Tuuci MAX CENTER POST Quick reference guide

1005157
1
|tuuci
MAX CENTER POST
LIGHT AND HEATERS
TUUCI
ASSEMBLY & OPERATING INSTRUCTIONS
TO PROTECT YOUR PRODUCT, PLEASE READ THE OPERATING INSTRUCTIONS BEFORE OPENING THE PARASOL

1005157
2
|tuuci
security stem
ELECTRICAL CORD
STEP 3
Once you have leveled the security
stem using the base installation
instructions, slide the post beauty
cover and umbrella over the security
stem (security stem is included with
umbrella).
STEP 1
Remove all packaging from umbrella.
STEP 2
Pull pin from cam lock and lift the handle to unlock.
pin
Ensure that electrical cord is
not pinched when inserting
the umbrella over the security
stem and when installing the
beauty cover.
AMBIA LIGHT & HEATERS MAX CENTER POST
control
panel
umbrella with 4 heaters
has 2 control boxes
umbrella with 2 heaters
has 1 control box
STEP 4
Mount (2) control box covers then push down cam lock handle in the down position.
Labels inside the covers indicate placement of control boxes, see image below.
cam lock
handle
LARGE CONTROL
BOX COVER SMALL CONTROL
BOX COVER
COVER COVER
BATTERY PLUG
MUST BE CLOSED
TIGHLY AT ALL TIMES

1005157
3
|tuuci
AMBIA LIGHT & HEATERS MAX CENTER POST
STEP 7
Insert crank handle and
unlock crank-lock button by
moving to up position.
crank-lock button
crank handle
STEP 8
Gently separate each rib individually
from the center hub approximately
10 inches. If the rib does not move
easily, do not force. Inspect the
product for additional packaging.
STEP 9
Open umbrella by turning crank handle clockwise until top telescopic
head makes contact with bottom post.
top telescopic
bottom post
STEP 10
Move crank-lock button to down position.
STEP 5
Plug in your umbrella into a 220V receptacle.
When the umbrella is properly plugged into the
power source the TUUCI logo on the user control
panel will be back-lit in white.
STEP 6
Press the Power button to turn on the umbrella. The
button will be back-lit in red when the power is ON.

1005157
4
|tuuci
AMBIA LIGHT & HEATERS MAX CENTER POST
lower hub
light fixture cable
light fixture pins (x2)
post pin hole (x2)
post light cable
STEP 12
Position ambia light in place by snapping-in the 2 post pin holes and the light fixture pins. See image for details.
Note: The half section of the light with no bottom cover has to be placed on the same side of the pole where the light cable is visible.
STEP 11
To install ambia light release tension from the steel wires by slightly cranking
umbrella counter-clockwise.
Slightly raise lower hub If more slack is needed when mounting ambia light.
The ambia light kit is safely stored in a separate packaging box.
kit includes:
bottom light cover
ambia light
2x screws
allen key
steel wires
lower hub

1005157
5
|tuuci
STEP 13
Insert screws on both sides,
do not tighten screws until both screws are in place.
Once both screws are placed tighten with provided allen key.
STEP 15
Install/snap-in place bottom light cover
AMBIA LIGHT & HEATERS MAX CENTER POST
STEP 14
Connect light cables
screws
screws

1005157
6
|tuuci
TURNING THE AMBIA LED LIGHT ON
Press the light bulb icon button to turn-on the Ambia LED light.
The color will change from white to blue after pressing the button, signaling that the light is ON.
TURNING THE HEATERS ON
Press the heater icon button to turn-on the heaters. The color will change from white to blue, signaling that the heaters are ON.
TURN ON LIGHT AND HEATERS
AMBIA LIGHT & HEATERS MAX CENTER POST
power on
Ambia light
heater
CLOSING UMBRELLA
Instructions to turn-off the Ambia LED light and heaters.
STEP 1
Press the heater icon button to turn-off the heaters.
After pressing the button, the color will change to white,
signaling that the heaters are OFF.
STEP 2
Press the light bulb icon button to turn-off the Ambia LED light.
After pressing the button, the color will change to white,
signaling that the light is OFF.
STEP 3
Press power button to turn off the umbrella.
STEP 4
Once heaters are cooled off pivot heaters 45 degrees to allow
umbrella to close fully.
NOTE:
Allow 15 minutes for heaters to cool down
before closing umbrella
STEP 5
When not in use, the canopy must be
carefully folded and secured with the tie-strap.
Note: close umbrella during wind
conditions that exceed manufacturer’s
specifications

1005157
7
|tuuci
Power Supply:
Main Input Voltage: 208-240VAC
50/60 Hz
Max. Amps: 13.7 A @220Volts AC
12.6 A @240Volts AC
Max. Watts: 3010 Watts
Lights and (4) Heaters Electrical Specs:
North America version:
208-240V, 2 phases 60Hz (requires a minimum 15 Amp circuit)
Umbrella comes with 10ft Power Cord & Plug
(Use with 20A - 250 Volts, NEMA 6-20R Receptacle compatible with NEMA 6-20P Plugs)
Europe version:
220-240V, 1 phase 50Hz (requires a minimum 16 Amp circuit)
Umbrella comes with 10ft Power Cord & Plug
(Use with 16A - 250 Volts, Schuko Receptacle compatible with Schuko 16A - 250 Volts Plug)
Customer must connect to a protected power source circuit with proper Current Rating “Amps”, near the umbrella, using an
above ground Junction box, according to their local electrical codes and regulations.
warnings & safety instructions
1. Read and understand entire owner’s manual before assembling or operating umbrella.
2. Read and understand the warnings posted on the umbrella and/or components installed on the umbrella.
3. Disconnect electrical power to umbrella during inclement weather.
4. There is a risk of  re if heaters contact  ammable materials or liquids.
5. Keep children away from power cords on or around umbrella.
6. Disconnect power before removing or servicing umbrella.
7. Allow suffi cient cooling of heaters before closing umbrella.
8. Do not use this umbrella for other than its intended use.
9. Replace warning labels if they become obscured or removed.
10. Make sure the umbrella is properly grounded if there are electrical devices installed such as heaters.
11. Provide for adequate space to open and close umbrella without obstructions.
12. Customer’s electrical power source connections if any, are to be installed / connected by a certi ed electrician. check local codes for guidance.
13. When closing / opening umbrella keep hands and face clear of all pinch points, or protruding umbrella components.
Emergency shut-down or interrupt Feature
Press the Power button to shut-down or interrupt the operation of any function (Ambia LED light and heaters). The red
light on the Power button will turn OFF. The white lights on the heater icon and the light icon will turn OFF. Press the
Power button to turn the umbrella back ON.
Control panel indicator when the Umbrella is not level (tipped or tilted on an angle)
The Power button will be  ashing in yellow when the umbrella is not level. All functions (Ambia LED light and heaters)
are inactive. The TUUCI logo is not back-lit. When the umbrella is level and no longer tipped or tilted, it will return to a
powered down state with the TUUCI logo back-lit in white and all other functions OFF. Press the Power button to turn-
on the umbrella. Then, turn-on the various functions.
Lock-out unauthorized users from turning-on or -o various features of the Umbrella
There is a lock-out feature to prevent unauthorized user access. To turn-on the lock-out feature, press and hold the
Power button for 5 seconds. All functions (Ambia LED light and heaters) will maintain their original state of ON or OFF.
To turn-off the lock-out feature, press and hold the Power button for 5 seconds. All functions (Ambia LED light and heaters)
will maintain their current state of ON or OFF. Users will have access again to turn ON-OFF the various functions.
If the Power button is pressed during a lock-out condition, activating the emergency shut-down or interrupt feature,
the Ambia LED light and heaters will be turned-off . All icon button lights will be OFF, except for the TUUCI logo.
Heater Automatic Turn O Safety Feature
As a safety feature, the heaters on the Automated Umbrella will automatically turn off after 2 hours of operation.
To turn the heaters back on, press the heater icon button.
LIGHT AND HEATERS FEATURES AND FUNCTIONS
