Tuchel Plus P1 Series User manual

Operating Manual
Plus - Sweeping Machine P1

Preface

Preface
Dear Customer,
with the Plus sweeping machine, you have purchased a product that has been manufactured according
to the highest quality standards.
This operating manual contains information and notes that are necessary, important and useful for the
operational safety and reliability of your Plus sweeping machine as well as for maintaining its value.
Its contents familiarise with the use of the machine and its service and maintenance. The manual also
helps you to avoid dangers and damage.
We wish you optimum results with your Plus sweeping machine.
Tuchel Maschinenbau GmbH
State: 05/2002 We reserve the right to incorporate changes resulting
from further technical development.
Preface

Preface

Table of Contents
Table of Contents
1 General................................. I-1
1.1 Purpose .............................................I-1
1.2 Product Specications....................... I-1
1.2.1 General ........................................I-1
1.2.2 Manufacturing Address ................I-1
1.2.3 Type Label....................................I-1
1.2.4 Labelling ......................................I-2
1.2.5 Declaration of conformity .............I-2
1.2.6 Specications for enquiries
and orders....................................I-2
1.2.7 Maximum load specications.......I-2
1.2.8 Connections.................................I-3
1.2.9 Energy consumption ....................I-3
1.2.10 Intended usage ............................I-3
1.2.11 Technical data sheet ....................I-4
2 Safety ................................... II-1
2.1 Labelling of notices in the operating
manual...............................................II-1
2.2 Qualication and training of
personnel...........................................II-1
2.3 Dangers in the case of nonobservance
of the safety notices........................... II-1
2.4 Safety-oriented working..................... II-2
2.5 Safety notes for the operator/user ..... II-2
2.6 Safety notices for carrying out service,
inspection and installation work.........II-3
2.7 Unauthorised conversion and
spare parts manufacturing.................II-3
2.8 Modes of operation that are
not permitted .....................................II-3
2.9 Warning images on the machine
according to ISO 11684.....................II-3
3 Plus Sweeping Machine ..... III-1
3.1 Description of the product and
accessories........................................ III-1
3.2 Storage .............................................. III-2
3.3 Attachment ........................................III-4
3.3.1 Fork arm receptacle.....................III-5
3.3.2 Receptacle on local government
vehicle..........................................III-6
3.3.3 Quick change receptacle
yard loader..................................III-7
3.3.4 Rear attachment to 3-point linkage
(or front attachment) ....................III-8
3.3.5 Front attachment with coupling
triangle .........................................III-10
3.4 Operation........................................... III-11
3.4.1 Transport trips ..............................III-11
3.4.1.1 Transport trip Local
government vehicle.......... III-12
3.4.1.2 Transport trips: quick
change receptacle for
yard loaders .....................III-12
3.4.1.3 Transport trips: front
attachment with coupling
triangle ............................. III-13
3.4.2 Start-up ........................................III-14
3.4.3 Adjusting/readjusting the
side broom ...................................III-16
3.4.4 Rpm adjustment...........................III-17
3.4.5 Emptying the dirt
collection vessel..........................III-18
3.4.5.1 Mechanically ....................III-18
3.4.5.2 Hydraulic..........................III-18
3.4.6 Conversion to the open sweeping
Plus-sweeping machine ............... III-19
3.4.6.1 Conversion with
mechanical emptying .......III-20
3.4.6.2 Conversion with
hydraulic emptying ...........III-21

Table of Contents
3.4.7 Side adjustment for open
sweeping usage ........................... III-22
3.4.7.1 Mechanic operation .........III-22
3.4.7.2 Hydraulic operation..........III-22
3.4.8 Overload protection......................III-23
3.4.9 Readjustment of the sweeping prole
III-23
3.5 Detachment ........III-24
3.5.1 Detachment in the case of a
fork arm receptacle ......................III-24
3.5.2 Detachment for local
government vehicles ....................III-25
3.5.3 Detachment for the quick change
receptacle on the yard loader ......III-26
3.5.4 Detachment for 3-point linkages ..III-27
3.5.5 Detachment in the case of a
coupling triangle...........................III-28
Table of Contents
4 Service and maintenance ... VI-1
4.1 General..............................................VI-1
4.2 Replacing brush rings........................ VI-2
4.2.1 Replacing brush rings,
external motor .............................. VI-2
4.2.2 Replacing brush rings,
internal motor..............................VI-4
4.3 Replacing the plate broom................. VI-6
4.4 Replacement of the Vulkollan rail.......VI-6
4.5 Water spraying device .......................VI-7
4.6 Lubrication plan .................................VI-8
4.7 Malfunctions; causes and
rectication ........................................VI-9
4.8 Hydraulic circuit diagrams .................VI-10

General
I-1
1 General
1.1 Purpose
The Plus sweeping machine of the HD series is
intended for installation on a 3-point linkage, series
HG for
installation with fork arms, series HK for installation
on a coupling triangle, series HH for the installation
on yard loaders, and series HU for the installation
on local government vehicles. Because of its
robust construction and the various operating
widths, this sweeping machine is suitable for the
use on streets and squares of any size.
The attachment of the Plus sweeping machine
takes place via the mechanically or hydraulically
operated quick change receptacle of the carrier
vehicle in question, the drive-in of a pallet fork into
fork arm pockets, or via a coupling triangle or via
attachment to a 3-point linkage.
Through the simple removal of the large-volume
dirt collection vessel, the Plus sweeping machine
may also be used as an open sweeping machine
to sweep large sealed surfaces.
Various optional equipment permits the Plus
sweeping machine to be adapted to different work
environments. This optional equipment includes,
e.g., the hydraulic emptying of the collection
vessel, the water spraying device to bind dust, a
side broom to sweep close to edges, a hydraulic
side adjustment to ease the work, or reinforced
castors, etc.
1.2 Product Specications
1.2.1 General
This operating manual applies to the Plus
sweeping machine series P1 HD 560, P1 HG 560,
P1 HK 560, P1 HH 560 and P1 HU 560.
1.2.2 Manufacturing Address
Tuchel Maschinenbau GmbH
Holsterfeld 15
D-48499 Salzbergen
Telephone +49 5971 9675 - 0
Fax +49 5971 9675 - 30
E-mail inf[email protected]
1.2.3 Type Label
P1 200 HH 560
Brush diameter in mm
Attachment options
H = yard loader receptacle
G = fork arm receptacle
U = attachment plate for
front appliances to local
government vehicles
K = coupling triangle
category I/II according to
ISO 730 - 1
D = 3-point category I/II
according to ISO 730
Type of drive
H = hydraulic
Operating width in cm
Front sweeping machine Type Plus

General
I-2
General
I-3
1.2.4 Labelling
The labelling takes place via the type label.
Model
Serial no.
Year of construction/
order no.
Maximum oil
pressure [bar]
Maximum oil
ow [l/min]
Net weight [kg]
The entire labelling (type label,
safety label, etc.) constitutes a
certicate and must not be altered
or made illegible. It must be
replaced if it is damaged or missing.
1.2.5 Declaration of conformity
The compliance of this attachable sweeper with
the “basic safety and health requirements” of the
machine directive 98/37 EWG entitles it to bear the
CE label.
During the development of the attachable sweeper,
the harmonised European standards DIN EN 292
1+2, DIN EN 982 and DIN pr EN 1553 were also
applied. This is documented in the EU declaration
of conformity.
1.2.6 Specications for enquiries and
orders
When ordering spare parts or accessories, please
specify the type label, serial number and the year
of construction of the Plus sweeping machine.
The use of accessories or spare
parts of other manufacturers is
only allowed after consultation with
the manufacturer.
Original accessories / original spare
parts and accessories authorised by
the manufacturer provide safety.
The use of other accessories /
spare parts invalidates the liability
for the consequences thereof.
1.2.7 Maximum load specications
Maximum operating
pressure at continuous load: 175 bar
N O T E
N O T E
N O T E

General
I-2
General
I-3
1.2.8 Connections
Design of the Plus sweeping machine with:
- hydraulic operation
=> one single-acting control circuit
Design of the Plus sweeping machine with:
- hydraulic operation
- side broom
=> one single-acting control circuit
Design of the Plus sweeping machine with:
- hydraulic operation
- hydraulic emptying of the collection vessel
=> one double-acting control circuit
Design of the Plus sweeping machine with:
- hydraulic operation
- side broom
- hydraulic emptying of the collection vessel
=> one double-acting control circuit
Design of the Plus sweeping machine with:
- hydraulic operation
- hydraulic emptying of the collection vessel
- hydraulic side adjustment
=> two double-acting control circuits
Design of the Plus sweeping machine with:
- hydraulic operation
- hydraulic emptying of the collection vessel
- hydraulic side adjustment
- side broom
=> two double-acting control circuits
1.2.9 Energy consumption
Type of drive: hydraulic
Oil quantity required: 25 - 60 l/min
Oil pressure required: 160 bar
Type of oil: hydraulic oil according to
ISO VG 46 DIN 51524
(e.g., Vitam GF 46,
manufactured by Aral)
1.2.10 Intended usage
The Plus sweeping machine P1 is a machine that
is set in motion via a hydraulic circuit and through
the attachment to a carrier vehicle. It is used to
sweep sealed surfaces with average soiling.
If the machine is used for a purpose different from
the one above, we, as the manufacturer, do not
take any responsibility for the safety; the risk in this
respect rests entirely with the user.
The intended usage includes the adherence to our
requirements regarding, operation, service and
maintenance.

General
I-4
1.2.11
Technical data sheet
The weights are approximate values only, since the machine’s equipment and
the receptacle type are not included.
ATTENTION: Use the weights to check compliance with the maximum allowed axle load
of the carrier vehicle!
We reserve the right to incorporate changes resulting from further technical development.
Plus sweeping machine P1 120 135 150 165 180 200 230 260 290
Maximum oil pressure at continuous load bar 175
Maximum oil ow at continuous load l/min 60
Revolutions main sweeping drum rpm
U/min
80-150
Operating width mm 1200 1350 1500 1650 1800 2000 2300 2600 2900
Operating width if positioned at an angle mm 1125 1265 1405 1545 1685 1870 2155 2435 2715
Diameter of sweeping drum mm 560
Diameter of side broom mm 600
Total width in case of external engine mm 1520 1670 1820 1970 2120 2320 2570 2820 3220
Total width in case of internal engine mm 1395 1545 1695 1845 1995 2195 2445 2695 3095
Total height excluding water spraying device
mm 790 (with 3-point linkage 1300)
Total height including water spraying device mm 1205
Volume of dirt collection vessel L 145 162 180 200 215 238 267 296 342
Volume of dirt collection vessel kg 218 243 270 300 323 357 400 444 513
Weight / centre of mass:
S1 sweeping machine open sweeping kg 170 178 186 193 203 215 221 244 264
S2 sweeping machine +
lled collector vessel kg 454 491 530 570 608 659 715 789 890
S3 sweeping machine +
water spraying device 200l kg 370 378 386 393 403 415 421 444 464
S4 sweeping machine + lled collector
vessel + water spraying device 200l kg 654 691 730 770 808 859 915 989 1090
(S4) 925
(S2) 1085
(S1) 695
(S3) 595 (S3) 420
(S1) 520
(S4) 750
(S2) 910

Safety
II-1
2 Safety
This operating manual contains fundamental
instructions that must be followed during the
attachment, operation and maintenance. Thus,
the personnel must read this operating manual
under all circumstances before operation and
commissioning. The personnel must always have
access to the manual.
Safety notices that must be followed include not
only the general safety notices in this section on
safety, but also the specic safety notices that are
included in other sections.
2.1 Labelling of notices in the
operating manual
The safety notices in this operating manual whose
nonobservance may be hazardous for persons are
highlighted with a general danger symbol
Safety sign according to DIN ISO 9244
when warning about injuries resulting from
squashing.
when warning about injuries resulting from cuts.
Safety notices whose nonobservance may be
hazardous for the machine and its functions, have
the word
attached.
Notes are labelled as follows:
Notes that are directly attached to the machine
must denitely be adhered to and must be kept in
a fully legible state.
2.2 Qualication and training of
personnel
The Plus sweeping machine must only be used,
serviced and maintained by persons that are
familiar with the machine and are informed about
its dangers. The area of responsibility, competence
and the supervision of the personnel must be
directed in detail by the operator. If the personnel
does not have the necessary knowledge, it must
be trained and instructed. Furthermore, the
operator must ensure that the personnel fully
understands the contents of the operating manual.
Maintenance work that is not described in this
operating manual must only be conducted by
authorised qualied workshops.
2.3 Dangers in the case of
nonobservance of the safety
notices
The nonobservance of the safety notes may cause
hazards for both persons and the environment as
well as the machine. The nonobservance of the
safety notices may result in the loss of any claims
for damage whatsoever.
In detail, nonobservance may, for example, lead
to the following hazards:
– hazards to persons due to non-secured work
areas
– failure of important machine functions
– failure of prescribed methods for service and
maintenance
– hazards to persons due to mechanical and
chemical inuences
– hazards to the environment due to leakage of
hydraulic oil
ATTENTION
N O T E

Safety
II-2
Safety
II-3
2.4 Safety-oriented working
The safety notes listed in this operating manual,
current national accident avoidance regulations
as well as company-internal regulations governing
work, operation, and safety that may apply must be
followed.
The accident insurance regulations governing
safety at work and accident avoidance are binding.
The safety notices of the vehicle manufacturer
must be followed.
When operating on public roads, the appropriate
legal regulations (in the Federal Republic of
Germany the StVZO and StVO) must be complied
with. Furthermore, the permitted axle loads of the
respective vehicle manufacturer must be adhered
to.
2.5 Safety notes for the operator/user
– Before starting work, familiarise yourself with
all equipment, operating elements and their
functions. During operation, it is too late for this.
– The clothing of the operators shall t tightly.
Avoid loosely tting clothes.
– Depending on the attachment type, the
attachment receptacle and its interlocking
mechanisms must be checked for tight t
and possible damage prior to start-up. The
positioning of the hydraulic hoses must also be
checked, as damages occur easily if hydraulic
hoses get entangled or squashed.
– During attachment and detachment, the
supports must be put into their respective
position.
– Observe permitted axle load, gross weight, and
transport dimensions.
– Check and attach transport equipment - such
as, e.g., illumination, warning equipment and
possible protective equipment.
– If lighting that is part of the standard carrier
vehicle is obscured in the transport position,
additional illumination devices must be
attached.
– Check the immediate area before starting to
drive and before start-up (children). Ensure that
there is sufcient visibility.
– No passengers may be carried on the machine
during operation and transport.
– For the transport, the hydraulic equipment
for operating and lowering the Plus sweeping
machine must be secured against accidental
operation.
– Never leave the driving seat during driving.
– The driving speed must be adapted to suit the
respective road and trafc conditions. Avoid
sudden turns during uphill and downhill driving
and when driving parallel to a slope.
– Pay attention to the inuence of the attached
Plus sweeping machine on driving behaviour
and steering and braking ability.
– Start the Plus sweeping machine only if all
safety equipment is attached and in protection
position.
– No person may be present in the area of
operation.
– The swivel mechanism must only be operated if
no persons are present in the area of rotation.
– Squashing and shear points are present on
hydraulically operated parts.
– Before leaving the carrier vehicle, lower the
Plus sweeping machine to the ground, pull
the ignition key and secure the carrier vehicle
against unintended start-up and rolling away!
– After switching off the device there is danger
due to the continued movement of the
centrifugal mass. Do not approach the machine
during this time period. Wait until it has come to
a complete standstill.
– Hydraulic system may be under pressure.
– Liquids (hydraulic oil) escaping under high
pressure may penetrate the skin and can cause
severe injuries. In case of injuries, see a doctor
immediately. Danger of infection!
– Connect the hydraulic hoses only in the
pressure-free state of the vehicle hydraulics.
– Hydraulic hoses must be replaced no later then
after 6 years of usage (including storage time of
at most 2 years).
– Regularly check the hydraulic hoses and
replace them in case of damage and ageing.
The replacement hoses must comply with the
technical requirements of the manufacturer.

Safety
II-2
Safety
II-3
– Leakages represent a danger to the
environment and must be removed immediately.
– When searching for leaks, use suitable
equipment to avoid injuries.
2.6 Safety notices for carrying
out service, inspection and
installation work
The operator must ensure that all service,
inspection and assembly work is carried out
by authorised and qualied personnel that has
sufciently informed itself through detailed study of
the operating manual.
Work on the machine must in principle only be
carried out during standstill. The machine’s halting
procedure described in the operating manual must
be observed under all circumstances.
When carrying out maintenance on the lifted
device, always secure it with suitable supports.
Use suitable tools and gloves when exchanging
the sweeping drum and sweeping rail.
Lawfully dispose of oils and grease.
Directly after nishing work, all safety and
protection equipment must be reattached or made
functional.
Before restarting, the points listed in the sections
on start-up must be adhered to.
2.7 Unauthorised conversion and
spare parts manufacturing
Conversion of or changes at the machine are only
permitted after consultation with the manufacturer.
Original spare parts and accessories authorised by
the manufacturer provide safety. The use of other
parts invalidates the liability for the consequences
thereof.
2.8 Modes of operation that are not
permitted
The operational safety of the machine supplied is
only warranted if used as intended according to
Chapter 1 - General – of the operating manual.
The limits specied in the data sheets must not be
exceeded under any circumstances.
2.9 Warning images on the machine
according to ISO 11684
Read the operating manual and adhere to the
safety notices before start-up.
Never reach into the squashing hazard area as
long parts may move there.
Part no. 00.KC.00100
Part no. 00.KC.00101

Safety
II-4
Do not touch any moving machine parts. Wait until
they have come to a complete standstill.
When lowering the Plus sweeping machine, keep
sufcient distance.
Do not stand in the rotation area during operation.
Danger of parts inging away while engine is
running - keep a safe distance.
Close the collector vessel before lowering the
sweeping machine.
The notice signs attached to the
machine must be kept in a clearly
legible state. Replace notice signs
that are no longer legible.
When ordering new notice signs,
specify the article number listed.
Part no. 00.KC.00103
Part no. 00.KC.00107Part no. 00.KC.00102
Part no. 00.KC.00104
Part no. 00.KC.00105
N O T E
N O T E

Plus Sweeping Machine
III-1
3 Plus Sweeping Machine
3.1 Description of the product and
accessories
The sweeping machine is designed for both pickup
and open sweeping usage. By unmounting the dirt
collection vessel, the machine is converted to the
open sweeping mode.
The frame is made of a robust and torsion-free
welded construction.
The sweeping drum is suspended freely in the
frame using a lever system. The brush adjustment
is carried out via a raster rail. Through the lever
action, the sweeping drum may be adjusted via the
raster level when necessary, which thus ensures a
continuously satisfactory sweeping result.
An external, high-powered hydraulic motor,
equipped with a collision protector, or optionally
an internal, high-powered hydraulic motor, fully
protected by the integration into the drum shaft,
directly drives the sweeping drum. The revolution
speed of the sweeping drum depends on the oil
ow and on the equipment of the carrier vehicle.
The sweeping drum is tted with Beeline plastic
brush rings as series equipment. The brush rings
are 560 mm in diameter.
The opening and closing of the dirt collection
vessel is accomplished via a bowden control or by
operating a hydraulic cylinder. This is controlled
from the carrier vehicle. An abrasion-proof
Vulkollan rail is connected to the lower edge of
the dirt collection vessel across the entire length
in order to lead the collection vessel’s lower edge
evenly and without damage along the ground.
The Plus sweeping machine is equipped with
a direct attachment option that matches the
carrier vehicle. The respective attachment type
is connected to the machine frame via a swivel
construction.
The pendulum compensation ensures a level-
compensating usage, even on uneven ground.
With the mechanical or hydraulic side adjustment,
the sweeping machine may be rotated by 20.5° to
the right or to the left.
Accessories
• dirt collection vessel with Vulkollan rail and
mechanical emptying.
• high-level lling ap for the extension of the
lling volume of the dirt collection vessel.
• hydraulic collection vessel emptying
• 3rd support wheel for even ground guidance
• water spraying device to bind dust, optionally
100 l or 200 l water tank, with a 12 V (24 V) dry-
running pump.
• hydraulic side broom
sweeping close to edges with rpm regulation
and adjustment via raster disks to achieve a
large number of working positions.
• protected hydraulic motor, positioned inside the
drum shaft.
• hydraulic side adjustment: inclination of the
sweeping machine using a hydraulic cylinder.
This requires a double-acting control valve on
the carrier vehicle.
• more durable castors in various designs.
• StVZO equipment, consisting of contour
illumination equipment which according to
StVZO is required and must be used when
driving on public roads.

Plus Sweeping Machine
III-2
Plus Sweeping Machine
III-3
3.2 Storage
Park sweeping machine on a rm and
level surface in a dry and clean place.
Accident hazard!
Ensure a secure standing of the sweeping
machine.
• for the open sweeping Plus sweeping machine,
move the supports downwards and secure
them.
• support wheels must point towards the back.
• relieve the ground pressure of the sweeping
drum (6), pull the handles of the raster lever (7)
to the outside.
Take the sweeping drum’s own weight into
account
• Let them latch into the uppermost position (8)
of the adjustment raster. (do this evenly on both
sides).
7
6
8

Plus Sweeping Machine
III-2
Plus Sweeping Machine
III-3
• in the case of a Plus sweeping machine with a
side broom, close the tap of the side broom.
• tilt the side broom upwards and unplug it. (see
Chapter 3.4.1)
• empty the water tank. Loosen the drainage bolt
(9) (bottom side of the tank).
• if there is danger of frosts, activate the pump of
the water spraying device for 10-15 sec. until no
more residual water remains in the hoses.
Accident hazard!
Hydraulic hoses, electric connection cable
and the bowden control are a tripping
hazard on the ground.
Put the hydraulic hoses and the electric
connection cable across the sweeping
machine.
Close the hydraulic connector
with the dust cap. Soiling leads to
damage on the hydraulic system.
If necessary, clean the sweeping machine
thoroughly. Dirt attracts humidity and leads to the
formation of rust.
• lubricate the sweeping machine.
• if necessary, repair paint damage.
9
ATTENTION

Plus Sweeping Machine
III-4
Plus Sweeping Machine
III-5
3.3 Attachment
The Plus sweeping machine must be
attached to or coupled to the intended
carrier vehicle using the supplied
attachment device
The attachment device itself must not be
changed or modied.
The permitted support loads, axle relief,
axle loads, gross weight and transport
dimensions must be taken from the
manufacturer’s information about the
carrier vehicle and must be checked
before start-up.
If a ballast weight is required, attach it as
prescribed to the intended attachment
points of the carrier vehicle before
attaching the sweeping machine.
During attachment or coupling, special
caution must be exercised.
Carry out maintenance, repair work
and modications on the Plus sweeping
machine only if the hydraulic drive is
switched off and the hydraulic connections
are decoupled. Secure the carrier vehicle
against unintended start-up and rolling
away!
During the attachment, follow the
operating manual of the carrier
vehicle’s manufacturer!
Only one example is described
and shown here for each case.
Verify the correct attachment and its
safeguards.
The positioning of the electric
connection and the hydraulic hoses
must be checked, as damage
occurs easily if they get entangled
or squashed.
Initial attachment
During the initial attachment of
the sweeping machine with water
spraying device or illumination
devices, the switchbox must be
mounted at a suitable position in the
carrier vehicle.
• Connect cable (3) to the battery (-).
• Connect cable (4) to the parking light terminal.
• Socket (5) for the electric connection of the Plus
sweeping machine.
• (1) fuse.
• (2) Off -On switch.
5
1
2
3
4
ATTENTION
N O T E
N O T E
N O T E

Plus Sweeping Machine
III-4
Plus Sweeping Machine
III-5
3.3.1 Fork arm receptacle
The safety notices of Chapter 3.3 apply
Check fork arm receptacle and
fork arms for soiling and clean if
necessary.
The distance between the fork arms
must be adjusted on the carrier
vehicle before they are driven into
the receptacles!
• On both sides of the fork arm receptacle, pull
the knob (1) towards the protection bracket (2)
and tilt it upwards until it snaps into the groove
(3). The locking bracket (4) now points towards
the ground.
• Drive the fork arms fully into the receptacle.
• Move the locking brackets (4) back into a
horizontal position.
• Adjust the distance (A) to the width of the fork
arms.
• Unscrew the screw (5) on both sides. Shift the
locking brackets (4) to the appropriate width.
Reinsert the screw through one of the holes (6)
from the underside and tighten it.
• In addition, the fork arm receptacle must be
secured with a chain (9).
• The chain must be pulled tightly through the
loop (7) and the slide carriage (8) of the carrier
vehicle and must be secured with the spring
hook (10).
The chain (9) must not touch the
guide rails of the lifting gear.
Check for the correct locking of the
locking bracket behind the fork arms.
Ensure a tight t of the chain (9).
• Connect the hydraulic lines according to the
instructions of the vehicle manufacturer.
• Connect the electric connection cable for the
water spraying device or illumination devices to
the cabinet in the carrier vehicle.
• Lift the sweeping machine and carry out a
functionality check.
10
N O T E
ATTENTION
ATTENTION
ATTENTION
7

Plus Sweeping Machine
III-6
Plus Sweeping Machine
III-7
3.3.2 Receptacle on local
government vehicle
The safety notices of Chapter 3.3 apply
Check the receptacle for soiling.
Clean if necessary.
• Drive the carrier vehicle towards the sweeping
machine until a distance of 300 mm remains.
• Compare the interface height of the carrier
vehicle’s receptacle with the receptacle of the
Plus sweeping machine.
• To shift the receptacle, unscrew the screws (1)
on both sides, move it along the perforated rail
(2) and re-secure it with the screws and new
locking nuts.
• Insert the receptacle of the carrier vehicle into
the receptacle of the sweeping machine and
lock it as described in the operating manual of
the carrier vehicle.
Verify the correct seating of the
receptacle and its lock.
• Remove the positioning bolt (3) by pulling the
linchpin (5), insert it into the intended hole (4)
and secure with linchpin (5).
• Connect the hydraulic lines according to the
instructions of the vehicle manufacturer.
• Connect the electric connection cable for the
water spraying device or illumination devices to
the cabinet in the carrier vehicle.
• Lift the sweeping machine and carry out a
functionality check.
ATTENTION
ATTENTION
This manual suits for next models
5
Table of contents
Other Tuchel Blower manuals
