OPERATING MANUAL
INFRARED HEATING
PANEL
TIH 500 S / TIH 700 S
EN
TRT-BA-TIH500STIH700S-TC-001-EN

1Operating manual – Infrared heating panel TIH 500 S / TIH 700 S EN
Symbols
Hazardous electric current!
Warns about hazards from electric current which can
lead to injuries or even death.
Hazard from hot surfaces!
Warns of hazards from hot surfaces which can
lead to injuries.
Danger!
Warns of a hazard which can lead to personal injury.
Caution!
Warns of a hazard which can lead to damage to
property.
The current version of the operating manual can be found at:
Legal notice
This release replaces all previous versions. No part of this
publication may be reproduced without written permission from
Trotec. The same applies for electronically processing,
duplicating or spreading the publication. Subject to technical
changes. All rights reserved. Trademarks are used without
guarantee that they may be used freely and primarily following
the spelling of the manufacturer. Product names are registered.
Changes to construction in the interests of constant
improvements to the product, as well as changes to the shape
and colour are reserved.
The scope of delivery may vary from product images. This
document was created with all due care. Trotec accepts no
liability whatsoever for possible mistakes or omissions.
© Trotec
Warranty and liability
The device complies with the fundamental health and safety
requirements of the applicable EU regulations and was tested at
the factory for perfect functionality multiple times. However, if
faults in the functionality occur and cannot be remedied with the
measures in the chapter Errors and faults, please get in touch
with your dealer or distributor. When making a warranty claim,
supply the serial number (see nameplate).
When manufacturer's instructions or legal regulations have not
been followed, or after unauthorised changes to the device are
made, the manufacturer is not responsible for the resulting
damages. Changes to the device or unauthorised replacement of
individual parts can drastically impact the electrical safety of this
product and leads to the forfeit of the warranty. Liability does not
extend to damages to people or property caused by the device
being used other than as described in the instructions in this
operating manual. Subject to changes to technical design and
model changes as part of constant development and product
improvement without prior notice.
No liability is accepted for damages resulting from improper use.
In such cases, entitlements to a warranty are then also forfeited.
Table of contents
Notes regarding the operating manual .................................... 1
Safety ..................................................................................... 2
Information about the device................................................... 3
Transport and storage............................................................. 3
Assembly................................................................................ 3
Operation................................................................................ 4
Errors and faults ..................................................................... 4
Maintenance and repair .......................................................... 4
Disposal.................................................................................. 4
Technical annex...................................................................... 5
Notes regarding the operating manual
TIH 500 S
http://download.trotec.com/?sku=1410003012&id=1
TIH 700 S
http://download.trotec.com/?sku=1410003014&id=1

EN Operating manual – Infrared heating panel TIH 500 S / TIH 700 S 2
Carefully read the operating manual before using the device
and keep it within reach!
Danger!
Improper use of the device can result in severe
injuries due to burns, fire hazard or electric shocks.
• Ensure a minimum distance of 50 cm to combustible
substances. Do not use the device in rooms where fuel,
solvents, varnishes or other easily inflammable vapours are
stored. Do not use the device in immediate proximity to
curtains.
• Keep away from children and animals. Do not leave the
device unattended during operation.
• The device must not be covered during operation, otherwise
it may overheat.
• Never drill into the heating panel.
• Do not transport the device during operation.
• Do not use the device outdoors.
• Only connect the device to the mains if voltage and frequency
correspond to the values given on the nameplate.
• Extensions to the connecting cable must be selected
depending on the device's power input, cable length and
intended use. Completely unroll extension cables. Avoid
electrical overload.
• Pull the plug from the socket if the device is not in use.
• Observe the storage and operating conditions (see chapter
Technical annex).
• Unplug the device from the mains before starting with
maintenance, service or repair work.
Intended use
Only use the device TIH 500 S / TIH 700 S to heat enclosed
spaces such as storage facilities, salesrooms, flats as well as to
heat construction areas and containers whilst adhering to the
technical data.
Improper use
Do not use the device TIH 500 S / TIH 700 S without wall
attachment. Do not use the device outdoors. Do not place any
objects on the device for drying. Do not use this device in
immediate proximity to sinks, bathtubs, showers or swimming
pools.
Any unauthorised changes, modifications or alterations to the
device are forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
electric devices.
• have read and understood the operating manual, especially
the Safety chapter.
Residual risks
Hazardous electric voltage!
Work on the electrical components must only be carried
out by an authorised specialist company!
Hazardous electric voltage!
Before any work on the device, remove the mains plug
from the mains socket!
Hazard from hot surfaces!
The surface of the device warms up during operation.
Do not touch the device surface during operation and
observe the minimum distance!
Danger!
The device is not a toy and does not belong in the hands
of children.
Danger!
Improper handling entails a risk of burning and electric
shock. Only use the device as intended!
Danger!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Danger!
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution!
In order to avoid overheating and fire hazards, the
device must not be covered!
Behaviour in the event of an emergency
1. Disconnect the device from the mains power in an
emergency.
2. Do not reconnect a defective device to the mains power.
Safety

3Operating manual – Infrared heating panel TIH 500 S / TIH 700 S EN
Device description
The infrared heating panel TIH 500 S / TIH 700 S is used to heat
interior spaces.
The infrared heating panel ensures an even heat distribution in
the room.
Device depiction
• Remove all packing materials which serve to protect the
device during transport.
• Should the device be damaged, please contact the
responsible dealer where the purchase was made.
Storage
• Store it in a dry location and protect it against dust.
• Before restarting the device, check the condition of the power
cable. If there are doubts as to the sound condition, contact
the customer service.
1. Spread out the foil over the back of the device and mark the
positions for the bore holes.
2. Attach the foil to the wall using adhesive tape or similar.
3. Drill the holes into the wall at the positions marked on the foil.
4. Insert suitable dowels into the bore holes.
5. Insert the screws into the dowels and fasten the screws.
– The screws should protrude approx. 0.5 cm from the dow-
els.
6. Hang the device in.
Information about the device
No. Operating element
1 Heating element
2Powercable
3 Wall attachment
Transport and storage
1
3
2
2
3
Assembly

EN Operating manual – Infrared heating panel TIH 500 S / TIH 700 S 4
Check whether the power cable is intact. If the power cable is
damaged, it must be replaced by the manufacturer, his customer
service or similarly qualified personnel. Make sure that the
electrical properties of the socket correspond to the values
specified in the operating manual or on the nameplate.
Switch-on
1. Plug the device into a sufficiently fused socket.
– The device is switched on and works automatically.
Switch-off
1. Pull the plug from the mains socket.
2. Allow the device to cool down.
The device still does not operate correctly after these
checks?
Bring the device to a specialist company or to Trotec for repairs.
For maintenance or repair work which requires the
housing to be opened, contact the Trotec customer
service.
Activities required before starting maintenance
• Do not touch the mains plug with wet or damp hands.
• Before any work, detach the mains plug!
• Allow the device to cool down for at least 15 min.
Cleaning the outside of the device
Clean the device with a soft, damp and lint-free cloth. Do not use
sprays, solvents or harsh cleaners to dampen the cloth.
In the European Union, electronic equipment must not
be treated as domestic waste, but must be disposed of
professionally in accordance with Directive
2002/96/EC of the European Parliament and of the Council of
27 January 2003 on waste electrical and electronic equipment
(WEEE). At the end of its life, please dispose of this device
according to the valid legal requirements.
Operation
Errors and faults
Fault Cause Remedy
The device makes
noises after switch-on
The material expands due
to heating. The insulation
expands as well and
generates the noises.
This is a normal process.
No measures are
required.
The surface of the
device bulges outward
The material expands due
to heating.
This is a normal process.
No measures are
required.
The surface only heats
up slightly
The mains voltage does
not meet the
requirements.
Check the mains voltage.
The ambient temperature
is low.
This is a normal process.
No measures are
required.
Maintenance and repair
Disposal

5Operating manual – Infrared heating panel TIH 500 S / TIH 700 S EN
Technical data
Wiring diagram
TIH 500 S
TIH 700 S
Technical annex
Parameter Value
Model TIH 500 S TIH 700 S
Article number 1410003012 1410003014
Heating capacity 580 W ± 5 % 700 W ± 5 %
Mains connection 1/N/PE ~ 230 V / 50 Hz 1/N/PE ~ 230 V / 50 Hz
Nominal current 2.6 A 3.2 A
Connection type CEE 7/7 (SchuKo) CEE 7/7 (SchuKo)
Cable length 2 m 2 m
Efficiency 98 % 98 %
Surface temperature 70–90 °C 70–90 °C
Type of protection IP 54 IP 54
Weight 4.8 kg 6.5 kg
Dimensions (width x height x depth) 905 x 605 x 22 (mm) 1,205 x 605 x 22 (mm)

EN Operating manual – Infrared heating panel TIH 500 S / TIH 700 S 6
Declaration of conformity
in accordance with the EC Low Voltage Directive 2006/95/EC and
the EC Directive 2004/108/EC about electromagnetic
compatibility.
Herewith, we declare that the infrared heating panels
TIH 500 S / TIH 700 S were developed, constructed and
produced in compliance with the named EC directives.
Applied harmonised standards:
EN 60335-1:2012
EN 60335-2-30:2009/A11:2012
EN 62233:2008
EN 55014-1:2006/A1:2009 and A2:2011
EN 55014-2:1997/A1:2001 and A2:2008
EN 61000-3-2:2006/A1:2009 and A2:2009
EN 61000-3-3:2013
Further applied standards:
EN 62321:2009
The marking is found on the device nameplate.
Manufacturer:
Trotec GmbH & Co. KG
Grebbener Straße 7
D-52525 Heinsberg
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
Heinsberg, 31 March 2014
Managing Director: Detlef von der Lieck

Trotec GmbH & Co. KG
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[e-mail]
www.trotec.com
