TUYA TC-C1 User manual

Access Control
Quick Start Guide

Statement
For More Help
To the maximum extent permitted by law, the products described in this manual (including hardware, software,
firmware, etc.) are provided as they are. There may be defects, errors, or malfunctions. This manual is for
guidance only. The graphics, icons, and illustrations provided in the manual are for explanation and illustration
only. There maybe differences with specific products, please refer to the actual product. The company does not
provide any form of express or implied guarantee, including but not limited to guarantees of marketability,
quality satisfaction, suitability for specifice purposes, and non-infringement of third-party rights, nor does
it prodive any special guarantees caused by the use of this manual or the company’s products. Incidental,
incidental or indirect damgaes, including but not limited to loss of businiess profits, loss of data or documents.
If you connect products to the internet, you need to bear your own risks, incuding but not limited to, the product
may suffer from hacker attacks, virus infections, network attacks, data leakage, etc. The company does not
assume any major or related responsibility for product failure, abnormality, information leakage and other is
sues caused by this. However, the company will provide users with product-related technical support.
When you use this product, you will collect, store, and use important personal information. As the data controller,
when collecting, storing, and using personal information, please follow the relevant laws and regulations
applicable to the protection of personal privacy. The company is not responsible for all personal and property
losses caused by misuse of personal data.
The company’s products have encrypted personal biometric information. Its characteristic value cannot be
restored to an image.
Please observe the laws and regulations of the place of use when using the product. If this product is used to
infringe the rights of a third party or other improper purposes, the company will not bear any responsibility.
If the content of this manual conficts with applicable laws, the legal provisions shall prevail.

Product Introduction
This product is controlled and set by Tuya APP. It can realize remote open, staff
access management, abnormal message prompts, temporary visitors password,
etc.
Product Appearance
Relay2
Relay1
LED
Interface
Antenna
Tamper
Switch
Door-Magnet
Exit Button
Temper Switch
Power

Temporar y Code
Password suppor t digits
Working Voltage\Cur rent
Processor
Recognition Speed
Lock Control Output
Temper Switch
Exit Button
Door Magnet Input
Verification Type
Working Environment
Install Type
Communication Mode
6Bit
Alar m Output
Material
Item
Users
Parameter
IP Grade
ABS, aluminum alloy, toughened Glass
DC12V±10%\2A(Non-loaded)
High-performance dual-core ARM chip /ISP/NPU
<0.5s
1000
Card/Password/Card+Password
10
1
1
1
1
1
-20℃-60℃ /10%-90%
IP53
Wall
Size L214XW166XH50mm
WiFi/Bluetooth
1Download and install Tuya APP.
2Turn on the permission of the APP to use bluetooth.
3Open the APP's permission to use the local area network and cellular network.
4Create a family to better manage devices.
2:24
JACK
86-135123456 78
Third-Party Voice Services
Home Management
Message Center
FAQ & Feedback
Homekit Information
Alexa
More
Google
Assistant
SmartThings
4
Home S cen e Sm art M e
Preparation
2
Please search for "Smart Life" in the APP
store, download and install, or scan the QR
code below to download and install directly.
Note: The interface used in this manual is
for illustration only, please refer to Tuya
APP.
Smart Life
Function Parameter

Relay2
Relay1
LED
Interface
Antenna
Tamper
Switch
Door-Magnet
Exit Button
Temper Switch
Power
3
4
Access Control×1 Light board cable×1
Packing List
The Interface Definition
Quick Satrt Guide×1 Antenna×1

V+
V-
NO COM
NC
Black
Red
Green
White
If need a sound pr ompt, please
connect blue a nd yellow
GND
L
N
OUTPUT：
AC 90~260V
50/60Hz
L
N
Danger of strong
electricity!
INPUT：
DC 12V
3A
GND
Temper Switch
Lock
Door-Magnet
Exit Button
Power
If need a sound pr ompt, please
connect blue a nd yellow
Black
Red
Green
White
Note：
● Please read this manual carefully before starting the installation.
● The distance from the card reader to the controller should not exceed 60 meters.
● Be sure to install the ground wire of the power supply.
● Avoid damp, strong electromagnetic environment, outdoor bare leakage places.
War ning：
● Please do not use the power supply that comes with this product to power the lock.
It is attendance only.
● Please do not connect the wires when the power is on.
● Please strictly comply with the national and regional electrical safety regulations.
● If you have any problem with the product, please contact the device seller.
Do not disassemble or modify this product without permission.
5
Name Status Caption
Light
Light once
Normal power supply
Searching the internet
Network search successful, waiting
for binding
Binding succeeded
Equipment Run
Read the card or p assword or unbind
successful ly.
Flashing red
Flashing blue
Green light is
always on
Flashing
Light once
Light once
Relay 1 action
Relay 2 action
A short beep
Two short beeps
Sound⑴Valid, allowed to pass
Invalid, not allowed to pass
Unbind and clear data successfully
APP operation is successful
Description of indicator lights and sound prompts
A long beep
Three short be eps
⑴
Sound :This function requires the use
of a card reader, please connect the BUZ
port of the controller to the indicator light
and sound controller line of the card reader.
The product picture is for reference, if any
difference, please refer to the actual
product.
Wiring of Access Control Function

6Add Device
2:24
Home S cen e
2:24
Cancel
Choose Wi-Fi and enter password
WIFI-AA
Next
2
2
3When the CON light of the device is flashing
blue, the APP will automatically search for the
device.
5
4
1
1Click the icon in the lower left corner of the screen to
enter "Home".
2Users can manually add devices in these two places
on the "Home" page.
4Select the WIFI that will be used. Note: The
WIFI used must be the same as the WIFI used
by the mobile phone.
5Fill in the WIFI login password.
2:24
Found 1devices，Added 0 successful ly
Smart Access Control
6
6Log in to WIFI and wait for binding.
2:24
Device to be added：1
Smart Access
Control
Add
Add Device
3
No devices
Smar t Me

3Click the Device Information button in the
upper right corner of this interface.
2"Remove device" in this interface is to
delete the device from the device list and
no longer control and use it. But the device
has not been unbound. Cannot be bound by
other users.
1
Home S cen e Sm art M e
All Devices
1Click the device in the device list to
enter the "A" interface. Long press
the device to enter the "B" interface.
2:24
Added
Smart Access Control
Device a dded s ucces sful ly
Done
8
9
2:24
Found 1devices，Added 1 successfull y
Smart Access Control
7
8Finish adding.
9A good name for the device can be better managed.
7Binding succeeded.
6
7
完成
Remove device
Add Device
Rem ove D evice
Smart Access Control
2:24
A1 Selected
2
Done
2:24
Smart Access Control
Press to unlock
Closed
Access control1
User Add te mpo rar y
code
Atte nda nce S ett ing
2
03/14 14 :25 A Open Acces s cont rol1
B3

2When an exception occurs when the device is used for the first
time, please turn on "Multiple Verification". Then use "Select
unlock mode" in "Unlock by single mode" and then turn off
"Multiple Verification". If the door cannot be closed automatically,
please turn on "Automatic lock" and set the "Auto lock Time 3s".
1Click the "Setting" interface to set some
parameters of the device.
4"Remove device" in this interface is to
unbind, and the unbound device can be
bound and used by other users. Please
note the distinction.
8
Smart Access Control
2:24
Device Information
Device Offline Notification
Offline Notification
Others
Check Now
Remove Device 4
Tap-to-Run and Automation
Share Device
Create Group
FAQ & Feedback
Add to Home Screen
Check Device Nerwork
Device Upadte No updates available
2:24
Smart Access Control
Press to unlock
Closed
Access control1
User A dd te mpo rar y
code
Atte nda nce S ett ing
2
03/14 14 :25 A OpenAcces s control1
1
2:24
Door keep open
Setting
Remote unlock setting
Permission settings
Passage set
Automatic lock
Auto lock time
Multiple verification
Unlock only by g roup mode if switch on
Open speed
Open rate
Alarm time
Ringtone
Doorbell volume
Language English
2s
0%
2
2
Permission all
Open speed sta te low
Doorbell vol ume mute
Ringtone sou nd 1
Setting Device Parameter

2Click the "+" button to add a new person.
1
Click the "User" button on the device interface
to enter the personnel management interface.
1Click the circular icon to open the door remotely. The device needs to match the key
when using it for the first time. If it fails, please try again.
10
9
10
2
2This icon is displayed to indicate
that the door is open.
3Access and usage records can
be found here.
2:24
Smart Access Control
Press to unl ock
Close d
Access control1
User A dd te mpo rar y
code
Atte nda nce S ett ing
2
03/14 14 :25 A OpenAcces s control1
1
3
Access control1
Open
Press t o loc k
Remote control
2:24
Smart Access Control
Press to unlock
Close d
Access control1
User A dd te mpo rar y
code
Atte nda nce S ett ing
2
03/14 14 :25 A OpenAcces s control1
1
2:24
Member
user Name/account
Administrator
AOwner
86-13512345678
00000
2
Ordinary member
Add User & Card

6After swiping the card within the specified time,
the RDOK indicator will light up once the card
is swiped.
5With the card ready, click "Start Add".
4Click "Add Card" to add a card to the person. 3Enter the basic information of the personnel,
and go to "Next" after completion.
2:24
Add user
Cancel Next step
User name A
135123456789
3
Country/area
User account
Administrator
Administrators can manage devices and members,but
members can only read unlock & alarm records
2:24
Face
Fingerprint
Code
Card
Telecontrol
De l e te u ...
Add
Add
Add
Add
Add
A
86-13512345678
A d m i n i s t r a t o r
4
2:24
How to add the card
Put card on recognition area as shown in t he figu re.D o not re move t he
card until the lock indicates th at the c ard is a dded . If the c ard is n ot add
in 30s,the card fails to be added
Start add
5
2:24
Add card
Keep card at given time and sensing area till
feedback done.
56s
Cancel
6

7Add complete.
For other functions, please refer to Tuya APP. Please take Tuya APP as allow.
2:24
Done
Add success
Card name
Card1
7
