TVS Apacha RTR 310 User manual

Revision:- Rev. 0, 06th Sep 2023 onwards

I
I
This is more than just a performance motorcycle.
This is your gateway into the world of the freestyler.
The TVS Apache RTR 310 has been designed to be the ultimate form of expression. It is engineered with precision to
let you perform in your own way.
It’s brimming with the latest tech to give you the freedom to freestyle.
To prolong your journey on the TVS Apache RTR 310, we urge you to get your TVS Apache RTR 310 services only at
TVS Motor Company Authorized Dealers.
TVS Motor Company Limited
ENTER THE WORLD OF # TheFreestyler
ENTER THE
W
ORLD OF
#TheFreestyler

II
BORN OF A RACING GENE
Every Apache is born of a racing gene. This can be traced back to 1982 when a TVS Moped clocked 105 km/h and
since then we’ve never looked back. TVS Racing has the distinction of being India’s first factory racing team and with
that legacy comes pride.
BORN OF A
RACING GENE
In 2005 the racing DNA manifested itself into the TVS
Apache, a machine that would set alight the tracks
of not only India, but the world. The RTR name has
become a mainstay of the top step of the podium.

III
III
THE EVOLUTION OF PURITAN TO PLAY
THE
EV
OLUTION
OF
PURIT
AN
TO
PLAY
The TVS Apache RR310 is the Ultimate Tack Weapon.
Crafted meticulously to shatter lap records and take
the chequered flag.
The TVS Apache RTR 310 keeps that essence of
performance but strips everthing else away to give
you the Ultimate Sport Naked. The poer, the riding
dynamics, the tech, all geared to let you truly express
yourself with performace.

IV
Brand Experience
Live the pure performance life.
Since 2005, TVS Apache has been at the helm of performance motorcycling, creating an entirely new breed of racers.
And now that you have chosen the ultimate race machine, you are also part of this esteemed legacy. Not just that, you
are also standing at the portal to a 360 moto-experience encompassing from out riding your limits at the racetrack to
becoming part of a league of riders who share your passion for motorcycling.
Apache Owners Group
Join the league of Apache motor enthusiasts that share your passion for riding. Explore the unchartered, tame every
terrain, forge unbreakable bonds, and make unforgettable memories with every journey.
Go on thrilling rides all year round –
Breakfast ride | Overnight ride | Marquee ride | Chapter ride
Apache Racing Experience
If you have the mettle, we have the track. Apache Racing Experience (ARE), a flagship property of TVS Racing &
Apache, is the embodiment of our philosophy,“the bikes we race are the bikes we sell.”Hone your racing skills
and techniques with the INMRC Champion riders from TVS Racing and test the limits of your machine and yourself.
TVS RacingTraining School
Founded in 2017, TVS Racing Training School aims at fostering motor sports in India. We believe that all our riders are
racers at heart and here, they can unleash that racer and learn the skills under National Champions. And through
multiple levels of training, we hope to turn these racing zealots into the podium winners of tomorrow.
Join the AOG community - https://www.tvsapache.com/assets/pdf/AOG-Regulations.pdf and also download the TVS
Connect app / https://www.tvsapache.com/aog.aspx
BRAND EXPERIENCE

1982
Our love of racing
began when a
TVS 50 Moped
clocked 105 km/h.
1992/93
Supra
won Indian the National
Rally Championship;
Special Rally kit 250
numbers were made
and sold.
Shaolin
won the Indian
National Rally and
Supercross
Championships.
1998
1988/89
AX 100
won the
Great Himalayan
Desert Rally.
1993/94
Shogun
kicked o scheme
bike racing
in India.
2000-2005
Fiero
won multiple
Indian National Rally, Super-
cross and
Road Racing championships.
2005 - Till date
2011
2016
2017
2015
2007
TVS Apache RTR
was launched. It started a rev-
olution in racing and continues
to dominate with 90% of race
wins and multiple national
championships.
TVS Racing wins their
18th Championship title
TVS Racing won
SLADA and Sri Lanka
National Championship
in 2011, 2016 and 2017.
First factory team in
India to sign a woman
rider and launch a dedi-
cated road racing cup for
women.
Won 12 national
championships
Supercross,
Motocross and Rally.
TVS leaves
its mark as the
1st Indian Manufacturer
in Dakar.
The RTR 160 wins
6 consecutive INMRC titles.
2017
2018
TVS Racing wins their
7th consecutive INMRC
title
2019
Finished the
Dakar Rally in 12th place
and won the INMRC,
INRC and INSC.
Finished on the
podium in the Andalusia
Int’l Rally,11th INMRC title
and debuted in ARRC
(250 cc production
category)
2020
Keep up with our pace. Follow TVS Racing on -

VII
VII
Incase you need any Clarification please contact above Dealer
Or
TVS Motor Company’s Area Offices (flip over for addresses)
Or
Toll Free Number : 1800-258-7111
Email : [e-mail]
Disclaimer : TVS Motor Company or any of its officials / Authorized Main dealer / Authorized Dealer do not ask customers
for bank / card / wallet details / authentication. In case you face any such claim, please report to the relevant local authorities
immediately.
CONTACT(S) FOR SUPPORT

VIII
Contact at Our Area Offices
KARNATAKA-1, 2 & GOA
4. TVS Motor Company Limited
No. 600, Anand Surya, 2nd Floor,
15th Cross, 6th Phase, JP Nagar,
Opp. BMTC Bus Stop,
Bangalore - 560 078.
Phone : [phone]
Email : [e-mail]
ANDHRAPRADESH & TELANGANA
5. TVS Motor Company Limited
Rukumani Towers, First Floor,
No. 3-11-30, Plot No. 11,
Paigha Colony, Behind Anand Theater,
Secunderabad - 500 003.
Phone : [phone]
Email : [e-mail]
[e-mail]
MAHARASHTRA-1 & 2
6. TVS Motor Company Limited
No. 401, 4th Floor, The Chambers,
Plot No. 4/12/3, Near Ganapati Chowk,
Viman Nagar, Pune - 411 014.
Phone : [phone]
Email : [e-mail]
TAMILNADU-1, 3 & 4
1. TVS Motor Company Limited
V Floor, Gee Gee Universal,
No. 2, MC Nichols Road,
Chetpet, Chennai - 600 031.
Phone : [phone]
Email : [e-mail]
[e-mail]
TAMILNADU-2
2. TVS Motor Company Limited
No. 10, 2nd floor,
Shree Shanmugapriya Towers,
Kannuswamy Street,
Behind Hotel Annapoorna,
R S Puram, Coimbatore - 641 002.
Phone : [phone]
Email : [e-mail]
KERALA
3. TVS Motor Company Limited
Ambady Towers, Second Floor,
Door No. 27/631, A6,
Edappally-Pookkattupady Road,
Edappally PO., Cochin - 682 024.
Phone : [phone]
Email : [e-mail]
MAHARASHTRA-3 & CHATTISGARH
7. TVS Motor Company Limited
No. 502B, 6th Floor, B Wing,
Shriram Shyam Towers,
Near LIC Square, Sardar,
Nagpur - 440 001.
Phone : [phone]
Email : [e-mail]
[e-mail]
GUJARAT
8. TVS Motor Company Limited
1208-1213, Shivalik Satyamev,
Below Bopal Over Bridge,
Ambli-SP Ring Road Junction, Bopal,
Ahmedabad- 380 058.
Phone : [phone]
Email : [e-mail]

IX
IX
DELHI & HARYANA
11. TVS Motor Company Limited
D-3 & D-4, 2nd Floor,
Sector - 10, Noida,
Uttar Pradesh - 201 301.
Phone : [phone]
Email : [e-mail]
PUNJAB & CHANDIGARH
12. TVS Motor Company Limited
4th Floor, Royal Business Park,
Chandigarh Ambala Highway,
Zirkapur - 140 603.
Phone : [phone]/465777
Email : [e-mail]
UTTAR PRADESH WEST
13. TVS Motor Company Limited
D-3 & D-4, 2nd Floor,
Sector - 10, Noida,
Uttar Pradesh - 201 301.
Phone : [phone]
Email : [e-mail]
MADHYA PRADESH-1 & 2
9. TVS Motor Company Limited
No. 211-212, 2nd Floor,
Chinar Incube Business Centre,
Chinar Fortune City,
Near Brindhavan Dhaba,
Hosangabad Road,
Bhopal - 462 026.
Phone : [phone]
Email : [e-mail]
[e-mail]
RAJASTHAN-1 & 2
10. TVS Motor Company Limited
Plot No. 17-18,
2nd Floor of National Motors Building,
Jhotwara Industrial Area,
Jaipur - 302 012.
Phone : [phone]
Email : [e-mail]
[e-mail]
UTTAR PRADESH CENTRAL & EAST
14. TVS Motor Company Limited
1st Floor, Cyber Tower, TC-34/V-2,
Vibhuti Khand, Gomti Nagar,
Lucknow - 226 010.
Phone : [phone]
Email : [e-mail]
WEST BENGAL
15. TVS Motor Company Limited
Ground Floor & First Floor,
133 A. S. P. Mukherjee Road,
Opp. Tollygunge Police Station,
Kolkatta - 700 026.
Phone : [phone]
Email : [e-mail]
BIHAR
16. TVS Motor Company Limited
N-Plaza, Jamal Road,
P.S. Kotwali,
Patna - 800 001.
Phone : [phone]
Email : [e-mail]

X
ORISSA & JHARKHAND
17. TVS Motor Company Limited
No. 303, 3rd Floor,
Creative Plaza, Rasulgarh,
Bhubaneshwar - 751 010.
Phone : [phone]
Email : [e-mail]
NORTH EAST STATES
18. TVS Motor Company Limited
147, Udayan, Ganesh Guri,
Near Hotel D Courtyard,
R G B. Road, Guwahati - 781 005.
Phone : [phone]
Email : [e-mail]

XI
XI
TVS Motor Company Limited advices you to read this
manual carefully in order to familiarise yourself with
your motorcycle. In case of any clarification, please
contact any of our Authorised Main Dealer.
For your safety and improved ownership experience,
this manual contains important information
about controls and operation, technical features,
maintenance and care to be taken to keep your
vehicle reliable and safe. We recommend that
you strictly follow the instructions in this manual,
especially those regarding the running-in period and
periodic maintenance.
TVS Motor Company Limited declines any liability
whatsoever for any mistakes incurred during the
development of this manual. All the information in
this manual is valid at the time of publication.
TVS Motor Company Limited reserves the right to
make any modifications required due to the ongoing
development of their products. In such events it is
possible that the relevant part of this Owner’s Manual
does not apply to your vehicle.
Prior permission of TVS Motor Company Limited is
required for quoting, copying or reproducing any part
of this Owner’s Manual.
INTRODUCTION
This Owner’s manual uses a set of symbols with
special meanings. They are:
This message indicates special procedures or
precautions to be followed to avoid damage to the
vehicle.
Caution
This message provides further clarification for clear
understanding of any particular information.
Note
Disregarding this message might result in injury to the
rider or deadly accidents.
Warning

XII
The terms ‘LH’ and ‘RH’ are referred to the motorcycle
viewed from the riding position.
Accessories shown in the picture may not be the part
of standard equipment.
For your safety, as well as to preserve warranty,
reliability and road worthy of your motorcycle, use
originalTVS Motor Company Limited spare parts only.
In order to ensure the reliability of your product, you
are strongly advised to refer our Authorised Main
Dealers for any service requiring particular technical
expertise.
Skilled personals of our Dealer have the tools
required to perform any servicing job to the highest
professional standards to ensure smooth running and
long life of your motorcycle.

XIII
XIII
CONTENTS
DESCRIPTION PAGE No.
ENTER THE WORLD OF # TheFreestyler I
BORN OF A RACING GENE II
THE EVOLUTION OF PURITAN TO PLAY III
BRAND EXPERIENCE IV
CONTACT(S) FOR SUPPORT VII
INTRODUCTION XI
RUNNING-IN INFORMATION 1
SAFE RIDING TIPS 2
Safe Riding Recommendations 2
Riding the Vehicle with Maximum Load 5
ACCESSORY INSTALLATION TIPS 6
KNOW YOUR MOTORCYCLE 7
Anti-Lock Brake System (ABS) 7
How does ABS work? 7
Rear wheel lift 8
EMS a Glance 9
Location of Parts - Vehicle RH Side View 10
Location of Parts - Vehicle LH Side View 11
Location of Parts - Vehicle Front and Rear View 12
Controls 13
Special Features of TVS Apache RTR 310 14
Ride by wire 14
Quick shifter 14
Dynamic headlamp 14
RT slipper clutch 15
Glide Through Technology (GTT) 15
Tyre Pressure Monitoring Sensor (TPMS) 16
Climate Controlled Seat 16
RTLSC (Race Tuned Linear Stability Control) 17
Straight line ABS system 17
Traction control system 17
Cruise control system 17
RTDSC (Race Tuned Dynamic Stability Control) 18
Cornering ABS 18
Cornering cruise control 18
Cornering traction control 19
Slope dependent control 19
Wheelie control 20
Rear lift protection 20
Vehicle Identification Number 21
Control Key 22
Ignition cum Steering Lock 23
Switch Assembly LH 24
Adjustable clutch Lever 33

XIV
DESCRIPTION PAGE No.
Gear Shift Pedal 34
Quick shifter 35
Rear Brake Pedal 37
Switch Assembly RH 38
Throttle Twist Grip 39
Front Brake Lever 40
Instrument Cluster - Key Features 41
Warning and indicator lights 43
TFT Multifunction display 45
Menu function 46
Ride mode 49
Trip details 63
My vehicle 66
Preferences 71
TVS Connect App 97
How to login 98
First time Bluetooth paring 103
Steps to ‘Forget This Device’ in iPhone: 107
Auto pairing 108
Digi Docs 110
Voice Assist 113
Major Components 120
Cooling System (Radiator) 121
Fuel Tank Cap 123
Refueling 123
Side Stand 125
Adjustable Suspension 126
Seat Lock (Rider and Pillion Seat) 127
Emission Control 130
RIDING YOUR MOTORCYCLE 132
Before Riding 132
While Riding 134
Starting the Engine 135
Moving the Vehicle 136
Braking 137
Stopping the motorcycle 137
Parking 137
Fuel Recommendation 138
Checks and Tips for Better Fuel Economy 139
GENERAL ADJUSTMENTS 141
Rear View Mirrors LH & RH 141
Clutch Lever - Adjustment 141
Front Brake Lever - Adjustment 142
Gear Shift Pedal - Adjustment 142

XV
XV
DESCRIPTION PAGE No.
Suspension Adjustment 143
Front fork adjustment 143
Rear shock absorber adjustment 146
Headlamp Aiming 151
MAINTENANCE 153
Maintenance Schedule 153
PM Schedule - Free service 154
PM Schedule - Pay service 157
Safety Precautions 160
Engine Oil Level 161
Clutch Free Play 163
Brake Fluid Level 165
Brake Pad Wear 166
Rims and Tubeless Tyres 167
Drive Chain 171
Front Wheel 174
Rear Wheel 176
Battery 180
Fuses 182
Mirror Assembly 184
Diagnostic Connector 185
Cleaning your Motorcycle 187
Storage Procedures 188
Restoring the Motorcycle to Use 189
Taking Long Trips 190
GENERAL INFORMATION 191
Tool Kit 191
Auxiliary Stand (Paddock Stand) 192
WARRANTY AND SERVICES 195
Limitations of Warranty 195
Service Information 201
Pre-Delivery inspection 202
Planned Service Schedule 203
PICKUP AND DROP 204
TECHNICAL SPECIFICATIONS 205
Recommended Fuel and Lubricants 205
Engine 207
Transmission 208
Dimension 209
Frame and Suspension 210
Wheels and Brakes 211
Free Plays 212
Electricals 213
Important Torque Details 214
Basic Troubleshooting 215
INSURANCE 216

1
1
Running-in Recommendations
Running-in is essential to preserve engine life and performance over time. Twisty roads and gradients are ideal to run
in the engine, brakes and suspension effectively. The first 1000 km is a running-in period for your motorcycle.
Maximum engine speed during running-in 0 to 1000 km - below 7000 rpm.
During the first 1000 km, avoid the full throttle starts and rapid acceleration, which could expose the engine parts to
excessive stress. It is advisable to run the engine at varying load and rpm, though still within recommended rpm limit.
Avoid riding at constant engine rpm for prolonged periods.
During initial running, use brakes gently. Do not brake hard or keep brake applied for too long to enable a correct
break-in of brake pad friction material against the brake discs. To allow all the mechanical parts of motorcycle to adapt
each another, and to avoid reduction of engine components life, it is advisable to avoid sudden acceleration and
running the engine at high rpm for too long, especially uphill.
Check the drive chain frequently and if required adjust it. Also ensure that the chain is lubricated as required to
increase its service life.
RUNNING-IN INFORMATION
On completion of running -in period, scheduled maintenance service should be observed carefully without fail. Failure to
comply with this will result in damage to the engine parts and other key parts of the vehicle or shorter engine life. Keeping to
the running-in recommendations will ensures longer engine life and reduce the need for overhauls and re-tuning.
Caution
During running-in period, only ‘Urban’ and ‘Rain’ ride modes will be available for the rider to select. The other three ride
modes like ‘Sport’, ‘Track’ & ‘Supermoto’ will be available for selection only after the completion of running-in period and
enabled by the TVS Motor Company Authorised Service personal.
Note

2
SAFE RIDING TIPS
Safe Riding Recommendations
The following points are applicable for every day
usage of your motorcycle and should be observed
carefully for safe riding of your motorcycle.
Riding skills and your mechanical knowledge forms
the foundation of safe riding practices. We suggest
you to practice riding your TVS Apache RTR 310 in a
low-traffic condition until you are thoroughly familiar
with your motorcycle and its controls.
Most of the accidents are the result of inexperience
of rider. Always make sure you are carrying your
driving license with you; you must have a valid
license that enables you to ride a motorcycle of this
kind. Avoid lending your motorcycle to the persons
who are inexperienced and not holding a valid driving
license.
A motorcycle is not designed to provide impact
protection, so defensive riding in addition to wearing
of protective apparel is very important.
Please do not let the protective apparels give you a
false sense of security.
Both the rider and the pillion should always wear an
ISI approved, correct fit, comfortable and good quality
safety helmet before riding the vehicle. Because, one
of the most serious injury that can happen is an head
injury.
You should also have a good quality goggles to
protect your eyes and help your vision.
Avoid wearing loose clothes or accessories that
could become tangled in the controls or limit your
field of vision.
Riding at proper speed and avoiding sudden
acceleration or deceleration are not only important for
safety and low fuel consumption. It is also important
for longer life of vehicle and smoother operation.
Avoid use of mobile phones while riding as it could
lead to fatal accident.
To prevent or minimise accident, never consume
alcohol or drugs before or during the operation of
your vehicle. Even minimal consumption of these will
affect the rider’s ability to control the vehicle.
Ride within the law and observe national and local
rules. Always respect speed limits. However, adjust
your speed according to the visibility, road and traffic
conditions.

3
3
Be sure about your visibility and do not ride with the
blind spot of vehicles or obstruction ahead you.
Take additional care at road junctions, exits of private
land, car parks and on the service roads to highways.
Before changing the lanes or take a turn, look over
your shoulder and make sure that your way is clear.
Do not completely rely on the rear view mirrors; you
may misjudge a vehicle’s distance and speed, or you
may not see is at all.
Always use turn signal lamps when you intend to
change lanes or take a turn. Be sure to switch it off
after changing the lane or negotiating the corner.
The rider should keep his/her foot on the footrests
while riding the motorcycle.
Always hold the handlebars firmly with both hands in
order to be ready for sudden changes of direction or
in the road surface.
Under no circumstances should both the hands be
removed from the handle bar, as it is very dangerous.
While riding in wet conditions, on loose gravels, the
ability to maneuver the vehicle will be reduced. Ride
smoothly on this conditions. Sudden acceleration,
braking or turning may cause loss of control.
On the wet roads, rely more on the throttle to control
vehicle speed and less on the front and rear brakes.
Use the throttle judiciously to avoid skidding the rear
wheel from too rapid acceleration or deceleration.
On the rough roads, exercise caution, slow down and
grip the fuel tank with your knees for better stability.
To get quick acceleration during overtakes, shift to a
lower gear to obtain the necessary power.
Do not downshift the gear abruptly at high rpm to
avoid damage to the engine due to overreving.
Avoid unnecessary weaving for the safety of both the
rider and other motorists.
While riding on uphill, shift to a lower gears so
that there is plenty of power to spare rather than
overloading the engine.
Do not downshift the gears in the midst of cornering.
Slow down to a safe speed before negotiating a
corner.
Hold the vehicle upright as you apply the brake.
Progressive application of brake is safer. Never
depress the clutch lever while braking at higher
speeds.
