OPERATING MANUAL
AIR CLEANER
TAC 750 E
EN
TRT-BA-TAC750E-TC-002-EN

1Operating Manual – Air Cleaner TAC 750 E EN
Symbols
Danger!
Warns of a hazard which can lead to injuries.
Hazardous electric voltage!
Warns of a hazard resulting from electric voltage which
can lead to injuries.
Caution!
Warns of a hazard which can lead to damage to property.
Note
Indicates information regarding the application or general
hints.
The current version of the operating manual can be found at:
www.trotec.de
Legal notice
This release replaces all previous versions. No part of this
publication may be reproduced without written permission from
TROTEC®. The same applies for electronically processing,
duplicating or spreading the publication. Subject to technical
changes. All rights reserved. Trademarks are used without
guarantee that they may be used freely and primarily following
the spelling of the manufacturer. Product names are registered.
Changes to construction in the interests of constant
improvements to the product, as well as changes to the shape
and colour are reserved.
The scope of delivery may vary from product images. This
document was created with all due care. TROTEC®accepts no
liability whatsoever for possible mistakes or omissions.
© TROTEC®
Table of contents
Notes regarding the operating manual .................................... 1
Information about the device................................................... 2
Safety ..................................................................................... 3
Transport and storage............................................................. 4
Technical data ........................................................................ 3
Operation................................................................................ 4
Errors and faults ..................................................................... 5
Maintenance........................................................................... 5
Disposal.................................................................................. 7
Overview and list of spare parts .............................................. 8
Declaration of conformity (Translation of the original).............. 9
Notes regarding the operating manual

EN Operating Manual – Air Cleaner TAC 750 E 2
Description of the device
Air cleaners are used to filter the room air. On building sites and
renovation areas high concentrations of dust can arise, for
instance when using angle grinders or during blasting, chiselling
or demolition operations as well as when mixing dry mortar or tile
cement.
The air is conveyed through the air intake opening (10) via the
filters. The air filtered this way can stream back outside via the air
outlets (4) at the sides and on top.
Filter types (not included in the scope of delivery)
The following air filters are geared to the device and come with
the largest possible filter surface based on the geometric
dimensions. Consequently, a high air flow rate is achieved.
Note:
Please observe that only one prefilter (1, 2 or 3) can be imple-
mented in a device at a time. Operation without prefilter is not
advisable, for otherwise the fan could be damaged and the life-
time of the high-efficiency particulate air filter (4) is reduced.
Device depiction
Information about the device
No. Designation
1 G4 Z line filter
2 Pleated filter F7
3 G3 spray paint filter
4 H13 high-efficiency particulate air filter (HEPA)
12
43
No. Designation
5 Air outlet
6 Tension lock
7Frontcover
8 On/off switch
9 Power cable connection
10 Speed controller
11 Air intake opening
12 Transport handle
6
5
5
6
7
8
10
12
9
11

3Operating Manual – Air Cleaner TAC 750 E EN
Accessories and supplies
Carefully read the operating manual before using the device
and keep it within reach!
• Do not use the device in potentially explosive rooms.
• Do not use the device in atmospheres containing oil, sulphur,
chlorine or salt.
• Only put up the device in a stable position on firm ground.
• Provide appropriate weather protection.
• Keep air inlets and outlets clear.
• Never insert objects into the device.
• Do not cover or transport the device during operation.
• Never use the device as storage place or footstep.
• Ensure that all electric cables outside of the device are
protected from damage (e.g. from animals).
• Only use extensions to the connecting cable which are
appropriate to the device power consumption, the length of
its cable and its use. Avoid electrical overload.
• Dispose of replaced filters properly.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Observe the storage and operating conditions (see chapter
Technical data).
Intended use
Only use the device to clean atmospheric air from non-conducting
and non-combustible dusts or suspended matter whilst adhering
to the technical data.
Improper use
Do not use the device in potentially explosive areas.
Do not place the device on damp or flooded ground.
Do not use the device to siphon off vapours or fluids.
Any unauthorised changes, modifications or alterations to the
device are forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
electric devices in damp areas.
• have read and understood the operating manual, especially
the Safety chapter.
Residual risks
Hazardous electric voltage!
Work on the electrical components must only be
carried out by electrically skilled persons!
Hazardous electric voltage!
Before any work on the device, remove the mains plug
from the mains socket!
Danger!
Do not leave the packaging lying around. Children may
use it as a dangerous toy!
Danger!
This appliance is not a toy! Children must be kept away
from the device.
Danger!
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way.
Observe the personnel qualifications.
Technical data
Parameter Value
Model TAC 750 E
Max. air volume without filter 750 m³/h
Max. air volume with G4 filter 680 m³/h
Max. air volume with G4 + H13 filter 290 m³/h
Power input 0.120 kW
Input voltage 230 V / 50/60 Hz
Sound level (1 m) 78 dB(A)
Dimensions (length x width x height) 430 mm x 315 mm x 430 mm
Max. weight empty/filled 6.0/7.5 kg
Item Article number
G3 spray paint filter 7160000416
G4 Z-line filter 7160000404
F7 pleated filter 7160000409
H13 high-efficiency particulate air filter (HEPA) 7160000220
Item Article number
Air transport hose Tronect SP-T203 6100001200
Hose/pipe adapter (Ø123) 6100010010
Air transport hose Tronect TF-L127 6100001120
Extension cable 7333000376
Safety

EN Operating Manual – Air Cleaner TAC 750 E 4
Transport
For easier transportation the device is equipped with a transport
handle.
Before transporting the device, proceed as follows:
1. Switch off the device.
2. Disconnect the mains plug from the socket and coil up the
cable. Do not use the power cable to drag the device!
Storage
When the device is not being used, observe the following storage
conditions:
•Dry,
• Protected from dust and direct sunlight,
• With a plastic cover to protect it from invasive dust, if
necessary.
Caution!
In order to protect the device from damage, we
recommend using it with at least one filter.
• Position the device near the source of air contamination or
install the air hose at this source.
• Set the device in an upright and stable position.
• Do not create tripping hazards when laying the power cable
or other electric cables.
• Make sure that no curtains or other objects interfere with the
air flow.
• Make sure that extension cords are completely unrolled.
1. Completely unwind the power cable and connect it to a fused
socket.
2. Press the On/Off switch (8).
– The switch lights up in green.
– The fan starts running after a delay.
3. Adjust the speed controller (10) to the desired intensity level.
Shutdown
1. Press the On/Off switch (8).
2. Remove the mains plug from the mains socket.
3. Clean the device according to chapter Maintenance.
4. Store the device according to chapter Storage.
Transport and storage
Operation
Start-up
8
10

5Operating Manual – Air Cleaner TAC 750 E EN
The accurate functionality of the device was tested during
production a number of times. However, if functionality faults do
occur, then check the device according to the following list.
The device does not start:
• Check the power connection (230 V AC /50 Hz).
• Check the mains plug for damages.
• Check the position of the speed controller.
Your device still does not operate correctly after these
checks?
Please contact the TROTEC®customer service.
Repair work which requires the housing to be opened
must only be carried out by electrically skilled
persons or by TROTEC®.
Activities required before starting maintenance
• Do not touch the mains plug with wet or damp hands.
Before opening the device, switch the device off and
disconnect it from the mains.
Changing the filter
1. Unlock both tension locks (5) at the left and right side of the
device.
2. Remove the front cover (6) from the device.
3. Remove the air filter.
Note
If you only want to change this air filter, please continue
with step 10.
If you want to exchange the HEPA filter as well, please
continue with step 4.
4. Remove the four knurled screws (12).
5. Remove the cover (13) from the device.
Errors and faults
Maintenance
5
6
5
1, 2
12
12
13

EN Operating Manual – Air Cleaner TAC 750 E 6
6. Remove the air filter (3).
7. Install the new air filter (3).
8. Put the cover (13) back on the device.
9. Affix the four knurled screws (12).
10. Install the new air filter. In doing so, pay attention to the
correct alignment (front/rear).
11. Put the front cover (6) back on the device.
12. Fasten the two lateral tension locks (5).
3
3
13 12
12
1, 2
5
6
5

7Operating Manual – Air Cleaner TAC 750 E EN
Cleaning the housing
Clean the device with a soft, damp and lint-free cloth. Ensure that
no moisture enters the housing. Do not use any sprays, solvents,
alcohol-based cleaning agents or abrasive cleaners, but only
clean water to moisten the cloth.
Do not use a high-pressure cleaner!
In the European Union, electronic equipment must not
be treated as domestic waste, but must be disposed of
professionally in accordance with Directive
2002/96/EC of the European Parliament and Council of 27th
January 2003 concerning old electrical and electronic equipment.
At the end of its life, please dispose of this device according to the
valid legal requirements.
Disposal

EN Operating Manual – Air Cleaner TAC 750 E 8
Overview and list of spare parts
No. Spare part Art. no. No. Spare part Art. no. No. Spare part Art. no.
1 handle P10001246 10 spacer sleeve P10001827 20 air filter P10000619
2 button P10001376 11 cover P10001839 21 air filter 7160000220
3 rotary button P10001250 12 rubber buffer P10001843 22 setscrew P10000469
4 fan P10000576 13 bottom P10001838 23 spacer sleeve P10001251
5 lock nut P10001248 14 fan shroud B1114 24 spacer sleeve P10001555
6 cable bushing P10001247 15 plug B1140 25 sandwich plate P10001826
7 spring tension element P10000004 16 nut P10000371 26 finger guard P10000293
8 gasket strip P10000002 17 potentiometer P10001751
9 gasket strip P10000003 18 operating element P10001827
123
19
9 25 16 20 8 13 147
15 221012 18 115263 1724 4
21 26
Note!
The position numbers of the spare parts differ from those describing the positions
of other parts mentioned in this operating manual.

9Operating Manual – Air Cleaner TAC 750 E EN
Declaration of conformity (Translation of the
original)
EC Declaration of Conformity
in accordance with EC Machinery Directive 2006/42/EC
TROTEC® GmbH & Co. KG
Grebbener Straße 7
D-52525 Heinsberg
herewith declares, that due to its design and construction, and in the version introduced by us,
the following machinery conforms with the relevant fundamental requirements of the listed EC
directives.
Important note:
In case of improper use, installation, maintenance etc. or unauthorized changes of the
factory-supplied device version, this declaration loses its legal validity.
Device version: Air Cleaner
Series: TAC 750 E
Year of ma nufactu re: as of 09/2014
Applicable regulations: 2006/42/EC
2004/108/EC
2011/65/EC
Machinery Directive
EMC Directive
RoHS
Applied harmonised
standards: EN 60335-2-65:2003
EN 55014-1:2006
EN 13857:2008
EN 60204-1:2006
EN ISO 12100:2010
Producer and authorised representative of the technical documentation:
Trotec GmbH & Co. KG · Grebbener Straße 7 · D-52525 Heinsberg
Phone: [phone] · Fax: [phone] · E-mail: [e-mail]
Heinsberg, 01/09/2014 Managing Director: Detlef von der Lieck

Trotec GmbH & Co. KG
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[e-mail]
www.trotec.com
