Trox Technik EASYLAB User manual

EASYLAB
CP-Touch 4.3 control panel
Assembly and operating instructions GB/en
Touch panel for fume cupboard control and room control

A00000086804, 2, GB/en
Installation and operating instructions (translation of the original)
© TROX GmbH 2021
TROX GmbH
Heinrich-Trox-Platz
47504 Neukirchen-Vluyn
Germany
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Internet: www.troxtechnik.com
10/2023
EASYLAB CP-Touch 4.3 control panel2

1 Control panel overview............................. 4
2 General information................................... 5
3 Safety.......................................................... 7
Correct use.................................................. 7
Incorrect use................................................ 7
Dangers and risks........................................ 7
4 Delivery and storage.................................. 8
Carrying the control panel............................ 8
Storing the control panel.............................. 8
Packaging.................................................... 8
5 Installation and connection...................... 9
Mounting the control panel.......................... 9
Connecting the control panel to the
EASYLAB system...................................... 10
6 Commissioning........................................ 11
7 Functional description............................ 13
8 Technical data.......................................... 15
9 Operation.................................................. 15
Structure of the graphical interface............ 16
Basic functions........................................... 23
Operating states......................................... 25
10 Fume cupboard control trouble-
shooting.................................................... 27
11 Room control troubleshooting............... 29
12 Removal and disposal............................. 32
13 Index.......................................................... 33
Table of contents
EASYLAB CP-Touch 4.3 control panel 3

1 Control panel overview
Fig. 1: CP-Touch 4.3 control panel
1 4.3" touch panel
2 Service socket
3 Casing mounting base
4 Interface X1, for EASYLAB and TROX UNI-
VERSAL CONTROLLER
5 Interface X2, for X-Aircontrol
6 Interface X3, for FSL-Control III
Control panel overview
EASYLAB CP-Touch 4.3 control panel4

2 General information
About this manual
This operating and installation manual enables
operating or service personnel to correctly install
the TROX product described below and to use it
safely and efficiently.
This operating and installation manual is intended
for use by fitting and installation companies, in-
house technicians, technical staff, properly trained
persons, and qualified electricians or air condi-
tioning technicians.
It is essential that these individuals read and fully
understand this manual before starting any work.
The basic prerequisite for safe working is to comply
with the safety notes and all instructions in this
manual.
The local regulations for health and safety at work
and general safety regulations also apply.
This manual must be given to the facilities manager
when handing over the system. The facilities man-
ager must include the manual with the system doc-
umentation. The manual must be kept in a place
that is accessible at all times.
Illustrations in this manual are mainly for informa-
tion and may differ from the actual design.
Other applicable documentation
In addition to these instructions, the following docu-
ments apply:
Product data sheets for control systems
– EASYLAB CP-Touch 4.3 control panel
– EASYLAB controller TCU3
– EASYLAB adapter module TAM
Operating and installation manual for the
EASYLAB controller TCU3
EASYLAB configuration software operating
manual (M375EV1)
Project-specific wiring documents
TROX Technical Support
To ensure that your request is processed as quickly
as possible, please keep the following information
ready:
Product name
TROX order number
Delivery date
Brief description of defect or issue
Online www.trox.de
Phone [phone]
Limitation of liability
The information in this manual has been compiled
with reference to the applicable standards and
guidelines, the state of the art, and our expertise
and experience of many years.
The actual scope of delivery may differ from the
information in this manual for bespoke construc-
tions, additional order options or as a result of
recent technical changes.
The obligations agreed in the order, the general
terms and conditions, the manufacturer's terms of
delivery, and the legal regulations in effect at the
time the contract is signed shall apply.
Warranty claims
The provisions of the respective general delivery
terms apply to warranty claims. For purchase
orders placed with TROX GmbH, these are
the regulations in section "Vl. Warranty claims"
of the Delivery Terms of TROX GmbH, see
www.trox.de/en/.
General information
EASYLAB CP-Touch 4.3 control panel 5

Copyright
This document, including all illustrations, is pro-
tected by copyright and pertains only to the corre-
sponding product.
Any use without our consent may be an infringe-
ment of copyright, and the violator will be held liable
for any damage.
This applies in particular to:
Publishing content
Copying content
Translating content
Microcopying content
Saving content to electronic systems and
editing it
Safety notes
Symbols are used in this manual to alert readers to
areas of potential hazard. Signal words express the
degree of the hazard.
Comply with all safety instructions and proceed
carefully to avoid accidents, injuries and damage to
property.
DANGER!
Imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING!
Potentially hazardous situation which, if not
avoided, may result in death or serious injury.
CAUTION!
Potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
NOTICE!
Potentially hazardous situation which, if not
avoided, may result in property damage.
ENVIRONMENT!
Environmental pollution hazard.
General information
EASYLAB CP-Touch 4.3 control panel6

3 Safety
Correct use
The CP-Touch 4.3 control panel serves as a com-
ponent of the EASYLAB system for the display of
values and for activating various functions.
If the control panel is connected to a fume cupboard
control, the status display complies with EN 14175;
operating modes and special functions can be acti-
vated by the user.
If a room is fully equipped with EASYLAB control-
lers, the control panel is intended for monitoring and
for operating mode default setting.
The control panel is allowed to be used for the fol-
lowing EASYLAB applications:
EASYLAB controller TCU3
– in the equipment function – fume cup-
board control (FH-xxx)
– in the equipment function – extract air
control (RE), supply air control (RS) or dif-
ferential pressure control (PC) with active
room management function (RMF)
EASYLAB adapter module TAM with active
room management function (RMF)
The control panel is installed at a suitable location
on the fume cupboard, e.g. on the side frame of
the fume cupboard (observe ergonomics). In the
function as a room control panel, it can be mounted
on the wall with or without a junction box.
Use the unit only with the connection values given
in the technical data.
Residual risks
A failure of the supply voltage is indicated on the
control panel only if the EASYLAB controller is
equipped with the EM-TRF-USV expansion module
and the battery pack has been connected and fully
charged.
Incorrect use
Do not use the control panel for areas of application
that are not described in this manual.
The control panel must not be used in the following
areas:
outdoors
in wet areas
in areas with potentially explosive atmospheres
Dangers and risks
NOTICE!
Risk of damage to property due to large tem-
perature differences
If any electronic components have been kept
in an unheated area, condensation may form
and damage the electronic components beyond
repair.
– Before you start commissioning, make
sure that all devices have warmed up to
the ambient temperature. Only after about
2 hours will the system have reached
ambient temperature.
NOTICE!
Risk of damage to property due to foreign
matter and liquids!
Foreign matter and liquids that get into the unit
may damage the electronic parts.
– Remove foreign matter, if any.
– If the device emits a smell or smoke, have it
checked by the manufacturer.
– If liquid gets into the module, let the module
completely dry before commissioning.
NOTICE!
Risk of damage to property!
Over tightening the fixing screws may damage
the casing.
– Tighten the screws only finger-tight.
Safety
EASYLAB CP-Touch 4.3 control panel 7

NOTICE!
Risk of damage to property due to scouring
or caustic cleaning agents!
Scouring or caustic cleaning agents may damage
the surfaces of the control panel.
– Wipe the glass surface with a cloth slightly
wetted with disinfectant or mild detergent.
Qualified staff
Only skilled qualified electricians are allowed to
work on live components.
The monitoring system is typically commissioned
with the fume cupboard, either by the laboratory
furniture manufacturer or by the system owner.
Malfunctions, if any, must only be eliminated by
trained in-house technicians employed by the
system owner, or by the TROX Technical Service.
4 Delivery and storage
Supply package
Check delivered items immediately after arrival for
transport damage and completeness.
Supply package
CP-Touch 4.3 control panel
Casing mounting base
4-pin spring-cage terminal
Connecting cable, approx. 5 m, patch cable,
blue
Installation and operating manual
Carrying the control panel
If possible, take the product in its transport
packaging up to the installation location.
Do not remove the protective wrapping until
just before installation.
Storing the control panel
For temporary storage of a control panel please
note:
Leave the product in its packaging and do not
expose it to the effects of weather.
Store the product in a dry place and away from
direct sunlight.
Temperature -10 °C to +70 °C, humidity 90%
max. (no condensation)
Packaging
Properly dispose of packaging material.
Delivery and storage
EASYLAB CP-Touch 4.3 control panel8

5 Installation and connection
Mounting the control panel
The control panel is suitable for surface mounting in
horizontal or vertical orientation.
Types of installation include:
Fume cupboard (observe ergonomics!)
– Mounting on side frame
– Mounting on other suitable surfaces
Surface mounting on wall
– Screwing onto junction box
– Screwing onto wall
Remove display
Fig. 2: Remove display from casing mounting base
1. First carefully pull on side of the display off
the casing mounting base.
2. Then pull off the display on the opposite side
as well.
3. Remove display carefully. If the control
panels are already connected, disconnect
the connecting cable before removing them.
Assembly
NOTICE!
Danger of short circuit due to using unsuit-
able fixing screws!
If the circuit board of the front module (display)
touches the fixing screws of the casing mounting
base, there is a risk of a short circuit.
– Fixing screws with a countersunk head
should be preferred.
– Fixing screws Ø 3-3.5 mm, screw head not
higher than 3.5 mm
– Choose screws which are appropriate for the
material of the surface to which they are
fixed.
1. Remove the casing mounting base from the
control panel.
2. Guide the enclosed connecting cables
through the opening X1 on the casing
mounting base.
Use the enclosed cable (type SF-UTP) for
connection; alternatively, a connecting cable
of equivalent or better quality can be used.
The maximum cable length is 40 m.
Fig. 3: Mounting example horizontal on concealed
socket
Installation and connection
EASYLAB CP-Touch 4.3 control panel 9

Fig. 4: Mounting example vertical on concealed
socket
3. Fix the casing mounting base to the fume
cupboard or the wall with 2-4 screws.
Attention: Pay attention to the orientation of
the service cover!
horizontal - Rubber cap at bottom
vertical - Rubber cap on right
4. Plug the connecting cables into interface X1
on the control panel.
5. Press the control panel together with the
connecting cable into the casing until it
locks.
6.
Control panel remote from con-
troller
If there is some distance between the
control panel and the TCU3 controller or
the TROX adapter module, you may use
a network patch cable type S-FTP with a
maximum length of 40 m instead of the
supplied connecting cable.
Lay the connecting cable for connecting the
control panel to the TCU3 controller or to the
TROX adapter module.
Connecting the control panel to the EASYLAB
system
Fig. 5: Connection of TCU3 controller or TROX
adapter module
Connect the control panel to either ter-
minal 1 (Fig. 5/①) or terminal 2 (Fig. 5/②)
of the TCU3 controller or TROX adapter
module.
The remaining connection is intended for a second
control panel.
Complete documentation
Installation and operating manual
Information describing commissioning and opera-
tion can be found in the installation and operating
manual You can download the manual from our
website at www.troxtechnik.com.
Installation and connection
EASYLAB CP-Touch 4.3 control panel10
