INSTALLATION AND
OPERATING INSTRUCTIONS
DRAINAGE PUMP – F-13
CHECK VALVE FITTED
LIGHT WEIGHT
ENERGY EFFICIENT
AUTOMATIC OR MANUAL
BUILT-IN THERMAL PROTECTION
WATER-COOLED
TSURUMI (AMERICA), INC., 1625 Fullerton Court, Glendale Heights, IL 60139
[phone] www.TsurumiPump.com FAX: [phone]
DISTRIBUTED BY:
[phone]US 04/03

APPLICATION
Compact submersible drainage pumps from Tsurumi are used where large
quantities of clear, rain or dirty water must be pumped quickly and reliably.
Permanent installations of pumps include basement sumps for water
removal. They are suitable for pumping washing effluent, for the drainage
of buildings and for pumping rainwater out of lower level rooms or
underpasses.
They are used as portable pumps to fill or empty containers of every type,
for use in drainage pits, to maintain dry conditions in ditches and to pump
out flooded cellars.
HANDLING
The pump is easy to transport and should be carried by the carrying
handle. It should never be suspended or raised by means of the power
cable.
INSTALLATION AND OPERATION
The pumps are supplied ready for operation.
WARNING: Pumps must be installed in accordance with governing
national and local electrical codes.
FOR AUTOMATIC OPERATION
Install discharge hose or pipe to pump discharge. Position the pump in the
sump, switch to the automatic position by pushing the switch down. The
float switch will now start the pump when the water level reaches about 6",
pump shuts off at about 2". Be sure to test automatic operation after
installing to make sure the pump is operating properly.
FOR MANUAL OPERATION
Install discharge hose or pipe to pump discharge, place the pump in the
water to be pumped, switch to the manual "HAND" position by pushing the
switch up. Switch the pump off when the water reaches approximately 2",
by pushing the switch down into the automatic position or by unplugging
the power cord.
NOTE: In portable applications, when a sump is pumped down below 1" of
water, the pump requires approximately 30 seconds to purge air from the
discharge when restarting.

MAINTENANCE
The pump has permanently lubricated bearings and an overload protection
device to ensure maximum pump serviceability. Regular inspection and
maintenance are, however, recommended in order to ensure long service life.
Always disconnect pump from electrical source before performing any type of
maintenance. The pump should be cleaned from time to time (depending on
degree of dirt present) and the inlet screen should be cleaned and rinsed in
clean water.
The volute\screen can be removed by turning it clockwise. Then the impeller
area may also be cleaned. (Due care should be taken not to dislodge the
motor).
(Please ensure O-Ring is in correct position when re-fitting
Volute/Screen.)
WARRANTY
Tsurumi (America), Inc. warrants the F-13 pump to be free from defects in
workmanship and material for a period of twelve (12) months from date of sale
to end customer. Pumps used in transportable (i.e. contractor / dewatering)
applications carry a six (6) month warranty from the date of sale to end
customer. This warranty does not cover the pumping of chemically or abrasively
polluted water. Tsurumi (America), Inc. shall not be liable for any special,
indirect or consequential damages of any kind. Defective equipment will be
repaired or replaced. Returns must have prior written authorization from the
company and be shipped prepaid.
NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE WILL APPLY.
WARNING
WARNING: Risk of electrical shock-this pump is
supplied with a grounding conductor and grounding-type
attachment plug. To reduce the risk of electrical shock, be
certain that it is connected only to a properly grounded,
grounding receptacle, motor is thermally protected.
To reduce risk of electrical shock, pull plug before servicing
this pump.
This pump has not been investigated for use in swimming
pool areas.

TECHNICAL DATA
Model F-13
Current Single Phase
HP 1/4
RPM 3450
Voltage 115
Amps See nameplate
Discharge 1¼" /1½"
Height 12" (308 mm)
Width 7.7" (196 mm)
Weight 6.6 lb (3.0 kg)
Cable 20 ft. U.L listed
F-13
