TS-49F-4
TS-49F-4
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LDH
*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TS-49F-4 4 49
1388
654
1/8
1375
291/2
750
783/8
1991
3/4
1
115/60/1
230-240/50/1
13.2
6.4
5-20P
▲
9
2.74
560
255
*Height does not include 5
" (127 mm) for castors or 6 " (153 mm) for optional legs. ▲Plug type varies by country.
1/06
Designed using the highest quality
materials and components to
provide the user with colder product
temperatures, lower utility costs,
exceptional food safety and the
best value in today’s food service
marketplace.
Extra large evaporator coil balanced
with higher horsepower compressor
and larger condenser; maintains
-10°F (-23.3°C) cabinet temperatures.
Ideally suited for both frozen foods
and ice cream.
300 series stainless steel exterior and
interior. The finest stainless available
with higher tensile strength for
fewer dents and scratches.
Adjustable, heavy duty PVC coated
shelves.
Positive seal self-closing doors.
Lifetime guaranteed door hinges
and torsion type closure system.
Automatic defrost system time-
initiated, temperature-terminated.
Saves energy consumption and
provides shortest possible defrost
cycle.
Bottom mounted units feature:
”No stoop” lower shelf.
Storage on top of cabinet.
Compressor performs in coolest,
most grease free area of kitchen.
Easily accessible condenser coil for
cleaning.
TS Series:
Reach-In 300 Series Stainless Steel Solid Half Door Freezer
R

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
25/8"
(67 mm)
13/8"
(35 mm)
TS-49F-4 TFGY20E TFGY20S TFEY02P TFGY203
TS-49F-4
DESIGN
• True’s solid door reach-in’s are designed
with enduring quality that protects your
long term investment.
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures, lower
utility costs, exceptional food safety and
the best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free) R404A
refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor and
large condenser maintains -10°F (-23.3°C).
Ideally suited for both frozen foods and ice
cream.
• Sealed, cast iron, self-lubricating
evaporator fan motor(s) and larger
fan blades give True reach-in’s a more
efficient, low velocity, high volume
airflow design. This unique design ensures
faster temperature recovery and shorter
run times in the busiest of food service
environments.
• Bottom mounted condensing unit
positioned for easy cleaning. Compressor
runs in coolest and most grease free area
of the kitchen. Allows for storage area on
top of unit.
• Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest
possible defrost cycle.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel doors,
front and sides. Matching aluminum back.
• Interior - 300 series stainless steel liner and
floor.
• Insulation - entire cabinet structure and
solid doors are foamed-in-place using high
density, CFC free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with 4" (102 mm)
diameter stem castors - locks provided on
front set.
DOORS
• 300 series stainless steel exterior and liners.
Doors extend full width of cabinet shell.
Door locks standard.
• Positive seal self-closing doors. Lifetime
guaranteed door hinges and torsion type
closure system.
• Lifetime guaranteed recessed door
handles. Each door fitted with 12"
(305 mm) long recessed handle that
is foamed-in-place with a sheet metal
interlock to ensure permanent attachment.
• Magnetic door gaskets of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• Six (6) adjustable, heavy duty PVC coated
wire shelves 249/16"L x 223/8"D (624 mm
x 569 mm). Four (4) chrome plated shelf
clips included per shelf.
• Aluminum shelf support pilasters. Shelves
are adjustable on 1/2" (13 mm) increments.
LIGHTING
• Incandescent interior lighting -safety
shielded. Lights activated by rocker switch
mounted above top doors.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• Exterior mounted solar, digital
temperature monitor.
• Rear airflow guards prevent product from
blocking optimal airflow.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase - 20 amp dedicated outlet. Cord and
plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒230-240V/50 Hz.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒Alternate door hinging (factory installed).
❒Additional shelves.
❒Half door bun tray racks. Each holds up
to eleven 18"L x 26"D (458 mm x 661 mm)
sheet pans (sold separately) (airflow guards
need to be removed).
❒Remote cabinets (condensing unit supplied
by others; system comes standard with
404A expansion valve and requires R404A
refrigerant), consult factory technical
service department for BTU information.
ELEVATION PLAN VIEW
115/60/1
NEMA-5-20R
TS Series:
Reach-In 300 Series Stainless Steel
Solid Half Door Freezer
5"
(127 mm)
7615/16"
(1955 mm)
785/16"
(1990 mm)
541/8"
(1375 mm)
835/16"
(2117 mm)
2517/32"
(649 mm)
291/2"
(750 mm)
267/8"
(683 mm)
551/32"
(1398 mm)
