Tuthill D Series Quick guide

Installation and Service Instructions
Excellence at work. Excellence in life.Version
D Series Service Pak
Excellence at work. Excellence in life.
Suggested Service Pak Tools
60129-1 Bearing Extractor Tool 60158-1 Medium Blade Screwdriver
60098-2 Bearing Installation Tool 60157-1 Bypass Nut Driver
60098-4 Body Bearing Installation Tool
(.11 - .19 Size Only) Optional Rubber Gloves
60154-1 T10 Torx Driver Optional Masking Tape
60155-1 T15 Torx Driver 60149-1 D Series Tool Kit (Includes all tools shown above
except 60098-4)
60169-1 Hex Key Wrench 9/64”
Service Pak includes: 2 Gears, 3 O-Rings, 5 Bearings, Silicone Lubrication and Instruction Sheet.
CAUTION
Warranty will not extend to goods altered or repaired by anyone other than the manufacturer or authorized representative.
Service Paks are designed to be installed by someone familiar with precision mechanical assemblies and tools. Observe reasonable
safety precautions, including the use of safety eye-wear when performing the steps listed below.
Important: Check the Service Pak parts you have received. Tuthill has changed the Driven Magnet to a “slip t” design for the Driving
Gear Assembly (12). This design does not require a Magnet Clamp Screw (5). If you have received a Service Pak with the “slip t” design
and your Pump has a Magnet Clamp Screw (5) design Driven Magnet (7) you will need to contact the factory and order a “slip t” Driven
Magnet (7). See pictorials at the end of these instructions.
Disassembly Instructions (Refer to Pages 3 & 4)
1. Provide a clean surface for work area.
2. Remove three Mounting Screws (3) and separate Pump-Head from Drive Housing.
Note: If the Gears are not being replaced and will be reused, after removing the Cap (16) in the next step mark the Gears
orientation with a permanent marker. This will allow the Gears to be reassembled in the same orientation. Remove two cap screws
(17) with a 9/64 Hex Socket Wrench. Models manufactured prior to 2001 use a T20 Torx Driver.
3. Remove two Cap Screws (17) in the Cap (16) holding the other parts in place and remove the Cap (16), Driven Gear (13), Cavity
Plate (15) and two Dowel Pins (14). If the pump is furnished with a Bypass take care not to damage the Poppet (20) sealing surface.
Remove Poppet Assembly (20) from Bypass Adjusting Screw (18). Turn Bypass Nut (19) counter-clockwise 1 ½ turns. Hold Bypass
Nut (19) against rotation and turn Bypass Adjusting Screw (18) counter-clockwise to remove from Cap (16).
4. Remove six Mounting Plate Screws (1) and remove the Mounting Plate (2) and Magnet Cup (4).
Note: Instructions for “slip t” Design. Pull the Driven Magnet (7) o the Driving Gear Assembly (12) shaft (no Screw is used in
this design). Instructions for Magnet Clamp Screw Design. To prevent damage to the Driving Gear (12) REMOVE Cap (16) BEFORE
installing or removing the Magnet Clamp Screw (5). NEVER install or remove the Magnet Clamp Screw (5) with Cap (16) in place.
Hold the Driven Magnet (7), Magnet Clamp (6), and Magnet Hub (8) from rotation and turn Magnet Clamp Screw (5) clock-wise
(left hand threads) to remove. Magnet Clamp (6) and Magnet Hub (8) are not part of a DX Driven Magnet (7).
5. Remove three O-Rings (9) from the Cap (16) and Body (10). O-Rings (9) may be removed with a blast of compressed air or with a
sharp pin.
Installation and Service Instructions
70016-1/H/50-7029

Version Page 2 of 4
Important: Do not nick or scar the sides of the bearing bores in the steps below.
6. Clamp the Bearing Extractor Tool in a vise and screw the Bearing (11) on the tool and gently tap with a soft mallet while supporting
and pulling the Cap (16) or Body (10) to free the Bearing (11). Repeat process until all ve Bearings (11) are removed. See Figure 1.
7. Inspect all parts for damage and wear. If wear on Cap (16), Cavity Plate (15) and Body (10) is excessive rebuilding the pump may
not be recommended (consult factory).
Assembly Instructions (Refer to Pages 3 & 4)
1. Clean all parts. Any foreign material clinging to the Driven Magnet (7) can be removed with masking tape.
2. Body Bearing Installation for .11 and .19 size pumps only: Use installation tool 60098-4. Body Bearings (11) should be installed to
.135/.145 below the face of the body (10). Install the cap bearings per step # 3.
3. Cap bearings (.11 – 2.3) and Body bearings (.23 to 2.3 only) use installation tool 60098-2. Press bearings into the Cap (16) and
Body (10). Bearings (11) should be .002/.005 below the face of the Cap (16) and Body (10). See Figure 2.
4. Apply a thin coat of silicone lubricant (furnished in Service Pak) to three new O-Rings (9) and install in the Cap (16) and Body (10)
O-Ring grooves. Omit silicone lubricant if it is incompatible with your pumped uid.
Note: Instructions for “slip t” Design. Install Driving Gear Assembly (12); then slip t Driven Magnet (7) on shaft (no screw
required for this design). Instructions for Magnet Clamp Screw Design. Install Driving Gear Assembly (12), Magnet Hub (8), Driven
Magnet (7), Magnet Clamp (6) and Magnet Clamp Screw (5). Hold Driven Magnet (7) to prevent rotation and tighten Magnet
Clamp Screw (5) counter-clockwise (left hand threads) to 200 in/oz torque (a rubber glove can be used to facilitate holding the
Driven Magnet (7). When performing the following assembly operations DO NOT apply forces to the Driven Magnet (7). Pushing or
pulling the Driven Magnet (7) may damage the Driving Gear Assembly (12).
5. Install two Dowel Pins (14) into Body (10) and slip the Cavity Plate (15) over the Dowel Pins (14) against the Body (10) face. The Cavity
Plate (15) will t properly in only one orientation. The Screw holes in the Body (10) and Cavity Plate (15) must align.
6. Install Driven Gear Assembly (13) with the longer shaft extension into the Body (10).
7. If pump is furnished with a Bypass, install Bypass Adjusting Screw (18) through the Bypass Nut (19) and turn clockwise until the
Bypass Adjusting Screw (18) is ush with the Bypass Nut (19). Attach Poppet Assembly Spring (20) onto Bypass Adjusting Screw (18).
8. Align Cap (16) with the Driving (12) and Driven (13) Gear Assembly shafts and Dowel Pins (14). Assemble carefully and make certain
the Poppet Assembly (20) goes fully into the Poppet hole and seats. See Figure 3.
9. Install two Cap Screws (17) in Cap (16) and torque alternately to 640 in/oz.
10. Rotate the Driven Magnet (7) by hand to check for any binding during rotation. The Driven Magnet (7) should turn freely. If there
is binding determine and remove cause.
11. Install Magnet Cup (4) and Mounting Plate (2) with six Mounting Plate Screws (1). Turn alternately until tight to 320 in/oz.
12. Assemble Pump-Head to Motor and Drive Housing with three Mounting Screws (3). Pump/Motor assembly is now complete.
Note: New parts may exhibit slight interference with mating surfaces. An initial “run-in” period may be required to allow the gears to seat.
Rebuilt pumps may initially decouple below normal dierential pressure or produce less than normal ow-rate until mating parts have fully
seated during initial period of operation.
Parts List & Drawing
1. Mounting Plate Screws 6. Magnet Clamp 11. Bearing 16. Cap
2. Mounting Plate 7. Driven Magnet 12. Driving Gear Assembly 17. Cap Screw
3. Pump Mounting Screws 8. Magnet Hub 13. Driven Gear Assembly 18. Bypass Adjusting Screw
4. Magnet Cup 9. O-Ring 14. Dowel Pin 19. Bypass Nut
5. Magnet Clamp Screw 10. Body 15. Cavity Plate 20. Bypass Spring, Guide & Poppet Assembly

Version Page 3 of 4
FIGURE 1
10
11
VISE
BEARING EXTRACTION TOOL
PN 60129-1
15 16
10
20 18 19
FIGURE 3
BYPASS SEAT
1
2
3
4
7
10
12
15
9
14
13
11
16
17
18
19
20
1
1
FIGURE 2
10
"IN" BEARING INSTALLATION TOOL
NOTE: CHAMFERED END "IN"
PN 60098-4 FOR THE BODY
PN 60098-2 FOR ALL THE CAP AND BODY
PN 60098-2 FOR THE CAP
D Series Pumphead w/ Slip Fit Magnet
= Slip t driven magnet and driving gear assembly.
1
SIZES .11 - .19
SIZES .23 - 2.3

Tuthill Pump Group
USA • United Kingdom • China
www.tuthillpump.com
Excellence at work. Excellence in life.
15 16
10
20 18 19
FIGURE 3
BYPASS SEAT
1
2
3
4
7
10
12
15
9
14
13
11
16
17
18
19
20
5
8
6
FIGURE 1
10
11
VISE
BEARING EXTRACTION TOOL
PN 60129-1
D Series Pumphead w/ Open Magnet
FIGURE 2
10
"IN" BEARING INSTALLATION TOOL
NOTE: CHAMFERED END "IN"
PN 60098-4 FOR THE BODY
PN 60098-2 FOR ALL THE CAP AND BODY
PN 60098-2 FOR THE CAP
SIZES .11 - .19
SIZES .23 - 2.3
