TYM T264NH User manual

Thank you very much for purchasing our tractor. We are confident it will give you many years of reliable service.
Read this manual carefully before using the tractor. The instruction in this manual set out the correct which manner of operating,
maintaining and checking the tractor to ensure long-term durability.
Please ensure correct operation of the tractor as incorrect operation can cause substantial mechanical damage as well as cause
accidents with the associated injuries.
Please note that in some cases differences can exist between this manual and your tractor due to the manufacture’s policy of
constant product improvement.
In the event that you strike a problem not covered by this manual, please contact your nearest dealer who will assist you in
resolving your problem.
FOREWORD
FOREWORD
WARNING
CALIFORNIA Proposition 65 Warning
The Engine Exhaust from this product contains chemicals
known to the State of California to cause cancer, birth defects
or other reproductive harm.

The following warning symbols in this manual draw additional attention to items of importance for the safe and correct operation
of the tractor.
SIGN MEANING OF THE SIGN
DANGER
Serious hazard with a very high level of risk of either serious injury or death.
WARNING
Hazard or unsafe practice that can lead to severe injury or death.
CAUTION
Hazard or unsafe practice that can lead in injury or death.
IMPORTANT
Instructions for the correct operation of the machine which, if followed, will ensure that it performs at
its best.
All information, illustrations and specifications in this manual are based on latest information available at the time of
publication. The right is reserved to make changes at any time without notice.
WARNING SIGNS IN THIS MANUAL

TABLE OF CONTENTS
SAFETY
GENERAL INFORMATION
OPERATION
MAINTENANCE AND SERVICE
SPECIFICATION AND TIPS
1
2
3
4
5
INDEX
6
7
DESCRIPTION OF OPERATING SYSTEM

TABLE OF CONTENTS
SAFETY 1
1. SAFETY INSTRUCTIONS
2. SAFE OPERATION OF THE TRACTOR
3. DO’S AND DONT’S
4. SAFETY SIGNS
5. UNIVERSAL SYMBOLS
………..…….....… 1-2
…... 1-10
…………………………. 1-17
…………………………….... 1-19
……………………. 1-22
GENERAL INFORMATION 2
1. ABOUT THIS MANUAL
2. TRACTOR INDENTIFICATION
3. INTRODUCTION & DESCRIPTION
4. OWNER ASSISTANCE
5. ROPS (Roll Over Protective Structures)
DESCRIPTIONOFOPERATINGSYSTEM 3
1. INSTRUMENT PANEL AND CONTROLS
2. PTO
3. HYDRAULICS
4. THREE-POINT LINKAGE AND DRAWBAR
5. CONNECTING AND DISCONNECITING
IMPLEMENT
MAINTENANCE AND SERVICE 5
1. MAINTENANCE AND ADJUSTMENT
2. SERVICING ENGINE
3. SERVICING TRANSMISSION
4. SERVICING ELECTRICAL
5. SERVICING MISCELLANEOUS
6. STORAGE
7. FUEL SAVING TIPS
8. HOW TO USE OF JACK
9. TROUBLESHOOTING
10. TOWING THE TRACTOR
SPECIFICATION AND TIPS 6
1. SPECIFICATION TABLE
2. NOISE LEVELS
3. VIBRATION REFERRED TO THE
OPERATOR POSITION
………..…….........… 2-2
……………... 2-3
………… 2-4
………………………. 2-7
……. 2-8
…. 3-2
…………………………………….…....... 3-13
………………………….…….. 3-15
3-18
…………………………………. 3-22
……… 5-2
……………………….... 5-4
…….…….…. 5-12
…………………. 5-15
…………… 5-17
……………………………………. 5-20
……………………….... 5-22
………………........ 5-24
……………………... 5-25
………………….. 5-28
…………………..... 6-2
…………………………….…. 6-3
…………………...…. 6-4
INDEX 7
1. INDEX ………..………………………………… 7-2
OPERATION 4
1. PRE-OPERATION CHECK
2. OPERATING THE ENGINE
3. OPERATING THE TRACTOR
………..………… 4-2
…………………. 4-3
………………. 4-5

SAFETY
1. SAFETY INSTRUCTIONS
2. SAFE OPERATION OF THE TRACTOR
3. DO’S AND DONT’S
4. SAFETY SIGNS
5. UNIVERSAL SYMBOLS
………..…….....… 1-2
….. 1-10
…………………………. 1-17
…………………………….... 1-19
……………………. 1-22
1

SIGNAL WORDS.
A signal word―DANGER, WARNING OR CAUTION―is used with safety alert symbol. DANGER
identifies the most serious hazards. Safety signs with signal Word ―DANGER OR WARNING―are
typically near specific hazards. General precautions are listed on CAUTION safety signs.
DANGER
WARNING
CAUTION
READ SAFETY INSTRUCTION
Carefully read all safety instructions given in this manual for your safety. Tempering with any of the
safety devices can cause serious injuries or death. Keep all safety signs in good condition. Replace
missing or damaged safety signs.
Keep your tractor in proper condition and do not allow any unauthorized modifications to be carried out
on the tractor, which may impair the function/safety and affect tractor life.
PROTECTION CHILDREN
Keep children and others away from the tractor while operating.
BEFORE YOU REVERSE
•Look behind tractor for children.
•Do not let children to ride on tractor or any implement.
RECOGNIZE SAFETY INFORMATION
This symbol means ATTENTION! YOUR SAFETY IS INVOLVED. The message that follows the
symbol contains important information about safety. Carefully read the message.
1-2
SAFETY
1. SAFETY INSTRUCTIONS

USE OF ROPS AND SEAT BELT
The Roll Over Protective Structure(ROPS) has been certified to industry and/or government standards.
Any damage or alternation to the ROPS, mounting hard-ware, or seat belt voids the certification and
will reduce or eliminate protection for the operator in the event of a roll-over. The ROPS, mounting
hardware, and seat belt should be checked after the first 100 hours of tractor and every 500 hours
thereafter for any evidence of damage, wear or cracks. In the event of damage or alteration, the ROPS
must be replaced prior to further operation of the tractor.
The seat belt must be worn during machine operation when the machine is equipped with a certified
ROPS.
Failure to do so will reduce or eliminate protection for the operator in the event of a roll over.
PRECAUTION TO AVOID TIPPING
Do not drive where the tractor could slip or tip.
Stay alert for holes and rocks in the terrain, and other hidden hazards.
Slow down before you make a sharp turn.
Driving forward out of a ditch or mired condition could cause tractor to tip over backward. Back out of
these situations if possible.
PARK TRACTOR SAFELY
Before leaving on the tractor;
Lower all equipment to the ground.
Stop the engine and remove the key.
KEEP RIDERS OFF TRACTOR
Do not allow riders on the tractor.
Riders on tractor are subject to injury such as being stuck by foreign objects and being thrown off of the
tractor.
SAFETY
1
1-3

HANDLE FUEL SAFELY-AVOID FIRES
Handle fuel with care; it is highly flammable. Do not refuel the tractor while smoking or near open flame
or sparks. Always stop engine before refueling tractors.
Always keep your tractor clean of accumulated grease and debris. Always clean up spilled fuel.
STAY CLEAR OF ROTATING SHAFTS
Entanglement in rotating shaft can cause serious injury or death.
Keep PTO shield in place at all times. Wear close fitting clothing. Stop the engine and be sure PTO
drive is stopped before making adjustments, connections, or cleaning out PTO driven equipment.
ALWAYS USE SAFETY LIGHTS AND DEVICES
Use of hazard warning lights and turn signals are recommended when towing equipment on public
roads unless prohibited by state or local regulations.
Use slow moving vehicle (SMV) sign when driving on public road during both day & night time, unless
prohibited by law.
PRACTICE SAFE MAINTENANCE
Understand service procedure before doing work.
Keep the surrounding area of the Tractor clean and dry.
Do not attempt to service Tractor when it is in motion.
Keep body and clothing away from rotating shafts.
Always lower equipment to the ground. Stop the engine.
Remove the key. Allow Tractor to cool before any work repair is caused on it.
Securely support any Tractor elements that must be raised for service work.
Keep all parts in good condition and properly installed.
Replace worn or broken parts. Replace damage/missing decals.
Remove any buildup of grease or oil from the tractor.
Disconnect battery ground cable() before making adjustments on electrical systems or welding on
tractor.
SAFETY
1-4

AVOID HIGH-PRESSURE FLUIDS
Escaping fluid under pressure can penetrate the skin causing serious injury. Keep hands and body
away from pinholes and nozzles, which eject fluids under high pressure. If any fluid is injected into the
skin. Consult your doctor immediately.
PREVENT BATTERY EXPLOSIONS
Keep sparks, lighted matches, and open flame away from the top of battery. Battery gas can explode.
Never check battery charge by placing a metal object across the poles.
PREVENT ACID BURNS
Sulfuric acid in battery electrolyte is poisonous. It is strong enough to burn skin, cause holes in clothing
and cause blindness if found entry into eyes.
For adequate safety always;
1. Fill batteries in a well-ventilated area.
2. Wear eye protection and acid proof hand gloves
3. Avoid breathing direct fumes when electrolyte is added.
4. Do not add water to electrolyte as it may splash off causing severe burns.
If you spill acid on yourself;
1. Flush your skin with water.
2. Flush your eyes with water for 10-15 minutes.
3. Get medical attention immediately.
SERVICE TRACTOR SAFELY
Do not wear a necktie, scarf or loose clothing when you work near moving parts. If these items were to
get caught, severe injury could result.
Remove rings and other jeweler to prevent electrical shorts and entanglement in moving parts.
BATTERY DISCONNECT
When working with your tractors electrical components you must first disconnect the battery cables.
To ensure that there are no accidents from sparks you must first disconnect the negative battery cable.
SAFETY
1-5
1

TRACTOR RUNAWAY
The tractor can start even if the transmission is engaged position causing Tractor to runaway and serious injury to the people
standing nearby the tractor.
For additional safety keep the transmission in neutral position, foot brake engaged and PTO lever in disengaged position while
attending to safety starter switch or any other work on tractor.
WORK IN VENTILATED AREA
Do not start the tractor in an enclosed building unless the doors & windows are open for proper
ventilation, as tractor fumes can cause sickness or death. If it is necessary to run an engine in an
enclosed area remove the exhaust fumes by connecting exhaust pipe extension.
To avoid injury, always engage park brake, ensure levers are in neutral position and PTO switch is off when starting
or running the engine.
SAFETY PRECAUTIONS WHEN USING THE LOADER
Never let anyone get in the loader and use the loader as a workbench.
Otherwise, it may lead to a fatal injury or even death.
SAFETY PRECAUTIONS WHEN USING THE LOADER
Do not stand under the lifted loader or get close to it. Also, lower the loader arm onto the ground before
leaving the tractor.
Otherwise, it may lead to a fatal injury or even death.
SAFETY
1-6

SAFETY PRECAUTIONS WHEN USING THE LOADER
When attaching or detaching the loader, fix all parts which are connected to the bucket and boom.
The bucket or boom can be accidentally dropped down, leading to an injury or even death.
IMPORTANT
SAFETY PRECAUTIONS WHEN USING THE LOADER
ROPS (Roll Over Protective Structure), sun canopy or cabin are not a FOPS (Falling
Object Protective Structure).
It never can protect the riders against falling objects. Avoid driving the vehicle into a
dangerous area such as falling rocks zone.
SAFETY PRECAUTIONS WHEN USING THE LOADER
Do not allow loader arms or attachment to contact electrical power lines.
Electrocution will cause serious injury or death.
SAFETY PRECAUTIONS WHEN USING THE LOADER
Never carry a big object with the loader unless a proper implement is attached. Keep a carried object
low during driving.
Otherwise, it may lead to an injury or even death.
SAFETY PRECAUTIONS WHEN USING THE LOADER
When attaching or detaching the loader, fix all parts which are connected to the bucket and boom.
The bucket or boom can be accidentally dropped down, leading to an injury or even death.
SAFETY
1-7
1

TOWING SAFELY
For the maximum towable loads, refer to the paragraph maximum towable loads in the technical data section.
•Maintain a suitable speed taking into account the weight of the trailed load and the gradient, remembering that braking
distances will be greater than with just the tractor.
Trailed loads with or without brake that are too heavy for the tractor or that towed at too high speed may cause the operatorto
loose of control of the tractor.
•Always take into consideration the total weight of the implements and their loads.
•When trailers are hitched to the tractor, before you leave the operator seat remember to put all the controls in neutral, apply
the handbrake, switch off the engine, engage first gear (with mechanical transmissions) and remove the ignition key.
ALWAYS chock both the tractor and the trailer wheels. The best way to transport a tractor that has broken down is to transport it
on a low loader. Always secure the tractor to the loader bed with chains.
Before transporting the tractor on a low loader or on a railway wagon, make sure that the engine hood, doors, open able roof(if
present) and windows are all closed and securely fastened.
Never tow the tractor at speeds in excess of 10kph.
An operator must stay in the operator position to steer and brake the tractor.
CAUTION
When a trailers is hitched to the tractor, before you leave the driving seat remember to put all the controls
in neutral, apply the handbrake, switch off the engine, engage first gear (if the tractor has a mechanical
transmission) and remove the key from the starter switch.
If the tractor is not parked on level ground, ALWAYS place chocks under the wheels of both the tractor and
the trailer.
For further information on safe working procedures, refer to the chapter "Parking the tractor" in the safe
section of this manual.
SAFETY
1-8

OPERATOR PROTECTIVE STRUCTURE(OPS)
The term OPS refers to a protective structure installed on a tractor in order to minimize risk of operator injury caused by objects
penetrating into the operator position area.
DANGER
This tractor is not equipped with an OPS. If work must be performed in areas subject to the risk of the
penetration of objects into the operator position, consult your dealer before starting work so that the tractor
can be equipped with an appropriate protective structure.
USE OF HAZARDOUS SUBSTANCES
The classification category, as stipulated by ISO 14269-5, of the cab installed on this range of tractors is given below:
- The engine operating at nominal speed.
- The maximum quantity of air drawn from outside the cab (recirculation closed).
- With fan at maximum speed.
The manufacturer of your tractor has made every effort to make it as safe as is humanly possible.
Beyond this point it is the responsibility of the operator to avoid accidents and we ask that you read and implement our
suggestions for your safety.
Ensure that only trained and competent operators use this tractor and ensure that they are fully conversant with the machine
and aware of all it’s control and safety features.
Operators should not operate the tractor or associated machinery while tired or untrained. To avoid accidents please ensure that
the operator wears clothing which will not get entangled in the moving parts of the tractor or machine and protect him or herfrom
the elements.
When spraying or using chemicals, please ensure that clothing and protective equipment is worn which prevents respiratory or
skin problems.
For full details consult the manufacturer of the chemicals.
To avoid lengthy exposure to noise ensure that ear protection is worn.
If adjustment to the tractor or machinery need to be made ensure the tractor or machine are turned off beforehand.
Use of certified Roll Over Protection Structure (ROPS) is a must while operating a tractor.
Use of seat belt is a must while operating a tractor.
In summary, ensure at all times that the safety of the operator and any other worker is paramount.
Ensure no one is between the tractor and a towed vehicle (trailer or implement).
SAFETY
1-9
1

The manufacturer of your tractor has made every effort to make it as safe as is humanly possible.
Beyond this point it is the responsibility of the operator to avoid accidents and we ask that you read and implement our
suggestions for your safety.
Ensure that only trained and competent operators use this tractor and ensure that they are fully conversant with the machine and
aware of all it’s control and safety features.
Operators should not operate the tractor or associated machinery while tired or untrained.
To avoid accidents please ensure that the operator wears clothing which will not get entangled in the moving parts of the tractor
or machine and protect him or her from the elements.
When spraying or using chemicals, please ensure that clothing and protective equipment is worn which prevents respiratory or
skin problems.
For full details consult the manufacturer of the chemicals.
To avoid lengthy exposure to noise ensure that ear protection is worn.
If adjustment to the tractor or machinery need to be made ensure the tractor or machine are turned off beforehand.
Use of certified Roll Over Protection Structure (ROPS) is a must while operating a tractor.
Use of seat belt is a must while operating a tractor.
In summary, ensure at all times that the safety of the operator and any other worker is paramount.
2. SAFE OPERATION OF THE TRACTOR
SAFETY
1-10

SAFETY TIPS DURING MAINTENANCE
1. At least on a daily basis check all oil levels.
Water level in the radiator and electrolyte level in the battery and perform services according to the service schedule.
2. Ensure tire pressure are even and the correct pressure for the job being done is maintained.
3. Check to ensure that the all controls and preventative mechanisms of the Tractor and implement work correctly and
effectively.
4. Ensure that an adequate set of the correct tools is available for maintenance and minor repairs.
5. Ensure that all service work and repairs are carried out on a flat area with a concrete or similar floor.
Do not carry out service work on a tractor until it is switched off, and the parking brake applied and wheels choked.
Where a tractor is started in a confined area, ensure that the area is well ventilated as exhaust gases are very harmful, and
can cause death.
6. Do not work under raised implements.
7. When changing wheels or tires ensure that a suitable wheel stand is placed under the axle prior to removing the wheel and
the wheels are chocked.
8. Where guards or shields need to be removed to perform a service or repair, ensure that the guard or shield is correctly
reinstalled before starting the tractor.
9. Never refuel near a naked flame or with an overheated engine. Ensure to turn off Engine before refueling.
10. The cooling system operates under pressure, take care when removing the Radiator cap on a hot engine to prevent being
scalded by steam or hot water.
Do not add water in the radiator when the engine is hot.
Add water to the radiator only after the engine cools down completely.
11. To prevent fires keep the tractor including the engine clean and free from inflammable material and well away from fuels and
other inflammable material.
SAFETY
1-11
1

MOUNTING AND DEMOUNTING IMPLEMENTS
1) Ensure that all mounting and removal of implements is done on safe flat ground.
Ensure no one is between the Tractor and implement and do not get under the implement to avoid accidental injuries.
2) After mounting the implement, ensure that all sway chains are correctly adjusted and, where PTO shafts are used that the
shaft is fitted and secured correctly.
3) Where heavy implements are used, ensure that the combination is well balanced or use proper ballast to achieve balance.
4) Before leaving the tractor at any time, lower the implement, stop the PTO shaft where applicable, set the parking brake and
switch off the engine.
5) While operating the implements with the PTO keep all bystanders away from any moving parts and do not attempt to make
adjustments while the machine is running.
6) Only the driver should ride on the Tractor with the ROPS frame fitted and with the seat belt properly fastened.
7) Where young children are present, particular care should be taken and the tractor should not be moved until the
whereabouts of all children is known.
8) Only trained operators should operate the Tractor and so taking care to ensure that other workers are not injured.In
particular they should take care during dusty operations, which will educe visibility substantially.
9) Never start the tractor unless the transmission is out of gear, the operator is in the seat and all round safety has been
checked.
10) Only operate the tractor seated in the drivers seat and never turn or brake suddenly at high speed as this can cause a roll-
over and serious injury or death.
11) When traveling on a public road ensure that the tractor and driver both meet all laws relating to safety and licensing.When
traveling with wide implements use red flags on the extremities and observe all legal including escort requirements.
12) When operating under adverse conditions, hilly terrain or on bad ground adjust the speed ofthe tractor to suit the conditions,
safety comes first. Never drive down hill at high speed or with the transmission in neutral. Use of the braking capacity of the
engine as well as the service brakes. Do not try to change gear going up or down a steep slope, select the correct gear
before starting.
13) Take care when traveling uphill with a heavy implement to ensure that it does not overbalance and tip up the front end.
14) Never remove or modify the seat belt.
15) Never remove, modify or repair the ROPS frame.
PLEASE REMEMBERTHAT ALITTLE BITOFEXTRACARE CAN PREVENTSERIOUSINJURYORDEATH AND AVOID DAMAGE TO YOUR TRACTOR.
SAFETY
1-12

■The Tractor
1. Read the operator’s manual carefully before using the tractor. Lack of operating knowledge can lead to accidents.
2. Use an approved rollover bar and seat belt for safe operation. Overturning of a tractor without a rollover bar can result in
death or injury.
3. Do not remove ROPS (Roll Over Protective Structure). Always use the seat belt.
4. Fiberglass canopy does not give any protection.
5. To prevent falls, keep steps and platform clear of mud and oil.
6. Do not permit anyone but the operator to ride on the Tractor. There is no safety place for extra riders.
7. Replace all missing, illegible or damaged safety signs.
8. Keep safety signs clean of dirt and grease.
■Servicing the Tractor
1. keep the tractor in good operating condition for your safety. An improperly maintained Tractor can be hazardous.
2. Stop the engine before performing any service on the tractor.
3. The cooling system operates under pressure, which is controlled by the radiator cap.
It is dangerous to remove the cap while the system is hot.
First turn the cap slowly to stop and allow the pressure to escape before removing the cap entirely.
4. Do not smoke while the refueling the tractor. Keep away any type of open flame.
THE PRECAUTION TO HELP PREVENT ACCIDENTS
A careful operator is the best operator.
Most accidents can be avoided by observing certain precautions.
Read and take the following precautions before operating the tractor to prevent accidents.
Tractor should be operated only by those who are responsible and properly trained to do so.
SAFETY
1-13
1

5. The fuel in the injection system is under high pressure and can penetrate the skin. Unqualified persons should not remove or
attempt to adjust a pump, injector, nozzle or any part of the fuel injection system. Failure to follow these instructions can
result in serious injury.
6. Keep open flame away from battery or cold weather starting aids to prevent fire or explosions.
7. Do not modify or alter or permit anyone else to modify or alter this tractor or any of its components or any tractor functions.
■Operating the Tractor
1. Before starting the tractor apply the parking brake, place the PTO (Power Take Off) lever in the “OFF” position, the hydraulic
control levers in the downward position, the remote control valve levers in the neutral position if fitted) and the transmission in
neutral.
2. Do not start the engine or controls while standing besides the tractor. Always sit on the tractor seat when the engine or
operating controls.
3. Safety starter switch.
In order to prevent the accidental starting of the tractor, a safety switch has been provided. The starting system of the tractor
is connected through this switch, which becomes operative only when the break pedal is depressed. All models sub shift
lever and PTO button should also be in neutral position for completing the starting circuit. Do not bypass the safety starter
switch. Consult your TYM tractor dealer / distributor if safety starting switch malfunctions.
4. Avoid accidental contact with the gear shifter lever while the engine is running. Unexpected Tractor movement can result
from such contact.
5. Do not get off or climb the tractor while it is in motion.
6. Shut off the engine, remove the key and apply the parking brake before getting off the tractor.
7. Do not operate the tractor in an enclosed building without adequate ventilation. Exhaust fumes can cause death.
8. Do not park the tractor on a steep slope.
9. If power steering or Engine seizes to operate, stop the tractor immediately.
SAFETY
1-14

10. Pull only from the swinging draw bar or the lower link drawbar in the down position. Use only a drawbar pin that locks in
place. Pulling from the tractor rear axle carriers or any point above the rear axle may cause the Tractor’s front end to lift.
11. If the front end of the tractor tends to rise when heavy implements are attached to the three-point linkage, install front end or
front wheel weights. Do not operate the tractor with a light front end.
12. Always use hydraulic position control lever when attaching equipment/implement and when transporting equipment. Be
sure that the hydraulic couplers are properly mounted and will disconnect safely in case of accidental detachment of
implement.
13. Do not leave equipment/implement in the raised position.
14. Use the flasher/ Turn signal lights and Slow Moving Vehicle (SMV) signs when driving on public roads during both day and
night time, unless prohibited by law.
15. Dim tractor lights when meeting a vehicle at night. Be sure the lights are adjusted to prevent the blinding on the eyes of
coming vehicle operator.
■Driving the Tractor
1. Watch where you are going especially at row ends, on roads, around trees and low hanging obstacles.
2. To avoid upsets, drive the tractor with care and at speeds compatible with safety, especially when operating over rough
ground, crossing ditches or slopes, and when turning at corners.
3. Lock the tractor brake pedals together when transporting on roads to provide proper wheel braking.
4. Keep the tractor in the same gear when going downhill as used when going uphill. Do not coast or free wheel down hills.
5. Any towed vehicle and/or trailer whose total weight exceeds that of the towing Tractor, must be equipped with its own
brakes for safe operation.
6. When the tractor is stuck or tires are frozen to the ground, back out to prevent upset.
7. Always check overhead clearance, especially when transporting the tractor.
SAFETY
1-15
1

■Operating the PTO (Power Take Off)
1. When operating PTO driven equipment, shut off the engine and wait until the PTO stops before getting off the tractor and
disconnecting the equipment.
2. Do not wear loose clothing when operating the power take-off or near rotating equipment.
3. When operating stationery PTO driven equipment, always apply the tractor parking brake and block the rear wheels from
front and rear side.
4. To avoid injury, always move down flip part of PTO. Do not clean, adjust or service PTO driven equipment when the tractor
engine is running.
5. Make sure the PTO master shield is installed at all times and always replace the PTO shield cap When the PTO is not in use.
■Diesel Fuel
1. Keep the equipment clean and properly maintained.
2. Under no circumstances should gasoline, alcohol or blended fuels be added to diesel fire or explosive hazard. Such blends
are more explosive than pure gasoline. In a closed container, such as a fuel tank. DO NOT USE THESE BLENDS.
3. Never remove the fuel cap or refuel the tractor with the engine running.
4. Do not smoke while refueling or when standing near fuel.
5. Maintain control of the fuel filler pipe when filling the tank.
6. Do not fill the fuel tank to capacity. Allow room for expansion.
7. Wipe up spilled fuel immediately.
8. Always tighten the fuel cap securely.
9. If the original fuel tank cap is lost, replace it with genuine cap. A none approved cap may not be safe.
10. Do not drive equipment near open fire.
11. Never use fuel for cleaning purpose.
12. Arrange fuel purchases so that winter grade fuel are not held over and used in the spring.
※It is suggested that after repairs if any of the safety decal/sign is peeled/defaced, the same may be replaced immediately in interest of your safety.
SAFETY
1-16
