Turo Light TL-EMRM24 User manual

INSTALLATION INSTRUCTIONS
FOR EMERGENCY LIGHTING
Package Contents
Part
Description
Quantity
1
Emergency Lighting
1
2
Hardware Kit
1
Warnings and Cautions
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. Review the diagrams thoroughly before beginning.
2. All electrical connections must be in accordance with local codes, ordinances and the National Electric code.
3. Disconnect power at fuse or circuit breaker before installing or servicing.
4. Do not use outdoors.
5. Do not mount in hazardous locations, or near gas or electric heaters.
6. Do not let power cords touch hot surface.
7. Equipment should be mounted in locations and at heights where it will not be subjected to tampering by
unauthorized personnel.
8. The use of accessory equipment not recommend by the manufacturer may cause an unsafe condition.
9. Do not use this equipment for other than intended use.
10. All servicing should be performed by qualified personnel only.
11. Allow battery to charge for 24 hours before first use.
SAVE THESE INSTRUCTIONS
Page 1

Mounting Instructions
NOTE: First turn off electricity.
Wall mounting
Page 2
Black
120VAC
INPUT
White
Neutral
Orange
347VAC
INPUT
5. Connect the battery to connector on the PCBA.
6. Snap fixture onto mounting plate and ensure no
wires are pinched. Make sure unit is fully attached.
Ceiling Mounting
1. Open top cover and knockout on the top of
fixture.
Secure the mounting plate to tube with nut.
3. Reference step 4 –7 in wall mounting above for
ceiling mounting.
1.Remove mounting plate from fixture.
2.Knockout in back of mounting plate and push
wires through the hole.
3.Securely attach mounting plate to J-box.
Max. mounting height is 7.33ft.
Make the proper supply wire connections.
If using 120VAC, connect the black and White
wires to the building utility.
If using 347VAC, connect the Orange and
White wires to the building utility.
4.ELECTRICAL CONNECTIONS
2. Secure the mounting plate to tube with nut.
Secure the mounting plate to tube with nut.
7. Restore power and press test button. Battery
powered LED will come on, AC light will turn off.
CAUTION:
Plug can be applied to 120V only;
347V Wiring only.
