Tyco R/C shell shocker User manual

<
I
O
q
q
w
tr
e
w
TYCO R/C SUPPORT
Questions or problems with your product?
DON’T RETURN IT TO THE STORE!
Just call us for help.
U.S. consumers may also register their products at this number.
1 888 557-TYCO (8926)
®
tycorc.com
Keep these instructions for future reference: they
contain important information. IMPORTANT: Please
read all “Consumer Information” before operating your
vehicle.
G3457-0920
G3457-9993-S1
XCAUTION: Surfaces may become hot and cause
burns if electronics get wet. Do not operate vehicle
through water or snow.
I. CREATURE FEATURES
Vehicle
Transmitter
Vehicle
q ON/OFF switch
w Battery compartment cover
Transmitter
q Left button controls left shells
w Right button controls right shells
e Bottom left toggle closes Shell Shocker™
r Bottom right toggle opens Shell Shocker™
t ON/OFF switch
II. HOW TO CONTROL THE BEAST!
Basic driving
q FORWARD
w LEFT
e RIGHT
r SPIN LEFT
t SPIN RIGHT
y Closes Shell Shocker™
u Opens Shell Shocker™
Shocking transformations!
Shell Shocker ™ features my ingenious armor shell
configuration that spins and opens for all kinds of
shocking stunts! Here are a few of my favorites.
A Whirlwind spin shield!
With Shell Shocker ™ in explore mode (all shell armor open
outward) push the left button up and the right button down.
For high-speed spins in the opposite direction, push the left
button down and the right button up!
A
NOT RECOMMENDED
FORCHILDRENUNDER
8 YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS,PRECAUTIONS SHOULD BE
OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC SHOCK. INPUT:
120VAC, 60Hz, 0.1A. OUTPUT:8.5VDC, 440mA, 3.74VA.
CAUTION-ELECTRIC TOY:
qwe r
y
tu

B Snap attack tail!
With Shell Shocker ™ in explore mode (all shell armor
open outward) push both buttons up to drive forward.
When you hit full speed, quickly jam both buttons
down. Your vehicle will snap attack with its tail!
*Note: In this mode the tail will come down fast!
Keep feet, fingers and anything that breathes away
from Shell Shocker™
C Defender bender!
With Shell Shocker ™ in explore mode (all armor open
outward) push the left button up and the right button
down. As the Shell Shocker™ spins press the bottom
left toggle switch beneath the transmitter. The shells
will begin closing even as the Shell Shocker™ spins
frantically about! Now open it up mid spin by pressing
the right toggle switch beneath the transmitter.
III. HOW TO BRING MY SHELL SHOCKER™TO LIFE!
Requires a 7.2v Tyco®Pro FlexPak®(NiMH) battery
pack for vehicle and a 9v battery for transmitter .
Vehicle
1. First turn Shell Shocker upside down, tail facing you.
2. Now unscrew the battery compartment cover
(screwdriver not included).
3. Hold the Tyco®Pro FlexPak®battery pack(not included)
facing up as shown.
4. Now slide the battery end marked #1 down into the
battery compartment. Before you press down on the
battery pack make sure to place the ribbon under-
neath the battery for easy pull out later.
5. To remove the battery, unscrew the battery door, pull
on the ribbon and lift out the battery.
Transmitter
1. Open the battery door as shown.
2. Install one 9v battery (not included) with polarity (+/-)
as shown inside the battery compartment.
3. Close the battery door.
1
2
B
C
7.2v d.c. NiMH,
6 x Sub C,
1600 mAh
(not included)

;IV.
DR. KRAIZD’S TOP SECRET QUICK TIPS
qWhen Shell Shocker™ starts to lose power you’ll start
to lose performance. It's time for a recharge. As a rule,
you should always start with a fully charged battery.
wBe forewarned-- Shell Shocker’s running time may
change depending on your driving style.
eRadio interference can mess up the signals you’re
sending, causing Shell Shocker™ to perform errati-
cally. Things to look for that may be causing the
interference: other R/C vehicles running on the
same frequency, electrical wires, large buildings,
CB radios, secret government agents attempting to
thwart my brilliant creations or other wireless gear
that can cause interference.
rPoint your transmitter antenna up - not down
toward Shell Shocker™. If Shell Shocker™
escapes your antenna’s grasp, you can kiss proper
functioning goodbye and send your poor deranged
creature into its default blink mode.
tDon’t drive Shell Shocker™ through water or snow.
Not only won’t you get very far, you might ruin the
creature. If my precious Shell Shocker™ does get
wet, wipe it with a towel and allow it to dry completely.
yDon’t store Shell Shocker™ near heat or in direct
sunlight. Always turn the switches OFF and,
if you’re not planning on taking the little creature
out of its cave for a while, remove all the batter-
ies...really. It’s amazing how one leaky battery can
bring all my brilliant work to ruin!
*Please recharge your battery when you find the
Shell Shocker™'s eyes blink slowly. If the Shell
Shocker™ is blocked by some obstacle, its eyes
will blink in a medium speed. If it cannot receive
any signal from the TX, the eyes will blink fast.
ìV. HANDLING THE BEAST WITH CARE!
Note to Adults: To ensure that the child’s play is both
safe and fun, please review all the operating instructions
and safety tips with your child.
Safety Tips
• Yes, Shell Shocker™ is a multi-terrain vehicle but
you should NEVER, EVER drive it on the street!
• DO NOT pick up Shell Shocker™ while in motion.
Take your fingers off the Transmitter buttons and
then pick it up.
XCAUTION: Keep fingers, hair and loose clothing
away from Shell Shocker™ while it’s on.
• In ‘Snap Attack’ mode the tail comes down fast.
Keep feet, fingers and anything that moves away
from Shell Shocker™ when practicing this mode.
• Adult supervision is recommended when Shell
Shocker™ is being used.
• To avoid accidental or unwanted operation, remove all
the batteries when not in use. Always turn Shell
Shocker™ OFF before removing the batteries.
q
w
e
r
t
y
BATTERY SAFETY INFORMATION
In exceptional circumstances batteries may leak fluids
that can cause a chemical burn injury or ruin your
product. To avoid battery leakage:
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the
product before being charged (if designed to be
removable).
• Rechargeable batteries are only to be charged under
adult supervision (if designed to be removable).
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (NiMH) batteries.
• Do not mix old and new batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the
product.
• The supply terminals are not to be short-circuited.
• Dispose of battery(ies) safely.
• Do not dispose of this product in a fire. The batteries
inside may explode or leak.
Battery Performance Note:
For best performance use regular or high-performance
alkaline batteries (where disposable batteries are
called for).

Mattel, Inc. warrants to the original consumer purchaser that this product will be
free of defects in material and workmanship for ninety (90) days (unless specified in
alternate warranties) from the date of purchase. Mattel will replace the product in
the event of such a defect within the warranty period.
In the event of a defect covered under this warranty, first call the toll-free number
listed below. Many problems can be solved in this manner. If necessary, you will be
instructed to return the product, postage prepaid and insured, to the address below.
Enclose your name, address, dated sales receipt,
and a brief explanation of the defect. Replacement and return shipment will be free
of charge.
This warranty does not cover damage resulting from unauthorized modification,
accident, misuse or abuse. If the product is returned without a dated sales receipt
the product may be excluded from coverage under this warranty.
Mattel’s liability for defects in material and workmanship under this warranty shall
be limited to repair or replacement, at our sole option, and in no event shall we be
responsible for incidental, consequential, or contingent damages (except in those
states that do not allow this exclusion or limitation). This warranty is exclusive, and
is made in lieu of any express or implied warranty. Valid only in U.S.A. This warran-
ty gives you specific legal rights and you may have other rights, which vary from
state to state. Some states do not allow the exclusion of incidental or consequential
damages, so the above exclusions or limitations may not apply to you.
TOLL-FREE NUMBER: 1-888-557-TYCO (8926) (valid only in U.S.A.)
Hours: 8:00 A.M. - 5:00 P.M. Eastern Time; Monday - Friday. Expect some delay in
January following the holiday season. Please be patient and keep trying the toll-free
number.
ADDRESS FOR RETURNS:
CONSUMER RELATIONS
636 GIRARD AVENUE
EAST AURORA, NY 14052
90 DAY LIMITED WARRANTY – TYCO® R/C PRODUCTS
© 2005 Mattel, Inc., 333 Continental Blvd., El Segundo, CA 90245
U.S.A. Consumer Affairs: 1 (800) 524-TOYS. PRINTED IN CHINA.
All Rights Reserved. MATTEL, TYCO and associated trademarks
and trade dress are owned by Mattel, Inc. Retain this address
for future reference: Mattel U.K. Ltd., Vanwall Business Park,
Maidenhead SL6 4UB. Helpline 01628 500303. Mattel Australia
Pty Ltd., Richmond, Victoria 3121 - Consumer Advisory Service:
1300 135 312. Mattel East Asia Ltd, Room 1106, South Tower,
World Finance Centre, Harbour City, Tsimshatsui, HK, China.
Diimport & Diedarkan Oleh: Mattel SEA Ptd Ltd. (993532-P) Lot
13.5, Menara Lien Hoe, Persiaran Tropicana Golf Country
Resort, 47410 PJ. Tel: [phone], Fax: [phone].
COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S. ONLY)
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may
cause undesired operation.
This device generates and uses radio frequency energy and if
not used properly may cause interference to radio and televi-
sion reception. It has been tested and found to comply with the
limits set by the FCC which are designed to provide reasonable
protection against such interference.
NOTE: Changes or modifications not expressively approved by
the manufacturer responsible for compliance could void the
user’s authority to operate the equipment.
