Tyent Scale Remover User manual

User Manual
To Our Valued Customers
Name of the each part of the product
Package Contents
The scale remover is designed to remove the scale inside of the water
ionizer. It is very important to handle this device with care in order to
properly descale and avoid malfunctions of the water ionizer. Please
read the following warnings carefully before using the device.
This device must be kept out of the reach of children
and must not be used by children without supervision.
Safety Precautions and Warnings
DO NOT USE any other substances other than the citric acid
provided by TYENT.
DO NOT DRINK the citric acid or citric acid water.
Keep the device out of reach of children
The method of using the scale remover for each water ionizer
model is different, so please read the user manual thoroughly
before using the device.
If the water outlet of the water ionizer is blocked due to scale,
the scale remover automatically stops or the connections may
be seperated due to internal pressure (Please contact the
service center)
If citric acid or scale substance remain in the scale remover
after use, it may cause malfunctions. Be sure to remove the
citric acid and scale substance thoroughly before storing.
Do not use on the wet floor.
※If placing the device on the sink, dry the floor before use.
Place the product on a flat surface to operate.
Do not use the device for more than 30 minutes continuously.
Do not spray water on the outside of device. It may cause
malfunctions.
Thank you for purchasing TYENT Scale remover. This device is for
scale removal and management that may be accumulated inside of
the water ionizer. Be sure to read this manual and use the product
correctly before using the scale remover.
Check the components after opening the package. Components are
subject to change in specification without prior notice in order to
improve the product performance.
Device
ø7 Connecting hose
ø10 Gender
Combined hose 2EA
*For UCE-PLUS only (see How to use)
*Use for direct connection to the
Drain hose (refer to “How to use)
※Read the manual before using and
cut it into appropriate length
Citric acid(25g)
4EA
Skimming filter
5EA
How to use
DO NOT operate the water ionizer while using the scale
remover.
For effective scale removal, the pump turns on/off automatically
repeated for 10 minutes.
※The pump operation sounds repeat on/off. It is not a malfunction.
If the connecting hose is blocked because of twisting during operation,
the device stops operation by the battery voltage.
Top cover
Inlet connection
Operation lamp
Operation button
Battery cover
※Connect with Drain
Outlet connection
※Connect with
alkaline water outlet
※Bottom
※LED’s on when device operates
908, Ungsang-daero, Yangsan-si, Gyeongsangnam-do, Korea
TEL [phone]
ㅣ E-mail. [e-mail] MADE IN KOREA
www.tyentgroup.com
ø10
5/16″- 7/16″
1/4″- 3/8″Connector
If the device is used in a humid place, it may cause the product failure.
Please do not use rechargeable batteries, be sure to use
1.5v Alkaline battery.
Remove the battery cover at the bottom and install the Battery(AA).
(After place the battery, be sure to close the battery cover.)
Check the filter is fixed inside of the scale remover.
Check the power plug of water ionizer before operating the scale remover.
Preparation before use

ø7 hose
*Connect with
the Scale Remover
*Alkaline outlet pipe, Drain outlet pipe
5/16″- 7/16″gender
Connect
ø10 Gender
Combined hose
B. How to use for the Undersink model
※If the connection location of ⓐ,ⓑis different, it may cause product malfunctions.
How to store after use
Product Warranty
If citric acid or scale substance remain in the Scale Remover
after use, it may cause malfunctions. Be sure to remove
the citric acid and scale substance thorough before storing.
A. How to use for the desktop model
C. How to use for the Hybrid model (Hybrid water ionizer)
D. How to use connector
Place the scale remover in the place to be used, and cut the connecting
hose to an appropriate size.
The connecting hose must be connected to different locations, each of ⓐ
and ⓑ, respectively, so cut the hose to the appropriate size before use.
This applies only to the initial operation. Please store the cut hose and use
it when operating the scale remover.
Connect water ionizer’s alkaline outlet and Scale Remover’s outlet connection
with the connecting hose. (Refer to ⓐ)
Connect water ionizer’s drain and Scale Remover’s inlet connection with
the connecting hose. (Refer to ⓑ)
Put 500ml of water into the Scale Remover, add 2 bags of the citric acid
included as a component, and stir until the citric acid is completely dissolved.
Check the connection hose between water ionizer and Scale Remover
again, and press the button of the Scale Remover to start the operation
(the operation LED light turns on while operating).
The Scale Remover operates for approximately 10 minutes and automatically
turns off. ※For high hardness areas, operate twice in a row.
After the operation is completed, disconnect the connecting hose from
the water ionizer and the Scale Remover.
To remove the residual cleaning liquid inside the water ionizer, press the
“Purified water” button and let the water out for about 3 minutes.
After washing the Scale Remover inside and hose, please put all
components in Scale remover and store the device safety.
After using the Scale Remover, remove the inlet hose and filter, clean
them separately, and dry them before storing.
Attach the hose with the Scale Remover’s outlet connection.
Wash the Scale Remover’s inside with clean water and put 500ml of water.
※DO NOT add citric acid.
Press the button to completely drain the Scale Remover’s inside water
and press the button again to stop the device.
Dry the device and the outlet hose completely, and store.
①
※
※
②
③
④
⑤
⑥
⑦
⑧
⑨
ⓐ
ⓑ
Inlet ⓑ
Outlet ⓐ
Alkaline outlet ⓐ
Drain ⓑ
Inlet ⓑ
Outlet ⓐ
Alkaline outlet ⓐ
Drain ⓑ
When using for UCE-PLUS
model, connect the gender
combined hose (2EA) with
the water ionzer’s outlet
pipe and connect with the
Scale Remover.
①
②
③
④
⑤
Attach hose with
outlet connection
Adjust the position to
make “discharge water”
flow to the sink
Wash inside
and
add water
Press the button
to clean the inside
Refer to ④
Power supply
Battery replacement cycle
Operating time
Battery replacement (AA x 3ea) *Separately sold item
approximately 10 times when operating for 10 min
10 minutes / 1 time operation
Dimension(mm) W118.5 * D101 * H179 Weight 360g
Product Name
Product Model
Date of Purchase
TYENT Scale Remover
YT25-SR
Warranty Period
One Year from the
Date of Purchase
[12months]
※If the connection location of ⓐ,ⓑis different, it may cause product malfunctions.
ⓐ
ⓑ
The Hybrid water ionizer should be turned on before using
the scale remover. Check the power plug before using.
①~④ Pease refer to how to use the Scale remover on top counter water ionizer.
⑤
※
※
⑥
⑦
⑧
⑨
⑩
⑪
Press the SET button of the water ionizer for 3 seconds to enter the
setting mode, and press the RTR button for 3 seconds in the setting
mode to run the scale cleaning mode. (2 beeps)
The device will automatically operate for 10 minutes, and the screen
will display twice for 5 minutes each.
Make sure to operate the Scale Remover after entering RTR mode.
(risk of leakage)
After checking the water ionizer’s scale cleaning mode, press the
button on the Scale Remover to start the operation (the operation LED
light turns on while operating).
The Scale Remover and the scale cleaning mode operate for approximately
10 minutes and automatically turns off.
Press the SET button for 3 seconds to return to stand by screen.
※For high hardness areas, operate twice in a row.(Refer to ⑤~⑦)
After the operation is completed, disconnect the connecting hose from
the Hybrid water ionizer and the Scale Remover.
To remove the residual cleaning liquid inside the water ionizer, press the
“Purified water” button and let the water out for about 3 minutes.
After washing the Scale Remover inside and hose, please put all
components in Scale remover and store the device safety.
*If connecting with the Drain hose
directly (without Darin Faucet)
When connecting the Scale Remover’s inlet connection and the water
ionizer’s Drain outlet, and when connecting the directly with Drain hose
without a separate drain faucet, you must use the connector to connect.
Please refer to the draft below
ø6 Drain hose
How to connect 2 hoses with the connector
1/4″- 3/8″ *Connect Water Ionizer Drain outlet
ø7 hose
*Connect with
the Scale Remover
When storing, be careful not to lose the filter inside
of the product. If the filter is lost or contaminated,
replace the filter(included as the components).
Place the scale remover in the place to be used, and cut the connecting
hose to an appropriate size.
The connecting hose must be connected to different locations, each of ⓐ
and ⓑ, respectively, so cut the hose to the appropriate size before use.
This applies only to the initial operation. Please store the cut hose and use
it when operating the scale remover.
Connect water ionizer’s alkaline outlet and Scale Remover’s outlet connection
with the connecting hose. (Refer to ⓐ)
Connect water ionizer’s drain and Scale Remover’s inlet connection with
the connecting hose. (Refer to ⓑ)
Put 500ml of water into the Scale Remover, add 2 bags of the citric acid
included as a component, and stir until the citric acid is completely dissolved.
Check the connection hose between water ionizer and Scale Remover
again, and press the button of the Scale Remover to start the operation
(the operation LED light turns on while operating).
The Scale Remover operates for approximately 10 minutes and automatically
turns off. ※For high hardness areas, operate twice in a row.
After the operation is completed, disconnect the connecting hose from
the water ionizer and the Scale Remover.
To remove the residual cleaning liquid inside the water ionizer, press the
“Purified water” button and let the water out for about 3 minutes.
After washing the Scale Remover inside and hose, please put all
components in Scale remover and store the device safety.
①
※
※
②
③
④
⑤
⑥
⑦
⑧
⑨
