, plus 1 x
Li-ion battery (3.6–3.7 V) on the charging contacts 5
or
- 6 x type AA or AAA batteries in the charging slots 1 to 4 7, plus 1 x
Li-ion battery (3.6–3.7 V) on the charging contacts 5
Charging Ni-MH/Ni-Cd batteries
♦ After you have connected the battery charger to mains power, you can now
insert Ni-MH/Ni-Cd batteries in charging slots 1 to 4 7and charge them.
♦ The charging process starts automatically as soon as the batteries have
been inserted. The battery charger has an operating status display 2for
each compartment in the charging slot. The operating status display of the
respective charging slots shows the current charge status of the individual
batteries. The display also shows the current charge level of the batteries
in percent.
NOTE
► If one of the operating status displays flashes red for longer than
5 seconds, the battery is improperly inserted or defective.
Charging Li-ion batteries
♦ After you have connected the battery charger to mains power, you can now
charge a Li-ion battery. Proceed as follows:
♦ Match the charging contacts 5to the positions of the positive and negative
terminals on your Li-ion battery, by sliding the charging contacts 5into the
corresponding positions.
♦ Insert the Li-ion battery with its charging contacts lined up with the charging
contacts 5of the battery charger.
CAUTION
► Ensure that the charging contacts 5are only in contact in the positive and
negative terminals of your Li-ion battery. The polarity and voltage of the
rechargeable battery catwalk are recognised automatically by the battery
charger. Li-ion often have more than two contacts. Connecting the charging
contacts 5with the other contacts of your Li-ion battery could destroy your
battery.

■ 8 │ GB│IE TLGL 1000 B1
♦ Fix the Li-ion rechargeable battery in place using the holder 6. To do this,
pull the holder 6backwards until the Li-ion battery fits in the slot and then
let go of the holder 6. The Li-ion battery is now fixed in place.
NOTE
► The bowl of the holder 6can be turned by 180° to allow you to fix Li-ion
batteries of different sizes.
♦ The charging process starts automatically as soon as the batteries have
been inserted. The operating status display 4shows the current charge
status of the battery. The display also shows the current charge level of
the batteries in percent .
Operating status displays
The various displays have the following meanings:
■ The LED flashes red and green once per second: The batteries are being
alternately charged and discharged. (Refresh-Function: older or long stored
batteries are being refreshed.)
■ The LED flashes green once per second: A deeply discharged battery is be-
ing gently recharged with a reduced current.
■ The LED glows constantly red: The batteries are being charged with the maxi-
mum charge current.
■ The LED glows constantly green: The batteries are fully charged and the bat-
tery charger has switched to trickle charge.
In addition, the current charge status of each battery is shown as a percentage
on the display .
Calculating the average charging time
Depending on the type, age and remaining charge in the batteries, the charging
process can take various lengths of time. The average charge time can be cal-
culated using the following formula. Take note however that the times given are
only guiding values.
Ni-MH/Ni-Cd batteries:
Charging time (min) = Battery capacity (mAh) x 1.4 x 60 + 30
Charging current of the device (mA)
Li-ion batteries:
Charging time (min) = Battery capacity (mAh) x 1.4 x 60 + 60
Charging current of the device (mA)

GB│IE │ 9■TLGL 1000 B1
Timer control
This battery charger has a timer control which automatically switches over to
retention charging after 17 hours. This serves as an additional protection against
overcharging should the charge termination not respond due to a possibly defec-
tive battery.
Charging a USB device
IMPORTANT
► Ensure that the power consumption of the USB device is not higher than
1000 mA. For more information, refer to the instruction manual of your
USB device.
♦ Insert the USB connector of the USB device into the USB output 3of the
battery charger.
♦ If necessary, switch the USB device on.
NOTICE
► You can simultaneously charge batteries in the battery charger and a USB
device at the USB output 3. Be aware that the charging current for the batter-
ies is thereby halved and the charging process thus takes somewhat longer.
Cleaning
DANGER
► Always remove the plug before cleaning the device. There is the risk of an
electric shock!.
► When you are cleaning the device ensure that no moisture gets inside it, so
as to avoid irreparable damage to it.
IMPORTANT
► Do not use aggressive or abrasive cleaning agents, as these can damage
the upper surfaces.
Cleaning the housing
♦ Clean the surfaces of the device with a soft, dry cloth. For stubborn soiling
use a lightly moistened cloth.
♦ Never clean the insides of the charging slots with moist cloths. Instead, use
a clean soft brush to clean them.
♦ If soiled, clean the charging contacts with a dry cloth.

■ 10 │ GB│IE TLGL 1000 B1
Troubleshooting
In this section you will receive important information for the localisation and
remedying of malfunctions.
Malfunction causes and remedies
The following table will help with localising and remedying minor malfunctions:
Defect Possible cause Solution
The battery
charger is not
functioning.
The power cable is not
plugged in.
Insert the power cable into a mains
power socket.
Mains power socket is not
supplying power. Check the circuit fuse.
The inserted
batteries are not
being charged.
The batteries are not inserted
as per their polarity.
Insert the batteries as per their polarity
(see marking in the charging slot).
Match the charging contacts to the
positions of the positive and negative
terminals on your Li-ion battery.
Observe the labelling on the Li-ion
battery.
The inserted batteries are
not suitable for charging.
Insert only rechargeable Ni-Cd and
Ni-MH batteries of the types AAA/
AA/C/D and 3.6 - 3.7V Li-ion
batteries.
The temperature monitoring
was initiated.
Disconnect the plug from the mains
power socket and allow the device to
cool down.
NOTICE
► If you cannot solve the problem with the aforementioned methods, please
contact Customer Services.
Storage/Disposal
Storage
If you do not intend to use the device for a longer time, remove the batteries and
store it in a clean, dry place away from direct sunlight.

GB│IE │ 11 ■TLGL 1000 B1
Disposal of the device
Do not dispose of the device in your normal domestic waste.
This product is subject to the provisions of the European Directive
2012/19/EU WEEE (Waste Electrical and Electronic Equipment).
Dispose of the device through an approved disposal centre or at your community
waste facility. Observe the currently applicable regulations. In case of doubt,
please contact your waste disposal centre.
Disposal of batteries
Used batteries/cells may not be disposed of in household waste. All consumers
are statutorily obliged to dispose of batteries at a collection site of his community/
city district or at a retail store. The purpose of this obligation is to ensure that
batteries are disposed of in a non-polluting manner. Only dispose of batteries/
cells when they are fully discharged.
Appendix
Information regarding the EC Declaration of Conformity
With regard to conformity with essential requirements and
other relevant provisions, this device complies with the
guidelines of the Electromagnetic Compatibility Directive
2014/30/EU as well as the Directive for Low Voltage
Devices 2014/35/EU.
The complete original Declaration of Conformity can be
obtained from the importer.
Importer
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

■ 12 │ GB│IE TLGL 1000 B1
Technical data
Input voltage 100-240 V ∼ 50/60 Hz
Current consumption 390 mA
Protection class II /
Fuse T1AL/250V T1A
Operating temperature 5° - 35°C
Storage Temperature -10° - 40°C
Humidity (no condensation) ≤ 75%
Output voltages 6 x 1,4 V (Loading slots 1 - 4)
1 x 4,2 V (Li-ion)
Charge currents (without using the
USB output)
6 x 1000 mA (Type AA)
6 x 500 mA (Type AAA)
4 x 1000 mA (Type C or D)
1 x 500 mA (Li-ion)
Charge currents (with use of the
USB output)
6 x 500 mA (Type AA)
6 x 250 mA (Type AAA)
4 x 500 mA (Type C or D)
1 x 250 mA (Li-ion)
Maximum assessment capacity
AAA: 1100 mAh
AA: 3000 mAh
C: 6000 mAh
D: 8000 mAh
Li-ion: 3000 mAh
USB 2.0 Output 5 V , 1000 mA
Measurements (W x H x D): approx. 22.6 x 6.1 x 16 cm
Weight approx. 660 g

GB│IE │ 13 ■TLGL 1000 B1
Warranty
The warranty for this appliance is for 3 years from the date of purchase. The
appliance has been manufactured with care and meticulously examined before
delivery.
Please retain your receipt as proof of purchase. In the case of a warranty claim,
please make contact by telephone with our Customer Service Department. Only
in this way can a post-free despatch for your goods be assured.
NOTICE
► The warranty covers only claims for material and manufacturing defects,
but not for transport damage, wearing parts or for damage to fragile
components, e.g. buttons or batteries.
This product is for domestic use only and is not intended for commercial use. The
warranty is void in the case of abusive and improper handling, use of force and
internal tampering not carried out by our authorised service branch.
Your statutory rights are not restricted in any way by this warranty. The warranty
period is not extended by repairs made under the warranty. This applies also to
replaced and repaired parts.
Damages and defects extant at the time of purchase must be reported immedi-
ately after unpacking, resp. no later than two days after the date of purchase.
Repairs made after the lapse of the warranty period are subject to charge.
Service
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: k[email protected]
IAN 274326
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: k[email protected]
IAN 274326

■ 14 │ GB│IE TLGL 1000 B1

DE│AT│CH │ 15 ■TLGL 1000 B1
Inhaltsverzeichnis
Einführung...............................................16
Informationen zu dieser Bedienungsanleitung .............................16
Urheberrecht. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Haftungsbeschränkung...............................................16
Bestimmungsgemäße Verwendung .....................................16
Verwendete Warnhinweise............................................17
Sicherheit ...............................................18
Grundlegende Sicherheitshinweise .....................................18
Umgang mit wiederaufladbaren Batterien (Akkus) .........................19
Inbetriebnahme ..........................................19
Lieferumfang und Transportinspektion ...................................19
Entsorgung der Verpackung ...........................................20
Bedienelemente ..........................................20
Bedienung und Betrieb ....................................20
Gerät ein-/ausschalten...............................................20
Ni-MH- / Ni-Cd-Akkus aufladen .......................................21
Li-Ionen-Akku aufladen ...............................................21
Betriebszustandsanzeigen ............................................22
Berechnung der durchschnittlichen Ladezeit...............................22
Timersteuerung .....................................................23
USB-Gerät aufladen .................................................23
Reinigung ...............................................23
Gehäuse reinigen...................................................23
Fehlerbehebung ..........................................24
Fehlerursachen und -behebung ........................................24
Lagerung/Entsorgung.....................................24
Lagerung .........................................................24
Gerät entsorgen ....................................................25
Batterien / Akkus entsorgen ...........................................25
Anhang .................................................25
Hinweise zur EG-Konformitätserklärung ..................................25
Importeur .........................................................25
Technische Daten ...................................................26
Garantie ..........................................................27
Service ...........................................................27

■ 16 │ DE│AT│CH TLGL 1000 B1
Einführung
Informationen zu dieser Bedienungsanleitung
Herzlichen Glückwunsch zum Kauf Ihres neuen Gerätes.
Sie haben sich damit für ein hochwertiges Produkt entschieden. Die Bedienungs-
anleitung ist Bestandteil des Akkuladegerätes (nachfolgend als Gerät oder
Produkt bezeichnet). Sie enthält wichtige Hinweise für Sicherheit, Gebrauch und
Entsorgung. Machen Sie sich vor der Benutzung des Produkts mit allen Bedien- und
Sicherheitshinweisen vertraut. Benutzen Sie das Produkt nur wie beschrieben und
für die angegebenen Einsatzbereiche. Händigen Sie alle Unterlagen bei Weiter-
gabe des Produkts an Dritte mit aus.
Urheberrecht
Diese Dokumentation ist urheberrechtlich geschützt. Jede Vervielfältigung bzw.
jeder Nachdruck, auch auszugsweise, sowie die Wiedergabe der Abbildungen,
auch im veränderten Zustand, ist nur mit schriftlicher Zustimmung des Herstellers
gestattet.
Haftungsbeschränkung
Alle in dieser Bedienungsanleitung enthaltenen technischen Informationen, Daten
und Hinweise für den Anschluss und die Bedienung, entsprechen dem letzten
Stand bei Drucklegung und erfolgen unter Berücksichtigung unserer bisheri-
gen Erfahrungen und Erkenntnissen nach bestem Wissen. Aus den Angaben,
Abbildungen und Beschreibungen in dieser Bedienungsanleitung können keine
Ansprüche hergeleitet werden. Der Hersteller übernimmt keine Haftung für
Schäden aufgrund von Nichtbeachtung der Bedienungsanleitung, nicht
bestimmungsgemäßer Verwendung, unsachgemäßen Reparaturen, unerlaubt
vorgenommener Veränderungen oder Verwendung nicht zugelassener Ersatzteile.
Bestimmungsgemäße Verwendung
Dieses Gerät ist ausschließlich für den nicht gewerblichen Gebrauch zum
− Aufladen von wiederaufladbaren Ni-Cd- und Ni-MH-Akkus der Größen
AAA/AA/C/D mit handelsüblichen Bemessungskapazitäten,
− Aufladen von schnellladefähigen sowie nicht schnellladefähigen Akkus,
− Aufladen von 3,6 - 3,7V-Li-Ionen-Akkus von Digitalkameras, Camcordern
oder Smartphones und
− zum Aufladen von akkubetriebenen Geräten mit USB-Schnittstelle, wie
z. B. MP3-Player
bestimmt.
Eine andere oder darüber hinausgehende Benutzung gilt als nicht bestimmungs-
gemäß. Ansprüche jeglicher Art wegen Schäden aus nicht bestimmungsgemäßer
Verwendung sind ausgeschlossen. Das Risiko trägt allein der Benutzer.
