Tuthill PD Plus 9000 Series User manual

Tuthill
Rotary Positive Displacement Blower
PD Plus
Models
9016
9020
9027
Horizontal Air Flow
Vertical Air Flow
Horizontal Flow, Single Envelope
Gastight Vertical Flow, Single
Envelope Gastight Horizontal Flow,
Double Envelope Gastight Vertical
Flow, Double Envelope Gastight
OPERATOR’S MANUAL
WARNING: Do Not Operate Before Reading Manual
Operator’s Manual: Tuthill PD Plus Rotary Positive Displacement Blower
Manual 2008 Rev A p/n 2008
Copyright © 2020 Tuthill Springeld
All rights reserved. Product information and specications subject to change.
Tuthill Springeld | tuthillvacuumblower.com | 800.825.6937

Disclaimer Statement:
All information, illustrations and specications in this manual are based on the latest infor-
mation available at the time of publishing. The illustrations used in this manual are intended
as representative reference views only. Products are under a continuous improvement policy.
Thus, information, illustrations and/or specications to explain and or exemplify a product,
service or maintenance improvement may be changed at any time without notice.
Rights Reserved Statement:
No part of this publication may be reproduced or used in any form by any means - graphic,
electronic or mechanical, including photocopying, recording, taping or information storage
and retrieval systems - without the written permission of Tuthill Springeld.
Copyright © 2020 Tuthill Springeld
All rights reserved. Product information and specications subject to change.
The employees of Tuthill Springeld thank you for your purchase!
Tuthill Springeld proudly manufactures Kinney®vacuum
pumps and M-D PneumaticsTM blowers and vacuum boost-
ers in Springeld, Missouri, USA. We bring 100+ years of
engineering experience and solid, hands-on care to help
customers keep their processes running. Your satisfaction
is important to us so please take time to provide your Tut-
hill sales representative with performance feedback. We
love to hear from our customers!
Tuthill is a family owned business that was started by
James B. Tuthill in 1892. At that time, Tuthill manufac-
tured common brick to Chicago construction companies
who were fueling the city’s rapid expansion. Fast forward
to today and Tuthill now serves sustaining, global markets
like agriculture, chemical, construction, energy, food and
beverage, pharmaceuticals and medical, transportation,
and utilities. While the company has changed in what it
manufactures, one thing remains throughout every Tuthill
line of business – we are a company with HEART. Our
slogan is “Pump Your Heart Into It” and everyday our
employees do just that as they represent the Tuthill brand
and dare to make better.
Thank you for making Tuthill Springeld part of your com-
pany’s process! FIND OUT MORE AT
TUTHILL.COM
A company with heart
right from the start.

i
Manual 2008 Rev A p/n 2008
Table of Contents
Introduction .................................................................................. 1
Applicable Documentation ................................................................... 1
Scope of Manual................................................................................... 1
Conventions and Data Plate ....................................................... 2
Graphic Conventions in this Manual ..................................................... 2
Data Plate.............................................................................................. 3
Lifting ............................................................................................ 5
Description ................................................................................... 6
Flow by Direction................................................................................... 7
Specifications........................................................................................ 8
General ............................................................................................... 10
Location.................................................................................... 12
Foundation................................................................................ 12
Blower Air Intake ...................................................................... 12
Soft Foot ................................................................................... 13
Safety .................................................................................................. 13
Lubrication .......................................................................................... 14
Filling Procedure ...................................................................... 15
Recommended Oil Change Intervals....................................... 16

ii
Table of Contents
Manual 2008 Rev A p/n 2008
Frequently Asked Questions Regarding Lubrication ............... 17
Hazards Associated With Breakdown or Ignition of
Lubrication ............................................................................... 17
Lubrication – Integral Pressure (19, 86, 55, 82, 66, 69 Series)........... 17
Oil Filter .................................................................................... 17
Oil Pressure Adjustment........................................................... 18
Oil Cooler ................................................................................. 18
Piping Connections............................................................................. 18
Hazards Associated With Hazardous Process Fluids.............. 19
Blockage or Restriction ............................................................ 19
Motor Drives ........................................................................................ 19
Direct Coupled ......................................................................... 19
V-Belts ...................................................................................... 19
Setting V-Belt Tension............................................................... 20
Motor and Electrical Connections ............................................ 22
Operation .................................................................................... 23
General ............................................................................................... 23
Start-Up Checklist............................................................................... 24
Operating ............................................................................................ 25
Water-Injected Blowers ....................................................................... 25
Operation ................................................................................. 26
Shutdown ................................................................................. 26
Recommended Shutdown Procedure to Minimize Risk of
Freezing or Corrosion ......................................................................... 26
Maintenance ............................................................................... 28
General ............................................................................................... 28
Regular Maintenance.......................................................................... 28

iii
Table of Contents
Manual 2008 Rev A p/n 2008
Spare Parts ......................................................................................... 29
Factory Service and Repair ................................................................ 29
Long-Term Storage ............................................................................. 30
Disassembly and Reassembly.................................................. 31
Disassembly of Blower ....................................................................... 31
Free End Disassembly ............................................................. 31
Gear End Disassembly (Series 17/19/46/55/57/81/82/86) ....... 31
Gear End Disassembly (Series 64/66/67/69) ........................... 31
End Plate and Rotor Disassembly............................................ 32
Assembly Of Blower ........................................................................... 32
Preparation of End Plates for Assembly .................................. 32
Lip Seal Installation (Series 17/19/46/86)................................. 32
Lip Seal Installation (Series 55/57/64/66/67/69/81/82)............. 33
Gear End Assembly ................................................................. 33
End Plate Installation (Series 55/57/64/66/67/69/81/82) .......... 33
Free End Assembly .................................................................. 34
Free End Assembly (Series 55/57/64/66/67/69/81/82)............. 34
Adjusting Interlobe Clearance ................................................. 35
Complete Drive End Assembly ................................................ 35
Complete Drive End Assembly
(Series 17/19/46/55/57/81/82/86) ............................................. 35
Complete Drive End Assembly
(Series 17/19/46/55/57/81/82/86) ............................................. 35
Complete Free End Assembly (Series 17/46/57/64/67/81) ...... 35
Complete Free End Assembly (Series 19/55/66/69/82/86) ...... 36
Special Instructions for Gear Head Blowers....................................... 36
Troubleshooting......................................................................... 37

iv
Table of Contents
Manual 2008 Rev A p/n 2008
Assembly Clearances................................................................ 39
Torque Chart............................................................................... 40
Recommended Lubricants........................................................ 41
Recommended Lubricants for Rotary Blowers and Vacuum
Boosters.............................................................................................. 41
Special Tool Drawings............................................................... 43
Parts List ............................................................................................. 44
Assembly Drawings ............................................................................ 50

1
Manual 2008 Rev A p/n 2008
CONGRATULATIONS on the purchase of a new
PD PLUS Rotary Positive Displacement Blower
from Tuthill Springeld. Please examine the blower
for shipping damage, and if any damage is found,
report it immediately to the carrier. If the blower
is to be installed at a later date, make sure it is
stored in a clean, dry location and rotated regularly.
Make sure covers are kept on all openings. If the
blower is stored outdoors, be sure to protect it from
weather and corrosion.
PD PLUS blowers are built to exacting standards
and, if properly installed and maintained, will
provide many years of reliable service. Read
and follow every step of these instructions when
installing and maintaining the blower.
OTE:N Record the blower model and serial
numbers of the machine in the
OPERATING DATA form on the inside
back cover of this manual. Use this
identication on any replacement part
orders, or if service or application
assistance is required.
APPLICABLE DOCUMENTATION
The applicable documents associated with this
manual are:
• 2006/42/CE – Machinery Directive
• EN 1012-1:1996 - Compressors and vacuum
pumps - Safety Requirements - Part 1:
Compressors
SCOPE OF MANUAL
The scope of this manual and the Declaration of
Incorporation includes the bare shaft rotary positive
displacement blower.
INTRODUCTION
01

2Manual 2008 Rev A p/n 2008
GRAPHIC CONVENTIONS IN THIS
MANUAL
This manual is the result of a risk assessment
according to the applicable documents referenced
in Applicable Documentation on page 1. The
following are hazard levels are referenced within
this manual:
DANGER
!
Indicates a hazardous situation that, if not
avoided, will result in death or serious injury.
WARNING
!
Indicates a hazardous situation that, if not
avoided, could result in death or serious
injury.
CAUTION
!
Indicates a hazardous situation that, if not
avoided, could result in minor or moderate
injury.
Indicates a situation that can cause damage
to the engine, personal property, and/or
the environment or cause the equipment to
operate improperly.
OTE:N Indicates a procedure, practice, or
condition that should be followed in
order for the equipment to function in the
manner intended.
CAUTION
!
Read manual before operation
or bodily harm may result.
Attention should be given to the
safety related sections of this
manual.
CONVENTIONS AND DATA PLATE
02

3
02
Conventions and Data Plate
Manual 2008 Rev A p/n 2008
DATA PLATE
WARNINGWARNING CAUTION CAUTION
http://www.tuthill.com
Hearing protection
re
q
uired.
Do not touch hot
surfaces.
ASUehtniedaM7396-528)008(
READ INSTRUCTION MANUAL BEFORE OPERATION OR BODILY HARM MAY RESULT
Keep body & clothing away
from machine openings.
Do not operate without
g
uards in
p
lace.
REBMUNLAIRESREBMUNLEDOM
Tuthill Vacuum & Blower Systems
4840 West Kearney Street
Springfield, Missouri USA 65803
YEARMAWP
MAX RPM
Figure 2-1 – General Operation and Symbols on Data Plate
The following information is contained on the data
plate:
WARNING
!
Keep body & clothing away
from machine.
During operation, keep body
and clothing away from inlet
and outlet of the blower.
WARNING
!
Do not operate without guards
in place.
CAUTION
!
Hearing protection is required
while the blower is in operation.
Noise levels may reach as high
as 81 dBA.
CAUTION
!
Do not touch hot surfaces.
The upper limit of the blower
operation is 400°F (205°C). Do
not touch the blower while it is
in operation and assure blower
is cool when not in operation.

4
02
Conventions and Data Plate
Manual 2008 Rev A p/n 2008
MODEL NUMBER: The specic model of the blower
SERIAL NUMBER: Unique to each blower
YEAR: Year of manufacture
MAWP: Maximum Allowable Working Pressure
The standard MAWP is per Table 4-2 – Maximum Operating Limits on page
8. The MAWP shall not be exceeded.

5
Manual 2008 Rev A p/n 2008
WARNING
!
The blower must be handled using an
appropriate device such as a fork truck or
appropriate lifting device. See Table 4-1 on
page 8 for approximate weights. Care
should be taken to assure blower does not
over-turn during handling and installation.
LIFTING
03

6Manual 2008 Rev A p/n 2008
Refer to specic data sheets for ow capacities
and vacuum capacities.
OTE:N Refer to diagrams in this manual for
proper rotation and orientation in inlet
and discharge.
Tuthill Springeld model 9000 Series rotary lobe
blowers are positive displacement type blowers,
whose pumping capacity is determined by
size, operating speed, and differential pressure
conditions. Blowers employ rotors rotating in
opposite directions within a housing closed at the
ends by end plates.
The inlet to the discharge is sealed with operating
clearances that are very small. Internal lubrication
is not needed, as there is no moving contact.
Clearances between the rotors during rotation are
maintained by a pair of accurately machined helical
timing gears, mounted on the two shafts extended
outside the air chamber. The intermeshing rotary
lobes are designed to rotate and trap air or gas
between each rotor and the housing. As the rotor
lobes rotate past the edge of the suction port, the
trapped air or gas is essentially at suction pressure
and temperature. Since the blower is a constant
volume device, the trapped air remains at suction
pressure until the leading rotor lobe opens into the
discharge port. The close clearances between the
rotors inhibit back slippage of the trapped volume
from between the rotors, and the trapped volume
is forced into the discharge piping. Compression
occurs not internal to the blower but by the amount
of restriction, either downstream of the blower
discharge port or upstream of the blower inlet port.
Figure 4-1 illustrates the air movement within the
machine. In addition, the machine can operate in
either direction. See Flow by Direction on page
7.
Never attempt to control capacity by means of a
throttle valve in the intake or discharge piping.
This will increase the power load on the drive
system, will increase operating temperatures, and
can overload and/or seriously damage the blower.
Likewise, if the possibility exists that ow to the
blower inlet may be cut off during normal operation
of a process, install an adequate vacuum relief
valve. A pressure-type relief valve in the discharge
line near the blower is also recommended for
protection against cutoff or blocking in this line.
Use check valves on each blower when more than
one blower is connected to a discharge line.
When a belt drive is used, it is possible to adjust
blower speed to obtain the desired capacity by
changing the diameter of one or both sheaves,
or by using a variable-speed motor pulley. In a
direct-coupled arrangement, a variable-speed
motor or transmission is required. Gas blowers can
use bypasses, but some applications may require
additional cooling. If there is a large volume of
high-pressure air or gas downstream of the blower,
a check valve in the piping downstream of the
blower will protect the blower from overspeeding in
a backward direction upon shutdown.
Consult a Tuthill Springeld sales professional if
questions arise.
DESCRIPTION
04

7
04
Description
Manual 2008 Rev A p/n 2008
INLET INLET INLET
DISCHARGE DISCHARGE DISCHARGE
Figure 4-1 – General Operation Principle
FLOW BY DIRECTION
WARNING
!
Refer to diagrams in this manual for
proper rotation and orientation in inlet and
discharge.
INTAKE INTAKE
DISCHARGE INTAKE
DISCHARGE
HORIZONTAL FLOWVERTICAL FLOW
DISCHARGE
INTAKE DISCHARGE
INTAKE
DISCHARGE
RIGHT DRIVE
CW ROTATION
LEFT DRIVE
CW ROTATION
LEFT DRIVE
CCW ROTATION
RIGHT DRIVE
CCW ROTATION
TOP DRIVE
CW ROTATION
TOP DRIVE
CCW ROTATION
BOTTOM DRIVE
CW ROTATION
BOTTOM DRIVE
CCW ROTATION
DISCHARGEINTAKE INTAKE
INTAKEDISCHARGE DISCHARGE
Figure 4-2 – Flow Direction by Rotation

8
04
Description
Manual 2008 Rev A p/n 2008
SPECIFICATIONS
MODEL
APPROXIMATE OIL CAPACITY
PORT SIZE MAX
RPM
APPROXIMATE WEIGHT
VERTICAL
FLOW
HORIZONTAL
FLOW
VERTICAL
FLOW
HORIZONTAL
FLOW
9016 8.0 gal (30.3 L)* 5.0 gal (18.9 L)* 12 in. (305 mm) 2400 2000 lb
(907 kg)
2000 lb
(907 kg)
9020 8.0 gal (30.3 L)* 5.0 gal (18.9 L)* 12 in. (305 mm) 2400 2300 lb
(1043 kg)
2300 lb
(1043 kg)
9027 8.0 gal (30.3 L)* 5.0 gal (18.9 L)* 14 in. (356 mm) 2400 2850 lb
(1292 kg)
2850 lb
(1292 kg)
Table 4-1 – Specifications
* Integral Lube units require up to 2 additional gallons.
MODEL MAXIMUM RPM
MAXIMUM
PRESSURE
DIFFERENTIAL
MAXIMUM VACUUM
MAXIMUM
TEMPERATURE
RISE
MAWP
9016
2400 15 psi
(1,035 mbar)
15 inch-Hg
(508 mbar) 280°F (156°C) 35 psi (2.4 bar)
9020
9027
Table 4-2 – Maximum Operating Limits
WARNING
!
The maximum pressure differential is based
on the difference between the inlet pressure
and the outlet pressure. The maximum
pressure differential shall not be exceeded.
Exceeding the maximum pressure differential
will cause serious damage to the equipment
and could cause bodily injury.
WARNING
!
The maximum allowable working pressure
(MAWP) is based on the absolute pressure of
the blower housing and is NOT the maximum
allowable pressure differential. Exceeding
the MAWP will cause serious damage to the
equipment and could cause bodily injury.
To permit continued satisfactory performance, a
blower must be operated within certain approved
limiting conditions. The manufacturer’s warranty
is, of course, also contingent on such operation.
Maximum limits for pressure, temperature, and
speed are specied in Table 4-2 for various
blower sizes when operated under the standard
atmospheric conditions. Do not exceed any of
these limits.

9
04
Description
Manual 2008 Rev A p/n 2008
Specially ordered blowers with nonstandard
construction, or with rotor end clearances
greater than shown in Assembly Clearances
on page 39, will not have the operating
limits specied here. Contact your Tuthill
Springeld sales representative for specic
information.
Special attention must be paid when a blower
has a higher than standard ambient suction
temperature. Special recommendations
for operating parameters and/or additional
cooling may be recommended. Consult the
factory or local representative for appropriate
information.

10
INSTALLATION
05
Manual 2008 Rev A p/n 2008
GENERAL
DANGER
!
The booster is not intended to be used
with explosive products or in explosive
environments unless fully approved by Tuthill
Factory prior to the purchase of the product,
designed specically for the gas application.
DANGER
!
It is the responsibility of the installer to
assure that proper guarding is in place and
compliant with all applicable regulatory
requirements.
WARNING
!
The bare shaft blower can
generate excessive noise.
Methods to reduce the noise
levels by installing inlet and
outlet silencers will be required.
Even with inlet and outlet
silencers, hearing protection
will be required.
WARNING
!
Customers are warned to provide adequate
protection, warning and safety equipment
necessary to protect personnel against
hazards in the installation and operation of
this equipment in the system or facility.
WARNING
!
The standard MAWP is per Table 4-2. The
MAWP shall not be exceeded unless specic
factory testing of the pressure containing
components of the blower has been
performed.
WARNING
!
Table 4-2 states the maximum operating
speed in RPM (rotations per minute) and
maximum temperature. Do not exceed these
limits. The installation of the blower shall
take these critical operating parameters
into account and adequate control features
implemented.

11
05
Installation
Manual 2008 Rev A p/n 2008
WARNING
!
Upon completion of the installation, and
before applying power, rotate the drive
shaft by hand. It must move freely. If it
does not, look for uneven mounting, piping
strain, excessive belt tension or coupling
misalignment or any other cause of binding.
If blower is removed and still does not move
freely, check inside the blower housing for
foreign material.
Remove the protective covers from the shaft
and inspect for damage.
Carefully check to ensure that no transit damage
has been sustained. If damage has occurred from
shipment, le a claim with the carrier immediately.
Preserve the shipping container for inspection by
the carrier.
In the event that your unit sustains damage
while being shipped to your facility, do not
return it to the factory without rst obtaining
shipping instructions from us.
Do not remove protective covers and plugs until
the connections are complete. Mount the blower on
a at, level surface. Use a baseplate that is rigid,
solidly supported, and structurally sound. Shim
under the legs where necessary so that each leg of
the blower supports an equal share of the blower
weight. This is necessary to prevent twisting of
the blower. Make sure the feet rest evenly on the
mounting surface before fastening down. Twisting
or cramping the blower during mounting will
cause rotor contact and binding during operation,
resulting in a condition called “soft foot.” See
Soft Foot on page 13 for further details and
preventative measures.
A blower that is factory-mounted on a base should
not require such adjustments. However, since
the assembly can become twisted in shipping or
installation, check for soft foot after installing the
base. Shims may be needed for alignment. Loosen
the foot hold-down screws to check foot contact
with the mounting surface. Mount the base on a
solid foundation or heavy ooring, using shims
as necessary at bolting points to prevent warping
the assembly. See Foundation on page 12 for
more information.
Transmission of small operating vibrations to a
support structure may be objectionable in some
applications. Use of vibration isolators or vibration-
absorbing materials can be effective in overcoming
this transmission. To avoid causing distortion, apply
the treatment under the common motor/blower
base or mounting plate rather than directly under
the feet alone.
Make sure piping is accurately squared with the
blower and supported independently. Stress
imparted from incorrectly aligned piping or
mounting will create problems with bearing and
seal life, possibly leading to premature internal
contact. The blower should sit stress free and
evenly on its supporting surface. Take care
to evenly tighten the mounting bolts to avoid
imparting undue stress into the blower. Stress
can be checked in a free state with feeler stock or
veried on a previously installed blower with the
aid of a dial indicator. Spring or gap should be less
than 0.002 in. (0.05 mm).
Use only clean, new pipe and make certain it is
free of scale, cuttings, weld beads, dirt, or any
other foreign material. To guard against damage
to the blower, make sure that an inlet lter is used.
Clean the lter of collected debris after 3 hours of
operation and periodically thereafter. See Piping
Connections on page 18 for additional details.
Figure 5-1 shows a typical complete installation
of the blower and accessories. Note the absence
of throttle or shut-off valves in both discharge and
intake piping. If it is possible for airow to be cut off
in either line, add a pressure and/or vacuum relief
valve. In some installations, it may be desirable to
use only an inlet silencer-cleaner supported directly
from the blower connection. Keep the weight of
accessories and piping to a minimum to prevent
blower casing distortion. If the weight exceeds
10% of blower weight, support the components
independently of the blower and connect them with a
exible hose or connectors. The approximate weight
of the blower is listed in Table 4-1 on page 8.

12
05
Installation
Manual 2008 Rev A p/n 2008
AIR FILTER
PRESSURE
RELIEF VALVE
CHECK VALVE
FLEX CONN.
PRESSURE GAUGE DISCHARGE
SILENCER
INTAKE SILENCER
FLOW
FLOW
Figure 5-1 – Typical Blower Installation
A blower may be driven by direct-coupling to
the driver or by V-belt drive for the purpose of
obtaining other speeds within the approved
range. See Motor Drives on page 19 for more
information.
Blowers from Tuthill Springeld are internally
and externally treated after factory assembly
and testing to protect against rusting in normal
atmospheric conditions prior to installation.
The maximum period of internal protection
is considered to be 6 months under average
conditions, provided closing plugs and seals are
not removed. Protection against chemical or salt-
water atmosphere is not provided. Avoid opening
the blower until ready to begin installation, as
protection will be quickly lost due to evaporation.
For recommended preparations for long-term
storage (longer than 6 months), see Long-Term
Storage on page 30.
Location
Install the blower in a room or outdoor area that
supplies adequate space and lighting for routine
maintenance. Make sure that indoor installation
areas are well ventilated and kept as cool as
possible, because operating the blower at elevated
temperatures can result in nuisance overload or
temperature shutdowns. An unprotected outdoor
installation is satisfactory only when correct
lubrication for the expected temperatures is
provided. See Recommended Lubricants on
page 41.
Foundation
Your blower does not need a special foundation;
however, it does require a solid, level oor and
adequate frame support. Bolt the blower system to
the oor and seal any cracks.
Blower Air Intake
To minimize maintenance, supply the blower with
the cleanest air possible. The air must not contain
any ammable or toxic gases, as the blower will
concentrate these gases. This could result in
damage to the blower and surrounding property
and lead to personal injury or death. Do not block
or restrict the opening of the blower, as the motor
could overheat and fail.
Do not use blowers on explosive or hazardous
gases. Do not exceed the limits described in
Table 4-2 on page 8 on performance criteria
such as pressure differential, running speed, and
discharge temperature.
If it is necessary to take air from a remote source,
such as in a vacuum application, make sure the
diameter of the piping is at least equal to the
diameter of the blower inlet. For distances greater
than 20 ft (6 m), enlarge the pipe diameter to
reduce inlet restriction. Excessive restriction will
reduce the efciency of the blower and elevate its
discharge temperature. The piping used should
also be corrosion-resistant and free of scale and
dirt. Keep the inlet covered to keep out foreign
objects and rain. Vacuum kits are available.

13
05
Installation
Manual 2008 Rev A p/n 2008
Soft Foot
Soft foot is a condition in which one of the blower
feet does not sit at on the base. Soft foot is
usually due to irregularities in the surface to which
the blower is mounted. When the bolt on the foot
gets tightened, a slight distortion occurs that can
affect bearing and seal life as well as internal
contact between parts.
ANGULAR
SOFT FOOT
PARALLEL
SOFT FOOT
Figure 5-2 – Illustrations of Soft Foot
1. Place the blower on the base.
2. Check each foot for gaps between the foot and
base (soft foot). Shim as necessary to ll the
gap within 0.002 in. (0.05 mm).
Figure 5-2 shows the two most common types
of soft foot conditions. If either type is present
at a measurement of more than 0.003 in.
(0.076 mm), the blower may fail prematurely.
3. Tighten all bolts.
4. Mount a dial indicator on the base contacting
one foot at 12 o’clock position.
5. Loosen the bolt on that foot. Observe indicator
travel and add shims as needed to reduce
“spring” to less than 0.002 in. (0.05 mm).
Repeat steps 4 and 5 on the remaining feet.
SAFETY
Tuthill Springeld recommends the use of relief
valves to protect against excessive pressure or
vacuum conditions. Test these valves at initial start-
up to be sure they are properly adjusted to relieve
at or below the maximum pressure differential
rating of the blower.
DANGER
!
It is the responsibility of the
installer to assure that proper
guarding is in place and
compliant with all applicable
regulatory requirements.
DANGER
!
Internal and external rotating
parts of the blower and driving
equipment can produce
serious physical injuries. The
blower should never be run
with the inlet or discharge
piping removed. If it becomes
necessary to inspect the
rotating parts of the blower or
to change V-belts, be absolutely
sure that all power to the motor
controls has been shut off, the
motor controls are locked out,
and properly tagged before
proceeding.

14
05
Installation
Manual 2008 Rev A p/n 2008
DANGER
!
Assure that properly sized vacuum breaks/
relief valves are used on the inlet side of
the blower. Also assure that properly sized
pressure relief valves are used on the outlet
of the blower. The sizing shall be such to
assure that the proper ow can be achieved
without exceeding the rated vacuum and
pressure ratings.
DANGER
!
Blower housing and associated
piping or accessories may
become hot enough to cause
major skin burns on contact.
WARNING
!
Use lock out/tag out procedures
to disable the electrical energy
source before any service or
work is done on the blower.
WARNING
!
Avoid extended exposure in
close proximity to machinery
with high intensity noise levels.
Wear adequate ear protection.
OTE:NUse proper care and good procedures in
handling, lifting, installing, operating, and
maintaining the equipment.
LUBRICATION
Every blower from Tuthill Springeld is factory-
tested, oil-drained, and shipped dry to its
installation point. Fill both oil reservoirs to the
proper level before operation.
Shaft bearings at the gear end of the blower are
splash-lubricated by one or both gears dipping
into an oil reservoir formed in the gear end plate
and cover. Shaft bearings at the back end of the
blower are lubricated by a slinger assembly dipping
into an oil reservoir. In addition to the splash
lubrication, blower series incorporate pressure
lubrication with an integral oil pump, pressure relief
valve, lter and oil-to-coolant heat exchanger.
Before starting the blower, ll the oil sumps as
described in Filling Procedure on page 15.
Tuthill Springeld approved mineral-based,
synthetic and food grade lubricants are listed in
Recommended Lubricants on page 41.
WARNING
!
Never attempt to change or add lubrication
while the blower is running. Failure to heed
this warning could result in damage to the
equipment or personal injury. Oil must be
checked when the blower is NOT running.
WARNING
!
Properly dispose of the spent lubricants.
Refer to the manufacturer of the lubricant and
any regulations to assure proper and safe
disposal.
WARNING
!
Do not start the blower until you are sure oil
has been put in the gear housing and rear
cover. Operation of the blower without proper
lubrication will cause the blower to fail and
void the warranty.
