Trotec TFC 220 E User manual

TRT-BA-TFC220E-TC2019-49-001-EN
TFC 220 E
EN
OPERATING MANUAL
FAN HEATER
EN This product is only suitable for well
insulated spaces or occasional use.

2 EN
fan heater TFC 220 E
Table of contents
Notes regarding the operating manual.................................2
Safety .....................................................................................2
Information about the device................................................4
Transport and storage...........................................................5
Assembly and installation.....................................................5
Operation ...............................................................................7
Errors and faults..................................................................10
Maintenance ........................................................................10
Technical annex...................................................................11
Disposal ...............................................................................13
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning of hot surface
This symbol indicates dangers to the life and health of
persons due to hot surface.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information
(e.g. material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
TFC 220 E
https://hub.trotec.com/?id=43767
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use!
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/ or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
Warning
Children of less than 3years should be kept away
unless continuously supervised.
Children aged from 3years and less than 8years shall
only switch on/off the appliance provided that it has
been placed or installed in its intended normal
operating position and they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
Children aged from 3years and less than 8years shall
not plug in, regulate and clean the appliance or
perform user maintenance.
Warning
Do not use the device in small rooms if persons are
present who cannot leave the room independently and
who are not under constant supervision.
• Do not use the device in potentially explosive rooms.
• Do not use the device in aggressive atmosphere.
• Set the device up in an upright and stable position.

EN 3
fan heater TFC 220 E
• Let the device dry out after a wet clean. Do not operate it
when wet.
• Do not use the device with wet or damp hands.
• Do not expose the device to directly squirting water.
• Never insert any objects or limbs into the device.
• Do not cover or transport the device during operation.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Do not sit on the device.
• This appliance is not a toy! Keep away from children and
animals. Do not leave the device unattended during
operation.
• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.
• Ensure that all electric cables outside of the device are
protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection
are damaged!
• The electrical connection must correspond to the
specifications in chapter Technical data.
• Insert the mains plug into a properly secured mains
socket.
• Observe the device's power input, cable length and
intended use when selecting extensions to the power
cable. Completely unroll extension cables. Avoid electrical
overload.
• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.
• Switch the device off and disconnect the power cable from
the mains socket when the device is not in use.
• Do not under any circumstances use the device if you
detect damages on the mains plug or power cable.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Defective power cables pose a serious health risk!
• When positioning the device, observe the minimum
distances from walls and other objects as well as the
storage and operating conditions specified in the Technical
data chapter.
• Do not use the device in immediate proximity to curtains.
• Make sure that the air inlet and outlet are not obstructed.
• Make sure that the suction side is kept free of dirt and
loose objects.
• Do not place the device on combustible ground.
• Allow the device to cool down before transport and/ or
maintenance work.
• Do not use this device near bathtubs, shower trays,
swimming pools or other water containers. Risk of electric
shock!
• The device must not be positioned directly beneath a wall
socket.
Intended use
This product is only designed for use inside well insulated
rooms or for occasional use.
The fan heater serves the purpose of heating and ventilating
closed rooms. The device was designed for private usage and is
not suited for commercial use. The device is particularly well
suited for additional heating. The device is only intended for
floor installation.
Improper use
• Do not place the device on wet or flooded ground.
• Do not place any objects, e.g. clothing, on the device.
• Do not use this device in the vicinity of fuel, solvents,
varnishes or other easily inflammable vapours or in rooms
where these substances are stored.
• Do not use the device outdoors.
• Do not use the device for heating vehicles.
• The device must not be used near swimming pools.
• Do not use this device in the immediate vicinity of sinks,
bathtubs or other water containers.
Never immerse the device in water.
• Never heat rooms with a cubature of less than 4m³.
Risk of overheating!
• Any operation other than as described in this manual is
prohibited. Non-observance renders all claims for liability
and guarantee null and void.
• Any unauthorised modifications, such as alterations or
structural changes to the device, are forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
electric devices in damp areas.
• have read and understood the operating manual, especially
the Safety chapter.
Maintenance tasks which require the housing to be opened
must only be carried out by specialist electrical companies or by
Trotec.

4 EN
fan heater TFC 220 E
Symbols on the device
Symbols Meaning
This symbol located on the device indicates that it
is prohibited to place objects (such as towels,
clothes etc.) above or directly in front of the
device.
In order to avoid overheating and fire hazards, the
heater must not be covered.
Residual risks
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning of electrical voltage
Before any work on the device, remove the mains plug
from the mains socket!
Hold onto the mains plug while pulling the power cable
out of the mains socket.
Warning of hot surface
Some parts of this product can become very hot and
cause burns. Particular attention has to be given where
children and vulnerable people are present!
Warning
Improper handling entails a risk of burning and electric
shock.
Only use the device as intended!
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
Improper installation entails a risk of fire.
Do not place the device on combustible ground.
Do not place the device on high-pile carpets.
Warning
In order to avoid overheating and fire hazards, the
device must not be covered!
Behaviour in the event of an emergency
1. Switch off the device.
2. In an emergency, disconnect the device from the mains
feed-in: Hold onto the mains plug while pulling the power
cable out of the mains socket.
3. Do not reconnect a defective device to the mains.
Overheating protection
The device is provided with a safety thermostat, which is
activated by overheating of the device. In such an event the
device switches off automatically.
When the safety thermostat is activated, allow the device to cool
down. Only then start to look for the cause of overheating.
Should the problem persist, please contact the customer
service.
Information about the device
Device description
The electric heater TFC 220 E serves to generate and distribute
warm air, e.g. in interior spaces.
The device generates heat by means of a heating element. The
air surrounding the heating element is heated. The heated air is
blown into the room by a fan.
The device is equipped with an integrated thermostat and so
generates a constant flow of warm air. In addition, you can set a
desired target temperature(15°C to 35°C) at the device.
The device is further equipped with an overheating protection.
In order to dissipate the accumulated heat, the fan keeps
running for approx. 15seconds after the heater's switch-off and
then switches off automatically.

EN 5
fan heater TFC 220 E
Device depiction
1
2
3
5
7
4
6
No. Designation
1 Display
2 Control panel
3 Feet
4 Air outlet
5 Power cable holder
6 Remote control
7 On/off switch
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
Before transporting the device, observe the following:
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Do not use the power cable to drag the device.
• Allow the device to cool down sufficiently.
Storage
Before storing the device, proceed as follows:
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Allow the device to cool down sufficiently.
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• in an upright position where it is protected from dust and
direct sunlight
• with a cover to protect it from invasive dust, if necessary
• Place no further devices or objects on top of the device to
prevent it from being damaged.
• Remove batteries from the remote control.
Assembly and installation
Scope of delivery
• 1 x Fan heater
• 1 x Remote control
• 1 x Cable holder
• 2 x Foot
• 4 x Fastening screw
• 1x Manual
Unpacking the device
1. Open the cardboard box and take the device out.
2. Completely remove the packaging.
3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.

6 EN
fan heater TFC 220 E
Assembly
Feet assembly
1. Place the device on a table or on the packaging board with
the glass surface pointing down.
2. Fasten both feet(3) with two screws each.
3. Check the feet(3) for tight fit.
4. Set the device up in an upright and stable position.
Start-up
Info
Odours might arise upon initial start-up or after a
longer period of non-use.
When positioning the device, observe the minimum distance
from walls or other objects as described in the Technical data
chapter.
A
B
C
C
D
• Before restarting the device, check the condition of the
power cable. If there are doubts as to the sound condition,
contact the customer service.
• Set the device up in an upright and stable position.
• Do not create tripping hazards when laying the power
cable or other electric cables, especially when positioning
the device in the middle of the room. Use cable bridges.
• Make sure that extension cables are completely unrolled.
• Make sure that no curtains or other objects interfere with
the air flow.
• Do not position the device directly below a wall socket.
• Make sure that the device cannot come into contact with
moisture or water.
Prior to initial start-up, insert the batteries in the remote control.
Connecting the power cable
• Insert the mains plug into a properly secured mains
socket.
• Make sure that the power cable is guided along the back
of the device. Never guide the power cable along the front
of the device!

EN 7
fan heater TFC 220 E
Operation
• Avoid open doors and windows.
Control panel
9
11
12
14
10
13
15
1617
18
19
21
20
22
23
8
No. Designation Meaning
8Timer indication Displayed when the timer is
activated.
9Comfort mode indication Displayed when comfort mode
is activated.
10 Night mode indication Displayed when night mode is
activated.
11 Eco mode indication Displayed when eco mode is
activated.
12 Frost monitor function
indication
Displayed when the frost
monitor function is activated.
13 Infrared receiver For signal reception from the
remote control
14 Temperature button For setting the desired room
temperature
15 Timer button For switching the timer
function on and off:
setting range of 1min to 24h
in increments of 1min
16 Increase value button For setting the desired room
temperature (15°C to 35°C)
or the number of hours and
minutes for the timer (1min to
24h)
17 Decrease value button
No. Designation Meaning
18 MODEbutton For selecting the operating
mode:
Comfort mode
Night mode
Eco mode
Frost monitor function
19 Power button For switching the device on or
activating standby mode
20 Heating indication Displayed when the heating is
activated.
21 Fan rundown function
indication
Displayed when the fan
rundown function is activated.
22 Hours / minutes
indication
Indication of the number of
hours and minutes during
timer programming
Indication of remaining timer
run-time
23 Temperature indication Indication of the current room
temperature during operation
Indication of the desired room
temperature during
temperature adjustment
Info
The display can be illuminated in two brightness levels.
The background illumination is brighter when one of
the control panel buttons is pressed. After approx. 15s
without any input, the brightness level will be reduced.
Switching the device on
Once you have completely installed the device as described in
the Start-up chapter, you can switch it on.
1. Set the on/off switch(7) toI.
ðAn acoustic signal is emitted.
ðThe device is now in standby mode.
ðThe room temperature is displayed in the temperature
indication(23).
Info
In standby mode, the device memorizes the room
temperature setting.

8 EN
fan heater TFC 220 E
Setting the operating mode
The device comes with the following operating modes:
• Comfort mode
• Night mode
• Eco mode
• Frost monitor function
Please proceed as follows to activate the desired operating
mode:
üThe device is switched on.
1. Press the power button(19).
ðThe display shines brightly and the control panel is
activated.
2. Repeatedly press the mode button(18) until the icon for
the desired operating mode(9, 10, 11 or 12) is displayed.
ðThe device starts in the desired operating mode.
Comfort mode
The device automatically operates at the high heating level until
the determined room temperature exceeds the desired room
temperature by 2°C. Then the heating switches off.
The heating indication(20) is no longer displayed.
The comfort modeindication(9) continues to be displayed.
If the determined room temperature falls below the desired
room temperature by 2°C, the heating switches back to
operation at the high heating level.
Night mode
The device automatically operates at the low heating level until
the determined room temperature exceeds the desired room
temperature by 2°C. Then the heating switches off.
The heating indication(20) is no longer displayed.
The night modeindication(10) continues to be displayed.
If the determined room temperature falls below the desired
room temperature by 2°C, the heating switches back to
operation at the low heating level.
Eco mode
The device automatically operates at the high heating level
when the room temperature is below 16°C.
The device automatically operates at the low heating level when
the room temperature is above 18°C.
The device switches off automatically when the room
temperature is above 21°C. This temperature cannot be
changed.
Frost monitor function
This function is only available in standby mode. The devices
heats automatically when the room temperature is below 5°C
and switches off when the temperature exceeds 7°C. These
temperatures cannot be changed.
Setting the desired room temperature
The determined room temperature is displayed in the
temperature indication(23). You can adjust the desired room
temperature in comfort mode and in night mode.
1. Press the temperaturebutton(14).
ðThe temperature indication(23) flashes.
ðThe desired room temperature is displayed.
2. Press the arrow buttons increase value(16) or decrease
value(17) to adjust the desired room temperature. Setting
is possible in the range between 15°C and 35°C in
increments of 1°C.
ðThe desired room temperature is saved and displayed in
the temperature indication(23) for approx.5seconds.
Then the current room temperature is displayed again.
Info
The desired room temperature should be higher than
the current room temperature.
Setting the timer
The timer has the following modes of operation:
• automatic switch-on upon expiry of a preset number of
hours and minutes
• automatic switch-off upon expiry of a preset number of
hours and minutes
The setting range for the timer spans from 1minute to 24hours
and can be adjusted in increments of 1minute.
Note
Do not leave the operating device unattended in a
freely accessible room with an activated timer.
Automatic switch-on
üThe device is set to the frost monitor function.
1. Press the timer button(15).
2. Select the desired number of hours and minutes by use of
the increase value(16) or decrease value(17) arrow
button. The value range is between 1minute and24hours.
ðThe number of hours and minutes flashes on the hours/
minutes indication(22).
3. Press the timer button(15).
ðThe desired time until automatic switch-on is saved.
ðThe timerindication(8) is displayed.
ðThe time left until switch-on is displayed in the hours/
minutes indication(22) and counted down.
ðOnce the set time has elapsed, the device will switch
over into comfort mode.
Notes regarding automatic switch-on:
• Manually switching the device on disables the automatic
switch-on function.
• If you select 0hours/ minutes, the timer will be off.

EN 9
fan heater TFC 220 E
Automatic switch-off
üThe device is switched on.
üThe device heats in comfort mode, night mode or eco
mode.
1. Press the timer button(15).
2. Select the desired number of hours and minutes by use of
the increase value(16) or decrease value(17) arrow
button. The value range is between 1minute and24hours.
ðThe number of hours and minutes flashes on the hours/
minutes indication(22).
3. Press the timer button(15).
ðThe desired time until automatic switch-off is saved.
ðThe timerindication(8) is displayed.
ðThe time left until switch-off is displayed in the hours/
minutes indication(22) and counted down.
ðOnce the set time has elapsed, the device will switch
over into standby mode.
Notes regarding automatic switch-off:
• Manually switching the device off disables the automatic
switch-off function.
• If you select 0hours/ minutes, the timer will be off.
Fan rundown function
In order to dissipate the accumulated heat, the fan keeps
running for approx. 15seconds after the heater's switch-off and
then switches off automatically. The icon for the fan rundown
function(21) will be indicated on the display during the fan's
rundown period.
Remote control
All settings of the device can also be made using the remote
control included in the scope of delivery.
17
14
15
16
18
19
No. Designation Meaning
14 Temperature button For setting the desired room
temperature
15 Timer button Switching the timer function on
and off:
setting range of 1min to 24h
in increments of 1min
16 Increase value button For setting the desired room
temperature (15°C to 35°C)
or the number of hours and
minutes for the timer (1min to
24h)
17 Decrease value button
18 MODEbutton For selecting the operating
mode:
Comfort mode
Night mode
Eco mode
Frost monitor function
19 Power button For switching the device on or
activating standby mode
Shutdown
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
1. Switch the device off.
2. Hold onto the mains plug while pulling the power cable out
of the mains socket.
3. Allow the device to cool down sufficiently.
4. Clean the device according to the Maintenance chapter.
5. Store the device according to the Storage chapter.

10 EN
fan heater TFC 220 E
Errors and faults
Warning of electrical voltage
Tasks which require the housing to be opened
must only be carried out by authorised specialist
companies or by Trotec.
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
The device does not start:
• Check the power connection.
• Check the power cable and mains plug for damages.
• Check the on-site fusing.
• Check the room temperature. The room thermostat may
have switched off, because the desired room temperature
has been reached.
• The motor might be defective. Have a defective motor
replaced by a specialist electrical company.
• The room thermostat might be defective. Have a defective
room thermostat replaced by a specialist electrical
company.
• Check whether the overheating protection has tripped, see
chapter Safety.
• Wait for 10minutes before restarting the device. If the
device is not starting, have the electrics checked by a
specialist company or by Trotec.
The device is switched on, but the heating is not operating:
• Check the room temperature. The room thermostat may
have switched off, because the desired room temperature
has been reached.
• Check whether the overheating protection has tripped, see
chapter Safety.
• The heating resistor might have blown. Have a defective
heating resistor replaced by a specialist electrical
company.
• The room thermostat might be defective. Have a defective
room thermostat replaced by a specialist electrical
company.
The air current is reduced:
• Check the air inlet and outlet. Make sure that air inlet and
outlet are not obstructed. Remove any dirt. Observe the
minimum distance from walls or other objects according to
the technical data.
The device is loud or vibrates:
• Check whether the device is set up in a stable and upright
position.
The device does not respond to the infrared remote control:
• Check whether the distance between remote control and
device is too large and reduce it if necessary.
• Make sure there are no obstacles, such as furniture or
walls, between the device and the remote control. Ensure
visual contact between device and remote control.
• Check the charging status of the batteries and change
them if required.
• If the batteries have only just been changed, check them
for correct polarity.
Note
Wait for at least 3 minutes after maintenance and
repair work. Only then switch the device back on.
Your device still does not operate correctly after these
checks?
Please contact the customer service. If necessary, bring the
device to an authorized specialist electrical company or to
Trotec for repair.
Maintenance
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Allow the device to cool down completely.
Warning of electrical voltage
Tasks which require the housing to be opened
must only be carried out by authorised specialist
companies or by Trotec.
Cleaning the housing
Warning of electrical voltage
Never immerse the device in water!
Clean the housing with a soft, damp and lint-free cloth. Ensure
that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Wipe the housing dry after cleaning.

EN 11
fan heater TFC 220 E
Technical annex
Technical data
Parameter Value
Model TFC 220 E
Heating capacity 2200W
Operating range -20°C to 50°C
Setting range 15°C to 35°C
Mains connection 230V/ 50–60Hz
Power consumption, max. 2200 W
Plug type CEE7/7
Cable length 1.5m
Protection class I
Weight 6kg
Dimensions
(depthx widthx height)
90x 520x 350mm
Minimum distance to walls and
other objects
A: top:
B: rear:
C: side:
D: front:
100cm
100cm
100cm
100cm

12 EN
fan heater TFC 220 E
Information requirements for electrical local space heaters
Parameter Value/item
Model TFC 220 E
Heat output
Nominal heat output Pnom 2.2 kW
Minimum heat output (indicative) Pmin 1.1 kW
Maximum continuous heat output Pmax,c 2.2 kW
Auxiliary electricity consumption
At nominal heat output elmax n/akW
At minimum heat output elmin n/akW
In standby mode elsb 0.0011kW
Type of heat input
Manual heat charge control, with integrated thermostat NO
Manual heat charge control with room and/or outdoor temperature
feedback
NO
Electronic heat charge control with room and/or outdoor temperature
feedback
NO
Fan assisted heat output NO
Type of heat output/room temperature control
Single-stage heat output, no room temperature control NO
Two or more manual stages, no room temperature control NO
With mechanic thermostat room temperature control NO
With electronic room temperature control NO
With electronic room temperature control plus day timer YES
With electronic room temperature control plus week timer NO
Other control options
Room temperature control, with presence detection NO
Room temperature control, with open window detection NO
With distance control option NO
With adaptive start control NO
With working time limitation YES
With black bulb sensor NO
Contact details TrotecGmbH
Grebbener Straße 7
D-52525 Heinsberg
NA = not applicable

EN 13
fan heater TFC 220 E
Disposal
The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. For further return options provided by us please
refer to our website www.trotec24.com.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.
In the European Union, batteries and accumulators must not be
treated as domestic waste, but must be disposed of
professionally in accordance with Directive 2006/66/EC of the
European Parliament and of the Council of 6September 2006
on batteries and accumulators. Please dispose of batteries and
accumulators according to the relevant legal requirements.

Trotec GmbH
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[email protected]
www.trotec.com
