Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
T-12F
T-12F
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LDH*
HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
T-12F 1 12
340
324
7/8
632
231/8
588
631/8
1604
1/4
1/3
115/60/1
230-240/50/1
2.6
2.5
5-15P
▲
9
2.74
205
93
* Height does not include 1" (26 mm) for door hinge. ▲Plug type varies by country.
6/07
R
True’s solid door reach-in’s are designed
with enduring quality that protects your
long term investment.
Designed using the highest quality
materials and components to provide the
user with colder product temperatures,
lower utility costs, exceptional food
safety and the best value in today’s food
service marketplace.
Extra large evaporator coil balanced
with higher horsepower compressor and
large condenser maintains -10°F (-23.3°C)
cabinet temperatures. Ideally suited for
both frozen foods and ice cream.
300 series stainless steel solid door and
front. The very finest stainless with
higher tensile strength for fewer dents
and scratches.
Adjustable, heavy duty PVC coated
shelves.
Positive seal self-closing door. Lifetime
guaranteed door hinges and torsion type
closure system.
Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest
possible defrost cycle.
Bottom mounted units feature:
“No stoop” lower shelf.
Storage on top of cabinet.
Compressor performs in coolest, most
grease free area of kitchen.
Easily accessible condenser coil for
cleaning.
T Series:
Reach-In Solid Door Freezer
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
T-12F TFAY55E TFAY55S TFAY55P TFAY553
T-12F
DESIGN
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures, lower
utility costs, exceptional food safety and
the best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free)
R404A refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains -10°F
(-23.3°C). Ideally suited for both frozen
foods and ice cream.
• Sealed, cast iron, self-lubricating
evaporator fan motor(s) and larger
fan blades give True reach-in’s a more
efficient low velocity, high volume
airflow design. This unique design
ensures faster temperature recovery and
shorter run times in the busiest of food
service environments.
• Bottom mounted condensing unit
positioned for easy cleaning.
Compressor runs in coolest and most
grease free area of the kitchen. Allows
for storage area on top of unit.
• Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest
possible defrost cycle.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel front.
Anodized quality aluminum exterior
ends, back and top.
• Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless floor
with coved corners.
• Insulation - entire cabinet structure and
solid door are foamed-in-place using
high density, CFC free, polyurethane
insulation.
• Welded, heavy duty galvanized frame
rail dipped in rust inhibiting enamel
paint for corrosion protection inside and
out.
• Base rail fitted with leg levelers (legs not
available).
DOOR
• 300 series stainless steel exterior with
white aluminum liner to match cabinet
interior. Door extends full width of
cabinet shell.
• Lifetime guaranteed recessed door
handle. Door fitted with 12" (305 mm)
long recessed handle that is foamed-
in-place with a sheet metal interlock to
ensure permanent attachment.
• Positive seal self-closing door. Lifetime
guaranteed door hinges and torsion
type closure system.
• Magnetic door gasket of one piece
construction, removable without tools
for ease of cleaning.
SHELVING
• Three (3) adjustable, heavy duty PVC
coated wire shelves 2013/16"L x 17"D
(529 mm x 432 mm). Four (4) chrome
plated shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on 1/2" (13 mm) increments.
LIGHTING
• Incandescent interior lighting - safety
shielded.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• Rear airflow guards prevent product
from blocking optimal airflow.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase - 15 amp dedicated outlet. Cord
and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒230 - 240V / 50 Hz.
❒Novelty baskets.
❒Additional shelves.
❒Remote cabinets (condensing unit
supplied by others; system comes
standard with 404A expansion valve
and requires R404A refrigerant). Consult
factory technical service department for
BTU information.
115/60/1
NEMA-5-15R
ELEVATION PLAN VIEW
T Series:
Reach-In Solid Door Freezer
64"
(1626 mm)
2413/16"
(631 mm)
263/32"
(663 mm)
231/32"
(585 mm)
601/8"
(1528 mm)
15/16"
(24 mm)
5/16"
(8 mm)
25/8"
(67 mm)
631/16"
(1602 mm)
4615/32"
(1181 mm)
