TW Audio BSX User manual

BSX Operating Manual

Operating Manual for BSX
Introduction
Thank you for choosing a high quality product "MADE IN GERMANY" from TW AUDiO.
The Big Subwoofer eXtender (BSX) is equipped with two powerful 21" drivers, with a
peak power of 10 kW per driver, this loudspeaker is able to reproduce an exceptionally
solid low frequency foundation. Thanks to the unique TW AUDiO hybrid enclosure prin-
ciple, maximum efficiency is achieved so that the acoustic energy is produced over a
greater distance than conventional subwoofers.
The BSX loudspeaker is primarily utilized as low frequency bass enhancement with
other subwoofer loudspeakers and can described as a ULF / Infra product. That said,
due to the BSX hybrid design and the extremely strong, yet light membranes, frequen-
cies up to 120 Hz are reproduced with exceptional transient response and in high fidel-
ity. This means the BSX loudspeaker can be operated in two modes or “Infra-bass/Ultra-
Low Frequency” or as a standard “Sub”. Therefore, it can also be combined directly with
the M, T, C or VERA systems.
If you lend your product to another party, inform that party of the safety-related operating
procedures and hand over this operating manual. If you therefore require additional cop-
ies of this operating manual, they can be obtained free of charge from TW AUDiO or
downloaded from: www.twaudio.de
Strictly adhere to the instructions contained in this operating manual that are marked as
follows:
Instructions in the operating manual
WARNING
This symbol in combination with the signal word "Warning" identifies a potentially haz-
ardous situation. Failure to comply with this safety instruction can lead to serious injury
or even death.
WARNING
This symbol in combination with the signal word "Warning" identifies a potentially haz-
ardous situation for persons with a pacemaker. Failure to comply with this safety instruc-
tion can lead to serious injury or even death.
CAUTION
This symbol in combination with the signal word "Caution" identifies a potentially hazard-
ous situation. Failure to comply with this safety instruction can lead to light or moderate
injury.
NOTE
This symbol in combination with the signal word "Note" identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to product damage.
TIP
This symbol in combination with the signal word "Tip" identifies additional information or
notes that will simplify working with TW AUDiO products on the basis of practical experi-
ence.

Operating Manual for BSX
Operating manual: OM-BSX
Version 1.0 en, 09/2016
© by TW AUDiO 2016; all rights reserved.
All information contained in this operating manual was correct to the best of our knowl-
edge at the time of printing.
Quality warranties or assurance of suitability for a certain type of use based on the tech-
nical specifications, dimensions and weights are not granted by TW AUDiO.
TW AUDiO also shall not assume liability for any secondary damage (property damage
and/or personal injury) nor for the failure to comply with this operating manual.
TW AUDiO reserves the right to make changes that take into account the latest engi-
neering advancements.
TW AUDiO is pleased to receive suggestions for improvement and recommendations on
this operating manual. Please send us any feedback you may have to the following e-
mail address.
[email protected]
TW AUDiO GmbH
Osterholzallee 140-2
71636 Ludwigsburg, Germany
Telephone: +49 71 41 - 48 89 89 0
Fax: +49 71 41 - 48 89 89 99
Notes on the products
Read manual
before use!
Before setting up the device, read the operating manual carefully and keep this docu-
ment in a safe place together with the BSX loudspeaker.
General information

Operating Manual for BSX
Content
Safety | Intended use .....................................................................................................1
Overview ........................................................................................................................3
Components ....................................................................................................................... 3
Operation modes ................................................................................................................4
Technical data ................................................................................................................5
Data sheet .......................................................................................................................... 5
Wiring diagram ................................................................................................................... 5
Setting up the loudspeaker ..........................................................................................6
Setup .................................................................................................................................. 6
Connecting cables ..............................................................................................................6
Operation ............................................................................................................................ 6
Transport and storage ..................................................................................................7
CE Conformity Declaration ...........................................................................................8
Disposal ..........................................................................................................................9

1
Operating Manual for BSX
1. Safety | Intended use
Please adhere to the following safety instructions to avoid risks when operating the loud-
speakers.
The BSX loudspeaker was developed for professional use in sound systems. The loud-
speaker may only be used by trained and qualified personnel.
Note the operation modes described in this operating manual.
Other uses are not permissible.
TW AUDiO GmbH shall not be held liable for any damage that ensues from unintended
use.
WARNING
Loudspeakers generate an electromagnetic field. Persons with pacemakers are not per-
mitted to remain in the immediate vicinity of loudspeakers as the electromagnetic fields
can cause pacemakers to malfunction.
WARNING
When working with heavy loads over 20 kg [44,09 lbs], use suitable aids (dollies, hoist-
ing slings, etc.). Multiple people may be required depending on the situation.
Ensure that the units are in a stable position and are firmly attached. A falling loud-
speaker can result in serious personal injury and property damage.
When using and assembling TW AUDiO loudspeakers, only use materials specified by
TW AUDiO. These tasks must be performed by qualified personnel. Adhere to the appli-
cable safety regulations.
NOTE
When using the loudspeakers, ensure that they are not exposed to the following ambient
conditions:
• Direct sunlight
• Moisture
• Jolting
•Dust
WARNING
Keep away from the immediate vicinity of loudspeakers that are operated at high sound
pressure levels. These loudspeaker systems are capable of endangering your health.
Sound levels beginning as low as approx. 90 dB SPL can lead to long-term hearing im-
pairment.
NOTE
Avoid:
• Feedback
• Distorted signals (clipping)
• Peaks that result when devices are switched on or hot plugged and unplugged.
These signals can lead to loudspeaker overload..

2
Operating Manual for BSX
Note that TW AUDiO does not provide a warranty for damage that can be attributed to
this type of overload and therefore cannot be held liable for any secondary damage.
WARNING
Ensure that the loudspeaker is not exposed to permanent thermal overloads. This may
cause a fire and result in serious property damage and personal injury.
NOTE
A permanent, magnetic field is present in the immediate vicinity of loudspeakers. Ensure
that objects which react sensitively to magnetic fields are not located in the immediate
vicinity of the loudspeaker. In particular, this applies to magnetic data carriers, EC cards
and CRT displays. A distance of approx. one meter is sufficient to avoid damage.
NOTE
Check loudspeakers and accessory parts regularly for visible wear. This is essential to
ensure fault-free operation on a permanent basis. Replace worn parts promptly. Spare
parts can be obtained from TW AUDiO.

3
Operating Manual for BSX
2. Overview
Figure 2.1 - Overview
1. Milling for rubber feet for safely stacking loudspeakers
2. Ergonomic carrying handles (12 pieces)
3. 18 mm multiplex enclosure – polyurea surface finish
4. Rubber feet (8 pieces)
5. Type label
6. Standard connection panel
7. 100 mm castor with stopper (2 pieces)
8. 100 mm castor without stopper (2 pieces)
9. 21" cone drivers
2.1 Components
2
2
2
7
8
9
3
6
4
4
1
1
5
9

4
Operating Manual for BSX
The BSX loudspeaker can be operated in two operation modes. The operation mode is
selected by choosing the preset in the system amplifier.
2.2.1. Full
Operation with Full Preset is recommended if the BSX loudspeaker is the only bass
loudspeaker used in the system.
2.2.2. Infra
Operation in Infra Preset is recommended if the BSX loudspeaker is used as an addi-
tional bass loudspeaker in the system for extending the lower limit frequency. In Infra op-
eration, the upper limit frequency of the loudspeaker is significantly lower than in opera-
tion with Full Preset.
Figure 2.2.2 Frequency response of BSX presets
2.2 Operation modes
+6 dB
0 dB
-6 dB
PRESETS RESPONSE
FULL
INFRA
63 Hz 100 Hz40 Hz25 Hz 160 Hz16 Hz

5
Operating Manual for BSX
3. Technical data
Figure 3.2 - Wiring diagram
3.1 Data sheet
Components 2x 21" LF
Frequency response 27 - 120Hz
Power handling, program/
peak 2x 3600 W / 2x 7200 W
Impedance 2x 4Ω
SPL max./1 m 142 dB
Dimensions (h x w x d) 606 x 1406 x 900 mm [23,86 x 55,35 x 35,43 in]
Weight 109 kg [240,3 lbs]
Finish Polyurea surface finish
3.2 Wiring diagram
4 OHM
4 OHM
+
--
+
--
parallel
PIN 1+
PIN 1–
PIN 2+
PIN 2–
PIN 1+
PIN 1–
PIN 2+
PIN 2–
LF 21"
LF 21"
S1
S2

6
Operating Manual for BSX
4. Setting up the loudspeaker
The BSX loudspeaker is designed for upright and horizontal operation.
To connect the loudspeaker with an amplifier rack from TW AUDiO, proceed as follows.
The correct presets need to be selected for the cable connections.
TW AUDiO recommends operating the BSX loudspeaker on a DSP controller.
TW AUDiO only recommends using presets developed by TW AUDiO. The TW AUDiO
system racks are ideal for this purpose.
4.1 Setup
WARNING
Ensure that the loudspeakers are securely attached to prevent personal injury and prop-
erty damage. Secure stacked loudspeakers properly so that they can be tipped by 10° in
any direction without toppling.
4.2 Connecting cables
NOTE
Please note that the parallel operation of several BSX loudspeakers is not recom-
mended by TW AUDiO due to the low impedance. This can cause damage to the loud-
speaker and amplifier.
NOTE
Ensure that the cable cross section is sufficiently large (at least 1.5 mm²) to avoid power
losses. TW AUDiO recommends using the loudspeaker cables available from
TW AUDiO.
When connecting the cables to the loudspeaker, ensure that the polarity (+/-) and pin as-
signment (1/2) are correct. Incorrect connection results in a significant change in the
loudspeaker sound characteristics and may damage the compression driver.
The pin connections of the BSX loudspeaker can be found in section 3.2 “Wiring dia-
gram” on page 5.
The total impedance of loudspeakers connected in parallel must not drop below the min-
imum operating impedance of the amplifier.
4.3 Operation
NOTE
Ensure that the right preset was selected before connecting the loudspeaker with the
amplifier.
Operating with an incorrect preset can damage parts of the loudspeaker.
NOTE
Ensure that the amplifier is properly sized according to requirements. Undersizing or
oversizing may damage the loudspeaker.
Please note the technical data in section 3.1 “Data sheet” on page 5.

7
Operating Manual for BSX
5. Transport and storage
NOTE
As the BSX loudspeaker weighs over 100 kg [220 lbs], four people are needed to move
and transport the unit.
To transport the unit with a single person, TW AUDiO recommends using the wheels on
the rear of the unit.
When transporting and storing the unit, it is important to ensure that the finish and front
grill of the loudspeaker are not damaged. Moisture can penetrate through exposed wood
surfaces and cause the wood to swell. A bent or broken front grill will no longer ade-
quately protect the sensitive speaker membranes.
In addition, appreciable dust deposits may considerably impair the functionality of a
loudspeaker membrane. For this reason, the loudspeakers should be transported and
stored in a safe, careful, dry and largely dust-free manner.
The following accessory parts for transport and storage are available from TW AUDiO:
• FDBSX (Frontdolly)
• CoverBSX (protective cover)
The original packaging is unsuitable as permanent storage and transport packaging.

8
Operating Manual for BSX
6. CE Conformity Declaration
Copy and translation of the original CE Conformity Declaration:
We hereby declare that the below-referenced components by virtue of their design and
construction, and in the configuration placed on the market by us, satisfy the safety and
health requirements of the applicable EC directives. This declaration becomes invalid in
case of modifications that have not been approved by us.
This declaration applies to the following components:
•BSX
as well as all model variants based on these, provided that they correspond to the origi-
nal factory models and have not been technically modified in any way.
Applicable directives:
• 2001/95/EC
• 2011/65/EU
Applicable national standards and technical specifications:
• DIN 18800
• DIN 4113
• DIN EN ISO 14121-1
• BGV C1/BGI 810-3
• EN 50581:2012
Ludwigsburg, Germany, 01 April 2014 ___________________________
Tobias Wüstner

9
Operating Manual for BSX
7. Disposal
It is prohibited to dispose of used electrical equipment with household refuse
All products of TW AUDiO GmbH are so-called B2B products. This means that they are
sold by a commercial business to a commercial business. TW AUDiO products that bear
the trash can symbol shown here are only permitted to be disposed of by TW AUDiO.
The loudspeaker owner is legally responsible for the disposal of used devices that do
not bear this symbol. This pertains to all products delivered prior to 29 March 2010. Nev-
ertheless, TW AUDiO will also be happy to assist you in this case.
If you have any question regarding the disposal of used devices, please contact us un-
der the following telephone number:
+49 (0) 71 41 - 48 89 89 0
Thus, TW AUDiO is in strict compliance with the Waste Electrical and Electronic Equip-
ment Directive (2012/19/EU) for the protection of our environment.
TW AUDiO is registered under the following WEEE reg. no. with the German National
Register EAR as a B2B manufacturer and distributor of electrical devices:
DE54488702
In countries outside of the European Union, follow the local regulations.

TW AUDiO GmbH
Osterholzallee 140-2
71636 Ludwigsburg, Germany
Germany
P: + 49 (0) 71 41-48 89 89 0
F: + 49 (0) 71 41-48 89 89 99
E: [email protected]
W: www.twaudio.de
