Tuttnauer TIVA8-MD User manual
Before starting to operate with
the washer disinfector, read
these instructions for use
INSTRUCTIONS FOR USE
Original instructions
Code Man205-0745009EN - Rev. 02
Edit. 06-2022
Language: English
Firmware version: 00B03
WASHER DISINFECTOR
TIVA8-MD
2
Operave Instrucons
WARNING
Operave Instrucons
) CAUTION! This sign warns that if the
operaons described are not correctly
performed, they can damage the machine.
a WARNING! This sign warns that if the
operaons described are not correctly
performed, they can cause serious injury.
b HAZARD! This sign warns that if the operaons
described are not correctly performed, they
can cause serious injury, death or long-term
health risks. Please read carefully the User
Manual.
d HAZARD! This sign indicates hot surfaces.
Danger of burns.
c HAZARD! This sign indicates a potenal risk
of electric shock that can cause serious injury,
death or long-term health risks.
Ö IMPORTANT NOTE! Carefully read and
memorize the informaon.
a WARNING! The manufacturer also declines
any and all liability for failure to comply
with the safety and prevenon regulaons
provided by the legislaon and the provisions
of this manual.
a WARNING! The machine must only be
installed and dismantled by personnel
trained for the purpose.
33.3" / 845 mm
23.6" / 600 mm
25.6" / 650 mm
Fig. 1
a WARNING! Failure to comply with the
instrucons in manual, operaonal
negligence, incorrect use of the washer
disinfector and execuon of unauthorized
changes, both on the machine and on the
programs, will be cause for cancellaon by
the manufacturer of the warranty granted.
For the installaon schemes see the Installaon Plan.
Ö IMPORTANT NOTE! The Installaon Plan
must be considered as an integral part of this
User Manual.
5
Operave Instrucons
Operave Instrucons
Ö IMPORTANT NOTE! The purchaser will only
be able to enforce its warranty rights if it
has complied with any addional condions
concerning the warranty service, also
indicated in the supply contract.
Ö IMPORTANT NOTE! This manual is the basic
tool for personnel who, in various capacies,
take care of the machine.
Operave Instrucons
Operave Instrucons
Ö IMPORTANT NOTE! it is the user’s
responsibility to supply the machine with
suitable water.
*The weight may vary depending on the conguraon.
2
1
1
5
4
6
7
8
8
3
9
10
10
Fig. 2
Upper door with tempered glass.
2) Internal chamber.
3) Upper door opening handle.
4) Control panel.
5) Air sucon lter.
6) Lower spray arm.
7) Connecon point for washing racks.
8) Hole for emergency release.
9) Machine label placed behind the lter panel.
10)Machine label placed on the back of the machine.
Operave Instrucons
Fig. 3a
Fig. 3b
Fig. 3c
Fig. 3d
Fig. 3e
Fig. 3f
Fig. 3g
3a: Washing rack posioned at the lower level, basic
version.
3b: Washing rack with spray arm posioned at the
upper level, basic version.
3c: 1/1 DIN basket manufactured in stainless steel,
suitable for washing all kinds of instruments.
3d: Support grid for racks posioned at the upper
level, allows to use DIN baskets.
3e: Insert for washing up to 14 trays or cassees.
3f: Insert for washing up to 6 trays or cassees
3g: 1/3 Basket manufactured in stainless steel,
suitable for washing all kinds of instruments.
Operave Instrucons
Fig. 4
b WARNING! Fix the stand to the oor with
screws.
Operave Instrucons
d HAZARD! Pay aenon where indicated, for a
potenal danger of hot surfaces highlighted
on the machine with this pictogram.
c HAZARD! Pay the utmost aenon where
indicated, for a potenal electrical hazard
highlighted on the machine with this
pictogram.
Operave Instrucons
b HAZARD! The loading/unloading operaons
can be very dangerous if not carried out with
the utmost care. Therefore, before starng
loading/unloading, move unauthorised
persons away; clear and delimit the area
where the operaon takes place, and check
the integrity and suitability of the liing and
transportaon equipment available.
a WARNING! Aer loading the machine, secure
it rmly to the surface on which it rests with
taut ropes to block any possible movement.
Fig. 5.1
Fig. 5.2
Fig. 5.3
Operave Instrucons
a WARNING! Wear cut-resistant protecve
gloves during manual transport and
posioning of the machine.
Fig. 6
Ö IMPORTANT NOTE! For a safe installaon,
the electrical disconnector/plug of the device
must be posioned free from any obstacle
and in a visible and accessible posion for
the operator, so that it's easy to control
it in case of emergency or prolonged safe
disconnecon.
b HAZARD! Do not install and/or use the
washer disinfector in environments with
ammable/explosive atmosphere.
a WARNING! Make sure that the oor is t to
support the load of the equipment when in
operaon.
a WARNING! Make sure that the machine is
perfectly vercal and stable, using a spirit
level, if necessary.
b HAZARD! All electrical and water connecons
(loading/unloading) can only be carried out
by specialised and authorised personnel and
by consulng the relave diagrams.
Operave Instrucons
a WARNING! The use of unsuitable parts,
and/or the implementaon of installaon
procedures other than those shown on the
installaon diagram, will immediately void
the machine warranty.
Ö IMPORTANT NOTE! The manufacturer is not
to be held liable for any damage caused by
improper grounding of the machine or faulty
power supply.
0.2
" / 50 mm
0.07" / 2,5 mm
0.07
" / 2,5 mm
Fig. 7
c HAZARD! Only qualied and experienced
personnel can connect the machine to the
mains supply, in compliance with the current
laws and regulaons.
a WARNING! In the single-phase version, the
main switch of the power supply line must be
a mul-pole circuit breaker, with adequate
residual current protecon.
a WARNING! In the three-phase version,
the main switch must be mul-pole circuit
breaker, with adequate residual current
protecon, posioned near the machine and
not covered by machines or other that may
hinder its use.
Ö IMPORTANT NOTE! The fuses must be in
compliance with Standards IEC 60127-2,
UL248-14, CSA C22.2.
Operave Instrucons
1
Fig. 8
Posions of the fuses (Fig. 8):
c HAZARD! Damaged fuses must be replaced
by authorised personnel (for the value and
size of the fuses see Annex 12.9).
a WARNING! Power supply cable: it is
compulsory for the retailer - installer to
adapt the insulaon class of the power
supply cable to suit the working environment
in compliance with current technical
regulaons.
) CAUTION! The water in the wash chamber is
not drinkable.
Operave Instrucons
.
b HAZARD! Be careful in case of a blockage of
the drain which could cause spill out of water
and the risk of slippery oor.
12
43
Fig. 9
Water connecons (Fig. 9)
1) Cold water connecon.
2) Hot water connecon.
3) Deionized water connecon.
4) Cold water condenser connecon.
Operave Instrucons
a WARNING! The ow pipes must not be
shortened or damaged.
*Recommended only for expert users.
a WARNING! During this operaon, check that
the plasc cap is closed.
a WARNING! The washing cycle performed
aer the «salt loading» may not work.
a WARNING! Failure to comply with these
recommendaons can lead to a malfuncon
of the water soening device. Just before
the salt runs out completely, the display will
show the message «Lack of salt». At this
point, the salt should be topped-up as soon
as possible, otherwise an error message will
appear and it will no longer be possible to
acvate a new cycle if not by reseng.
Operave Instrucons
Ö IMPORTANT NOTE! Aer the salt rell acon,
the rst wash cycles may fail.
Ö IMPORTANT NOTE! The "Rell Salt Tank"
alarm may persist for few hours aer the salt
rell acon, unl the brine is being created.
This will not aect the funconality of the
device.
A B
1
13
2
2
Fig. 10
Water and drain system (Fig. 10):
A) Floor drain connecon.
B) Wall drain connecon.
1) Hose connecon waste water.
2) Hose connecon capacitor discharge machine.
3) Minimum connecon point 3.9" (100 mm).
Maximum connecon point 23.6" (600 mm).
Ö WARNING! The washer disinfector drain pipe
must be maintained if backow and other
drainage issues are to be avoided. Keep the
drain pipe free from kinks and knots, and
minimize the number of twists and turns in
the pipe. Be careful not to crush the pipe.
If the pipe has been crushed, kinked, or
otherwise damaged, consider replacing it to
prevent future drainage issues.
Operave Instrucons
b WARNING! If the waste connecon is
installed incorrectly, the waste water could
ow backwards into the machine’s chamber.
Ö WARNING! The manufacturer is not liable
in case of environmental polluon due to an
incorrect use of the washer disinfector.
1
3
2
4
Fig. 11
Filter unit (Fig. 11):
1) Central lter.
2) Mesh lter.
3) Chamber boom lter.
4) Salt tank cap.
Ö IMPORTANT NOTE! In case of washing shoes,
clogs and instruments with parcle-sensive
dirt, it is recommended to remove the
chamber boom lter before the washing
cycle, in order to avoid to clogging it. If the
chamber boom lter is not removed, it is
recommended to clean it aer each washing
cycle.
Fig. 12.1
Operave Instrucons
1
2
Fig. 12.2
Spray arm rotaon idencaon (Fig. 12.2):
1) Spray arm without magnet for idencaon.
2) Spray arm equipped with magnet for idencaon.
Ö WARNING! Spray arm assembly direcon,
the water outlet holes must face towards the
inside of the chamber otherwise the spray
arms will NOT work.
a WARNING! It is recommended to handle the
liquids with cauon.
a WARNING! Failure to follow these
recommendaons may damage the washer
disinfector.
