Trynex SnowEx Accu Pro SP-100 User manual

800-725-8377
© Trynex International 2007 AP 7 — 1
800-725-8377
© Trynex International 2007 (REV 000) L1260
Owner / Operator’s Manual
Spreaders for Snow & Ice Control
FOR MODEL
SP-100 Accu Pro
This Manual Must Be Read Before Operating The Equipment
CUSTOMER COPY
Warren, Michigan 48089
800-725-8377
Protected by the following patents, #6,089,478, #6,088,865, #Des.425,915
and other pending U.S. and foreign patent applications.

© Trynex International 2007 L1260
AP 7 — 2
Table of Contents
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
REGISTRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6
•PREPARATION
•OPERATIONS
•SERVICE
SPREADER PARTS/DIAGRAMS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 12
•SP-100 SPREADER MAIN ASSEMBLY
•SP-100 INSTALLATION INSTRUCTIONS
•SP-100 DRIVE ASSEMBLY
•SP-100 ELECTRIC GATE ASSEMBLY
13 - 16
WIRING INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
•WIRING DIAGRAM
OPERATING THE SPREADER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 -19
SPREADER MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20
BLANK PAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
WARRANTY CARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
21

© Trynex International 2007 L1260 AP 7 — 3
Introduction
This manual has been designed for your help. It will assist you and instruct you on the proper set-up, installation and use of
this spreader. Refer to the table of contents for an outline of this manual.
We require that you read and understand the contents of this manual completely (especially all safety information) before
attempting any procedure contained herein. Extra copies of Owner/Operator Manuals can be purchased at your Snowex Dealer.
THIS SIGN SHOULD ALERT YOU:
The Society of Automotive Engineers has adopted this SAFETY ALERT SYMBOL to pinpoint characteristics
that, if NOT carefully followed, can create a safety hazard. When you see this symbol in this manual or on the
machine itself, BE ALERT! Your personal safety and the safety of others is involved .
Defined below are the SAFETY ALERT messages and how they will appear in this manual:
(RED)
Information that, if not carefully followed,
can cause death!
(ORANGE)
Information that, if not carefully followed,
can cause serious personal injury or death!
(YELLOW)
Information that, if not carefully followed,
can cause minor injury or damage to equipment.

© Trynex International 2007 L1260
AP 7 — 4
General Information
You have purchased a member of the Snowex family, an advanced concept in multi-purpose spreaders.
Our unique design allows many material spreading applications to be addressed. The modular concept allows multiple hitch
applicationsions using the same spreader attachments to meet different vehicle types and varied spreading requirements.
Your Spreader may be attached to many types of vehicles ranging from pick-up trucks, sport utilities, tractors, utility vehicles, etc.
The simplicity of construction using high quality steel and deluxe electrostatic finish requires minimal maintenance.
Our poly hopper with custom engineered frame structure, state-of-the-art electronic controller coupled with hi-torque drive
assembly will give you ultimate performance and control when spreading.
Snowex reserves the right to make any changes or improve the design of any parts and not be obligated to make changes on units
previously sold.
Registration
Record the following information in this manual for quick reference.
Spreader Model Number _____________________________________________________________________________________
Spreader Serial Number________________________________ Controller Serial Number _______________________________
Date of Purchase___________________________________________________________________________________________
Dealer Where Purchased _____________________________________________________________________________________
When ordering parts, the above information is necessary. This will help to insure
that you receive the correct parts.
At the right is a diagram of the ID tag. This tag on the spreader is located
on the frame.
Please fill out the warranty card with all the necessary information to validate it. This will also give us a record so that
any safety or service information may be communicated to you.
WARREN, MICHIGAN
800-725-8377
SERIAL N O .

© Trynex International 2007 L1260 AP 7 — 5
Before attempting any procedure in this book, these safety instructions must be read and understood by all workers who
have any part in the preparation or use of this equipment.
For your safety warning and information decals have been placed on this product to remind the operator of safety precautions.
If anything happens to mark or destroy the decals, please request new ones from Snowex.
Remember, most accidents are preventable and caused by human error. Exercising of care and
precautions must be observed to prevent the possibility of injury to operator or others!
Never operate equipment when under the influence of alcohol, drugs, or medication that might
alter your judgment and/or reaction time.
.riahdeniartsernudnagnihtolcgnittifesoolllaeruces,redaerpsehthtiwgnikrowerofeB
dluocsihtodoteruliaF.latemtsniagalatemgnikrownehwsdleihsedishtiwsessalgytefasraewsyawlA
result in serious injury to the eyes.
Never allow children to operate or climb on equipment.
Never weld or grind on equipment without having a fire extinguisher available.
Always check areasto be spread to be sure no hazardous conditions or substances are in the area.
Always inspect unit for defects:broken, worn or bent parts, weakened areas on spreader or mount.
Always shut off vehicle and power source before attempting to attach or detach or service spreader
unit. Be sure vehicle/power source is properly braked or chocked.
Always make sure personnel are clear of areas of danger when using equipment.
Always keep hands, feet, and clothing away from power-driven parts.
Remember, it is the owner’s responsibility to communicate information on safe usage and proper
maintenance of all equipment.
Safety

© Trynex International 2007 L1260
AP 7 — 6
Safety Precautions
Never exceed 45 m.p.h. when loaded spreader is attached to vehicle. Braking distances may be reduced
and handling characteristics may be impaired at speeds above 45 m.p.h.
Never use wet materials, or materials with foreign debris in the SP-100.This unit is designed to
handle dry, clean, free-flowing material. Note: Can not spread water softener salt.
Never leave material in hopper for long periods of time. Be aware that all ice melters are hygroscopic
and will attract atmospheric moisture and harden up.
Always inspect pins, and latches whenever attaching or detaching spreader, and before traveling.
Inspect the unit periodically for defects. Parts that are broken, missing, or worn out must be replaced
immediately. The unit, or any part of it should not be altered without prior written permission from the
manufacturer.

© Trynex International 2007 L1260 AP 7 — 7
Accu Pro
Model #SP-100
.ytQnoitpircseD.oNtraPyeK
D 4318 3/8" Fender Washer
14
14
8316D
D 6462 5/16" - 18 x 1-3/4" HHCS
5/16" Lock Nut
12.7 Cu/Ft Seeder Hopper Yellow6753D
1Electric Gate Assembly
Drive Assembly 1
D 6712 Hopper Tube Support 1
4
SEE DRIVE EXPLODED
VIEW
SEE GATE EXPLODED
VIEW
SEE DRIVE EXPLODED
VIEW

© Trynex International 2007 L1260
AP 7 — 8
Assembly Views
Model #SP-100

© Trynex International 2007 L1260 AP 7 — 9
Accu Pro
Complete Drive Assembly
Key Part No. Description Qty.
D 4135 2-5/16" Hair Pin Clip 1
D 4136 5/8" x 5-1/2" Hitch Pin 1
D 6131 1/4"-20 x 1/2" Serr. Flange Bolt 4
D 6746 5/16'' x 1-1/4 Detent Clevis 1
D 6172 #10-32 x 5/8" Serr Flange Bolt 2
D 6140 5/16" - 18 x 3/8" S.S. Set Screw 1
D 6750 10" Plastic Spinner 1
D 6232 Motor Drive Coupler 1
1
5 Agitator046D
D 6106 Motor 12 Volt DC 1
D 6487 #8 x 1/2" Hex Head Sheet Screw 5
D 6715 Transmission 14.5 to 1 1
D 7153 Plastic Bottom Cover 1
D 6480 Transmission Weldment 1
D 6485 Light Duty Receiver Mount 1
D 4116 1/2"-13 x 1-1/2" Hex Bolt 4
D 4120 1/2" Lock Nut 4

© Trynex International 2007 L1260
AP 7 — 10
Accu Pro
Electric Gate Control System

© Trynex International 2007 L1260 AP 7 — 11
Gate Assembly
Model #SP-100
.ytQnoitpircseD.oNtraPyeK
1
D6302 Gate Stop Knob
T-15004 Gate Position Indicator
T-15001 Gate Deck
T-15003 Gate Stop
T-15002 Gate Slide
T-15012 1/4-28 x 2-1/2 SHCS
T-15009 Stainless Spring
T-15007 Stainless Arm #3
T-15006 Stainless Arm #2
T-15005 Stainless Arm #1
T-15008 12 Volt Actuator
T-15020 Actuator Power Cord
D6166 5/16-18 x 1 Hex Bolt
T-15021 1/4-20 x 3/4 PPH MS Stainless
T-15016 1/4-20 Nylock Stainless
1
1
1
1
1
1
1
1
1
1
1
2
5
6
T-15017 5/6 Nylon Flat Washer
T-15018 5/16-18 Nylock Stainless
T-15023 1/4” Nylon Flat Washer
T-15013 1/4-28 x 2-3/4 HHCS Stainless
T-15014 1/4” Flat Washer Stainless
5
5
3
1
1

© Trynex International 2007 L1260
AP 7 — 12
Electric Gate Assembly Views
Model #SP-100

© Trynex International 2007 L1260 AP 7 — 13
SP-100 Electrical System Overview
Key Part No. Description Qty.
T 15020 SOLENOID WHIP 1
T 15034 SPREADER HARNESS 1
T 15028 VEHICLE HARNESS 1
D 6474 CONTROL 1
T 15011 BATTERY HARNESS 1

AP 7 — 14
SP-100 Control Back View
SP-100 Control Front View D 6474
GATE SWITCH
ON/OFF
SPREADER POWER
ON/OFF
SPINNER SPEED
CONTROL
POWER IN
POWER OUT
RED (+) POS
ORG (-) NEG
BLUE (-) NEG
BLK (-) NEG
BLK (-) NEG
RED (+) POS
RED (+) POS
© Trynex International 2007 L1260
TO BATTERY

© Trynex International 2007 L1260 AP 7 — 15
SP-100 Solenoid Power Cord T 15020
SP-100 Spreader Harness T 15034
BLU (+) POS
GRN (-) NEG
BLK (-) NEG
RED (+) POS
BLK RED BLU GRN
(-)
(+)
RED (+) POS
BLK (-) NEG

© Trynex International 2007 L1260
AP 7 — 16
SP-100 Battery Harness T 15011
SP-100 Vehicle Harness T 15028
CONNECT TO BLK (-) NEG
BATTERY HARNESS
CONNECT TO GATE
SWITCH
ORG (+) POS
BLUE (-) NEG
BLK (-) NEG
RED (+) POS
BLK RED ORG BLU
20 AMP
MINI FUSE
RED (+) POS
BLK (-) NEG
CONNECT TO
GATE SWITCH (+)
CONNECT TO
BLUE WIRE (-)
POWER IN (+)
POWER IN (-)

© Trynex International 2007 L1260 AP 7 — 17
Operating the Spreader
PREPARATION
CAUTION –Sweep area clear of foreign objects or obstacles that could cause personal injury. Keep other persons, children, or animals out
of the area to be spread.
SPREADER LOADING
WARNING –Do not overload vehicle. Use chart below to calculate weight of material. Weights of material are an average for dry materials
.
Material Weight Per Cubic Ft.
Rock Salt 35-40 lbs.
•Be sure to comply with manufacturer’s maximum gross vehicle weight ratings.
• Warning– Never leave materials in hopper for long periods of time as salt is hygroscopic and will attract atmospheric moisture and
harden up.
SPREADING TIPS
•Never exceed 10 m.p.h. when spreading.
•For a wider pass, increase spinner speed.
•Never operate spreader near pedestrians.
•Spread ice melters with the storm to prevent unmanageable levels of ice.
•Calculate spread pattern when near vegetation.
SPREADER OPERATION
SP-100 SPREADER
•Comes standard with electronic speed control with electric gate flow control kit.
•To start, select proper gate stop position, desired starting speed and switch control power on.
•To open gate, engage switch to the left of the control on/off switch, to close gate dis-engage switch.
You will need to adjust speed up or down to achieve a proper pattern when using different material types.
•

© Trynex International 2007 L1260
AP 7 — 18
Troubleshooting
Loose electrical connections.
Blown Fuse.
Motor Seized.
Jammed auger.
Poor electrical connections.
Electrical short.
Controller failure.
Empty hopper.
Wet material.
Frozen or coarse material.
Spinner not turning.
Auger loose on shaft.
Whenever service is necessary, your local Snowex Dealer knows your Spreader best. Take your Spreader to your local dealer
for any maintenance or service needs on your unit. If this is not possible, the Troubleshooting Guide below may assist you in
Warning: First read all warning instructions and safety messages before servicing your spreader.
Preliminary Checks
•Be sure all electrical connections are tight and clean.
•Be sure nothing is jammed in the hopper.
Motor doesn’t run.
Controller shut down.
Material not flowing
Gate wont open Frozen/Rusted linkage Lubricate with Moly based product
Solenoid won’t engage Check connections Replace/Repair
Check switch Replace/Repair
Unit burned out Replace
from hopper.
Check all connections.
Replace fuse.
Replace motor.
Carefully clear jammed material.
Clean or replace connectors.
Use dielectric grease.
Check electrical connections.
Check for bare wires.
Replace controller.
Fill hopper.
Replace with dry material.
Replace material.
Check drive assembly.
Tighten locking bolt on the side of the auger. There is a flat
machined on the driver shaft. Align the auger with this flat
and tighten the bolt.
PROBLEM POSSIBILE CAUSE SOLUTION
locating the problem.

© Trynex International 2007 L1260 AP 7 — 19
Troubleshooting
Spreader SP-100
SPREADER
DOESN'T RUN FIX OR REPLACE
AGITATOR
INTERFERENCE
FUSE
BLOWN JAMED AGITATOR
MATERIAL
ISSUE
BAD MOTOR
CHECK WITH TEST KIT
TEST GOOD
NO LOAD
4-20 AMPS
BAD MOTOR/TRANS
ASSEMBLY
TOO MUCH
AMP DRAWN
TEST BAD
20+ AMPS
BAD TRANSMISSION
CHECK WITH TEST KIT
TEST TURN SHAFT
BY HAND SHOULD
TURN FREELY
CORROSION AT
CONNECTION CLEAN OR REPLACE
DON'T FORGET
USE DIELECTRIC
GREASE
DON'T FORGET
USE DIELECTRIC
GREASE
BAD ELECTRICAL
CONNECTION
LOOSE CONNECTION TIGHTEN OR REPLACE
REPLACE WIRING
DEAD SHORT
IN WIRING
BAD MOTOR
CHECK WITH TEST KIT
ELECTRICAL
CONNECTION
TEST DIRECT POWER
(12 VOLTS) TO MOTOR
CHECK
SWITCH
LOOSE OR
UNPLUGGED
CORROSION
CHECK BATTERY LOAD TEST
GATE WON'T OPEN RECONNECT OR
REPLACE CABLE
MATERIAL WILL
NOT FLOW
MATERIAL
ISSUE

© Trynex International 2007 L1260
AP 7 — 20
Spreader Maintenance
•WARNING – When servicing is necessary, perform it in a protected area. Do not use power tools in rain or snow because of danger of
electrical shock or injury. Keep area well lighted. Use proper tools. Keep the area of service clean to help avoid accidents.
•WARNING – Disconnect electricity to spreader before servicing.
•CAUTION – The controller is a solid state electronic unit and is not serviceable. Any attempt to service will void warranty.
•CAUTION – There are no serviceable parts in the motor/transmission assembly. Any attempt to service will void warranty.
•CAUTION – When replacing parts, use only original manufacturer’s parts. Failure to do so will void warranty.
•Use dielectric grease on all electrical connections to prevent corrosion at the beginning and end of the season and each time
power plugs are disconnected.
•Wash unit after each use to prevent material build-up and corrosion.
•CAUTION – When pressure washing motor enclosure area, stay at least 36'' away from motor enclosures.
•Paint or oil all bare metal surfaces at the end of the season.
•If motor cover is removed for any reason, use silicone sealant to ensure weather proofing of enclosure.
•After first use, tighten all nuts and bolts on spreader and mount.
•KEEP GATE LINKAGE LUBRICATED THROUGHOUT USE WITH MOLY BASED LUBRICANTS.
