TYAN GT75-BP012 Quick start guide

1
http://www.tyan.com
GT75-BP012
Service Engineer’s Manual

2
http://www.tyan.com

3
http://www.tyan.com
PREFACE
Copyright
This publication, including all photographs, illustrations, and software, is
protected under international copyright laws, with all rights reserved.
Neither this manual, nor any material contained herein, may be reproduced
without written consent of manufacturer.
Copyright 2017 MITAC COMPUTING TECHNOLOGY CORPORATION. All
rights reserved. TYAN®is a registered trademark of MITAC COMPUTING
TECHNOLOGY CORPORATION.
Version 1.0b
Disclaimer
Information contained in this document is furnished by MITAC COMPUTING
TECHNOLOGY CORPORATION and has been reviewed for accuracy and
reliability prior to printing. MITAC assumes no liability whatsoever, and
disclaims any express or implied warranty, relating to sale and/or use of TYAN®
products including liability or warranties relating to fitness for a particular
purpose or merchantability. MITAC retains the right to make changes to
produce descriptions and/or specifications at any time, without notice. In no
event will MITAC be held liable for any direct or indirect, incidental or
consequential damage, loss of use, loss of data or other malady resulting from
errors or inaccuracies of information contained in this document.
Trademark Recognition
All registered and unregistered trademarks and company names contained in
this manual are property of their respective owners including, but not limited to
the following.
TYAN®is a trademark of MITAC COMPUTING TECHNOLOGY
CORPORATION.
Intel®is a trademark of Intel®Corporation.
AMI®, AMIBIOS® and combinations thereof are trademarks of AMI
Technologies.
Microsoft®, Windows®are trademarks of Microsoft Corporation.
IBM®, PC®, AT®and PS/2®are trademarks of IBM Corporation.
Winbond®is a trademark of Winbond Electronics Corporation.

4
http://www.tyan.com
● FCC Declaration
Notice for the USA
Compliance Information Statement (Declaration of Conformity Procedure) DoC FCC
Part 15: This device complies with part 15 of the FCC Rules.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following conditions:
‧This device may not cause harmful interference.
‧This device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
Notice for Canada
This Class A digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la Classe A est conforme à la norme NMB-003 du Canada.
● Notice for Europe (CE Mark)
This product is in conformity with the Council Directive 2014/30/EU.

5
http://www.tyan.com
Warning
This equipment is compliant with Class A of CISPR 32. In a residential environment
this equipment may cause radio interference.
CAUTION
Lithium battery included with this board. Do not puncture, mutilate, or dispose of
battery in fire. There will be danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by manufacturer.
Dispose of used battery according to manufacturer instructions and in accordance
with your local regulations.
● VCCI-A
この装置は、クラスＡ情報技術装置です。この装置を家庭環境で使用すると電波妨
害を引き起こすことがあります。この場合には使用者が適切な対策を講ずるよう要
求されることがあります。
● Safety: EN/IEC 60950-1
This equipment is compliant with CB/LVD of Safety: EN/IEC 60950-1.

6
http://www.tyan.com
Taiwan BSMI RoHS declaration
設備名稱： 伺服器
Equipment Name: Server
單位
Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛
Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
Chromium
(Cr6+)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
電池/電池組
Battery/Battery pack
–O O O O O
CD/DVD 驅動器
CD/DVD Drive
–O O O O O
風扇 Fans –O O O O O
硬碟 Hard Disk
Drive
–O O O O O
擴充抽取盒 I/O
Drawer
–O O O O O
機械組件
Mechanical
Assemblies
–
O O O O O
塑膠材料 Plastics OO O O O O
PCI 介面卡 PCI Card –O O O O O
電源線 Power Cord –O O O O O
電源供應器 Power
Supply
–O O O O O
印刷電路板 Printed
Circuit Board
–O O O O O
處理器模組
Processor Module
–O O O O O
固態硬碟 Solid State
Drive
–O O O O O
備考 1：“O” 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 1：“O” indicates that the percentage content of the restricted substance does not exceed the
percentage of reference value of presence.
備考 2：“ – " 係指該項限用物質為排除項目。
Note 2：“ – " indicates that the restricted substance corresponds to the exemption.
法律免責聲明 CNS 15663 免責聲明：此表格提供的資訊僅符合台灣適用法律。並不代表神雲科技向客戶履行
任何保證或責任。該表格的假設正常條件是產品的使用情況與神雲科技操作手冊運作一致。
CNS 15663 Disclaimer: The information provided in this table is solely to comply with applicable laws of
Taiwan. It does not create any warranties or liabilities on behalf of MITAC Computing Technology
Corporation (“MITAC”) to customers. The table assumes that the product will be used under normal
conditions in accordance with the MITAC operating manual.

7
http://www.tyan.com
About this Manual
This manual is intended for trained service technician/personnel with hardware
knowledge of computers. Components inside the compartments should be serviced
only by a trained service technician/personnel. This manual is aimed to provide you
with instructions on installing your TYAN GT75-BP012.
How this guide is organized
This guide contains the following parts:
Chapter 1: Overview
This chapter provides an introduction to the TYAN GT75-BP012 barebones and
standard parts list, describes the external components, gives an overview of the
product from different angles.
Chapter 2: Setting Up
This chapter covers procedures on installing the processors, memory modules, hard
drivers and other optional parts.
Chapter 3: Replacing the Pre-installed Components
This chapter covers the removal and replacement procedures for pre-installed
components.
Chapter 4: Mainboard Information
This chapter lists the hardware setup procedures that you need to abide by when
installing system components. It includes description of the jumpers and connectors
on the motherboard.
Chapter5: Petitboot Bootloader
This chapter describes the Petitboot menu program. The menu program lets you
modify basic configuration settings. The settings are then stored in a NVRAM
partition that retains the information even when the power is turned off.
Chapter 6: Diagnostics
This chapter introduces the Hostboot initial program loads (IPLs) progress codes The
table describes the type of checkpoints that may occur during the IPLs portion of the
Hostboot: BIOS codes and technical terms to provide better service for the
customers.
Appendix:
This chapter provides the cable connection table, the FRU parts list for reference of
system setup, and technical support in case a problem arises with your system.

8
http://www.tyan.com
Safety and Compliance Information
Before installing and using TYAN GT75-BP012, take note of the following
precautions:
·Read all instructions carefully.
·Do not place the unit on an unstable surface, cart, or stand.
·Do not block the slots and opening on the unit, which are provided for
ventilation.
·Only use the power source indicated on the marking label. If you are not
sure, contact the power company.
·The unit uses a three-wire ground cable, which is equipped with a third pin to
ground the unit and prevent electric shock. Do not defeat the purpose of this
pin. If your outlet does not support this kind of plug, contact your electrician
to replace your obsolete outlet.
·Do not place anything on the power cord. Place the power cord where it will
not be in the way of foot traffic.
·Follow all warnings and cautions in this manual and on the unit case.
·Do not push objects in the ventilation slots as they may touch high voltage
components and result in shock and damage to the components.
·When replacing parts, ensure that you use parts specified by the
manufacturer.
·When service or repairs have been done, perform routine safety checks to
verify that the system is operating correctly.
·Avoid using the system near water, in direct sunlight, or near a heating
device.
·Cover the unit when not in use.

9
http://www.tyan.com
Safety Information
Retain and follow all product safety and operating instructions provided
with your equipment. In the event of a conflict between the instructions in
this guide and the instructions in equipment documentation, follow the
guidelines in the equipment documentation.
Observe all warnings on the product and in the operating instructions. To
reduce the risk of bodily injury, electric shock, fire and damage to the
equipment, observe all precautions included in this guide.
You must become familiar with the safety information in this guide before
you install, operate, or service TYAN products.
Symbols on Equipment
Caution. This symbol indicates a potential hazard.
The potential for injury exists if cautions are not
observed. Consult equipment documentation for
specific details.
Caution. Slide-mounted equipment is not to be
used as a shelf or a work space.
Warning. This symbol indicates the presence of
hazardous energy circuits or electric shock
hazards. Refer all servicing to qualified personnel.
Warning. This symbol indicates the presence of a
hot surface or hot component. If this surface is
contacted, the potential for injury exists.
To reduce risk of injury from a hot component,
allow the surface to cool before touching.
General Precautions
· Follow all caution and warning instructions marked on the equipment and
explained in the accompanying equipment documentation.

Machine Room Environment
· This device is for use only in a machine room or IT room.
 · Make sure that the area in which you install the system is properly
ventilated and climate-controlled.

10
http://www.tyan.com
· Ensure that the voltage and frequency of your power source match the
voltage and frequency inscribed on the electrical rating label of the
equipment.
·Do not install the system in or near a plenum, air duct, radiator, or heat
register.
·Never use the product in a wet location.
Equipment Chassis
· Do not block or cover the openings to the system.
·Never push objects of any kind through openings in the equipment.
Dangerous voltages might be present.
·Conductive foreign objects can produce a short circuit and cause fire,
electric shock, or damage to your equipment.
·Lift equipment using both hands and with your knees bent.
Equipment Racks
To avoid injury or damage to the equipment:
·Observe local occupational health and safety requirements and guidelines
for manual materials handling.
·Do not attempt to move a rack by yourself; a minimum of two people are
needed to move a rack.
·Do not attempt to move a fully loaded rack. Remove equipment from the
rack before moving it.
·Do not attempt to move a rack on an incline that is greater than 10 degrees
from the horizontal.
·Make sure the rack is properly secured to the floor or ceiling.
·Make sure the stabilizing feet are attached to the rack if it is a single-rack
installation.
·Make sure racks are coupled together if it is a multiple-rack installation.
·Make sure the rack is level and stable before installing an appliance in the
rack.
·Make sure the leveling jacks are extended to the floor.

11
http://www.tyan.com
·Make sure the full weight of the rack rests on the leveling jacks.
·Always load the rack from the bottom up. Load the heaviest component in
the rack first.
·Make sure the rack is level and stable before pulling a component out of the
rack.
·Make sure only one component is extended at a time. A rack might become
unstable if more than one component is extended.
To avoid damage to the equipment:
· The rack width and depth must allow for proper serviceability and cable
management.
· Ensure that there is adequate airflow in the rack. Improper installation or
restricted airflow can damage the equipment.
·The rack cannot have solid or restricted airflow doors. You must use a
mesh door on the front and back of the rack or remove the doors to ensure
adequate air flow to the system.
·If you install the Model in a rack, do not place equipment on top of the unit.
It will cause restricted airflow and might cause damage to the equipment.
·Make sure the product is properly matted with the rails. Products that are
improperly matted with the rails might be unstable.
·Verify that the AC power supply branch circuit that provides power to the
rack is not overloaded. This will reduce the risk of personal injury, fire, or
damage to the equipment. The total rack load should not exceed 80 percent
of the branch circuit rating. Consult the electrical authority having jurisdiction
over your facility wiring and installation requirements.
Equipment Power Cords
· Use only the power cords and power supply units provided with your
system. The system might have one or more power cords.
·Plug the power cord into a grounded (earthed) electrical outlet that is easily
accessible at all times.
·In all European electrical environments, you must ground the Green/Yellow
tab on the power cord. If you do not ground the Green/Yellow tab, it can
cause an electrical shock due to high leakage currents.
·
Do not place objects on AC power cords or cables. Arrange them so that no

12
http://www.tyan.com
one might accidentally step on or trip over them.
·Do not pull on a cord or cable. When unplugging from the electrical outlet,
grasp the cord by the plug.
·To reduce the risk of electrical shock, disconnect all power cords before
servicing the appliance.
Equipment Batteries
· The system battery contains lithium manganese dioxide. If the battery pack
is not handled properly, there is risk of fire and burns.
·Do not disassemble, crush, puncture, short external contacts, or dispose of
the battery in fire or water.
·Do not expose the battery to temperatures higher than 60°C (140°F).
·The system battery is not replaceable. If the battery is replaced by an
incorrect type, there is danger of explosion. Replace the battery only with a
spare designated for your product.
·Do not attempt to recharge the battery.
·Dispose of used batteries according to the instructions of the manufacturer.
Do not dispose of batteries with the general household waste. To forward
them to recycling or proper disposal, use the public collection system or return
them to TYAN, your authorized TYAN partner, or their agents.
Equipment Modifications
· Do not make mechanical modifications to the system. TYAN is not
responsible for the regulatory compliance of TYAN equipment that has been
modified.
Equipment Repairs and Servicing
· The installation of internal options and routine maintenance and service of
this product should be performed by individuals who are knowledgeable about
the procedures, precautions, and hazards associated with equipment
containing hazardous energy levels.
·Do not exceed the level of repair specified in the procedures in the product
documentation. Improper repairs can create a safety hazard.
·Allow the product to cool before removing covers and touching internal

13
http://www.tyan.com
components.
·Remove all watches, rings, or loose jewelry when working before removing
covers and touching internal components.
·Do not use conductive tools that could bridge live parts.
·Use gloves when you remove or replace system components; they can
become hot to the touch.
·If the product sustains damage requiring service, disconnect the product
from the AC electrical outlet and refer servicing to an authorized service
provider. Examples of damage requiring service include:
– The power cord, extension cord, or plug has been damaged.
– Liquid has been spilled on the product or an object has fallen into the
product.
–The product has been exposed to rain or water.
– The product has been dropped or damaged.
– The product does not operate normally when you follow the operating
instructions.

http://www.tyan.com
14
Table of Contents
Chapter 1: Overview....................................................................... 17
1.1 About the TYAN GT75-BP012 ............................................... 17
1.2 Product Models....................................................................... 17
1.3 Features.................................................................................. 18
1.4 Standard Parts List ................................................................. 24
1.4.1 Box Contents ................................................................... 24
1.4.2 Accessories ..................................................................... 24
1.5 About the Product................................................................... 25
1.5.1 System Front View .......................................................... 25
1.5.2 System Rear View ........................................................... 27
1.5.3 System Top View............................................................. 28
Chapter 2: Setting Up..................................................................... 29
2.0.1 Before you Begin ............................................................. 29
2.0.2 Work Area........................................................................ 29
2.0.3 Tools ................................................................................ 29
2.0.4 Precautions...................................................................... 30
2.1 Installing Motherboard Components ...................................... 31
2.1.1 Removing the Chassis Cover.......................................... 31
2.1.2 Removing the Air Duct..................................................... 32
2.1.3 Installing the CPU, Heatsink and Air Duct....................... 33
2.1.4 Installing the Memory ...................................................... 35
2.1.5 Installing the LAN Mezz Card .......................................... 38
2.1.6 Installing Hard Drives ...................................................... 39
2.2 Rack Mounting........................................................................ 41
2.2.1 Installing the Server in a Rack......................................... 41
2.2.2 Installing the inner Rails to the Chassis .......................... 42
2.2.3 Installing the Outer Rails to the Rack .............................. 44
2.2.4 Rack mounting the Server ............................................... 45
Chapter 3: Replacing Pre-Installed Components ........................ 47
3.0.1 Introduction...................................................................... 47
3.0.2 Disassembly Flowchart.................................................... 47
3.1 Removing the Cover............................................................... 48
3.2 Replacing Motherboard Components..................................... 48
3.2.1 Disconnecting All Motherboard Cables ........................... 48
3.2.2 Removing the Motherboard ............................................. 49
3.3 Replacing the Storage Mezz Card ......................................... 50
3.4 Replacing the Fan .................................................................. 51
3.5 Replacing the HDD Backplane Board .................................... 53
3.5.1 HDD BP Board Features ................................................. 55

http://www.tyan.com
15
3.5.2 Connector Pin Definitions ................................................ 56
3.6 Replacing the Front Panel Board ........................................... 57
3.6.1 Front Panel Board Features ............................................ 58
3.6.2 Connector Pin Definitions ................................................ 59
3.7 Replacing the Power Supply .................................................. 60
Chapter 4: Mainboard Information................................................ 61
4.1 Board Image ........................................................................... 62
4.2 Block Diagram ........................................................................ 63
4.3 Mainboard Mechanical Drawing ............................................. 64
4.4 Board Parts, Jumpers and Connectors .................................. 65
4.5 Tips on Installing Motherboard in Chassis ............................. 72
4.6 Memory................................................................................... 74
4.7 Connecting External Devices ................................................. 76
4.8 Installing the Power Supply .................................................... 77
Chapter 5: Petitboot Bootloader ................................................... 79
5.1 About the Petitboot ................................................................. 79
5.1.1 Setup Basics.................................................................... 79
5.1.2 Getting Help..................................................................... 80
5.1.3 In Case of Problems ........................................................ 80
5.1.4 Setup Variations .............................................................. 80
5.2 Petitboot Main Menu............................................................... 81
5.3 Petitboot System Information ................................................. 83
5.4 Petitboot System Configuration.............................................. 84
5.5 Petitboot Config Retrieval....................................................... 86
5.6 Petitboot Shell ........................................................................ 87
Chapter 6: Diagnostics .................................................................. 89
6.1 Flash Utility ............................................................................. 89
6.2 Hostboot IPLs Progress Code................................................ 90
Appendix I: Cable Connection Tables .......................................... 95
Appendix II: FRU Parts Table ........................................................ 97
Appendix III: Set BMC IP address................................................. 99
A.1 Via Petitboot to set BMC IP.................................................... 99
A.2 Via MEGARAC to set BMC IP.............................................. 103
Appendix IV: Technical Support ................................................. 105

http://www.tyan.com
16
NOTE

http://www.tyan.com
17
Chapter 1: Overview
1.1 About the TYAN GT75-BP012
Congratulations on your purchase of the TYAN®GT75-BP012, a highly optimized
1U rack-mountable barebone system. The GT75-BP012 is designed to support
single IBM®Power 8 Turismo SCM processor and up to 512GB 1600MHz
DDR3L-RDIMM memory, providing a rich feature set and incredible performance.
Leveraging advanced technology from IBM®, the GT75-BP012 server system is
capable of offering scalable 32 and 64-bit computing, high bandwidth memory
design, and lightning-fast PCI-E bus implementation. The GT75-BP012 not only
empowers your company in nowadays IT demand but also offers a smooth path for
future application usage.
TYAN®also offers the GT75-BP012 in a version that can support up to four
hot-swap SAS/SATA 6G/12G hard drives. The GT75-BP012 uses TYAN’s latest
chassis featuring a robust structure and a solid mechanical enclosure. All of this
provides GT75-BP012 the power and flexibility to meet the needs of nowadays
server application.
1.2 Product Models
The system board within the Tyan MicroServer blades contain different processors
and chipsets, which are defined by the following models:
GT75-BP012: IBM-based platform

http://www.tyan.com
18
1.3 Features
TYAN GT75-BP012 (BSP012G75V4H-B4C)
System
Form Factor 1U Rackmount
Gross Weight 18 kg
Chassis Model GT75
Dimension (D x W x
H) 29.72" x 17.24" x 1.72" (755 x 438.5 x 43.7mm)
Motherboard SP012GMR-1U
Barebone BP012G75V4H
Front Panel
Buttons (1) RST / (1) NMI / (1) ID / (1) PWR w/ LED
LEDs (1) HDD / (1) ID / (1) Warning / (3) LAN
I/O Ports (1) USB 3.0 port
External Drive
Bay
Type / Q'ty 3.5"/2.5” Hot-Swap / (4)
Supported HDD
Interface (4) SAS 12Gb/s / SATA 6Gb/s
Pre-install TYAN
Storage Mezzanine
MP012-9235-4I (4-port SATA 6Gb/s IOC w/o RAID
stack)
Pre-install HDD/SSD (2) 512GB SSD
System Cooling
Configuration FAN (8) 4cm fans
Power Supply
Type PSU
Efficiency 80 plus Platinum
Input Range AC 100~127V/ 9.2A / AC 200~240V/ 4.4A
Frequency 47 - 63 Hz
Output Watts 750 Watts
Processor
Supported CPU
Series IBM POWER8 Turismo SCM processor
Socket Type / Q'ty IBM POWER8 Turismo SCM/ (1)
Thermal Design
Point (TDP) wattage Up to 130W (Nominal) / 169W (Turbo)
Pre-install Processor (1) POWER8 8-Core 2.328GHz processor
Chipset Switch IC (1) PLX PEX8748
Chipset (4) IBM Centaur MBC
Memory
Supported DIMM Qty (32) DIMM slots
DIMM Type / Speed RDIMM-DDR3L 1600
Capacity Up to 512GB
Memory voltage 1.35V
Pre-install Memory (8) R-DDR3L 16GB
Expansion Slots PCI-E (1) PCI-E Gen.3 x8 slot
LAN
Port Q'ty (4) GbE ports / (1) PHY
Controller Broadcom BCM5719
PHY Broadcom BCM5221A

http://www.tyan.com
19
Pre-install TYAN
LAN Mezz Card
(1) MP012-B719-4C Broadcom 1GbE LAN Mezz
Card
Graphic
Connector type D-Sub 15-pin
Resolution Up to 1920x1200
Chipset Aspeed AST2400
I/O Ports
USB (4) USB ports (1x USB3.0 @ front, 2x USB3.0 @
rear, 1x USB1.1 @ rear no function)
COM (1) DB-9 COM port
VGA (1) D-Sub 15-pin port
RJ-45 (4) GbE ports, (1) PHY dedicated for IPMI
System
Monitoring
Chipset Aspeed AST2400
Voltage Monitors voltage for CPU, memory, chipset & power
supply
Temperature Monitors temperature for CPU & memory & system
environment
LED Over temperature warning indicator / Fan & PSU fail
LED indicator
Server
Management
Onboard Chipset Onboard Aspeed AST2400
AST2400 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub
PNOR
Brand / ROM Size IBM / 64MB
Features
Boot from USB device / CD-ROM / Storage / PXE
via LAN / IPMI Support / Device Tree / Console
Redirection / OCC (Power Management) / Petitboot
Bootloader (PPC64)
Regulation
FCC (DoC) Class A
CE (DoC) Class A
VCCI Class A
CB/LVD Yes
RCM Class A
Operating
Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Package
Contains
Barebone (1) GT75-BP012 Barebone w/MP012-9235-4I
SATA 6G Mezz Card
Manual (1) Web User's manual / (1) Quick Installation Guide
Others
(8) R-DDR3L 16GB / (2) 512GB SSD / (1) POWER8
8-Core 2.328GHz processor / (1) MP012-B719-4C
TYAN LAN Mezz Card

http://www.tyan.com
20
TYAN GT75-BP012 (BSP012G75V4H-Q4T)
System
Form Factor 1U Rackmount
Gross Weight 18 kg
Chassis Model GT75
Dimension (D x W x
H) 29.72" x 17.24" x 1.72" (755 x 438.5 x 43.7mm)
Motherboard SP012GMR-1U
Barebone BP012G75V4H
Front Panel
Buttons (1) RST / (1) NMI / (1) ID / (1) PWR w/ LED
LEDs (1) HDD / (1) ID / (1) Warning / (3) LAN
I/O Ports (1) USB 3.0 port
External Drive
Bay
Type / Q'ty 3.5"/2.5” Hot-Swap / (4)
Supported HDD
Interface (4) SAS 12Gb/s / SATA 6Gb/s
Pre-install TYAN
Storage Mezzanine
MP012-9235-4I (4-port SATA 6Gb/s IOC w/o RAID
stack)
Pre-install HDD/SSD (2) 1TB SSD
System Cooling
Configuration FAN (8) 4cm fans
Power Supply
Type PSU
Efficiency 80 plus Platinum
Input Range AC 100~127V/ 9.2A / AC 200~240V/ 4.4A
Frequency 47 - 63 Hz
Output Watts 750 Watts
Processor
Supported CPU
Series IBM POWER8 Turismo SCM processor
Socket Type / Q'ty IBM POWER8 Turismo SCM/ (1)
Thermal Design
Point (TDP) wattage Up to 130W (Nominal) / 169W (Turbo)
Pre-install Processor (1) POWER8 10-Core 2.095GHz processor
Chipset Switch IC (1) PLX PEX8748
Chipset (4) IBM Centaur MBC
Memory
Supported DIMM Qty (32) DIMM slots
DIMM Type / Speed RDIMM-DDR3L 1600
Capacity Up to 512GB
Memory voltage 1.35V
Pre-install Memory (16) R-DDR3L 16GB
Expansion Slots PCI-E (1) PCI-E Gen.3 x8 slot
LAN
Port Q'ty (1) PHY / (4) 10GbE ports
Controller Qlogic BCM57840 + Broadcom BCM84834
PHY Broadcom BCM5221A
