TVS Stryker 125 User manual

All information, illustrations, photographs and
specifications contained in this owner‘s manual are based
on the latest product information available at the time of
this publication. TVS Motor Company Limited may, however
incorporate modifications or improvements on its vehicles
at any time without notice and therefore, in such events it is
possible that the relevant part of the owner‘s manual does
not apply to your vehicle.
Prior permission of TVS Motor Company Limited is required
for quoting, copying or reproducing any part of this owner‘s
manual.
Part number:- N5211440 Revision 0, November 2015
FOREWORD - NOTICE
1
NOTICE
FOREWORD
Dear Friend,
Thank you for choosing TVS Stryker 125.
As an elite owner of the TVS Stryker 125, you are now part of
TVS family with millions of satisfied customers.
TVS Stryker 125 is a supreme combination of contemporary
styling, thoughtful engineering and premium features. It is a
re-imagination of comfort and convenience like no other
bike in the category.
This manual explains the multiple features and operations of
your TVS Stryker 125. Please read it carefully and follow the
instructions to enjoy a fabulous ride.
To prolong your premium ride, we urge you to get your TVS
Stryker 125 serviced only at TVS Motor Company Authorised
Distributor or Dealers / Authorised Service Centers.
Wishing you a joyful riding experience!
TVS MOTOR COMPANY LIMITED
Accessories shown in the picture may not be part of the standard
equipment.
NOTE
FOREWORD - NOTICE

UNIQUE FEATURES OF TVS Stryker 125
UNIQUE FEATURES OF TVS Stryker 125
2
125CC ECOTHRUST ENGINE
Tailor made to belt out maximum
p o w e r w i t h m i n i m u m f u e l
consumption. Turn the key, ignite
and feel the engine come alive. All of
11 PS in it. And you get a whopping
mileage out of it.
ROTO PETAL DISC BRAKE*
Prevention is better than cure. The
thinking behind the disc brakes that
makes instant stopping in any
situation. In case of the worst, you’ll
have the best at your disposal (refer
page no. 37 for details).
TUBELESS TYRES*
Safety first. Tubeless tyres make sure
there is no sudden loss in air pressure.
You can easily reach the nearest
service station or home. To simply
put, stop only when you want (refer
page no. 40 for details).
FULLY DIGITAL SPEEDOMETER
Special care has been given even to the
tiniest of detail. Easy to read digital
tachometer with a sporty white backlit
display. It even warns you to low
battery levels, reminds you to timely
service the bike and keep it in perfect
running condition. Think of it as the
best companion on the road (refer
page no. 13 for details).

Information 04
Safe riding tips 05
Know your TVS Stryker 125 08
Riding your TVS Stryker 125 23
Maintenance 28
Service record sheet 44
Technical specifications 46
CONTENTS
CONTENTS
CONTENTS
3

RUNNING-IN INFORMATION
The first 1000 km is a crucial part of TVS Stryker 125. Proper
running-in operation during this period helps in ensuring a
maximum life and smooth performance of your motorcycle.
The reliability and performance of your motorcycle depends
on the special care and restrain exercised during the
running-in period. It is especially important that you avoid
operating the engine in high speed (RPM), which could
expose the engine parts to excessive stress. Maximum
recommended speed during the running-in is:
Maximum 50 kmph speed upto 1000 km (vary the engine
speed for better mating of parts).
The first service at 500 ~ 750 km is most important. During
running-in period all the engine components and other
parts will have set in. All adjustments to be restored, all
fasteners to be tightened. Engine cum transmission oil to be
replaced. Timely performance of the first service will ensure
optimum life and performance from the engine.
WARNING
CAUTION
Operating this vehicle safely is an important responsibility
of the rider. To help you make decisions about safety, we
have provided operating procedure and other information
in this manual. This information alerts you on potential
hazards that could hurt you or others. Since it is not possible
to warn you about all hazards associated with operating or
maintaining the vehicle, you must use your own judgement.
You will find important safety information in following form
with corresponding connotations in this manual:
Disregarding this message might result in injury to the rider.
This message indicates special procedures or precautions to be
followed to avoid damage to the vehicle.
This message provides further clarification for clearer
understanding of any particular information.
SAFETY INFORMATION
Replacing the engine cum transmission oil during first service is
most important for better life of engine. Always use TVS TRU4
PREMIUM, 4T oil (SAE10W30API-SL, JASO MA2) for better
performance and life.
NOTE
CAUTION
INFORMATION
4
INFORMATION

Two wheeler safety equipment starts with a safety helmet of good
quality. One of the most serious injuries that can happen is head
injury. Always wear good quality helmet. You should also have good
suitable eye protection.
SAFE RIDING RECOMMENDATIONS
Any two wheeler riding requires some precautions to be
taken to ensure the safety of the rider, pillion rider and other
road users. These precautions are:
Riding apparel
Loose, fancy clothing can be uncomfortable and unsafe
when riding a two-wheeler. Choose good quality two
wheeler riding apparel.
Familiarise yourself with new TVS Stryker 125
Riding skill and your mechanical knowledge form the
foundation of safe riding practices. We suggest you to
practice riding TVS Stryker 125 in a low-traffic condition
until you are thoroughly familiar with your vehicle and its
controls. Remember practice makes you perfect.
Know your limits
Ride within the boundaries of your own skill at all times.
Knowing these limits and staying within them will help you
avoid accidents.
SAFE RIDING TIPS
WARNING
5
Posture
Proper vehicle riding starts with proper posture.
1. Keep your elbows inside close to the body and flexible.
2. Hold your arms at an angle of about 120°.
3. Hips should be in a position so that arms and shoulders
are relaxed.
4. Look widely instead of gazing at one point.
5. Relax to guard against a sudden impact.
6. Hold the tank tightly with knees.
7. Point the toes straight ahead.
Cornering
When cornering, centrifugal force works in a direction
perpendicular to the direction in which the vehicle is
moving.
Centrifugal force increases in proportion with speed and
SAFE RIDING TIPS

radius of the corner. During cornering, reduce speed so as to
lessen the effects of centrifugal force. By all means, avoid
abrupt application of brakes or sudden steering.
One-hand riding is dangerous. Keep both hands firmly on the
handle bar and both feet securely on the foot rest. Under no
circumstances should both the hands be removed from the handle
bar, as it is very dangerous.
Avoid use of mobile phones while riding as it could lead to
fatal accident.
Do not downshift the gear in the midst of cornering. Slow down to a
safe speed before negotiating a corner. If this is the first time that
you are riding a vehicle of this type, we suggest that you practice on
a safe, open area to become thoroughly familiar with the operation
of the vehicle.
SAFE RIDING TIPS
WARNING
Braking
For safe riding, it is very important to master the braking
techniques.
1. Close / release the throttle.
2. Hold the vehicle upright as you apply the brake.
3. Progressive application of brake is safer.
4. Never depress the clutch lever while braking at higher
speeds.
6
5. Apply both the brakes.
6. Riding down hills simultaneously while cornering and
on wet roads close throttle and down shift the gear to
take advantage of gearbox and engine which acts as an
additional brake. This will avoid the loss of control over
the vehicle due to over speed.
Causes for poor braking
1. If the brake shoes / pads or drum / disc are worn out or if
there is water or oil on them, sufficient friction does not
develop and brakes do not work well.
2. Even when the brake works normally, if the road surface
is wet or the tyre surface is worn-out, tyres do not take a
firm hold on the road surface, thus increasing the
stopping distance.
3. Approximately 60% braking effect is from front brake.
Non-usage of front brake causes poor braking.
As the vehicle speed increases, the stopping distance also increases
progressively. Be sure that, you have sufficient distance between
you and the vehicle or obstruction ahead of you.
Using only the front or rear brake is dangerous and can cause
skidding and loss of control. Apply both the brakes together and
WARNING
SAFE RIDING TIPS

ACCESSORY INSTALLATION AND SAFETY TIPS
Use extreme caution while selecting and installing the
accessories for TVS Stryker 125 motorcycle.
The addition of unsuitable accessories can lead to unsafe
operating conditions. Your friendly Distributor / Dealer will
assist you in selecting quality accessories and installing
them correctly.
While selecting the accessories, make sure the accessories
should not obstruct lighting, steerability, suspension level
and ground clearance. Please ensure that, if the tank cover is
used, it is not getting en-trapped between fuel tank and fuel
tank cap.
Additional electrical equipments and controls should not
exceed the specified electrical system load of the vehicle
(capacity of battery and magneto).
EMISSION CONTROL
All the TVS vehicles are tested in the factory for optimum
fuel efficiency and lowest possible CO levels.
Do not disturb the Carburettor settings as this may lead
to higher fuel consumption and also higher CO levels.
If the vehicle needs any adjustments, please consult nearest
TVS Motor Company Authorised Distributor or Dealer /
Authorised Service Centers.
While adequate care is exercised at the factory to ensure
that the emissions are within the limits, it is essential for the
owner to always maintain the motorcycle in good condition
by getting it periodically checked and serviced by TVS
Motor Company Authorised Distributor or Dealer /
Authorised Service Centers so that the emission and fuel
consumption levels are maintained as per norms.
SAFE RIDING TIPS
with great care on a wet road or other slippery surfaces. Any abrupt
braking on slippery or irregular roads can cause loss of control.
7
SAFE RIDING TIPS

VEHICLE IDENTIFICATION NUMBER
Serial numbers of both frame and engine are required for vehicle identification. They are also required to assist your Distributor
/ Dealer for ordering parts or referring to special information.
Please fill the above boxes now for future reference
Frame number
Engine number
Control key number
The frame serial number is stamped on the left side of the
steering head tube. The engine serial number is stamped on the top of the left side crankcase near cylinder block.
KNOW YOUR TVS Stryker 125
KNOW YOUR TVS Stryker 125
8

LOCATION OF PARTS - HANDLE BAR
1. Choke lever
2. Horn switch
3. Turn signal lamp switch
4. Clutch lever
5. Pass by switch
6. Rear view mirror L
7. High / low beam switch
8. Digital speedometer
9. Ignition cum steering lock
10. Master cylinder front*
11. Rear view mirror R
12. Hazard switch
13. Front brake lever
14. Throttle grip
15. Head lamp switch
16. Electric starter switch
17. Fuel tank cap
12
13
14
15
16
17
6 7 8 10 11
9
1
2
3
4
5
KNOW YOUR TVS Stryker 125
9
KNOW YOUR TVS Stryker 125

LOCATION OF PARTS - VEHICLE LEFT SIDE
1. Front wheel axle
2. Fuel cock
3. Gear shift lever
4. Rider foot rest L
5. Centre stand
6. Side stand
7. Pillion foot rest L
13
1011
45689
KNOW YOUR TVS Stryker 125
10
KNOW YOUR TVS Stryker 125
LOCATION OF PARTS - VEHICLE RIGHT SIDE
12 13
39
1011 45678
8. Rear wheel axle
9. Chain case
10. Rear shock absorber L
11. Cover frame L
1. Disc plate front
2. Front wheel axle nut
3. Front caliper assembly
4. Spark plug
5. Gauge oil level
6. Rear brake pedal
7. Rider foot rest R
8. Kickstarter lever
9. Pillion foot rest R
10. Muffler assembly
11. Rear brake adjuster
12. Rear shock absorber R
13. Cover frame R
12
27

KNOW YOUR TVS Stryker 125
KNOW YOUR TVS Stryker 125
11
LOCATION OF PARTS - VEHICLE FRONT AND REAR
FRONT
1. Turn signal lamp front L
2. Head lamp assembly
3. Position lamp
4. Turn signal lamp front R
REAR
1. Pillion handle
2. Tail lamp assembly
3. Turn signal lamp rear R
4. Reflex reflector
5. Turn signal lamp rear L
4
4
5
3
11
2
3
2

KNOW YOUR TVS Stryker 125
KNOW YOUR TVS Stryker 125
12
CONTROL KEY
TVS Stryker 125 comes with a pair of identical control keys.
These keys are to operate ignition cum steering lock, fuel
tank cap and cover frame R.
IGNITION CUM STEERING LOCK
There are three positions in the ignition cum steering lock.
They are:
1. ‘OFF’ position
All the electrical circuits are turned ‘OFF‘ in this position.
Engine will not start. Key can be taken out.
2. ‘ON’ position
In this position, all the electrical circuits are turned ‘ON’ and
the engine can be started. Key cannot be removed in this
position.
3. ‘LOCK’ position
TVS Stryker 125 steering can be locked in both ‘left’ and
‘right’ directions.
To lock the steering, turn the handle bar all the way to the
‘left’ or ‘right’. Push the key in and turn it to the ‘LOCK’
position and take out. All the electrical circuits are turned
‘OFF’ in this position.
Insert the key into the lock and tun it to ‘OFF’ or ‘ON’
position to unlock the steering.
WARNING
CAUTION
Never attempt to move the vehicle when the steering is locked, you
may lose balance.
Leaving the ignition cum steering lock in ‘ON’ position will drain the
battery when the vehicle is not in use . So “Switch off” and take the
key out when the vehicle is not in use. For safety, always lock the
steering while parking.

KNOW YOUR TVS Stryker 125
KNOW YOUR TVS Stryker 125
13
3. Turn / hazard signal indicator
Flashes when the ‘left’ or ‘right’ side turn signal indication or
hazard signal indication is activated.
4. High beam indicator
Glows when the head lamp high beam is activated.
5. Multi functional digital display
1
2
3
4
5
DIGITAL SPEEDOMETER
1. Mode switch
Press the switch to change the display mode (‘ODO’ or
‘TRIP’).
2. Neutral indicator lamp (N)
Glows when the vehicle is in neutral and goes ‘OFF’ when
gear is shifted from neutral.
NOTE
When the ignition lock is turned ‘ON’ the speedometer performs
self test. Wait till the self test cycle of speedometer gets over.
The back light of the speedometer glows continuously once the
ignition is turned ‘ON’.
5a
5b
5c
5f
5e
5d
5a. Odometer / trip meter
Odometer registers and displays the total distance
covered by the vehicle in kilometers. The digit after the
dot mark denotes one tenth of a kilometer. Set the
display in ‘ODO’ mode to know the reading.

KNOW YOUR TVS Stryker 125
14
KNOW YOUR TVS Stryker 125
Trip meter registers and displays the partial distance
covered in kilometers. The digit after the dot mark
denotes one tenth of a kilometer.
Set the display in ‘TRIP’ mode to know the reading.
Press the mode switch for a few seconds (in ‘TRIP’
mode) to reset the trip meter whenever required.
If the ‘ODO/TRIP’ segments of speedometer are
blinking during riding, contact nearest TVS Motor
Company Authorised Distributor or Dealer /
Authorised Service Centers.
5b. Speedo meter
Displays the driving speed in kilometer per hour (km/h)
in real time.
5c. Tachometer
Digital bars of tachometer indicates the engine speed in
multiples of 1000 rpm (revolutions per minute).
5d. Fuel gauge
Digital bars indicates the approximate fuel quantity
available in fuel tank. There are eight bars to indicate the
quantity of fuel available in the fuel tank.
All the eight bars will be displayed when the fuel in the
tank reaches above 10.5 liters approximately (full tank).
When the fuel reaches half tank (6 liters approx.) the fuel

KNOW YOUR TVS Stryker 125
KNOW YOUR TVS Stryker 125
15
gauge displays only five bars as shown.
The fuel gauge shows only single bar when the fuel
reaches level of 2.1 liters approx.
Fuel tank symbol (A) starts blinking and one bar will be
visible when the fuel reaches the level of approximately
1.5 liters. Refill the fuel immediately. Once the fuel level
reaches 1 liter, no bar will be visible and fuel tank symbol
(A) glows continuously. If all the fuel level bars start
blinking, contact nearest TVS Motor Company
Authorised Distributor or Dealer / Authorised
Service Centers.
5e. Service reminder
When the vehicle is due for service, whenever the
ignition lock is turned ‘ON’, the spanner symbol ‘ ’
blinks for 10 seconds after the self test cycle, and
continues to glow till the vehicle is serviced and reset.
Get the vehicle serviced at TVS Motor Company
Authorised Distributor or Dealer / Authorised Service
Centers.
5f. Low battery indicator
A battery symbol ‘ ’ glows when the battery charge
is too low. Get the battery checked at TVS Motor
Company Authorised Distributor or Dealer / Authorised
Service Centers.
NOTE
Service reminder indicator lamp works only based on the distance
(km) covered by the vehicle. This is only a reminder indicator.
Customers are advised to keep track and follow the service
schedule.
HANDLE BAR LEFT SIDE
1. Choke lever
Pull the choke lever towards left for choke application.
During cold start, apply the choke and start the vehicle
using electric starter or kick lever without opening /
with less opening of throttle. Once the engine is started
and running in stable RPM, release the choke and ride the
vehicle.
CAUTION
Always use choke for starting the cold engine. Never open the
throttle fully when the choke is applied. It may lead to flooding of
engine and difficulty in starting.

KNOW YOUR TVS Stryker 125
KNOW YOUR TVS Stryker 125
16
2. Horn switch
Press the switch ‘ ‘ to operate the horn.
3. Turn signal lamp switch
Slide the turn signal lamp switch to left ‘ ’ or right side
‘ ’ to operate respective turn signal lamps (LH/RH). Press
the knob in to turn ‘OFF’.
4. Clutch lever
Use the clutch lever to disengage the drive to the rear wheel
1
2
3
4
56
while shifting the gears. Pressing the lever towards grip
disengages the drive.
5. Pass by switch
Press the pass by switch intermittently to signal the
opposite vehicle during overtaking. If the switch is pressed
during day time, the head lamp high beam flashes. But in
night time, if the switch is pressed the head light beam
toggles between ‘High’ and ‘Low’ depending on the switch
position.
6. Head lamp high / low beam switch
With the head lamp switch in ‘ON’ condition, press the beam
control switch towards ‘ ’ to turn-on the head lamp high
beam. Press the switch towards ‘ ’ to turn-on the head
lamp low beam.
WARNING
Always use the appropriate turn signal lamps when you intend to
change lanes or take turns. Be sure to switch ‘OFF’ the turn signal
lamps after negotiating the turns or lanes.
WARNING
Use appropriate head lamp beam ‘high / low’ as per the traffic and
road conditions for your safety and to avoid inconvenience to other
riders.
If the pass by is operated with the engine in ‘OFF’ condition, the
head lamp glows only with 50% illumination.
NOTE

KNOW YOUR TVS Stryker 125
KNOW YOUR TVS Stryker 125
17
HANDLE BAR RIGHT SIDE
1. Electric starter switch
Press the electric starter switch ‘ ’ to start the engine
electrically with the transmission in neutral or by depressing
the clutch lever when the transmission is in gear.
If the electric starter switch is pressed more than 3 sec
continuously, the starter motor gets disabled
automatically and will not crank the engine. The motor
cranks the engine only after 3 sec or if the switch is
released and repressed.
2. Head lamp switch
Head lamp switch has three positions. Working of head
lamp at various positions are as follows:
OFF: All the lamps are turned ‘OFF’ (except speedo
backlit) when the switch is at ‘ ’ position even
though the ignition is ‘ON’ / engine is running.
PO : Position lamps and tail lamp glows when the switch
is at ‘ ’ position with the ignition ‘ON’.
ON: Head lamp glows along with the above said lamps
when the switch is at ‘ ‘ position and engine is
running. If the engine is idling for more than 30
seconds, the head lamp power (brightness)
reduces automatically. Once the throttle is
operated, the head lamp will be back to normal
brightness.
3. Throttle grip
Engine speed is controlled by the rotation of the throttle
grip. Twist it towards you to increase the engine speed and
away from you or release it to decrease the engine speed.
4. Front brake lever
The front brake is applied by pressing the front brake lever
gently towards the throttle grip. The brake lamp glows on
application of front brake.
5 4
1 2 3
CAUTION
For cold starts, avoid using electric starter. Use kickstarter. A typical
example is early morning start. This would reduce load on the
battery and prevents quick drain.

KNOW YOUR TVS Stryker 125
18
KNOW YOUR TVS Stryker 125
5. Hazard switch
Whenever it is necessary to park the motorcycle in a
hazardous location due to emergency situation, press the
hazard switch towards front with the ignition in ‘ON’
condition. This makes all the turn signal lamps to flash
simultaneously to make other road users aware of presence
of the vehicle. Press back the switch towards you to turn-off
the lamps.
NOTE
Avoid unnecessary usage of hazard warning lamps with engine in
off condition. Battery may get drained.
* Fuel tank is not a measuring instrument and capacity of the fuel
tank may slightly vary from the indicated capacity.
WARNING
NOTE
Avoid spilling of fuel on the hot engine. Never refill fuel near open
flame. Do not smoke while refueling. Do not use cell phones while
refueling.
Whenever refueling the bike, fill upto the bottom of neck portion of
the fuel tank. Filling above the neck may result in improper
breathing of fuel tank and seepage of fuel.
FUEL TANK* CAP
To open the fuel tank cap, insert the control key into the
lock, turn it in clockwise direction and lift the cap.
To close, press the cap back to its original position. Take out
the key after closing.
FUEL COCK
Fuel cock has the following three positions:
ON: Fuel flows in this position when the fuel is above the
reserve level in the tank.
RES: Switch over the fuel cock lever to this position when
the fuel stops flowing in ‘ON’ position.
OFF: Fuel flow cuts off from the fuel tank to carburettor.

KNOW YOUR TVS Stryker 125
KNOW YOUR TVS Stryker 125
19
KICK STARTER LEVER
The kick starter lever is located on the right side of the
vehicle. To start the vehicle, keep the ignition in ‘ON’
condition and transmission in neutral. Keep your foot on the
lever extension and kick from top and stroke to bottom with
rapid motion.
RES
OFF
ON
CAUTION
Leaving the fuel cock in ‘ON’ or ‘RESERVE’ position may cause the
fuel tank to completely drain out, incase any malfunctioning of
carburettor float system.
Similarly, if the fuel cock is positioned between ‘ON’ and ‘OFF’ may
drain off entire fuel while riding the vehicle.
NOTE
It is recommended to start the vehicle always in neutral gear.
However, the vehicle can be started in any gear using electric starter
by depressing the clutch lever.
Please note that the engine can be started with the
kickstarter lever only when the vehicle is in neutral.
GEAR SHIFT LEVER
TVS Stryker 125 has a heel and toe gear shift lever. To shift
the gear from neutral to higher gears, press the rear end of
gear shift lever by heel once for each gear with application
of clutch.

KNOW YOUR TVS Stryker 125
KNOW YOUR TVS Stryker 125
20
REAR BRAKE PEDAL
Rear brake pedal is located on the right side of the vehicle.
Press the rear brake pedal with your right foot to apply the
rear brake. The brake lamp glows on application of brake.
STANDS
TVS Stryker 125 is equipped with a centre (1) and side stand
(2). To place the vehicle on the centre stand, hold the handle
bar left grip with left hand and pillion handle with right
hand. Place your foot firmly on the centre stand extension
(1a) and press with adequate effort. Ensure both the legs of
centre stand are touching the ground before placing the
vehicle on the stand.
Side stand can be operated by sitting on the vehicle with
your left foot by pushing it away from the vehicle fully.
4
3
2
1
N
N
1
2
3
4
Lower gears
Higher gears
Similarly, to down shift to lower gears, press the front end of
the lever by toe once for each gear after applying the clutch.
Brakes are items of personal safety and should always be
maintained in proper condition.
WARNING
WARNING
Always release the side stand to its full up position before moving
the vehicle.
