Trynex SnowEx RTG-2400 User manual

© Trynex International 2007 L1186 (REV 000) 8 — 1
Spreaders for Snow & Ice Control
FOR MODEL
RTG-2400

L1186 © Trynex International 2007
8 — 10
RTG-2400 Auger Drive Assembly
Parts Breakdown

© Trynex International 2007 L1186 8 — 11
.ytQnoitpircseD.oNtraPyeK
3
D6453 5/16” x 1” Serrated 18-8 SS
RTG-2400 Auger Drive Assembly
Parts Breakdown
Auger Drive
Assembly
D6584 3/8” Flange Nut
D5527 1” Bearing
D5702 Bearing Cover
D5709 6” Variable Pitch Auger
D5706 5/16” Serrated Flange Nut
D6452 3/8” Serrated HHCS
D6842 Love Joy Coupling
D6843 Urethane Spyder
D6873 3/16” Key Stock
D6825 12 Volt Auger Motor
D6894 Auger Transmission
1
1
2
4
4
4
2
1
3
1
1

L1186 © Trynex International 2007
8 — 12
RTG-2400 Spinner Drive Assembly
Parts Breakdown

© Trynex International 2007 L1186 8 — 13
RTG-2400 Spinner Drive Assembly
Parts Breakdown
.ytQnoitpircseD.oNtraPyeK
D6854 1/4-20 x 1” HWH Serrated
D6823 Urethane Spinner
D5718
D6133
D6327
D4121
D6131
D6877
D5721
D4135
D5739
D5741
D5740
D6447
D5738
D5722
D6232
D5723
D5715
D6135
D4124
Spinner Mounting Hub
5/16-18 x 1/2” Hex Bolt
Spinner Deflector
3/8”-16 x 1” HHCS
1/4-20 x 1/2” SS HWH Serrated TCS
#8 x 3/4 Self Driller HWH
Spinner Drive Enclosure
5/16 Hair Pin Clip
Spinner Drive Pin
Long Leveler Rod
Short Leveler Rod
5/16” x 1” Self Driller
Leveler Mount Bracket
Spinner Motor
Motor Coupler
Spinner Transmission
Spinner Motor Cover
#10-32 x 5/8” HMS
3/8” Lock Nut
3
1
1
1
1
2
4
6
1
4
1
1
1
2
1
1
1
1
1
2
2
Complete Drive Assembly
D4125 3/8” Flat Washer 2

L1186 © Trynex International 2007
8 — 14
RTG-2400 Hopper Assembly
Parts Breakdown

© Trynex International 2007 L1186 8 — 15
RTG-2400 Hopper Assembly
Parts Breakdown
.ytQnoitpircseD.oNtraPyeK
5710
D
6131D
D 5720
D 5700
D 5724
D 6515
D 4125
D 4122
D 5711
D 5713
D 5714
Hopper
Assembly
Hopper Auger Motor Cover
1/4-20 x 1/2” SS HWH Serrated TCS
Auger Cover Screw Cap
RTG Hopper
3/8-16 x 2-3/4 HHCS
Heavy Duty Vibrator
3/8” Flat Washer
3/8-16 x 1-1/2 HHCS
Vibrator Link Arm
Short Baffle Plate
Long Baffle Plate
1
6
6
1
9
1
15
4
1
1
1
D 5712 Interior Main Baffle Support Frame 1
D 6453 5/16 x 1” Serrated 18-8 SS 4
D 6165 5/16 Flat Washer 3
D 4121 5/16-18 x 1” HHCS 3

L1186 © Trynex International 2007
8 — 16
RTG-2400 Frame Assembly
Parts Breakdown
Optional Universal Mounting Kit Shown In Illustration
As Part Of Frame Assembly.

© Trynex International 2007 L1186 8 — 17
RTG-2400 Frame Assembly
Parts Breakdown
Qty.
.
oNtraPyeK Description
2 ea.
Frame
Assembly
D 5705
D 5736
D 5728/29
D 4122
D 5730/31/32
2400 Frame Weldment
Upper Pin Bracket 1.125 & 1.0 (UMK- 175 Kit)
3/8-16 x 1-1/2 HHCS
Lower Pin 1.25, 1.0, .750 (UMK - 175 Kit)
1
Upper Gussett (UMK -175 Kit) 2
2 ea.
8
1
D 5735
D 5734
Right Hand Main Bracket (UMK - 175 Kit)
Left Hand Main Bracket (UMK - 175 Kit)
1
FRAME SHOWN WITH OPTIONAL UMK MOUNTING KIT

L1186 © Trynex International 2007
8 — 18
Vehicle Harness Wiring Instructions
Step 1: Take harness assembly and route from the rear of the vehicle to the front. Route harness along frame and attach to frame holes
and frame supports. It is not recommended to attach to fuel or brake lines for obvious reasons. Do not route close to exhaust system or
engine, even though Snowex uses high temperature wiring, it still could melt under extreme heat and short the spreader electric al system, as
well as the vehicle electrical system.
Step 2: Mount rear plug above hitch plate using supplied bolts, locate between hinges (important) make sure wiring and plug
are clear of dump body pinch points. Apply a small amount of dielectric grease to contacts.
Step 3: Secure harness from the rear to the front using heavy duty ty-wraps or frame clips along the frame and lighter duty ty-wraps
everywhere else.
Step 4: Drill a 1-1/4 hole in the firewall or use existing access hole (check to make sure you are clear on the other side you intend to drill).
Route connector and harness through hole.
The power harness from control box to battery will need to be routed from
fromthe large high amperage connector. Route leads with lugs to battery —
do not connect power at this time.
Step 5: Connect harness to the back of the controller and mount to a suitable location. NOTE: You may want to contact customer before
mounting controller, some prefer not to have holes drilled into the dashboard. Ty-wrap loose controller harness and move to the
engine
compartment. Do not mount close to any heater vents.
Step 6: Connect power leads to the battery: Red + Positive, Black – Negative, always connect to the primary battery if using a dual ba
ttery
system, secure loose loom to any other large or medium vehicle harness with medium duty ty-wraps this will secure wiring harness.
Step 7:
Push the ON/OFF button on the controller to check for power, when that has been confirmed turn power OFF. The electrical porti
on
of the installation is complete.
the inside of the cab to the battery – this results

© Trynex International 2007 L1186 8 — 19
.
ytQ
.oNtraPyeK
1
RTG-2400 Electrical System
Parts Breakdown
D 6835
D 6837
D 6896
D 5708
Description
Spreader Speed Control
Control Power Harness
Vehicle Harness
Spreader Harness
1
1
1

© Trynex International 2007 L1186
8 — 2
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Information and Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-7
Spreader Assembly and Exploded Views. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8-17
Wiring Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18
Electrical System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19-22
Spreader Mounting System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23-24
Spreader Operating Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25-27
Troubleshooting Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28-30
Spreader Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Determine Vehicle Payload Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
32
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
33-34

L1186 © Trynex International 2007
8 — 20
D6835 Control
Black
Negative (–)
Vibrator
Red Positive (+)
Vibrator
Black Negative (–)
Spinner
Red Positive (+)
Spinner
Black Negative (–)
MAIN INPUT
POWER
OUTPUT
Red
Positive (+)
Auger
Black Negative (–)
Auger
Red Positive (+)
20 Amp
Circuit Breaker
Pre-Wetting System
Output Data Port
20
Connect to control
mating half
Positive
White with Red Tracer (+) to battery
Ring Terminal
Negative
Black (–) to battery
Ring Terminal
* NOTE:
A) Leads must only be attached to battery.
B) 100 Amp breaker must be inserted.
D6837 Control Power Cable with D6840 Breaker
Key Part No. Description Qty.
D 6837 Control Power Cable 1
D 6839 6 GA. Breaker Wire 1
D 6840 100 AMP Resetable Breaker 1

© Trynex International 2007 L1186 8 — 21
D5708 Spreader Power Harness
Circuit Diagram
AUGER
Black Negative (–)
MAIN POWER PLUG
SPREADER
AUGER
Red Positive (+)
SPINNER
Red Positive (+) SPINNER
Black Negative (–)
VIBRATOR
Black Negative (–)
VIBRATOR
Red Positive (+)
Red
Positive (+)
Black
Negative (–)
VIBRATOR
POWER PLUG SPINNER
POWER PLUG
Black
Negative (–)
Red
Positive (+)

L1186 © Trynex International 2007
8 — 22
D6896 Vehicle Harness
Circuit Diagram
VIBRATOR
Yellow Positive (+)
VIBRATOR
Green Negative (–)
SPINNER
Orange Negative (–)
SPINNER
Blue Positive (+)
AUGER
Red Positive (+)
AUGER
Black Negative (–)
Red
Positive (+)
Black
Negative (–)
Anderson
Block
(2) Pos
Anderson
Block
(4) Pos
VIBRATOR OUTPUT
Yellow Positive (+)
VIBRATOR OUTPUT
Green Negative (–)
SPINNER OUTPUT
Blue Positive (+) SPINNER OUTPUT
Orange Negative (–)
BUMPER
PLUG
CONTROL
OUTPUT PLUG
SPINNER/VIBRATOR
CIRCUIT
AUGER
CIRCUIT
OUTPUT
* NOTE: Reference Bumper Plug for Color Code

© Trynex International 2007 L1186 8 — 23
RTG-2400 UMK-175 Mounting System
Required Mounting Instructions
.ytQnoitpircseD.oNtraPyeK
D 4122 3/8”-16 x1-1/2” Hex Bolt 8
D 5735 Right Hand Main Bracket 1
D 5728 Upper Pin Bracket w/1.125 Hole 2
D 5729 Upper Pin Bracket W/1.0 Hole 2
D 5730 Lower Weld On Pin 1.250 Dia 2
D 5731 Lower Weld On Pin 1.0 Dia 2
D 5732 Lower Weld On Pin .750 Dia 2
D 5734 Left Hand Main Bracket 1
D 5736 Upper Gussett 2
Central Lift Point

L1186 © Trynex International 2007
8 — 24
RTG-2400
Mounting Instructions for UMK-175 (optional mtg kit)
Step 1: Use centrally locatedlifting point on spreader frame. Hang spreader in center of dump body opening, (note) spreader
opening must be level with dump floor.
Step 2: Using bolts Provided in kit, mount left and right main angle to spreader frame.
Step 3:
Mark and trim angles to appropriate width to match tailgate, remount angles to spreader frame.
Step 1: Secure long leveling rod D-5741 to spinner enclosure through bottom hole in bracket with hair pin clip through hole
hole in pin (see fig 1)
Step 2:
Mount drive leveling bracket D-5738 to frame rail 4” below center of hinge. Weld or bolt in place (see fig 2)
Step 3: Connect D-5740 short leveling rod to drive leveling bracket with hair pin clip. Align both rods next to each other (see fig2)
and weld togther.
Step 4:
Using correct pin size provided in kit for lower latch pin, measure and cut pin to correct length. Clamping pins in correct location,
tack weld pins to angles securely and lock lower hinge point.
Step 5:
Using correct pin/ears provided for upper hings point, measure and cut to correct length. Clamping ears in correct location,
tack weld securely to the left and right main angles (see page 8-23) and secure upper hinge point.
Step 6: Double check that spreader will remove and install with ease.
Step 7: If using ears for upper hinge point support, upper gussetts must be welded directly behind mounting ears.
(see page 8-23)
Step 8: Complete welding pins and ears to angle fully.
Step 9: Remove angles from spreader for paint and reinstall.
Mounting Instructions for self leveling spinner bracket
fig. 1 fig. 2

© Trynex International 2007 L1186 8 — 25
Operating the Spreader
PREPARATION
CAUTION –
Sweep area clear of foreign objects or obstacles that could cause personal injury. Keep other persons, children, or animals out
of the area to be spread.
SPREADER LOADING
WARNING –
Do not overload vehicle. Use chart below to calculate weight of material. Weights of material are an average for dry materials
.
Material Weight Per Cubic Ft.
Rock Salt 35-40 lbs.
Sand/Salt Mix 95-120 lbs.
•Be sure to comply with manufacturer’s maximum gross vehicle weight ratings.
• Warning– Never leave materials in hopper for long periods of time as salt is hygroscopic and will attract atmospheric moisture and
harden up. When spreading sand mix, a 1:1 ratio for Sand/Salt mix is recommended to prevent the material from freezing.
SPREADING TIPS
•Never exceed 10 m.p.h. when spreading.
•For a wider pass, increase spinner speed.
•For a heavier pass, drive slower, or increase auger speed.
•Never operate spreader near pedestrians.
•Spread ice melters with the storm to prevent unmanageable levels of ice.
•Calculate spread pattern when near vegetation.
7500 CONTROL OPERATION
•The Dual Variable Speed Control has dual finger-tip dials for maximum performance, digital system status with warning protec
tion and
built-in Vibrator Switch.
•To start, press power switch on controller and spreader will accelerate to speed set on spinner and auger dials.
•To stop, press power switch on controller to off position.
•Speed of auger and spinner may be adjusted separately to get desired flow and spread distance
from spreader.
•The Vibrator Switch is needed for dense material or to increase the flow to the auger. This eliminates bridging of material in hopper.

© Trynex International 2007 L1186
8 — 26
Operating the Spreader(continued)
RTG INTERIOR BAFFLE & INVERTED-V INSTRUCTIONS
•The 2400 uses a multi-function baffle syetm over the auger area.
. This twin bafle design is used to reduce load on the auger drive train which controls amperage load to the electrical
system. It must not be removed unless servicing the unit.
•WARNING: Always disconnect power source before attempting to remove material baffle.
•There are to covers provided one long and one short. They can be removed in different combinations depending on the
material type or moisture content. Ultimately they aid in controling material flow to the auger area, however for wet sand
both baffles should remain in place.
. The baffle system is also connected to the vibrator link arm assembly to assist with material flow. Make sure vibrator bolts
and link arm hardware are tight before operating spreader
Short Baffle
Long Baffle
Connect To Link Arm

© Trynex International 2007 L1186 8 — 27
Operating the Spreader(continued)
WARNING PROTECTION
•If audible beeping occurs, read display to identify problem. If display reads “OL” (overload) or “OH” (overheat). Shut contr oller down and
carefully clear jammed auger. If display reads “E1“ this means there is a dead short in system. Do not use until problem is cor rected. If
display reads “E 0” this means that the motor is not getting any power. Check all connections. If display reads “LB” the vehicl
e battery
is extremely low (possibly caused by a poor or corroded connection) and could damage the system.
•If there are any problems while operating the spreader, refer to Troubleshooting Guide.
