Tycon Power Systems TP-SW5G User manual

TYCON POWER SYSTEMS
TP-SW5G(-NC)
5 port PoE Endspan (Switch)
(Extend Ethernet and PoE)

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
2
1. General Information..............................................................
2. Hardware Description...........................................................
LED Indicators.......................................................................................
Power Wiring ........................................................................................
Ethernet Port Wiring..............................................................................
PD Port Wiring......................................................................................
Network Application……………………………………............................
3. Model Information...........................................................
4. Technical Specification........................................................
3
3
3
5
8
10
11
12
13

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
3
1. General Information
The PoE (Power Over Ethernet) Switch family provide four 10M/100M/1000M TX ports with PoE PSE
function plus one 10M/100M/1000M TX up-link port with PoE PD function. It allows power souring
equipment (PSE) to be powered from PoE and deliver power to PoE powered device (PD), which are
compliant with IEEE802.3af and IEEE802.3at standard to receiver and deliver both Ethernet data and DC
power through the traditional UTP or STP cable. The PoE Switch can extend Ethernet data and DC power
up to 200 meters. This manual will help you install and maintain the PoE switch. Installation of the PoE
switch is very easy and you can start to use the product as soon as you are powered up.
2. Hardware Description
*LED Indicator
There are 12 LEDs on the PoE switch to indicate the status of power and signal. The following section
describes the functions of each LED indicator.
Front panel detail

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
4
*POWER LED
LED
STATUS Description
Power
Green
LED ON when power input (DC IN on
rear panel or Port 5 (UPLINK) on front
panel) has valid power supplied.
Red
The indicator is only used on
TP-SW5G-NC, LED ON when the
following warning condition happens.
*Power input under voltage (Vin<10V)
*Power input over voltage (Vin>59V)
*PoE over current (2A/per port)
the indicator is unused on
TP-SW5G/TP-SW5G24
Off No power supplied.
*SWITCH LED (the right indicator on RJ45)
LED STATUS Description
P1~P5
Link/Act
Green A network device is detected (1000Mbps),
but no communication activity is detected.
Green
Blinking
This port is transmitting to, or receiving
package from another device at 1000Mbps.
Yellow A network device is detected (10Mbps or
100Mbps), but no communication activity
is detected.
Yellow
Blinking
This port is transmitting to, or receiving
package from another device at 10Mbps or
100Mbps.
Off No device is detected.

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
5
*PoE LED (the left indicator on RJ45)
P1~P4
PoE
Yellow A valid Powered Device (PD) is detected
and delivering power on this port.
Off No PD is detected on this port.
P5 (UPLINK)
PoE
Yellow
TP-SW5G&TP-SW5G24:
Powered via all 4 data pairs.
TP-SW5G-NC: power via another PoE(2
data pairs or 4 data pairs)
Yellow
Blanking
TP-SW5G&TP-SW5G24:
Powered via 2 data pairs. (1,2,3,6 or 4,5,7,8
are all acceptable).
TP-SW5G-NC::unused.
Off No power is detected on this port.
*Power wiring
The PoE switch family includes 3 models, be used for 3 different ranges of input voltage:
full range voltage (12 to 57VDC) (P/N: TP-SW5G-NC)
24VDC typical (12 to 36VDC) (P/N: TP-SW5G24)
48VDC typical (40 to 57VDC) (P/N: TP-SW5G)
The PoE switch family allow powered by another PoE source on port 5 (UPLINK) as a PoE repeater or
extender. For TP-SW5G/TP-SW5G24 is 42.5~57VDC, for TP-SW5G-NC is 12~57VDC.
For PoE operation, make sure your power supply may offer at least 75W for 4x 802.3af PoE port, or 150W
for 4x 802.3at PoE port.
If powered via the rear terminal, please make sure the input current is not over 10A. If powered on port 5,
make sure the input current is not over 1Amp.

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
6
Ports 1~4 will deliver DC power over the Ethernet cable as detailed below:
* Data pair A on line 1 and 2
* Data pair B on line 3 and 6
* Data pair C plus V+ on line 4 and 5
* Data pair D plus V- on line 7 and 8
Port 5 may get DC power over the Ethernet cable, as detailed below:
* Data pair A plus V+ /V- on line 1 and 2
* Data pair B plus V-/V+ on line 3 and 6
* Data pair C plus V+/V- on line 4 and 5
* Data pair D plus V-/V+ on line 7 and 8
The terminal block on the rear panel should be wired as detailed below:
*For TP-SW5G24
Please note that the maximum power per port of 35W can only be achieved using 24VDC input operation. If
your input is 12VDC, then the total power per port should be de-rated to 17W per port.
Total output of TP-SW5G24 is 35W(802.3at) x2 or 17W (802.3af) x 4.
*For TP-SW5G
The input voltage must be in the range of 44 to 57VDC if running for 802.3af operation.
The input voltage must be in the range of 50 to 57VDC if running for 802.3at operation.
If the TP-SW5G is not powered with the above designated input voltage, it will only function as an Ethernet
switch without PoE output.

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
7
Model Input Voltage
(REAR) Input Voltage (Port 5) Output voltage 802.3af/at
Isolated
TP-SW5G-NC
12-57VDC No input
12-57VDC
(As input voltage)
(non-regulated) No No
No input 12-57VDC 12-57VDC
(non-regulated) No No
12-57VDC 12-57VDC
Higher voltage
output
(REAR or Port 5)
No No
TP-SW5G24
12-36VDC No input 56VDC
(regulated) Yes No
No input 42.5-57VDC 42.5-57VDC
(non-regulated) Yes No
12-36VDC 42.5-57VDC 56VDC
(regulated) Yes No
TP-SW5G
40-57VDC No input 40-57VDC
(non-regulated) Yes No
No input 42.5-57VDC 42.5-57VDC
(non-regulated) Yes No
40-57VDC 42.5-57VDC
Higher voltage
output
(REAR or Port5)
Yes No
You can use the TP-SW5G(NC) series with our adaptor products as detailed below: (OPTION)
PSHP-18 PSHP-24 PSHP-48
Maximum output 18VDC/7.5A 24VDC/6.25A 48VDC/3.125A
Related model TP-SW5G-NC
TP-SW5G24
TP-SW5G-NC
TP-SW5G24
TP-SW5G-NC
TP-SW5G

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
8
*Ethernet Port Wiring
The PoE switch family supports one RJ-45 uplink (port 5 with PoE PD) and four RJ-45 ports (port 1~4 with
PoE PSE) with automatic MDI/MDI-X crossover, auto-sense for speed and duplex for 10Base-T,
100Base-TX or 1000Base-T connection. Automatic MDI/MDI-X crossover allows you to connect to other
devices (switches, hubs, or workstations etc.), without regard to using straight-through or crossover cabling.
Port 1 to 4 provides Power over Ethernet function that delivers DC power through the data pairs C & D (pair
4,5 and pair7,8) to the PD. Port 5 provides Power Device function that receive power from 4 pairs or 2 pairs
Ethernet cable.
The following tables describe the wiring diagram of straight-through and crossover cabling. The crossover
cables simply cross-connect the transmit lines at each end to the receive lines at the opposite end.
Straight-through Cabling
Pin 1 Pin 1
Pin 2 Pin 2
Pin 3 Pin 3
Pin 6 Pin 6
Pin 4 Pin 4
Pin 5 Pin 5
Pin 7 Pin 7
Pin 8 Pin 8

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
9
Cross-over Cabling
Pin 1 Pin 3
Pin 2 Pin 6
Pin 3 Pin 1
Pin 6 Pin 2
Pin 4 Pin 7
Pin 5 Pin 8
Pin 7 Pin 4
Pin 8 Pin 5
Connect an Ethernet cable into any switch port and connect the other side to your
attached device. The Link/Act LED (green or yellow) will light up when the cable is correctly connected.
Refer to the LED Indicator section for descriptions of each LED indicator.
If a port LED is off, go back and check for connectivity problems between that port and the network device
connected.
The maximum cable length for 10/100/1000BaseT with Cat 5 twisted pair cables is typically 100m (328 ft.).

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
10
*PD Port Wiring
Port 1 to 4 provides PoE injection function with maximum 35W ability to power up the powered device
using the straight-through or cross-over Ethernet cable.
The PoE switch follows the IEEE802.3af Alternative B mode connector assignment. The following table
shows pin assignment of alternative A and B for the Power Source Equipment.
Conductor Alternative A
(MDI-X) Alternative A (MDI) Alternative B (All)
1Negative Vport Positive Vport
2 Negative Vport Positive Vport
3 Positive Vport Negative port
4 Positive Vport
5 Positive Vport
6 Positive Vport NegativeVport
7 Negative Vport
8 Negative Vport
Be sure the twisted pair cable is bound with the standard RJ-45 pin, especially the pins 4, 5, 7 and 8. If the
RJ-45 is bound with the wrong pin number, the PoE switch will not recognize the PD and won’t deliver DC
power to the PD. The yellow PoE LED will light up when the cable is correctly connected. Refer to the LED
Indicator section for descriptions of each LED indicator. If a port LED is off, go back and check for
connectivity problems between that port and the network device connected.

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
11
*Network Application
The PoE Switch can receive power from a PoE midspan and provide power to the PD which follows the
IEEE 802.3af/at standard in the network. The PoE Switch can be installed in a more appropriate position for
better performance to extend Ethernet to 200 meters. The following figure is an example of a network
application for the PoE Switch.
(TP-SW5G-NC added the repeater function since S/N 128000001ARC01)

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
12
3. Model Information
Model Input Voltage
(REAR) Input Voltage (Port 5) Output voltage 802.3af/at
Isolated
TP-SW5G-NC 12-57VDC 12-57VDC 12-57VDC
(non-regulated)
No No
TP-SW5G24 12-36VDC 42.5-57VDC 56VDC
(regulated) Yes No
TP-SW5G 40-57VDC 42.5-57VDC 40-57VDC
(non-regulated)
Yes No
AC/DC Adapter (Option)
PSHP-18 PSHP-24 PSHP-48
Maximum output 18VDC/7.5A 24VDC/6.25A 48VDC/3.125A
Related model TP-SW5G-NC
TP-SW5G24
TP-SW5G-NC
TP-SW5G24
TP-SW5G-NC
TP-SW5G

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
13
4. Technical Specifications
Standards IEEE802.3/IEEE802.3u standards/IEEE802.3ab (10
base-T/100base-TX/1000base-T)
Ports 5 ports with PoE (4 PSE & 1 PD), support auto-crossover &
auto-polarity
Transmission speed 1000Mbps (1000base-T).100 Mbps (100base-TX), 10 Mbps(10base-T)
Auto-negotiation
Switch technology store-and-forward
Protocols CSMA/CD
Flow control IEEE802.3x (full-duplex), back pressure (half-duplex)
Data transmission rate 1488000pps for1000base-T, 148800pps for 100base-T, 14880pps for 10base-T
Address table 1K MAC address table, self-learning
Connect RJ-45
PoE port Port 1-4, PSE auto power management
Pin assignment: data pair A(1,2),data pair B(3,6),data pair C plus
V+(4,5),data pair D plus V-(7,8)
Port 5, 4 pairs PD
Maximum PoE power Port 1-4: IEEE802.3af – 16.8W
IEEE802.3at – 35W
Current limited – 1A, total 4Amaximum
(Total power for TP-SW5G24 – 70W)
Port 5: 90W (802.3at 2 event classification)
Current limited – 1A
TP disconnect mode DC disconnect

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
14
PoE auto detection IEEE802.3af & IEEE802.3at (2 event classification signaling)
PoE protection Over-temperature, over-current, over/under voltage
LEDs *Link/Activity (Green ON/ Green Blinking @1000Mbps,
Yellow/Yellow Blinking @10M/100Mbps)
*PoE (Yellow) port 1-4 ON - PD detect
Port 5 TP-SW5G & TP-SW5G24
ON – 4 pair power, Blinking-2 pair power
TP-SW5G-NC ON – 2 or 4 pair power
*POWER Green-normal, Red-alarm
Power input Port 5 from network switch or midspan, or optional DC power supply
(see detail on page 7)
Power consumption less than 5W when without PD loading
Input TP-SW5G-NC TP-SW5G24 TP-SW5G
12V 0.190A 0.340A 0.190A
24V 0.104A 0.170A 0.104A
48V 0.061A 0.073A 0.061A
56V 0.056A 0.061A 0.056A
Power efficiency 85% at full load (@48V typical)
Operating temperature -20℃~ +75℃
Operation humidity 90% relative humidity, non-condensing
Storage temperature -40℃~+85℃
Dimension 40mm(H)x118mm(W)x150mm(D) DIN RAIL Mountable
Surge Protection on signal pairs
Signal
Operating Voltage Data 5V
Clamping Voltage
Data 16.5V (@I PP =5A, t p =8/20µs, I/O pin to GND)
Peak Pulse Current 20A (tp=8/20µs)

User’s Manual TYCON TP-SW5G(-NC) series
TYCON POWER SYSTEMS
15
Pin Protected All 8 pin protected
Max. Shut Capacitance <3pF (VR = 0V, f = 1MHz, I/O pin to GND)
< 1.5 pF (VR = 0V, f = 1MHz, Between I/O pins)
IEC COMPATIBILITY (EN61000-4) IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact) IEC61000-4-4 (EFT) 40A (5/50ns)
IEC61000-4-5 (Lightning) 20A (8/20µs)
