Dear friend,
Thank you for choosing the all new TVS StaR City+, the StaR of Style.
As a proud owner of TVS StaR City+, you are now a part of a family of millions of satisfied TVS customers.
Your StaR City+ comes with all new urban designer styling which makes it much more chiseled, muscular and
exudes definitive road presence that signals your arrival in Style, because great Style never goes out of Style!
The all new styling, coupled with never before features and an all new advanced 110cc EcoThrust engine makes
your StaR City+ stand out and gives it a definitive edge.
This manual explains the features and operations of your TVS StaR City+. Please read it carefully and follow the
instructions to enjoy years of safe riding.
To ensure reliable performance, we urge you to get your TVS StaR City+ serviced only at TVS Motor Company
Authorised Main Dealers / Authorised Dealers at specified regular intervals.
Happy Riding!
TVS MOTOR COMPANY LIMITED
FOREWORD
FOREWORD
-II-

NOTICE
-III-
NOTICE
This manual should be considered as a permanent part of the motorcycle and should remain with the motorcycle
when resold or transferred to a new owner.
All information, illustrations, photographs and specifications contained in this owner’s manual are based on the
latest product information available at the time of this publication. TVS Motor Company Limited may, however,
incorporate modifications or improvements on its vehicles at any time without notice, and therefore, in such
events it is possible that the relevant part of the owner’s manual does not apply to your vehicle.
Prior permission of TVS Motor Company Limited is required for quoting, copying or reproducing any part of this
owner’s manual.
Note
Accessories shown in the picture may not be part of the standard equipment.
Pictures shown in this manual are of TVS StaR City+ Electric Start version
Part Number :- NA210010 Revision 0, April 2014

Safety information 01
Running-in information 02
Safe riding tips 03
Know your TVS StaR City+ 07
Riding your TVS StaR City+ 24
Maintenance 29
Warranty and services 48
Technical specifications 60
General information 63
CONTENTS
CONTENTS
-IV-

SAFETY INFORMATION
SAFETY INFORMATION
Operating this vehicle safely is an important responsibility of the rider. To help you make decisions about safety,
we have provided operating procedure and other information in this manual. This information alerts you on
potential hazards that could hurt you or others. Since it is not possible to warn you about all hazards associated
with operating or maintaining the vehicle, you must use your own judgement.
You will find important safety information in following form in this manual. These words carry the following
connotations:
Warning
Disregarding this message might result in injury to the rider.
Caution
This message indicates special procedures or precautions to be followed to avoid damage to the vehicle.
Note
This message provides further clarification for clear understanding of any particular information.
-1-

The first 1000 km is a crucial part of your motorcycle. Proper running-in operation during this period helps in
ensuring a maximum life and smooth performance of your motorcycle.
The reliability and performance of your motorcycle depends on the special care and restrain exercised during the
running-in period. It is especially important that you avoid operating the engine in high speed (RPM), which could
expose the engine parts to excessive stress. Maximum recommended speed during the running-in is:
Maximum 50 kmph speed upto 1000 km (vary the engine speed for better mating of parts).
The first free service at 500 ~ 750 km is most important. During running-in period all the engine components and
other parts will have set in. All adjustments to be restored, all fasteners to be tightened. Engine cum transmission
oil to be replaced. Timely performance of the first free service will ensure optimum service life and performance
from the engine.
Caution
Replacing the engine cum transmission oil during first free service is most important for better life of engine.
Always use TVS TRU4 PREMIUM oil (SAE 10W30 SL-JASO MA2) for better performance and life.
RUNNING-IN INFORMATION
RUNNING-IN INFORMATION
-2-

SAFE RIDING RECOMMENDATIONS
Any two wheeler riding requires some precautions to be taken to ensure the safety of the rider, pillion and other
road users. These precautions are:
Familiarise yourself with new TVS StaR City+
Riding skill and your mechanical knowledge form the foundation of safe riding practices. We suggest you to
practice riding TVS StaR City+ in a low-traffic condition until you are thoroughly familiar with your vehicle and its
controls. Remember practice makes you perfect.
Riding apparel
Loose, fancy clothing can be uncomfortable and unsafe when riding a two-wheeler. Choose good quality two
wheeler riding apparel.
Know your limits
Ride within the boundaries of your own skill at all times. Knowing these limits and staying within them will help
you to avoid accidents.
Warning
Two wheeler safety equipment starts with a safety helmet of good quality. One of the most serious injuries
that can happen is a head injury. Always wear ISI approved helmet. You should also have good suitable eye
protection.
SAFE RIDING TIPS
SAFE RIDING TIPS
-3-

Posture
Proper vehicle riding starts with proper posture.
1. Sit erect on the seat at the position which you
feel most comfortable.
2. Keep your arms relaxed to give extra cushion
for body on uneven road surfaces.
3. Keep right arm and foot close to the brake lever
and pedal, so as to enable fast action during
panic braking.
4. Look widely instead of gazing at one point.
5. Alter your sitting location/posture slightly at
intervals during long rides. This will reduce
fatigue.
Cornering
When cornering, centrifugal force works in a
direction perpendicular to the direction in which
the vehicle is moving. Centrifugal force increases
in proportion with speed and the radius of the
corner.
During cornering, reduce speed so as to lessen the
effects of centrifugal force. By all means, avoid
abrupt application of brake or sudden steering.
SAFE RIDING TIPS
SAFE RIDING TIPS
Warning
One-hand riding is dangerous. Keep both hands
firmly on the handle bar and both feet securely on
the foot rest. Under no circumstances should both
the hands be removed from the handle bar, as it is
very dangerous.
Avoid use of mobile phones while riding as it
could lead to fatal accident.
Do not downshift the gear in the midst of
cornering. Slow down to a safe speed before
negotiating a corner. If this is the first time that you
are riding a vehicle of this type, we suggest that
you practice on a safe, open area to become
thoroughly familiar with the operation of the
vehicle.
-4-

Braking
For safe riding, it is very important to master the
braking techniques.
1. Close / release the throttle.
2. Hold the vehicle upright as you apply the brake.
3. Progressive application of brake is safer.
4. Never depress the clutch lever while braking at
higher speeds.
5. Apply both the brakes.
6. Riding down hills, while cornering and wet
roads, close the throttle and down shift the
gear to take advantage of gearbox and engine
which acts as an additional brake. This will
avoid the loss of control over the vehicle due to
over speed.
Causes for poor braking
1. If the brake shoes / pads or drum / disc are worn
out or if there is water or oil on them, sufficient
friction does not develop and brakes do not
work well.
2. Even when the brake works normally, if the
road surface is wet or the tyre surface is
worn-out, tyres do not take a firm hold on the
surface, increasing the stopping distance.
3. Approximately 60% braking effect is from front
brake. Non-usage of front brake causes poor
braking.
SAFE RIDING TIPS
SAFE RIDING TIPS
Warning
As the vehicle speed increases, the stopping
distance also increases progressively. Be sure
that, you have sufficient distance between you and
the vehicle or obstruction ahead of you.
Using only the front or rear brake is dangerous and
can cause skidding and loss of control. Apply both
the brakes together and with great care on a
wet road or other slippery surfaces. Any abrupt
braking on slippery or irregular roads can cause loss
of rider control.
-5-

ACCESSORY INSTALLATION AND
SAFETY TIPS
Use extreme caution while selecting and installing
the accessories for your motorcycle.
The addition of unsuitable accessories can lead
to unsafe operating conditions. Your friendly
Dealer will assist you in selecting quality
accessories and installing them correctly.
While selecting the accessories, make sure the
accessories should not obstruct lighting,
steerability, suspension level and ground
clearance. Please ensure that, if the tank cover is
used, it is not getting en-trapped between fuel tank
and fuel tank cap.
Additional electrical equipments and controls
should not exceed the specified electrical
system load of the vehicle (capacity of battery
and magneto)
EMISSION CONTROL
All the TVS vehicles are tested in the factory for
optimum fuel efficiency and lowest possible CO
levels.
Do not disturb the Carburettor settings as this
may lead to higher fuel consumption and also
higher CO levels.
If the vehicle needs any adjustments, please
consult nearest TVS Motor Company Authorised
Main Dealer or Authorised Dealer.
While adequate care is exercised at the factory to
ensure that the emissions are within the limits, it is
essential for the owner to always maintain the
motorcycle in good condition by getting it
periodically checked and serviced by TVS Motor
Company Authorised Main Dealer or Authorised
Dealer so that the emission and fuel consumption
levels are maintained as per norms.
SAFE RIDING TIPS
SAFE RIDING TIPS
Note
Get your vehicle certified by the Government
authorised emission testing stations at
specified intervals.
-6-

KNOW YOUR TVS StaR City+
KNOW YOUR TVS StaR City+
Please fill the above boxes now for future reference
Frame number
Engine number
Control key number
-7-
The frame serial number is stamped on the left side
of the steering head tube.
Engine serial number is stamped on the top
surface of left side crankcase assembly near
cylinder block.
VEHICLE IDENTIFICATION NUMBER
Serial numbers of both frame and engine are required for vehicle identification. They are also required to assist
your Dealer for operating parts or referring to special information.

1. Choke lever
2. Horn switch
3. Turn signal lamp switch
4. Clutch lever
5. Rear view mirror L
6. Pass by switch
7. High / low beam switch
8. Speedometer
9. Ignition cum steering lock
10. Fuel gauge / ODO meter
11. Rear view mirror R
12. Front brake lever
13. Throttle grip
14. Head lamp switch
15. Electric starter switch*
16. Fuel tank cap
KNOW YOUR TVS StaR City+
KNOW YOUR TVS StaR City+
LOCATION OF PARTS - HANDLE BAR
-8-
* Applicable for electric start model only
9 10
8
5 6 7
12
14
15
16
1
2
3
4
13
11

KNOW YOUR TVS StaR City+
KNOW YOUR TVS StaR City+
-9-
LOCATION OF PARTS - VEHICLE LEFT SIDE
1. Front brake adjuster
2. Front wheel axle
3. Fuel cock
4. Gear shift lever
5. Rider foot rest L
6. Centre stand
7. Side stand
8. Chain inspection window
9. Pillion foot rest L
10. Rear shock absorber L
11. Rear wheel axle
12. Lady foot rest
13. Saree guard
14. Seat lock
1 2 3 4 5 6 7 8 9 12 1310 11
14

KNOW YOUR TVS StaR City+
KNOW YOUR TVS StaR City+
-10-
LOCATION OF PARTS - VEHICLE RIGHT SIDE
1. Front wheel axle nut
2. Spark plug
3. Gauge oil level
4. Rear brake pedal
5. Kick starter lever
6. Rider foot rest R
7. Pillion foot rest R
8. Rear shock absorber R
9. Muffler assembly
10. Rear brake adjuster
11. Pillion handle
10 9 8 7 4 3 2 1
6 5
11

KNOW YOUR TVS StaR City+
KNOW YOUR TVS StaR City+
-11-
LOCATION OF PARTS - VEHICLE FRONT AND REAR
FRONT
1. Turn signal lamp front L
2. Head lamp assembly
3. License plate front*
4. Crash guard
5. Turn signal lamp front R
REAR
1. Pillion handle
2. Tail lamp assembly
3. Turn signal lamp rear R
4. Reflex reflector
5. License plate rear*
6. License plate lamp
7. Turn signal lamp rear L
* Optional accessory will be charged extra
1
21
32
43
4
5
5
7
6

-12-
KNOW YOUR TVS StaR City+
Insert the key into the lock and turn it to ‘OFF’ or
‘ON’ Position to unlock the steering.
KNOW YOUR TVS StaR City+
Caution
Leaving the ignition cum steering lock in ‘ON’
position will drain battery when the vehicle is not in
use . So “Switch off” and take the key out when
the vehicle is not in use.
Warning
Never attempt to move the vehicle when the
steering is locked, you may lose balance.

KNOW YOUR TVS StaR City+
-13-
KNOW YOUR TVS StaR City+
When the ignition switch is turned ‘ON’ the
speedometer performs self test. Wait till self test
cycle of speedometer gets over.
Note
N
2
3
4
1
8
9
6
Note
Service reminder indicator lamp works only based
on the distance (km) covered by the vehicle. This is
only a reminder indicator. Customers are advised
to keep track and follow the service schedule.
5
7

000001
ODO
KNOW YOUR TVS StaR City+
-14-
KNOW YOUR TVS StaR City+
EF
EF
EFAlways ride the vehicle in economy mode (green
lamp) for better fuel efficiency.
Note

KNOW YOUR TVS StaR City+
-15-
KNOW YOUR TVS StaR City+
Caution
Always use choke for starting the cold engine.
Never open the throttle fully when the choke is
applied. It may lead to flooding of engine and
difficulty in starting.
Warning
Always use the appropriate turn signal lamps when
you intend to change lanes or take turns. Be sure to
switch ‘OFF’ the turn signal lamps after negotiating
the turns or lanes.
1
23
45 6

KNOW YOUR TVS StaR City+
-16-
KNOW YOUR TVS StaR City+
Warning
Use appropriate head lamp beam ‘high / low’ as per
the traffic and road conditions for your safety and to
avoid inconvenience to other riders.
42 3
1
