TV One CM2-547-MK2 User manual

Firmware versionV600and above
PDF-CM2-547-MK2-V1.0
Sep 2023
CM2-547-MK2 CORIOmaster2™ MK2
CORIOgrapher™ V4.0 and above
User Guide V1.0

In this guide
Welcome 1
Get to know your products 2
About your CORIOmaster2™ MK2 3
Show me an example 4
About modules 6
Input modules 6
Output modules 6
Bonding modules 7
Audio modules 7
Power supply module 7
Adapters 7
About your Streaming media and 4K playback input module 8
About your HDBaseT input module 9
About your HDMI input and output module 10
8HD Player – Synchronized playback mode 11
FTP Server media synchronization 15
AES file decryption 17
About your S/PDIF and analog audio module 18
What's breakaway audio? 18
Hardware recommendations 19
Get help with your Magenta Encoder-100 19
Set it up 20
Planning and installing video installations 22
Planning a video installation 22
What is a window? 23
What is a preset? 23
Installing your hardware 23
Setting up a video installation in CORIOgrapher™ 26
CORIOgrapher™ system requirements 26
About CORIOgrapher™ 27
Getting started with CORIOgrapher™ 28
To connect to your CORIOmaster2 and get its configuration 28
To log in with secure mode 29
To create a configuration offline 29
To send a configuration to your CORIOmaster2 30
Naming input and output ports and channels 30
Naming the channels of a Streaming media and 4K playback input module 30
Enabling secure mode 32
About HDCP 33
Keying windows on your CORIOmaster2™ 37
Source-linking on your CORIOmaster2™ 40

Editor tools 44
Markers 44
Guildlines 46
Canvas grid 48
Snapping options 48
Shrink or grow a window 49
Creating a video installation 50
Do I want Synclock or Framelock? 50
Do I want a dedicated window or a free window? 52
What are window qualities? 52
Testing your video installation 54
Set up and test audio 55
Settings 57
Device settings 58
Naming your CORIOmaster2™ 58
Choosing your working units 58
Customizing the front panel of your CORIOmaster2™ 59
Backing up and restoring your settings 59
Backing up your settings on your CORIOmaster2 59
Restoring your settings from your CORIOmaster2 60
Backing up your settings to a file on your computer 60
Restoring or copying settings from a file on your computer 61
Problems sharing settings between CORIOmaster2 units 61
Resetting your CORIOmaster2™ to factory default settings 61
User settings 62
Creating and editing users 62
What are user roles? 62
Why set a timeout time? 63
Changing other users' passwords 63
Changing your own password 64
Network settings 64
Configuring network settings for your CORIOmaster2™ 64
Configuring network settings for streaming media 66
About static IP addresses 66
To configure network settings for streaming media 66
Finding the MAC address of your Streaming media and 4K playback input module 67
Playlist settings 68
Renaming playlists and moving playlists between modules 68
Deleting playlists 68
Managing encoders and streams 69
Resolution Editor 71
About custom resolutions 71

Creating and editing custom resolutions 71
Using your CORIOmaster2™ 75
Presets 75
Creating and editing presets 76
What is a preset? 76
What is included in a preset? 76
What is not included in a preset? 76
For best results 76
Creating a new preset with all windows 78
Creating a new preset with windows that are selected on the canvas 78
Creating a new preset and choosing which windows to include 79
Edit a preset in the preset editor 80
Previewing changes on the device while editing a preset 81
Quick edit, overwrite, cloning, and deleting presets 82
Loading a preset 83
What is a preset? 83
Loading a preset from CORIOgrapher 83
Show me some preset scenarios 84
Adding more windows with existing presets. 86
Enabling or disabling the preset window analyzer 86
Manually updating presets with the new windows 86
Bulk updating presets 87
Changing the source playing in a free window 88
Changing the source in CORIOgrapher from the Properties panel 88
Changing the source in CORIOgrapher from the window 88
Changing the source using the dashboard 88
Using audio 90
Playing embedded audio 90
About embedded audio 91
Disabling and enabling audio for a source or display 91
Choosing what to listen to with CORIOgrapher 94
What's breakaway audio? 94
Choosing which outputs play audio 96
Adjusting input audio level and muting sources 96
Muting individual audio outputs 98
Cutting to black and muting individual outputs 98
Adjusting volume and muting all displays and outputs associated with a canvas 99
Cutting to black and muting all displays and outputs associated with a canvas 100
Controlling audio from the dashboard 101
Emergency cut to black and mute 101
Media and streams 102
Playing media and streams 102

Before you start 103
Adding and editing media streams 103
Adding media items, streams, and playlists to your play queue 105
Playing a multicast stream from an Magenta Encoder-100 on multiple CORIOmaster2
units 106
Changing the duration of media items 107
Playing streams with low latency 108
Using the playback controls 109
Managing the play queue 110
Saving the play queue 111
Show labels for media and streams 111
Playing the play queue automatically 112
Saving media to internal storage 112
Creating and managing playlists 113
About playlists 113
Creating a new playlist 114
Saving the play queue to a playlist 115
Managing and editing playlists 116
Deleting a playlist 118
Moving playlists between modules 118
Deleting all playlists 118
Duplicating playlists 119
Using the internal drive 120
Replacing all items on the internal drive with all items on the USB drive 120
Removing all items from the internal drive 121
Current location 121
Copying a single item or folder to the internal drive 121
Managing media on the internal drive 121
Playing items from the internal drive 122
Choosing the best resolution for your playlist or play queue 123
Understanding the format of resolution 123
How do I know what resolution my media items are? 123
Replacing a module 124
Removing an input module from your CORIOmaster2™ 125
Inserting an input module into your CORIOmaster2 125
Removing an output module from your CORIOmaster2™ 126
Inserting an output module into your CORIOmaster2 126
Adding and managing custom EDID files 127
Before you start 127
Adding a saved EDIDfile 127
Removing EDIDfiles 127
Troubleshoot it 128

Checking and updating the firmware of your CORIO device 129
Checking your firmware version and downloading new firmware 129
Updating the firmware 130
I can't see my CORIOmaster2™ in the Discovered Devices list 131
I can't log in to CORIOgrapher™ 133
What do the error codes on the front panel mean? 133
Why is my window pixelated, or looks blurry when Iselect a window source? 134
My Streaming media and 4K playback input module keeps overheating 134
I can't hear any audio 136
General problems with audio 137
Audio from the Streaming media and 4K playback input module 141
If that doesn't work 142
I can't update the firmware of my Streaming media and 4K playback input module 143
General troubleshooting checklist 144
Returning a product for repair 144
What are the minimum requirements for running CORIOgrapher? 144
What's the password for my CORIOmaster2™? 145
Do I need output bonding modules? 145
Show me an example 145
Can I use HDMI extenders with CORIOmaster2™ output modules? 146
How large is the internal storage on a Streaming media and 4K playback input module? 146
How do I find the MAC address of my Streaming media and 4K playback input module? 146
How fast is my connection to the Streaming media and 4K playback input module? 146
Which media formats can I add to a play queue? 146
Can I save my play queue? 146
How do I mute audio? 147
More 149
What's new in CORIOgrapher™ V4.0 for CORIOmaster2™ 149
Regulatory compliance for CORIOmaster2™ and all modules 149
Contact us 150

Welcome
Welcome to tvONE Help, the place to get help with your:
nCORIOmaster2™
nCORIOgrapher™
Get more help
You can read more online. To open the online help, select Helpin CORIOgrapher, or visit help.tvone.com/r/docs/cm2-
mk2/home/1.
Meet CORIOmaster2
CORIOmaster2 connects to a wide range of sources and displays, and works with CORIOgrapher™ software to
allow you to build dynamic video installations with an easy-to-use visual interface.
Features
Output to monitors, LED screens, and projectors, including devices that support 8K with quad 4K @60Hz
Source-linking, synchronized sources stitched together making an 8K source from 4 x 4K sources.
Our largest ever creative canvases at 64,000 x 64,000 pixels
Consumes less electricity than an equivalent PC based system
Wide range of inputs, including HDMI, DVI, SDI, HDBaseT™, 4K, and streaming media
Supports 4:4:4, 4:2:2, or 4:2:0 chroma subsampling on supported modules
Supports up to HDCP 2.2 on supported modules
Embedded and S/PDIF audio support with S/PDIF audio module
New front panel status screen
Combination of different size and resolution of displays can be used
Adjustable bezel compensation
Edge blending of projectors
Up-down-cross conversion
Window luminance keying supported on all modules
Control your video wall with CORIOgrapher, secure IP, or serial connection
HTTP and HTTPS connectivity, RESTful multi-user control, WebSocket event monitoring
Horizontal alignment on analog PC inputs
Crestron module available
CORIOmaster2 MK2: 4RU frame size, 12 Gigapixel, up to three video walls
Meet CORIOgrapher
CORIOgrapher V4.0 is packed with features to help you create and manage your video walls.
Simple, powerful, software interface
Save window configurations as presets and transition between presets
Rotate outputs in 1° increments
Choose sources for windows
LEDtools, markers, grid, and guidelines to help with building and organizing canvases.
Manage streaming media
Use custom resolutions, and manage EDIDdata
See your changes instantly with live changes mode
Undo and redo your work
Control audio, configure labels, borders, and colors
Position your displays and windows with pixel-precision
PDF-CM2-547-MK2-V1.0 tvONE 1

Get to know your products
Learn about the features and functions of your hardware.
In this section
About your CORIOmaster2™ MK2 3
About modules 6
About your Streaming media and 4K playback input module 8
About your HDBaseT input module 9
About your HDMI input and output module 10
8HD Player – Synchronized playback mode 11
FTP Server media synchronization 15
AES file decryption 17
About your S/PDIF and analog audio module 18
Hardware recommendations 19
Get help with your Magenta Encoder-100 19
PDF-CM2-547-MK2-V1.0 tvONE 2

About your CORIOmaster2™ MK2
CORIOmaster2 connects to a wide range of sources and displays, and works with CORIOgrapher™ software to
allow you to build dynamic video installations with an easy-to-use visual interface.
Slots
Your CORIOmaster2 has 17 slots.
Slots in area A are for input modules, slots in area B are for output modules. You can have up to eight input
modules and up to seven output modules.
Slot 13 is for an S/PDIF and analog audio module, CM2-AUD-2IN-3OUT
Slot 14 is for a CPU module.
Rules for placing input modules
Standard bandwidth input modules can go in any position in column A and B, slots 1, 2, 4, 5, 7, 8, 10, and 11.
High bandwidth input modules can only go in column B, slots 2, 5, 8, and 11.
Risk of damage
Do not insert high bandwidth input modules in column A. The device and module can be damaged. If you are unsure contact
your distributor.
Standard bandwidth module connector High bandwidth module connector
Rules for placing output modules
PDF-CM2-547-MK2-V1.0 tvONE 3

Output slots are arranged into groups. Each group has the same amount of bandwidth. You must either:
nFill all the slots of a group with modules
You can either fill all the slots with output modules, or you can fill empty slots in the group with bonding
modules.
OR
nLeave all the slots of a group empty
You don't need to use bonding modules in groups that contain no output modules.
Place output modules in the first slot of each group first, starting with group C, slot 17. Fill empty slots with
bonding modules.
Groups are linked by bandwidth and also by canvases in CORIOgrapher. You can only use the outputs in a
single group together on the same canvas. You can use more than one group on the same canvas, but if you
want to use more than one canvas, you must use more than one group.
Show me an example
A CORIOmaster2 has two output modules. The first output module goes into group C, slot 17. The second
goes into group A, slot 3. Bonding modules go into group A, slots 6 and 9. Group B contains no output
modules, so it doesn't need any bonding modules.
CORIOmaster2 front panel
The front panel of your CORIOmaster2 includes a customizable status screen. The status screen can show the
IP address of your CORIOmaster2, its status, and the name of the device.
PDF-CM2-547-MK2-V1.0 tvONE 4

CORIOmaster2 rear panel
Input module (blue) Connect to sources
Output module (white) Connect to displays
Bonding module Used to fill empty slots in a group
Optional audio module Optional: connect to audio sources and/or playback
devices
CPU module
Connect to your network with Ethernet
Optional: connect to serial controller with RS-232
Optional: connect directly to a PC with Ethernet or RS-232
Power supply unit (PSU) Connect to electrical outlet
Optional second PSU, sold
separately Optional: connect to electrical outlet
PDF-CM2-547-MK2-V1.0 tvONE 5

About modules
CORIOmaster2 supports a range of input and output modules, with model numbers starting with CM2-. Each
module supports specific connections, but our range of adapters means you can connect almost any type of
source to your CORIOmaster2.
See our range of available input and output modules for your CORIOmaster2 at help.tvone.com/r/docs/cm2-
mk2/modules/1.
Input modules
Module Product number Connections
Quad 3G-SDI broadcast input
module
CM2-3GSDI-4IN 4 x 3G-SDI up to 1080p @60 Hz
Dual DVI-U input module CM2-DVIU-2IN 2 x DVI-U up to 1080p @60 Hz
HDCP 1.4 compliant
Quad 1080p HDMI input module
Read more about HDMI modules
on page 10.
CM2-HDMI-4IN 4 x HDMI up to 1080p @60 Hz
HDCP 1.4 compliant
Dual 4K HDMI input module
Read more about HDMI modules
on page 10.
CM2-HDMI-4K-2IN 2 x HDMI
HDCP 1.4 compliant
Supports up to 2x4K@30 Hz, or
1x4K@60Hz
Quad 4K HDMI input module
(high bandwidth)
Read more about HDMI modules
on page 10.
CM2-HDMI-4K-4IN 4 x HDMI up to 4K @60 Hz
Supports 4:4:4, 4:2:2, or 4:2:0
chroma subsampling
Supports up to HDCP 2.2
Dual 4K HDBaseT input module
Read more about the HDBaseT
module on page 9.
CM2-HDBT-2IN-1ETH 2 x HDBaseT
Ethernet
HDCP 1.4 compliant
Streaming media and 4K playback
input module
Read more about the Streaming
media and 4K playback input
module on page 8.
CM2-AVIP-IN-1USB-1ETH-128 1 x USB 3.0
1 x Ethernet
1x 128 GB SSD
Supports up to 2x4K@30 Hz, or
1x4K@60Hz
Output modules
Module Product number Connections
Quad 4K HDMI output module
Read more about HDMI modules
on page 10.
CM2-HDMI-4K-4OUT 4 x HDMI up to 4K@60 Hz
Supports up to HDCP 2.2
Octad HDMI output module
Read more about HDMI modules
on page 10.
CM2-HDMI-HD-8OUT 8 x HDMI up to 1080p@60 Hz
Supports up to HDCP 2.2
PDF-CM2-547-MK2-V1.0 tvONE 6

Bonding modules
Module Product number
Output bonding module for CORIOmaster2 output modules. CM2-BONDING
Read more about output bonding modules on page 145.
Audio modules
Module Product number Connections
S/PDIF and analog audio module
Read more about the S/PDIF and
analog audio module on page 18.
CM2-AUD-2IN-3OUT Input:
1 x analog and 1 x S/PDIF
Output:
1 xanalog and 3 x S/PDIF
Power supply module
Module Product number Connections
Redundant PSU for 4RU series
units
CM2-4RPS 1 x IEC power cord
Redundant 700W PSU for 4RU
series units
CM2-4RPS-700 1 x IEC power cord
Adapters
You can use our adapters to connect any of the following formats to the DVI modules.
Adapter Product number Female connector
HDMI adapter CMD1941 HDMI
Analog PC adapter ZDH-2040 VGA
Analog RGBHV adapter ZDB-2038 Analog RGBHV
YPbPr/YUV adapter ZDR2042 YPbPr/YUV
YC (S-Video) adapter ZDB2048 2 x composite video
YC (S-Video) adapter ZDS2046 4-pin mini-DIN
Composite video adapter ZDC-2050 BNC
PDF-CM2-547-MK2-V1.0 tvONE 7

About your Streaming media and 4K playback input module
The Streaming media and 4K playback input module allows you to decode and play:
nMedia and images from a USB drive
nMedia and images from internal storage
nVideo streams from IP sources.
Sources include streaming server, and any device used with an IP encoder, for example, the Magenta™
Encoder-100.
Features
nPlay two simultaneous channels of media, including IP streams
nPlay video clips from USB drive up to 4K@30Hz
nPlay single IP streams up to 100 Mb/s
nPlay dual IP streams up to 40 Mb/s
nPlay still images up to 8K
nPlay streams with low latency
nPlay media from streaming server
nCreate and save up to 20 playlists
nPrimary channel supports up to 4K@30Hz
nSecondary channel supports 1080p@60Hz
nIP streams up to 4K@30Hz
nSave up to 40 IP streams
nFull resolution and frame rate scaling
nStart playing media when your device starts
nSupports USB 3.0
n8HD Player mode for synchronized playback of 8x 1080/30 fps files into 2x 4K @30 Hz inputs
nIP and Media playback labels
nFTP synchronization for media files
nSupport AES CBC encrypted streams with 128 or 256 bit keys
For CORIOmaster2™, CM2-AVIP-IN-1USB-1ETH-128 comes with 128 GB internal storage
USB
(LED)
Indicates the status of the USB drive. Green means that the USB drive is working correctly.
Red means that the USB drive is over current.
USB3.0
USB2.0
Connect a USB drive to play media directly.
For best results, we recommend using quality USB drives compatible with USB 3.0.
ST1(LED) Indicates the status of the module. Green means that the module is working correctly. Red
means that the module is starting, or that there is a problem.
ST2(LED) Indicates the status of the sub-module. Green means that the sub-module is working
correctly. Red means that the sub-module is starting, or that there is a problem.
LAN Connect an Ethernet cable to play media over IP.
If any status indicator stays red , restart your CORIOmaster2™. If that doesn't work, contact tvONE support.
Contact details are at the back of this guide.
PDF-CM2-547-MK2-V1.0 tvONE 8

About your HDBaseT input module
The 4K HDBaseT™ modules allows you to receive uncompressed, high-resolution 4K video and audio from
stand-alone transmitters located up to 150m away. The input module also allows you to extend Ethernet to
remote transmitters that support HDBaseT Class A and HDBaseT Class B.
See our range of active optical cables and signal extenders at help.tvone.com/r/docs/g/signal-extension
Features
nHDBaseT Class A to 150m
nHDBaseT Class B to 60m
n1x channel 4K60 or 2x channels 4K30 or below
nAudio support
Status
indicator
(LED)
Indicates the status of the module by the LED directly below the middle RJ45 connector. Green
means that the module is working correctly. Red means that the module is starting, or
that there is a problem. Off means the module is powered down.
Ethernet
links
(LED)
Two LEDs built into the middle RJ45 connector.
nLeft LED Ethernet Link/Activity.
nRight LED Ethernet speed, off for 10 Mbps or green for 100 Mbps.
HDBaseT
link
(LED)
Indicates the link status by the LED directly below the left and right RJ45 connectors.
There is a green LED for the HDBaseT status and red LED for the HDMI status, they can
combine to make orange.
LEDstatus patterns No Link Ethernet
Fallback
HDBaseT
No HDMI off fast green/off green
HDMI with HDCP red orange/off orange
HDMI without HDCP red/off orange/red/off orange/green
If any status indicator stays red , restart your CORIOmaster2™. If that doesn't work, contact tvONE support.
Contact details are at the back of this guide.
PDF-CM2-547-MK2-V1.0 tvONE 9

About your HDMI input and output module
The High-Definition Multimedia Interface (HDMI™) modules are a proprietary audio/video interface for
transmitting uncompressed video data and compressed or uncompressed digital audio data from an HDMI-
compliant source device.
See our range of active optical cables and signal extenders at help.tvone.com/r/docs/g/signal-extension
STATUS
(LED)
Indicates the status of this module. Green means that the module is working correctly. Red
means that the module is starting, or that there is a problem. Off means the module is
powered down.
If any status indicator stays red , restart your CORIOmaster2™. If that doesn't work, contact tvONE support.
Contact details are at the back of this guide.
What does the status LED under the HDMI connector mean?
HDMI
(LED)
Indicates the status by the LED directly below the HDMI connectors on supported modules.
LEDstatus patterns
off No signal
green Valid signal with HDCP 2.2
green/short off Valid signal with HDCP 1.4
orange Valid signal without HDCP
red HDCP problem
red/off Fault or unrecognized resolution
PDF-CM2-547-MK2-V1.0 tvONE 10

8HD Player – Synchronized playback mode
The streaming media and 4K playback module has two different operating modes.
The 8HD player is designed to play up to 8x 1080p30 media files from the module's internal drive. Playback
will occur in perfect synchronization into each of the four quadrants of a UHQ (4K) window and in this mode
two of these windows are available to place on a canvas.
For example four files are shown with one 4K30 window. A media file has been cut in to 4x 1080p30 files.
In synchronized mode the windows placed on the canvas from the module are as shown. The window is
separated in to four quadrants by dotted lines and the quadrants are numbered from 1 to 4 on the first
window and from 5 to 8 on the second window.
How to change the operating mode?
1. To change the operating mode in CORIOgrapher, select Settings >Module Configuration
2. Find the Streaming media and 4K playback module that you want to set up, and select > Configure
PDF-CM2-547-MK2-V1.0 tvONE 11

3. Change the operating mode from Standard to Synchronized.
4. Select Save and close to change operating mode.
5. The Streaming media and 4K playback module will reboot into the synchronized mode.
How do Isetup and play my media?
To playback the files we must set up at least one synchronized group.
1. Double-click the window you wish to play media, and from Properties, select (Media Player) Manage.]
2. Select Synchronized Groups then + Add synchronized group
PDF-CM2-547-MK2-V1.0 tvONE 12

3. Give your group a name (must be unique and max of 64 characters)
4. Drag and drop files from your Internal Drive to each empty slot (up to 8)
The files can be in any order in the group, but they will play back into the quadrant for the number selected, for example a
clip placed in position 8 will playback in the quadrant numbered 8.
5. Synchronized groups can now be added to a playlist
PDF-CM2-547-MK2-V1.0 tvONE 13

Notes about playing media
nMedia files should be the same resolution and frame rate
nIdeally, they should be from the same source, for example a video belt, but they can be different files.
nThe longest file will determine playback time for the group and if there are shorter files the window will
hold the last frame until the last file has finished playing before moving to the next synchronized group in
the playlist or repeat if you have that option selected.
nThe files should have the same presentation timestamps (PTS) to be frame synchronized for playback.
nAudio for the window is taken from the clip in position 1 only
nOnly synchronized groups can be added to a playlist (not individual media files or stills)
nSynchronized groups can only be added to a play queue when the module is in synchronized mode.
How to position displays and windows?
For example displays 1 through 4 must be physically placed under the correct window quadrant on the
canvas for the content to playback into the correct display.
The displays must be positioned physically under the window content as the window cannot be split in to
separate parts.
Four 1080p30 files can playback in to one 4K30 window.
PDF-CM2-547-MK2-V1.0 tvONE 14
