Heat TorchTM 150 Quick Guide
www.farnam-custom.com
Heat TorchTM 150 Quick Guide
Product Descripon
Tutco-Farnam’s Heat TorchTM inline air heaters are ideal for
rapidly heang air. Industrial strength open coil heaters provide
ecient heat transfer through direct heang element contact
with the airow
Operaon
To operate this heater, ensure air is owing and ener-
gize the main supply disconnect. Set the controlling
device to the desired temperature.
During inial heang, it is recommended to slowly
ramp up the process set point and inspect the heang
system for problems.
DO NOT operate the heater at voltages higher than the
recommended use.
DO NOT operate the heater at ow rates below the
minimum ow range (4.8 SCFM)—reduced ow can
shorten heater life.
Supply clean, dry air to the heater at a max of 120 psi.
CAUTION
Tutco-Farnam Custom Products recommends
installaon be performed by qualied personnel
familiar with the Naonal Electrical Code and all
local codes and standards. It is the responsibility
of the installer to verify the safety and suitability
of the installaon.
Failure to follow Tutco-Farnam’s recommenda-
ons could result in premature failure, serious
equipment damage, injury or death.
WARNING
DO NOT mount heaters in an atmosphere containing combusble gases,
vapors, dusts or bers.
Hazardous voltages are present in this equipment. Lock out and tag the
branch circuit disconnect switch before working on this heater.
Exterior of heater at exhaust is approximately the air temperature. Treat the
exterior of the heater as a burn hazard.
Typical causes for uneven airow are structural components blocking air or
mounng the heater too close to elbows, transions or the fan/blower.
REV 02/29/16
Electrical Informaon
Tutco-Farnam Custom Products strongly recommends the use
of an electrical interlock with the air source—this helps ensure
that the heater will not run without air.
Where thermocouple extension wire is required between the
heater and control panel, verify that it is connected with proper
polarity. Failure to do so may result in an uncontrolled heater.
For Standard type K thermocouple: Yellow + and Red -
The heater must be grounded.
Wiring your Heat Torch 150
Wire your HT150 according to the images
below.
3 PHASE CONFIG.
Ground
L1
L2
L3
1 PHASE CONFIG.
Ground
L1
L2

Heat TorchTM 150 Quick Guide
www.farnam-custom.com
REV 02/29/16
Dimensions
Please visit www.farnam-custom.com for detailed drawings
Troubleshoong your HT150
CAUTION: Troubleshoong and repairs should only be aempted by
qualied maintenance personnel
Maintaining your HT150
If reduced heat output is suspected…
1. Disconnect power to the heater.
2. When the heater is fully cooled, check the resistance across
each power lead and ground—if there is a low resistance
measured it indicates that the coil has shorted to ground.
Cease operaon and replace the heater.
3. Check the resistance across each pair of power leads—If
there is a very high/innite resistance it indicates the
heang element has a break in it. Cease operaon and
replace the heater.
4. Contact Farnam Custom Products to replace the heater.
Periodically check all electrical connecons, including
eld and factory-made connecons for ghtness and all
wiring for deterioraon.
Inspect periodically for moisture buildup, airway obstruc-
ons and corrosion.
DO NOT connue using a heater if there are signs of
damage. Consult Farnam Custom Products.
