TYM ET350 ECONO User manual

TYM
OPERATOR’S MANUAL
FOR
TRACTORS
ET350 ECONO
#604-9, Namsan-dong, Changwon-city, Kyungnam, Korea ■TEL:[phone], FAX:[phone] ■www.tym.co.kr

JIANGDONG
Off-Road compression-Ignition Engine
Emission Control System Warranty statement
EMISSION RELATED SYSTEM DEFECT WARRANTY
The warranty period shall begin on the engine or equipment purchaser of certified fuel.
JIANGDING Group.co. warrants to the ultimate purchaser and each subsequent purchaser of certified
off-road compression-ignition engine (powering off-road machines and equipment), that such engine is;
1) Designed, built, and equipped so as to confirm with all applicable regulations adopted by the
Environmental Protection Agency.
2) Free from defects in materials and workmanship which cause the failure of a warranted part to be
identical in all material respects to the part as described in the engine manufacturer’s application for
certification for period of five years for 3000 hours of operation, whichever occurs first, for all engines
rated at 19kw and greater, except as noted below, in the absence of a device to measure hours of use, the
engine shall be warranted for a period of five years. For all engines rated less than 19kw, and for constant
speed engine rated under 37kw with rated speeds higher than or equal to 3000 rpm, the period of two
years or 1500 hours of operation, whichever occurs first, shall apply, in the absence of a device to
measure hours of use, the engine shall be warranted for a period of two years.
If a warranted part fails because of a defect during the terms of this warranty, JIANGDONG will repair or
replace it at any authorized JIANGDONG dealer. Any other parts damaged by the failure of a warranted
part will also be repaired or replaced. The repair and/or replacement will be made at no charge to the
owner for parts, labor and diagnosis. Any such part repaired or replaced under the warranty shall be
warranted for the remaining warranty periods.
In case of emergency, repairs may be performed at any service establishment, or by the owner, using any
replacement part.
JIANGDONG Group.co.will reimburse the owner for their expenses, including diagnostic charges for
such emergency repair. These expenses shall not exceed JIANGDONG Group.co. suggested retail price
for all warranted parts replaced, and labor charges based on JIANGDONG Group.co.recommended time
allowance for the warranty repair and geographically appropriate hourly labor rate.
A part not available within 30 days or a repair not being complete within 30 days constitute an emergency.
As a condition of reimbursement, replaced parts and receipt invoices must be presented at a place of
business of an authorized JIAGDONG engine dealer or other establishment and authorized by
JIANGDONG Group.co.
This warranty covers the following emission-related parts and components.
-Fuel Injection pump
-Nozzle Assembly
-Injection pipe
-Turbocharger (if equipped)
-Intake, Exhaust manifold
If failure of these components results in failure of another part, both will be covered by this warranty. Any
replacement part may be used for maintenance or repairs. The owner should ensure that such parts are
equivalent in design and durability to JIANGDONG genuine parts.
Use of non-genuine JIANGDONG parts does not invalidate the warranty. However JIANGDONG
Group.co. is not liable for parts, which are not genuine JIANGDONG parts.

RESPONSIBILITY AND LIMITATIONS.
These warranties are subject to the following:
JAINGDING Group.co.RESPONSIBILITIES.
During the emission warranty period, if a defect in material or workmanship of a warranted parts or
component is found. JIANGDONG Group.co.will provide;
-New, remanufactured, or repaired parts and-or components required to correct the defect.
Items replaced under this warranty become the property of JIANGDONG Group.co.
-Labor, during normal working hours, required to make the warranty repair.
This includes diagnosis and labor to remove and install the engine, if necessary.
Owner’s Warranty Responsibilities.
As the JIANGDING Group.co. off-road compression-ignition owner, you are responsible for the
performance of the required maintenance listed in your Owner’s Manual. JIANGDONG Group.co.
cannot deny warranty solely for the lack of required maintenance was the reason for the repair, then
the claim will be denied.
You are responsible for presenting your JIANDONG engine to a DIANGDONG Group.co.dealer as soon
as a problem exists. The warranty repairs should be completed in a reasonable amount of time, not to
exceed 30 days.
As the JIAMGDONG engine owner, you should also be aware that JIANGDONG Group.co.may deny you
warranty coverage if your JIANGDONG engine or parts has failed due to abuse, neglect, improper
maintenance or unapproved, modifications. If you have any questions regarding your warranty rights and
responsibilities, you should contact JIANGDONG Group.co.
Division at 1801 Quality Drive
LIMITATION
The emission control system defects warranty and the emission control system performance warranty shall
not apply to: - malfunctions in any part directly caused by abuse, misuse, modification, improper
adjustment except those done by a dealership during warranty service work, alterations, tempering
connections, improper or inadequate maintenance, neglect or use of leaded diesel or other fuels not
recommended in the owner’s Manual.
-Damage resulting from accident or an Act of God.
-Failure that are a direct result of a lack of performance of required emission control maintenance as
outlined in your Owner’ Manual.
-Parts or accessories used in applications for which they were not designed or not approved for use on the
engine by JIANGDONG Group.co.
-Parts not supplied by JIANGDONG Group.co.or damage to other parts caused directly by
non-JIANGDONG Parts or non-equivalent parts.
-The charge for diagnostic labor which does not lead to the determination that a warrantable condition
exists.
-JIANGDONG Group.co.is not responsible on which or consequential damages such as downtime or loss-
use of engine powered equipment.
-Although you purchase the equipment on which JIANGDONG engine is mounted, if the equipment is not
manufactured by JIANGDONG, you will make contact with purchasing dealer.

EMERGENCY SERVICE
If emergency Emission Control System Warranty service is required and the owner is unable to readily
locate an authorized JIANGDONG dealer or if a warranted part is available within 30 days, then, repairs
may be performed at any available service establishment, or by the owner, using any replacement part.
JIANGDONG will reimburse the owner for the owner’s expenses including diagnostic charges for such
emergency repair or replacement at JIANGDONG ’s suggested retail price for all warranted parts
replaced and labor charges based on JIANGDONG ‘s recommended time allowance for the warranty
repair and the geographically appropriate hourly labor rate. Replaced part and copies of paid original
receipts must be available for presentation to JIANGDONG as a condition of reimbursement for these
emergency repairs.
In addition, the owner must provide JIANGDONG a detailed description indicating why the situation
was considered an emergency and why an authorized JIANGDONG dealer was not being complete
within 30 days constitutes an emergency.

Thank you for purchasing our ET 350 ECONO tractor. ET 350 ECONO tractor is characterized by its
compact construction, and big excess power. With relevant implement, it can make various kind or work,
such as plowing, Rototilling, harrowing, seeding, harvesting, irrigation, electric generation,
transportation and gardening, etc…
The correct usage, adjustment and maintenance of the tractor may prolong their service life, and give
their full play. This book, for this reason, is complied to provide the above information for owners of the
tractor.The user of the tractor is required to read this book carefully before putting the tractor into
operation, and strictly to observe the regulations and instructions in using and servicing the tractors.
This Operation Manual excludes the information for engine chapter, which you can find on the separate
Engine Operation Manual attached with.
With the requirements of customers and the developments of engineering science, this product will be
improved continuously. So please notice the contents of the book may be somewhat not accordance with
the tractor you have owned. We will publish new one periodically.
FOREWARD

CONTENTS
CHEPTER 1 Main Specifications of Tractor …………………………………………………..
CHAPTER 2 Safety Regulations and Important Instructions..……………………………….
2.1 Safety Instructions …………………………………………………………………………
2.2 Safety Regulations …………………………………………………………………………
2.3 Important Instructions. ……………………………………………………………………..
2.4 ROPS (Roll Over Protection Structure) …………………………………………………..
2.5 Safety signs…………………………………………………………………………………
CHAPTER 3 Oiling and Running – in process ….………………………………………………
3.1 Oiling and Fueling of the Tractor ……………………………………………………………
3.2 Running – In of a New Tractor ………………………………………………………………
3.3 Work on the Tractor after Running – in ……………………………………………………...
CHAPTER 4 Operation of Tractor ……………………………………………………………….
4.1 Controls and Instruments …………………………………………………………………….
4.2 Operating and Driving ………………………………………………………………………..
4.3 Operation of Working Facilities ……………………………………………………………...
4.4 Operation of Electrical Equipment …………………………………………………………...
CHAPTER 5 Important Adjustments …………….………………………………………………
5.1 Important Adjustments Date of Engine ……………………………………………………….
5.2 The Components of Clutch ……………………………………………………………………
5.3 Adjustments of Transmission …………………………………………………………………
5.4 Adjustments of Brakes ………………………………………………………………………..
5.5 Adjustments of Final Drive ……………………………………………………………………
5.6 Fully Hydraulic steering system……………………………………………………………….
5.7 Lifter Hydraulic Tube system …………………………………………………………………
5.8 Adjustment of Tread …………………………………………………………………………..
5.9 Adjustment of Lifter …………………………………………………………………………..
5.10 The Operation Controls of Front Drive Axle …………………………………………………
5.11 The Structure and Adjustment of Front Drive Axle…………………………………………
5.12 The Structure, Installation and Disassembly of Transmission Shaft and Transfer Case……
1
4
4
9
9
10
13
17
17
18
19
20
20
24
26
27
30
30
30
35
37
37
38
40
41
42
43
44
47

5.13 Connection and adjustment of Front Axle and Its Bracket ……………………………….
5.14 Adjusting of Front Wheel Deflection Angle and Toe – in ……………………………….
5.15 Lubricating Points of Front Drive System and Steering System …………………………
CHAPTER 6 Technical Maintenance of Tractor..……………………………………………...
6.1 Technical Maintenance per Shift …………………………………………………………..
6.2 1st Technical Maintenance …………………………………………………………………
6.3 2nd Technical Maintenance ………………………………...………………………………
6.4 3rd Technical Maintenance ………………………………………………………………...
6.5 Special Maintenance of Winter ……………………………………………………………..
CHAPTER 7 Trouble Shooting …………………………………………………………………..
7.1 Engine ……………………………………………………………………………………….
7.2 Chassis ………………………………………………………………………………………
7.3 Electrical System ……………………………………………………………………………
CHAPTER 8 APPENDICES …………………………………………………………..…………..
8.1 Tightening Torque of important Bolts and Nuts …………………………………………….
8.2 Diagram of Transmission System …………………………………………………………...
8.3 Electrical system wiring Diagram …………………………………………………………...
8.4 Fuel System Diagram ……………………………………………………………………..…
8.5 Hitch System Dimensions ………………………………………………………………..….
47
48
49
50
50
50
51
51
52
53
53
53
56
59
59
60
62
64
64

1
CHAPTER 1. MAIN SPECIFICATIONS OF TRACTOR
General specifications
Tractor Model ET 350 ECONO
Type Frameless, 4WD tractor
Rated draft(kn/kgf) 9.14/932
Dry weight(kg 1450
Min. operation weight(kg) 1565
Wheel tread(mm)
Front wheel 1160
Rear wheel 1100~1400
Radius of turning circle(m)
With one side braked 3.4
Without braking 3.8
Min,ground clearance(mm) 290
Overall dimensions(mm)
Length 3070
Width 1493
Height(to the top of steering wheel) 1540
Theoretical travel speed of tractor(km/h)
1st gear 1.74
2nd gear 2.20
3rd gear 3.58
4th gear 5.68
5th gear 6.83
6th gear 8.63
7th gear 14.04
8th gear 22.27
1st rev. Gear 1.63
2nd rev.Gear 6.38
Engine
Model TY395E
Type Vertical,in-line,water-cooled,four-stroke
Number of cylinders 3
Bore X Stroke(mm) 95/105

2
Tractor Model ET 350 ECONO
Rated speed(r/min) 230
Rated output(kW/hp) 25.7/35
Max.torque(Nm) ≥122.7
Speed at max. torque(r/min) ≤ 1725
Fuel consumption(g/kWh) 245
Oil consumption(g/kWh) ≤ 2.04
Method of lubrication Pressure and splash combined
Method of cooling Closed and forced water circulation
Method of starting Electric starting
Rotating direction(as viewed from the fan) Clockwise
Transmission system
Clutch Dry single-disk constant engagement or
Double Belleville spring interlock controlled
Gear box Straight gear (4+1) X 2
Central drive Spiral bevel gear
Differential Two bevel planetary-gear, closed type
Final drive External exterior engagement, straight gear type
Brake Pedal, mechanical-actuated, closed shoe-type
Running and steering system
Type of drive Rear-wheel drive
Type of front axle Tube with adjustable wheel tread
Specification of tire
Front wheel 6.50-16
Rear wheel 11.2-24
Tire pressure(MPa)
Front wheel 0.23~0.25
Rear wheel 0.10~0.12
Toe-in(mm) 3~11
Camber, front wheel 2°
Kingpin inclination 10°
Kingpin caster 0
Steering gear Worm and roller or BZZ1-80 fully-hydraulic
Ackerman steering Backward of axle
Working facilities
Hydraulic lift
Type Partial separated units
Working depth control Draft and position control combined

3
Tractor Model ET 350 ECONO
Oil pump type CBN316L
Opening pressure of relief Valve(MPa) 13.7
Hydraulic cylinder
Type Horizontal, single-action piston type
Bore(mm) 85
Stroke(mm) 110
Distributor Sliding valve control type
Rated lift capacity(at hitch shaft)(kN) 8.33
Suspension linkage
Type Rear-mounted, three - point ball joint, category I
Upper hitch pin diameter(mm)
Lower hitch pin diameter
Power take-off shaft
Type Non-independent or semi-independent
Dimensions of spline
PTO Speed(r/min) 540,1000
Electrical system
Type 12V, Negative-grounded, single-line system
Alternator JF11(14V,350W) or FWB 15C31
Regulator FT-70 or FT-111
Starting motor QD146
Battery 6-QA-90
Head light 12V upper beam 45W. Lower beam 40W
Tail light 12V 32CP
Multi - indicating panel
Filling capacities(ℓ)
Fuel tank 40
Engine cooling system 7~9
Engine oil sump 4.5
Fuel injection pump 0.3
Hydraulic oil tank 5.7
Chassis 20.8
Hydraulic lift 7
Front drive axle 6
Intermediate Housing 3.5
φ19
φ22.4 +0.33
+0
+0.51
+0.30
8-spline-38 X 29 X 6 or
6-spline-34.79±0.06 X 28.91 ±0.05 X 8.69
+0.032
+0.100
0
-0.28
-0.04
-0.01 -0.040
-0.098

CHAPTER 2. SAFETY REGULATIONS AND
IMPORTANT INSTRUCTIONS
2.1 SAFETY INSTRUCTIONS
SIGNAL WORDS.
A signal word―DANGER, WARNING OR CAUTION―is used
with safety alert symbol. DANGER identifies the most serious
hazards. Safety signs with signal Word ―DANGER OR
WA R N I N G ―are typically near specific hazards. General
precautions are listed on CAUTION safety signs.
DANGER
WARNING
CAUTION
RECOGNIZE SAFETY INFORMATION
This symbol means ATTENTION! YOUR SAFETY IS
INVOLVED. The message that follows the symbol contains
important information about safety. Carefully read the message
READ SAFETY INSTRUCTION
Carefully read all safety instructions given in this manual for
your safety. Tempering with any of the safety devices can cause
serious injuries or death. Keep all safety signs in good condition.
Replace missing or damaged safety signs.
Keep your tractor in proper condition and do not allow any
unauthorized modifications to be carried out on the Tractor,
which may impair the function/safety and affect Tractor life.
PROTECTION CHILDREN
Keep children and others away from the Tractor while operating.
BEFORE YOU REVERSE
- Look behind Tractor for children.
- Do not let children to ride on Tractor or any implement.
4

USE OF ROPS AND SEAT BELT
The Roll Over Protective Structure(ROPS) has been certified to
industry and/or government standards. Any damage or alternation to
the ROPS, mounting hard-ware, or seat belt voids the certification
and will reduce or eliminate protection for the operator in the event
of a roll-over. The ROPS, mounting hardware, and seat belt should
be checked after the first 100 hours of Tractor and every 500 hours
thereafter for any evidence of damage, wear or cracks. In the event
of damage or alteration, the ROPS must be replaced prior to further
operation of the Tractor.
The seat belt must be worn during machine operation when the
machine is equipped with a certified ROPS.
Failure to do so will reduce or eliminate protection for the operator
in the event of a roll over.
PRECAUTION TO AVOID TIPPING
Do not drive where the Tractor could slip or tip.
Stay alert for holes and rocks in the terrain, and other hidden
hazards.
Slow down before you make a sharp turn.
Driving forward out of a ditch or mired condition could cause
Tractor to tip over backward. Back out of these situations if
possible
PARK TRACTOR SAFELY
Before working on the Tractor ;
Lower all equipment to the ground.
Stop the engine and remove the key
KEEP RIDERS OFF TRACTOR
Do not allow riders on the Tractor.
Riders on Tractor are subject to injury such as being stuck by
foreign objects and being thrown off of the Tractor
5

HANDLE FUEL SAFELY-AVOID FIRES
Handle fuel with care; it is highly flammable. Do not refuel the
Tractor while smoking or near open flame or sparks.
Always stop engine before refueling Tractors.
Always keep your tractor clean of accumulated grease, and debris.
Always clean up spilled fuel.
STAY CLEAR OF ROTATING SHAFTS
Entanglement in rotating shaft can cause serious injury or death.
Keep PTO shield in place at all times.
Wear close fitting clothing. Stop the engine and be sure PTO drive
is stopped before making adjustments, connections, or cleaning out
PTO driven equipment.
ALWAYS USE SAFETY LIGHTS AND DEVICES
Use of hazard warning lights and turn signals are recommended
when towing equipment on public roads unless prohibited by state
or local regulations.
Use slow moving vehicle (SMV) sign when driving on public road
during both day & night time, unless prohibited by law
PRACTICE SAFE MAINTENANCE
Understand service procedure before doing work.
Keep the surrounding area of the Tractor clean and dry.
Do not attempt to service Tractor when it is in motion.
Keep body and clothing away from rotating shafts.
Always lower equipment to the ground. Stop the engine.
Remove the key. Allow Tractor to cool before any work repair is
caused on it.
Securely support any Tractor elements that must be raised for
service work.
Keep all parts in good condition and properly installed.
Replace worn or broken parts. Replace damage/missing decals.
Remove any buildup of grease or oil from the Tractor.
Disconnect battery ground cable() before making adjustments on
electrical systems or welding on Tractor
6

AVOID HIGH-PRESSURE FLUIDS
Escaping fluid under pressure can penetrate the skin causing
serious injury. Keep hands and body away from pinholes and
nozzles, which eject fluids under high pressure. If ANY fluid is
injected into the skin. Consult your doctor immediately.
PREVENT BATTERY EXPLOSIONS
Keep sparks, lighted matches, and open flame away from the top of
battery. Battery gas can explode.
Never check battery charge by placing a metal object across the poles.
PREVENT ACID BURNS
Sulfuric acid in battery electrolyte is poisonous. It is strong enough to
burn skin, cause holes in clothing and cause blindness if found entry
into eyes.
For adequate safety always;
1.Fill batteries in a well-ventilated area.
2.Wear eye protection and acid proof hand gloves
3. Avoid breathing direct fumes when electrolyte is added.
4. Do not add water to electrolyte as it may splash off causing severe
burns.
If you spill acid on yourself;
1.Flush your skin with water.
2.Flush your eyes with water for 10-15 minutes.
Get medical attention immediately.
SERVICE TRACTOR SAFELY
Do not wear a necktie, scarf or loose clothing when you work near
moving parts. If these items were to get caught, severe injury could result.
Remove rings and other jeweler to prevent electrical shorts and
entanglement in moving parts.
7

Safety Starter Switch is to be replaced after every 2000 hours/4 years, whichever is earlier
TRACTOR RUNAWAY
1. The tractor can start even if the transmission is engaged position causing Tractor to runaway and
serious injury to the people standing nearby the tractor.
2. For additional safety keep the pull to stop knob (fuel shut off control) in fully pulled out position.
Transmission in neutral position, Foot brake engaged and PTO lever in disengaged position while
attending to Safety Starter Switch or any other work on Tractor.
SAFETY STARTER SWITCH
1. Clutch operated safety switch is provided on all Tractors which allow the starting system to
become operational only when the Clutch pedal is fully pressed.
2. Do not By-pass this safety starter switch or work on it. Only Authorized Dealers are
recommended to work on safety starter switch.
3. On some models Safety Starter switch is provided on transmission High-low shifter lever and in
PTO shifter lever.The tractor can be started only if High-low shifter lever is in neutral position.
WORK IN VENTILATED AREA
Do not start the Tractor in an enclosed building unless the doors &
windows are open for proper ventilation, as tractor fumes can cause
sickness or death. If it is necessary to run an engine in an enclosed area
remove the exhaust fumes by connecting exhaust pipe extension.
Caution
8

9
2.2 Safety Regulations
(1) Only those people who have been trained properly are allowed to drive a tractor.
(2) Before moving a tractor, you must observe whether there are obstacles on the road, especially whether
there is a man between the tractor and its trailer or its implement.
(3) Nobody is permitted to get on or alight from a moving tractor. While the engine is running, nobody
shall be allowed to work under the tractor for inspection and repair.
(4) When climbing or going down a steep hill, drive only at low gear. It is not permitted to shift gear
under such conditions.
(5) When a tractor is used for transportation, the left and right brake pedals must be locked together.
(6) Never make sharp turns when the tractor is being driven at high speeds. It is even more strictly
forbidden to make sharp turns with one side braked.
(7) Frequently inspect the tightness of bolts and nuts, fasten those connections such as the engine and the
chassis, driving wheels(or paddy wheels) and the axle shaft, steering gear and intermediate housing, etc..
Retighten any loosening of bolts and nuts.
(8) At the time of personnel changing shift, any troubles occurred with the tractor must be informed to the
workers of next shift. If necessary, the troubles must be eliminated before the tractor is assigned to work.
2.3 Important instructions
(1) Tractors that are newly delivered from the plant or rebuilt must undergo running – in process according
to the requirements stated in Chapter 3 before being assigned to work under normal load.
(2) Before starting the tractor, you must inspect the fuel system, electric system, cooling system and the
lubrication system. In any condition, it must not be permitted to fill unfiltered fuel into the fuel tank,
After starting the engine, you must ensure that the instruments or meters are working normally.
(3) When moving the tractor with implements attached, hydraulic lock of lifter must be turned to the
locking position.
(4) When hydraulic power output is used, the lift arm shall be at the lowest position and the cutoff valve
shall be turned in. On the other hand, if the attached implement is used for fields work, the cut-off valve
shall be turned out. It is not allowed to work both at the same time.
(5) When the tractor is used for stationary work through the use of belt and pulley system, the range shift
lever must be put in the neutral position, and the main gear shift lever must be in the 1st or 2ed gear
position, thus ensuring good lubrication of the front bearing of the 1st shaft in the transmission housing.
(6) This tractor is equipped with silicon rectifier alternator whose negative terminal is grounded.
Any mistake of wiring will damage the alternator and the regulator. It is strictly forbidden to make short
circuit tests by contacting the terminal to the ground, as this will destroy the diode. When the engine is
stopped, the key shall be turned to the position “0” to prevent the battery from continued discharging.

2.4 (ROPS) Roll Over Protective Structures
Roll Over Protective Structures (ROPS)
ET 350 ECONO tractor is equipped with a frame for the protection of operators.
In the case of cab tractors the frame is incorporated in the cab structure.
The objective of the frame or cab structure is to protect the operator in the event of a roll over
and they are designed to support the entire weight of the tractor in that event.
ET 350 ECONO tractor’s ROPS frame or cab structure is designed and has been tested to meet
industry and or Government standards.
Included in these tests were all mounting bases and bolts or other fasteners.
DANGER
For ROPS frames to be effective and protect the operator, the seat belt provided must be
worn in order to keep operators within the ROPS protected area in the event of a roll over.
Failure to use the seat belt can still cause serious injury or death.
On some models the ROPS frame has a fold down feature, which can be used to enter low
buildings etc.
Take care when lowering the upper section of the ROPS frame and take extreme care while
driving the tractor with the ROPS frame lowered.
Do not wear the seat belt with the ROPS lowered and please remember that the fold down facility
is for special circumstances only and must not be lowered for general use.
Use of the tractor with the ROPS lowered can cause fatal injuries.
As the ROPS frame or cab together with the seat belt was designed to meet certain standards,
they must be maintained in good order and condition.
To achieve this objective, both the structure and the seat belt should be inspected on a regular
basis (every time the tractor is serviced)
In the event that the seat belt is damaged or frayed, it should be replaced and in the event that the
ROPS frame or any part of the mounting structure is damaged or cracked, the faulty component
must be replaced with a new unit.
Such a unit must meet all of the test criteria of the original unit.
Fitment of an inferior item or items affects the certification of the entire ROPS structure and the
effectiveness of the structure in the event of an accident.
Drilling or welding of the ROPS structure is forbidden.
10

Damage of the ROPS
If the tractor has rolled over or the ROPS has damaged (such as striking an overhead object during
transport), It must be replaced to provide the original protection. After an accident, check for damages
to the 1.ROPS. 2.Seat 3.seat belt & seat mountings. Before you operate a Tractor, replace all
damaged parts.
DO NOT WELD, DRILL OR STRAIGHTEN THE ROPS
Warning
Never attach chains, ropes to the ROPS for pulling purposes; this will
cause the Tractor to tip backwards. Always pull from the Tractor drawbar.
Be careful when driving through door opening or under low overhead
objects. Make sure there is sufficient overhead clearance for the ROPS
fatal injuries
Warning
If the ROPS is removed or replaced, make certain that the proper hardware
is used to replace the ROPS and the recommended torque values are
applied to the attaching bolts
Warning
Always wear your seat belt if the tractor is equipped with ROPS
11

FOR Sliding seat
To select Seat position, move Adjusting lever and slide Seat closer to or away from Dash panel and
controls.
NOTE: Do not use solvents to clean the seat. Use warm water with a little detergent added.
Before operating a Tractor it is important to adjust the seat to the most comfortable position & check
whether it is properly locked in its position. Figure 1 identifies the seat fitted to your Tractor.
Danger
Check whether the seat properly locked in its position before driving the
tractor
12
Seat Adjusting Lever
Danger
Always use the seat belt when the ROPS is installed.Do not use the seat
belt if a foldable ROPS is down or there is no ROPS.Check the seat belt
regularly and replace if frayed or damaged
Sliding seat

13
2.5 SAFETY SIGNS
(Replace all missing, damaged or illegible signs)
GENERAL SAFETY INFORMATION
IMPORTANT: This “General safety Information” should be kept with the machine at all times as
reference data.
This symbol means ATTENTION! YOUR SAFETY IS INVOLVED.
The message that follows the symbol contains important information about safety.
Follow recommended precautions and safe operating practice.
WA R N I N G
• Before starting and operating know the operating
and safety instructions in the operators Manual
and on the tractor
• Clear the area of bystanders.
• Locate and know operation of controls.
• Start engine only from Operator’s seat with
depressed clutch pedal, transmission in the neutral
, PTO disengaged and hydraulic control in lower
position
• Slow down on turns, rough ground and slopes to
avoid upset.
• Do not permit anyone but the operator to ride
on the tractor. There is no safe place for rider.
• Lock brakes together, use warning lights and
SMV emblem while driving on roads.
• Lower equipment, place gear shift levers in
neutral, stop engine, remove the key and apply
parking brake before leaving the tractor seat.
• Air pressures are specified by the manufacturer
FAILURE TO FOLLOW ANY OF THE INSTRUCTIONS ABOVE CAN CAUSE SERIOUS
INJURY TO THE OPERATOR.
