True Induction QUAD BURNER User manual

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL
TRUE INDUCTION QUAD BURNER
INDUCTION COOKTOP MANUAL

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL
I. Important Safety Information 1 - 3
II. Cooktop Features 4 - 6
III. Using the Cooktop 7 - 10
IV. Operational Cooktop Noises 11
V. Compatible CookWare 12
VI. Cleaning Your Cooktop 13
VII. Troubleshooting Guide 14 -15
VIII. Installation Instructions 16 - 20
Thank you for purchasing the True Induction 30 Inch Induction Cooktop unit. Please read the
entire instruction manual prior to using your unit. If you have any questions regarding the
True Induction Cooktop, please visit TrueInduction.com or call: 1-877-862-7049
Before installation, record the model and serial number as found on the
front of your cooktop. If you require service or call with a question, please
have this information ready.
Table of Contents
Serial Number ________________________________________________________
Model Number ________________________________________________________
About Induction Cooking
Induction cooking is a safe, advanced, efficient, and economical cooking technology. It
works by electromagnetic field generating instant heat directly in the cookware bottom, rather
than indirectly through heating the glass surface. The glass becomes hot only because the
cookware warms it up.
Our induction cooktop has been tested and complies with Part 18 of the FCC Rules for ISM
equipment. Product meets the FCC requirements to minimize interference with other devices
in residential installation.

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P. 1
I. Important Safety Information
IMPORTANT
Keep these instructions handy for future use.
The appliance is manufactured in compliance with the relevat safety standard.
Intended Use
• This appliance is designed for built-in
household use only.
• DO NOT use outdoors.
• DO NOT use the appliance to heat a room.
• DO NOT allow aluminum foil, paper
or cloth to come in contact with a hot
element.
• Avoid preparing food in aluminum foil
or plastic containers over the hot
cooking zones.
• Protective liners - DO NOT use
aluminum foil to line cooking zone, drip
bowls or oven bottoms, except as
suggested in the manual. Improper use
of electric shock or fire.
• DO NOT allow pans to boil dry or empty.
• Never leave the cooktop unattended
when in use.
• Always use the proper pot and pan size.
• The use of undersized cookware will
expose a portion of the hot element,
which can result in ignition of clothing or
personal burners.
Cooking Safety
WARNING
!
• Always remove the covers on sealed or
canned goods and before heating to
avoid explosion.
• Close supervision is necessary when
any appliance is used by or near
children.
• DO NOT touch hot surfaces. Use dry
potholders to hold the handles of pots
and pans.
• Use only dry potholders - moist or damp
potholders on hot surfaces may result
in burns from steam. DO NOT let the
potholder touch hot heating element.
• DO NOT use a towel or other bulky
cloth.
• We strongly recommend that a person
with physical or mental impairments not
use the appliance unless accompanied
by a qualified person.The same
recommendation applies to children.
• When the unit is on, DO NOT touch
outside the control panel as the surface
may contain residual heat. It is important
to be aware that the unit’s surface will
remain hot for a short period of time after
use. DO NOT touch any hot surfaces.
Read all instructions carefully before installation and
operation of the appliance.
WARNING
!
Failure to follow these warnings could result in a fire or
explosion that causes property damage, personal injury or death. To reduce
the risk of fire, electric shock or injury, take the following precautions:
WARNING
!

• To reduce the risk of fire, DO NOT let any
objects (glass, paper, etc.) obstruct the
inlet and outlet of your cooktop.
• To reduce the risk of electric shock, DO
NOT mount unit over a sink.
• To reduce the risk of fire, DO NOT store
anything directly on top of the appliance
surface when the appliance is in operation.
• Always have a working smoke detector in
or near the kitchen.
• DO NOT leave lids or
other metal objects such as knives, forks
or spoons on the cooktop. If the cooktop is
turned on, these objects can heat up quickly
and may cause burns. DO NOT place rough
or uneven objects on the unit as they may
damage the surface. If the cooktop is near a
window, ensure that curtains DO NOT blow
over or near the unit
QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P. 2
I. Important Safety Information
Cleaning Safety
WARNING
!
Condition of Unit
• DO NOT use steam cleaners or high
pressure cleaners to clean the cooktop,
as this may result in electric shock.
• DO NOT operate any
appliance with a damaged cord or after
the appliance malfunctions or has been
damaged in any manner. Return appliance
to the nearest authorized service facility for
examination, repair, or adjustment.
• DO NOT cook on
broken cooktop. If cooktop breaks, cleaning
solutions and spillovers may penetrate the
broken cooktop and create a risk of electric
shock.
WARNING
!
IMPORTANT
!
• DO NOT use
the cooktop as a work surface. Certain
substances such as salt, sugar, or sand
can scratch the glass ceramic surface.
DO NOT store hard or pointed objects
over the cooktop as they can damage
the unit if they fall on top.
• DO NOT put detergents or flammable
materials in the equipment installed
under the cooktop.
• While cooking any overflowed fat or oil
on the cooktop may ignite. There is a
risk of burning and fire; therefore,
control the cooking process at all times.
• The use of accessory attachments not
recommended by the appliance
manufacturer; doing so may cause
injuries.
• Items with a magnetic field such as:
radios, televisions, credit cards,
cassette tapes etc., can affect the unit.
• The marked electrical rating should be
at least as great as the electrical rating
on the appliance.
• To prevent accidents and achieve
optimal ventilation, allow for sufficient
space around the cooking area.
• DO NOT store items
of interest to children in cabinets above
the range or on the backguard of a range.
Children climbing on the range to reach
items could get hurt or seriously injured.
CAUTION
!
IMPORTANT
!
Environment of Unit
IMPORTANT
!
CAUTION
!

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P. 3
I. Important Safety Information
Environment of Unit
• Use proper cookware size - This
appliance is equipped with four Cooking
Elements of different sizes. Choose
cookware with a flat bottom large enough
to cover the unit heating surface. The use
of undersized cookware will expose a
portion of the heating surface where direct
contact may be made and cause serious
injury. Compatible cookware will improve
efficiency.
• To reduce risk of burns, ignition of
flammable materials, and spillage due
to unintentional cntact with cookware,
the cookware handles should be turned
inward and not extend over adjacent
heating surface.
• Wear proper apparel - loose fitting or
hanging garments should never be
worn while using the appliance.
• DO NOT allow cord to touch hot surface.
A short power supply cord or detachable
power supply cord should be used to
reduce the risk of becoming entangled
in or tripping over a longer cord.
• Always attach plug to appliance first,
then plug cord into the wall outlet. To
disconnect, turn any control to OFF, then
remove plug from wall outlet.
• The cord should be arranged so that it
will not drape over the countertop where
it can be pulled on by children or tripped
over.
Service and Repair Safety
• DO NOT repair or
replace any part of the appliance unless
specifically recommended in the manual.
All other services should be referred to a
qalified technician.
• There are no user serviceable parts on
this appliance. Only an authorized service
representative should sttempt to service
your cooktop.
WARNING
!
This product may not be treated as household waste. Instead it should be handed over to the
applicable collection point for the recycling of electrical and electronic equipment. By ensuring
this product is disposed of correctly, you will help prevent potential negative consequences for
the environment and human health, which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information about recycling of this product, please
contact your local city office, your household waste disposal service or the shop where you
purchased the product.
Power Cord Safety
WARNING
!
• To protect against
electric shock, DO NOT immerse cord,
or main body in water or any other liquid.
• DO NOT let cord hang over edge of table
or counter.
WARNING
!
Save These Instructions

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P. 4
II. Cooktop Features
78 6
5
4
3
2
1
9
Left Front Cooking Zone1.
Left Rear Cooking Zone2.
Right Rear Cooking Zone3.
Right Front Cooking Zone4.
Ceramic Glass5.
Right Rear Cooking Zone
Controls
6.
Right Front Cooking Zone
Controls
7.
Left Front Cooking Zone
Controls
8.
Left Rear Cooking Zone
Controls
9.
10 11
13 12
Control Lock Indicator Light10.
Main Power Indicator Light11.
Main Power ON/OFF12.
Control Lock13.
30” (76.2cm) Model TI-4B

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P. 5
II. Cooktop Features
15
14
161718
20
19
2122
Power Lever & Residual
Heat Display
14.
Cooking Zone Symbol15.
Power ON/OFF16.
Increase Power17.
Decrease Power18.
Minute TImer Display
Window & Cooking
Element Symbol
19.
Minute TImer Setting Up20.
Minute TImer21.
Minute TImer Setting Down22.

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P. 6
II. Cooktop Features
Model TI-4B
Product Dimension (WxDxH)
Cut-Out Dimension (WxD)
Voltage (Volts)
Frequency (Hz)
Total Power (Watts)
Minimum Circuit Breaker Amperage
Elements
Front Left
Rear Left
Front Right
Rear Right
30” x 21” x 2¹⁄6”
Min. 28³⁄4” x 19³⁄4” Max. 29¹⁄4” x 20”
240
60
7400
40
4
2100W/2500W
1600W/2000W
1400W/1800W
2300W/2700W
DISPLAY DESCRIPTION
The power level
The power boost
A cooking element is still hot to touch (residual heat)
Electronics fault error message of specific cooking element
Error Code (see Troubleshooting Guide, P.15)
Specifications
Heat Setting Displays

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P. 7
III. Using The Cooktop
Controls Lock
To Lock
• Controls Lock is activated when the
cooktop is off: Controls Lock prevents
activation of any sensor key, except for
the Lock key pad, so you must
deactivate the control lock firstly, then
touch the main POWER key pad to turn
the cooktop.
• Controls Lock is activated during the
cooktop use: Controls Lock prevents
activation of any sensor key, except for
the ON/OFF, Power and Lock key pad.
Touch and hold Lock key pad for 3
seconds, a “beep” will sound and the
indicator light above the Lock key pad
will be lit up.
To Unlock
Touch and Hold Lock key pad for 3
seconds, a “beep” will sound, the
indicator light will turn OFF.
Touch and Hold for 3 seconds
To Turn On The Cooktop
While in the Standby Mode, touch the
Main Power key pad, a “beep” will
sounds and the indicator light above the
Power key pad will be lit up, indicating
that the induction cooktop functions are
ready to use. The unit will automatically
return to Standby Mode if no cooking
elements are set within 30 seconds.
To Turn Off The Cooktop
Touch the ON/OFF key of the cooking
element to shut off the cooking
element.
Touch the Main Power key pad to turn
off the entire cooktop, a “beep” will
sound and all indicator lights will turn
off, indicating the cooktop has entered
into the Standby Mode.
1.
2.

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P. 8
III. Using The Cooktop
Power BoostOperating The Cooktop Elements
To turn on one or more Cooking Elements,
place a compatible pot or pan on the
desired cooking element. With the cooktop
being ON as mentioned above, touch the
ON/OFF key pad of the desired cooking
element, the Power display will show a “5”,
indicating the unit heat at level 5.
Power Management
Touch “-” key or “+” key to adjust the
desired power level; NOTE: During
cooking, the unit is equipped with
safeguards against parching.
NOTE: Heating will appear intermittent
phenomenon when cooking element is
used for frying, stir-frying, grilling and
other high temperature cooking formats.
Automatic Power Level Control
The power lever displayed may be
different from the actual power lever at
the power sharing and high temperature
range. To prevent the cooktop from
overheating, the power level is controlled
automatically.
Touch “+” key to level 9, then press once
to enter into Boost Mode, the power
display will show a “P”. The “Boost”
function is used to cook at maximum
power for a short period of time (maximum
10 minutes). The power is reduced to level
9 at the end of the maximum boost time.
In the Boost status, touch “-” key or after
10 minutes the power boost setting will
switch off automatically, Power Boost
indicator light will turn off, Power digital will
switch from “P” to “9”.
Power Boost is only
recommended for BOILING WATER.
DO NOT leave a pot
unattended while in Boost Mode or other
high power settings.
WARNING
!
WARNING
!

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P. 9
Power Sharing
III. Using The Cooktop
Four cooktops are divided into two
separate cooking areas, the right and
left side cooking elements share power
of a inverter.
Power sharing is activated when the
cooking element in the same area are
activated; the controls adjust the power
automatically for “Power Sharing”. This
power sharing is administered by unit’s
microprocessors, which will alternate
power in one area.
Power Sharing Tips: Remember to
select the power setting last for the
cooking element you want to maintain
at full setting heat. To maintain full
setting heat for two items, place one
item on a element in one section (left
side), and the other item on a element
in another section (right side).
Residual Heat Indicator
After using any of the Cooking Element,
the cooking area will remain hot. Even
after turning off the entire unit, the
surface of the cooktop will remain hot
for some time. The digital display for the
Cooking Element will show an “H”
(shown above) to warn the user that the
surface is hot to touch (Hot Surface
Indicator) after the Cooking Element
switches off. Wait until the “H” is no longer
displayed to clean the unit. You may turn
the Cooking Element back on even if the
“H” is displayed.
30” (76.2cm) Model TI-4B
Left Zone Right Zone

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P.10
III. Using The Cooktop
Set Timer
The automatic timer settings range from
1 minute to 99 minutes. (NOTE: There
is no “seconds” and “hours” display, only
minutes). The red dot next to the Time
symbol indicator will illuminate indicating
that the cooking elements is selected.
While cooking, touch the Timer key pad
until time light of the desired cooking
element is ON, Time digital display reads
“00” and blinking; Touch “+” or “-” key to
set the desired number. Once the Timer
is set and no “+” or “-” keys are pressed
for 5 seconds, the Minute Timer begins
the countdown and the timer display will
stop blinking and will stay on in the
display. Once the Minute Timer reaches
“00”, a “beep” will sound, indicating that
the time is up, the Particular Cooking
Element will automatically shut off.
If you want to set another burner to switch
off automatically, touch Timer key until the
desired time symbol indicator blinks,
repeat the same steps above.
If you want to check the remaining time for
another Cooking Element, touch the Timer
key until the time symbol indicator for the
desired Cooking Element blinks.
If more than one switch off time is
programmed, the shortest time remaining
will show in the Time digital display, the
indicator for that particular burner will be
blinking.
Cancel Timer
Touch the Timer key until the Time symbol
indicator for the desired Cooking Elements
blinks, then touch the “+” or “-” to set the
timer to 00. The Time digital display will
blink for 5 seconds and then turn off,
indicating that the timer of selected cooking
element has been cancelled.

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P. 11
IV. Operational Cooktop Noises
Cookware Noise
The induction fields are generated by
electronics equipment, which are pretty
much silent but they do produce heat at
high power level. A soft sounding cooling
fan runs when the unit is running multiple
cooking elements at high settings at once
or when a cooking element is set at very
high power settings.
What can sometimes produce sound with
induction cooking is not the induction
equipment but the cookware itself. Slight
sounds may be produced by different types
of cookware. Some of the possible causes
include:
• Heavier pans such as enameled cast iron
produce less noise than a lighter weight
multi-ply stainless steel pan; Light weight
cookware may also vibrate. Heavy weight
quality cookware is recommended.
• Cookware with irregular or warped bottoms
can vibrate audibly on the ceramic glass
surface, though again typically only at high
power settings.
• A “cracking” noise may be heard if the
cookware base is made of a layer of
different material.
• A low “humming” noise occurs when
cooking, which is normal particularly
at high power settings.
• Whistling can occur if both elements
are being used at the same time at
the high settings, and the cookware
has bases made of a layer of different
material.
• Loose fitting handles on cookware,
typically when riveted on, can vibrate
slightly.
• High quality cookware of solid cast iron
including enamelware will lower the
noise.

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P.12
V. Compatible Cookware
The quality of your cooking is dependent on the cookware you use. Because
induction cooking requires a magnetic vessel for heating, only certain materials
can be used on your cooktop.
Visit TrueInduction.com for more information about our compatible cookware collection.
Optimally the cookware will have this
induction image on the retail box:
The following are not compatible:
heat-resist glass, ceramic, copper,
aluminum pots/pans, round
bottomed cookware, or cookware
with a base less than 5 inches.
NOTE: Some cookwares can produce noises when used on induction cooking zones.
This is not a fult in the cooktop, and its function will not be impaired in any way as a result.
Induction requires pots and pans that are
made of ferrous (meaning magnetic)
materials.
Check your cookware’s retail box for the
induction symbol. To tell if your current
cookware is compatible with the induction
technology, grab a magnet and see if it
holds to the bottom of the cookware. If
your magnet stays on then your cookware
is ready to be used on the True Induction
cooktop!

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P.13
VI. Cleaning Your Cooktop
Please follow these directions along with Important Safety steps for cleaning, advised
at the beginning of the manual. Use a ceramic glass cleaner on the glass cooktop. To
maintain and protect the surface of your glass cooktop, follow these steps:
Before using the cooktop for the first time, clean it to protect the top and makes cleanup
easier.
1. Daily use of ceramic glass cleaner when the cooktop is cool will keep the cooktop
looking new.
2. Shake the cleaning solution well. Apply a few drops of ceramic glass cleaner directly to
the cooktop.
3. Use a paper towel or a soft cleaning pad for ceramic surface to clean the entire cooktop
surface.
4. Use a dry cloth or paper towel to remove all cleaning residue. No need to rinse. Never
run the cooktop under water.
Cleaning Burned on Residue:
NOTE: It is very important that you DO NOT use the cooktop until it has been thoroughly
cleaned.
WARNING: Damage to the glass surface may occur if you use scrub pads or any other
type of abrasive cleaning materials.
1. Allow the cooktop to cool.
2. Spread a few drops of the ceramic glass cleaner on the burned residue area.
3. Using the ceramic glass cleaning pad, rub the residue area, applying pressure as
needed.
4. If any residue remains, repeat the steps listed above.
5. For additional protection, after all residue has been removed, polish the entire surface
with the ceramic glass cleaner and a paper towel.
Cleaning Heavy Burned on Residue:
1. Allow the cooktop to cool.
2. Using a single edge razor blade scraper at approximately a 45 degree angle against
the glass surface, and scrape off the residue.
3. After scraping off the residue, apply a few drops of the ceramic glass cleaner on the
entire burned residue area. Use the cleaning pad to remove any remaining residue.
4. For additional protection, after all residue has been removed, polish the entire surface
with the ceramic glass cleaner and a paper towel.
Metal Marks and Scratches:
Be careful not o slide pots or pans across the cooktop surface. It will leave behind metal
markings. These marks are removable using the ceramic glass cleaner along with the
cleaning pad for induction cooktop.
If pots with a thin overlay of aluminum or copper boil dry, the overlay may leave a black
discoloration on the cooktop. This should be removed immediately before using the
cooktop again or the discoloration will become permanent.
NOTE: If cracks or indentations in the glass surface occurs, the cooktop glass will have
to be replaced. Contact the manufacturer for assistance.

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P.14
VII. Troubleshooting Guide
If you encounter the following problems while using your cooktop, check the guide
below to see if you can correct the problem yourself before calling for assistance
or service:
Problem Possible Cause Solutions
• Cooktop does not work
• Cooktop does not heat
• Cooktop turns off while cooking
• Cooktop controls are locked
• Power outage
• Installation wire not complete
• Circuit breaker has tripped or fuse
is blown
• Make sure Lock mode is turned off
• Check house lights to confirm power
outage
• No cookware or improper cookware
placement on the cooking element
• Incorrect cookware size for the
selected cooking element
• Cookware is not properly resting on
cooking element
• Incorrect cooking element selected
• No power to cooktop
• Cooktop internal heat sensor has
detected high temperature inside
the cooktop, activating automatic
shut off
• Liquid or object on the controls ares
• Make sure that the cookware is
centered on the cooking element,
and that cookware is also of correct
type for induction cooking. See
Compatible Cookware
• The bottom of the cookware must be
large enough to cover cooking
element completely. See Compatible
Cookware
• Cookware bottoms must be flat and
centered on the cooking element.
See Compatible Cookware
• Make sure the correct control is ON
for the cooking element being used
• See “Cooktop does not work” above
• Make sure the cooktop vents are not
blocked
• The cooktop features an automatic
shut off feature that turns off the
entire cooktop if any cooking element
has been on continuously for 2 hours
• The cooktop control panel may
register liquids or objects obstructing
the panel, which can cause the
cooktop to shut off. Clean up spills or
remove objects and restart the unit

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P.15
VII. Troubleshooting Guide
If you encounter the following problems while using your cooktop, check the guide
below to see if you can correct the problem yourself before calling for assistance
or service:
Problem Possible Cause Solutions
• Power boost does not work
• Boost function is not available if
adjacent burner is in use (2 burners
in the right zone or 2 burners in the
left zone
• See Power Sharing
• The fans keep running for one minute
after the cooking element has been
switched off
• The electronics are cooling down • This is a normal occurrence
• “E” appears in the power display • Electronics fault error message of
particular cooking element • See E0, E1, E2, E3, E7, E8, E9, EE
• “E0” appears in the timer display
• “E1” appears in the timer display
• “E2” appears in the timer display
• IGBT overheating • Turn off unit to allow IGBT to cool,
then restart the unit
• No cookware found or improper
placement of cookware on the
cooking element
• Make sure that the cookware is
centered on the cooking element, and
that it is also induction compatible. See
Compatible Cookware
• Supplied voltage to cooktop is too
low
• This may be caused by reduced
voltage being supplied to the house
circuit. If connections are correct
and the supplied voltage returns to
normal, the code will disappear
• “E3” appears in the timer display • Supplied voltage to cooktop is too
high
• This may be caused by increased
voltage being supplied to the house
circuit. If connections are correct
and the supplied voltage returns to
normal, the code will disappear
• “E7” appears in the timer display • NTC1 Break off • Turn the cooktop OFF; then pull the
plug out for about 30 seconds. Then
reinsert the plug and turn the cooktop
on using the POWER pad. If the error
message is still displayed, call for
service
• “E8” appears in the timer display
• “E9” appears in the timer display
• “EE” appears in the timer display
• NTC1 Short circuit
• NTC2 Break off
• NTC2 Short circuit
• Noise • Noise like humming, crackling and
buzzing
• This is a normal occurrence, See
Operational Cooktop Noises

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P.16
VIII. Installation Instructions
IMPORTANT SAFETY INFORMATION
Before Installing the Cooktop
WARNING
!
Installation and service must be performed by a qualified installer
or service technician.
IMPORTANT Read and save these instructions for future reference.
DANGER
!
Always read and obey all safety information, failure to follow these
instructions can be killed or seriously injured.
1. Visually inspect the cooktop for damage.
Also make sure all cooktop screws are on tight.
2. Record the model and serial number as found
on the bottom of your cooktop. When ordering
parts for or making inquires about your cooktop,
always be sure to include the model and serial
numbers and a lot number or letter from the
serial plate on your cooktop.
3. Cutout dimensions of the countertop.
4. Make sure the wall coverings, countertop and cabinets around
the cooktop can withstand heat (up to 200°F) generated by the
cooktop.
5. Gently lower the cooktop into the countertop cutout.
NOTE: Do not seal the cooktop to the countertop, the cooktop
must be removable if service is necessary.
Serial plate is located under
the front of the cooktop
Electrical Connection
Observe all governing codes and local ordinances.
IMPORTANT
!
Model TI-4B needs 40 Amp service.
Maximum Connected Load
Model TI-4B - 7.4kW at 240 VAC, 6.4kW at 208 VAC

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P.17
VIII. Installation Instructions
The Induction Cooktops must connect to a separate, grounded wire, single phase,
AC Only electrical supply with their own circuit breaker. These appliances must be
installed in accordance with National Electrical Codes, as well as all state, municipal
and local codes. This appliance must be supplied with the proper voltage, frequency,
and amperage, which is protected by a properly sized circuit breaker or time delay
fuse.
The cable from appliance is equipped with 3-wires:
If 3-Wire Cable from Home Power Supply
IMPORTANT: Use the 3-wire cable from Home Power Supply where local codes
permit a 3-wire connection.
Cable from Power Supply
Cable from Appliance
Red Wire
Black Wire
Green Wire
(Grounding)
Junction Box
Red Wire
Black Wire
3-Wire Cable from Home Power Supply

QUADRUPLE BURNER INDUCTION COOKTOP MANUAL P.18
VIII. Installation Instructions
4-Wire Cable from Home Power Supply
Cable from Power Supply
Cable from Appliance
Green Wire
(Grounding)
Junction Box
Red Wire
Black Wire
Red Wire
Black Wire
White Wire
If 4-Wire Cable from Home Power Supply
IMPORTANT: Use the 4-wire cable from Home Power Supply where local codes
do not allow grounding through neutral.
Electrical Ground is Required on this Appliance
WARNING
!
The cooktop conduit wiring is approved for copper wire connection
only, if you have aluminum house wiring, use only special connectors which are approved
for joining copper and aluminum wires conform with local codes and ordinances. Follow
the electrical connector manufacturer’s recommended procedure closely.
