TYM T264 Instruction manual

TYM
WORKSHOP MANUAL
for tractors
Model T264 HST
Zip code (570-941) TongYangMoolSan CO., LTD. 7-45, Wanggungnonggongdanji-gil, Iksan-si, Jeollabuk-do, Republic of Korea
■TEL. : ++82-63-830-1951~4, FAX : [phone] ■www.tym.co.kr

HST TRACTOR
T264 HST
SERVICE MANUAL
Chapter 1. Introduction ------------------------------------
Chapter 2. Disassembly and reassembly of major point ------
Chapter 3. Engine accessories ------------------------------------
Chapter 4. HST system ---------------------------------------------
Chapter 5. Transmission -----------------------------------
Chapter 6. Front axle (4WD) ---------------------------------
Chapter 7. Rear axle and Brakes ---------------------------------
Chapter 8. Power steering system---------------------------------
Chapter 9. Hydraulic system -------------------------------------
Chapter 10. Electric accessories and instruments ----------
Chapter 11. Service standard and other information -----
01
02
03
04
05
06
07
08
09
10
11

Chapter 1
Introduction
INTRODUCTION-------------------------------------------------------------
SAFETY INTRODUCTION-------------------------------------------------
WARNING SIGNS IN THIS MANUAL----------------------------------
SAFETY SIGNS----------------------------------------------------------------
SAFETY DECALS-----------------------------------------------------------
UNIVERSAL SYMBOLS---------------------------------------------------
SECTION 1. TRACTOR TYPES AND PUNCHED
IDENTIFICATION MARKS -----------------------------
SECTION 2. SPECIFICATIONS------------------------------------------
SECTION 3. GEAR TRAIN DIAGRAMS-------------------------------
SECTION 4. PRECAUTIONS FOR TRACTOR OPERATIONS---
1. INSTRUMENTS -------------------------------------------------------
2. CONTROLS -----------------------------------------------------------
3. FILLING DIAGRAM AND CAPACITY TABLE---------------
4. MAINTENANCE CHART -------------------------------------------
1-01
1-02
1-04
1-05
1-10
1-13
1-14
1-16
1-19
1-20
1-20
1-22
1-23
1-24

Chapter 1 .Introduction
This tractor service manual is for qualified service personnel engaged in servicing and
overhauling T264HST tractor. Use of this publication is not recommended for field operators
since they usually do not have access to special tools and shop equipment essential for most
servicing.
Servicing procedures outlined herein contain sufficient information to return all component parts
of a tractor to new condition. In discussion of each component parts,it is assumed that a complete
overhaul is been performed,consequently,
complete disassembly and reassembly are outlined.The mechanic is relied upon to decide how far
disassembly must be carried when complete overhaul is not required.
Study unfamiliar service procedures thoroughly and clearly understood before attempting
disassembly. Specific data essential for proper overhaul,such as running clearances and torque
values,have been provided in interline of Inspection and reassembly procedures of each group
section.
This manual was compiled from latest information available at time of publication.
Manufacturer reserves the right to make changes at any time without notice.
Whenever the terms "left"and "right" are used, They means as viewed by the operator when
seated in the operator's seat.
1-1

SAFETY INSTRUCTION
ALWAYS PRACTICE SAFETY BY THINKING BEFORE ACTION
AVOID FIRE HAZARDS.
-Keep fire extinguishers easily available and in good operating condition.
All relevant personnel should know how to operate fire fighting equipment.
-Keep a first aid kit in an easily accessible location.
-Do not smoke while handling fuel,or other highly flammable material.
-Do not use an open pail for transporting fuel.
-Use of an approved fuel container.
-Dispose of all fuel-soaked rags in covered containers where cigarettes cannot be dropped
carelessly.
-Do not smoke and avoid open flame when charging,jumping,or boosting batteries.
-Batteries give off gas which is flammable and explosive.
-Do not charge batteries in a closed area. Provide proper ventilation to avoid explosion of
accumulated gases.
Avoid acid burns.
-Wear safety goggles when handling battery electrolyte.It contains sulfuric acid which is a poison
and can cause blindness.Avoid it contacting eyes,skin,or clothing. sulfuric acid will eat through
clothing and can cause severe burns to skin.
AVOID HIGH-PRESSURE FLUIDS
1) Before beginning work on hydraulic system components,turn off engine and operate hydraulic
control levers to relieve internal hydraulic pressure.
2) Oil under pressure can penetrate skin and lead to personal injury.Treat sources of oil pressure
with extreme care,wearing safety goggles.
3) If hydraulic leak develops,correct immediately.Escaping hydraulic oil can have extremely high
pressure. A stream of high pressure oil may easily penetrate skin just like modern needless
vaccination equipment,but with the exception that hydraulic fluid may cause blood poisoning.
It is imperative that connections are tight and that all lines and pipes should be in good condition.
If injured by escaping hydraulic fluid,see a doctor at once.
1-2

STAY CLEAR OF PTO
1) Entanglement in rotating drive line can cause serious injury or death.
2) Keep tractor master shield and drive line shield in place at all times except for special applications
as directed in the implement operator's manual.
3) Wear fairly tight tight fitting clothing.Stop the engine and be sure PTO driveline is stopped before
making adjustment,connections,or cleaning out PTO drive equipment.
SERVICE TIRES SAFELY
Tire changing can be dangerous and should be done by trained personnel using proper tools and
equipment.
Do not re-inflate a tire that has been run flat or seriously under-inflated.Have it checked by qualified
personnel.
Use wheel handling equipment adequate for weight involved when removing and installing wheels.
1-3

WARNING SIGNS IN THIS MANUAL
The following warning symbols in this manual draw additional attention to items of importance for the
safe and correct operation of the tractor.
SIGN MEANING OF SIGN
DANGER
Serious hazard with a very high level of risk of either serious injury or
death
WARNING
Hazard or unsafe practice that can lead to severe injury or death.
CAUTION
Hazard or unsafe practice that can lead in injury or death.
IMPORTANT
Instructions for the correct operation of the machine which, if followed,
will ensure that it performs at it’s best
1-4

1-5
SAFETY SIGNS
SIGNAL WORDS.
A signal word―DANGER, WARNING OR CAUTION―is used with
safety alert symbol.
DANGER identifies the most serious hazards. Safety signs with signal
Word ―DANGER OR WARNING―are typically near specific
hazards. General precautions are listed on CAUTION safety signs.
DANGER
WARNING
CAUTION
READ SAFETY INSTRUCTION
Carefully read all safety instructions given in this manual for your safety.
Tempering with any of the safety devices can cause serious injuries or
death. Keep all safety signs in good condition. Replace missing or
damaged safety signs.
Keep your tractor in proper condition and do not allow any unauthorized
modifications to be carried out on the Tractor, which may impair the
function/safety and affect Tractor life.
PROTECTION CHILDREN
Keep children and others away from the Tractor while operating.
BEFORE YOU REVERSE
- Look behind Tractor for children.
- Do not let children to ride on Tractor or any implement.
RECOGNIZE SAFETY INFORMATION
This symbol, Safety-Alert Symbol, means ATTENTION! YOUR SAFETY
IS INVOLVED. The message that follows the symbol contains important
information about safety. Carefully read the message

1-6
USE OF ROPS AND SEAT BELT
The Roll Over Protective Structure(ROPS) has been certified to industry
and/or government standards. Any damage or alternation to the ROPS,
mounting hard-ware, or seat belt voids the certification and will reduce or
eliminate protection for the operator in the event of a roll-over. The ROPS,
mounting hardware, and seat belt should be checked after the first 100
hours of Tractor and every 500 hours thereafter for any evidence of
damage, wear or cracks. In the event of damage or alteration, the ROPS
must be replaced prior to further operation of the Tractor.
The seat belt must be worn during machine operation when the machine is
equipped with a certified ROPS.
Failure to do so will reduce or eliminate protection for the operator in the
event of a roll over.
PRECAUTION TO AVOID TIPPING
Do not drive where the Tractor could slip or tip.
Stay alert for holes and rocks in the terrain, and other hidden hazards.
Slow down before you make a sharp turn.
Driving forward out of a ditch or mired condition could cause Tractor to
tip over backward. Back out of these situations if possible
PARK TRACTOR SAFELY
Before working on the Tractor ;
Lower all equipment to the ground.
Stop the engine and remove the key
KEEP RIDERS OFF TRACTOR
Do not allow riders on the Tractor.
Riders on Tractor are subject to injury such as being stuck by foreign
objects and being thrown off of the Tractor

1-7
HANDLE FUEL SAFELY-AVOID FIRES
Handle fuel with care; it is highly flammable. Do not refuel the Tractor
while smoking or near open flame or sparks.
Always stop engine before refueling Tractors.
Always keep your tractor clean of accumulated grease, and debris. Always
clean up spilled fuel.
STAY CLEAR OF ROTATING SHAFTS
Entanglement in rotating shaft can cause serious injury or death.
Keep PTO shield in place at all times.
Wear close fitting clothing. Stop the engine and be sure PTO drive is
stopped before making adjustments, connections, or cleaning out PTO
driven equipment.
ALWAYS USE SAFETY LIGHTS AND DEVICES
Use of hazard warning lights and turn signals are recommended when
towing equipment on public roads unless prohibited by state or local
regulations.
Use slow moving vehicle (SMV) sign when driving on public road during
both day & night time, unless prohibited by law
PRACTICE SAFE MAINTENANCE
Understand service procedure before doing work.
Keep the surrounding area of the Tractor clean and dry.
Do not attempt to service Tractor when it is in motion.
Keep body and clothing away from rotating shafts.
Always lower equipment to the ground. Stop the engine.
Remove the key. Allow Tractor to cool before any work repair is caused
on it.
Securely support any Tractor elements that must be raised for service
work.
Keep all parts in good condition and properly installed.
Replace worn or broken parts. Replace damage/missing decals.
Remove any buildup of grease or oil from the Tractor.
Disconnect battery ground cable() before making adjustments on
electrical systems or welding on Tractor

1-8
AVOID HIGH-PRESSURE FLUIDS
Escaping fluid under pressure can penetrate the skin causing serious injury.
Keep hands and body away from pinholes and nozzles, which eject fluids
under high pressure. If ANY fluid is injected into the skin. Consult your
doctor immediately.
PREVENT BATTERY EXPLOSIONS
Keep sparks, lighted matches, and open flame away from the top of
battery. Battery gas can explode.
Never check battery charge by placing a metal object across the poles.
PREVENT ACID BURNS
Sulfuric acid in battery electrolyte is poisonous. It is strong enough to burn
skin, cause holes in clothing and cause blindness if found entry into eyes.
For adequate safety always;
1. Fill batteries in a well-ventilated area.
2. Wear eye protection and acid proof hand gloves
3. Avoid breathing direct fumes when electrolyte is added.
4. Do not add water to electrolyte as it may splash off causing severe
burns.
If you spill acid on yourself;
1.Flush your skin with water.
2.Flush your eyes with water for 10-15 minutes.
Get medical attention immediately.
SERVICE TRACTOR SAFELY
Do not wear a necktie, scarf or loose clothing when you work near moving
parts. If these items were to get caught, severe injury could result.
Remove rings and other jeweler to prevent electrical shorts and
entanglement in moving parts.
WORK IN VENTILATED AREA
Do not start the Tractor in an enclosed building unless the doors &
windows are open for proper ventilation, as tractor fumes can cause
sickness or death. If it is necessary to run an engine in an enclosed area
remove the exhaust fumes by connecting exhaust pipe extension.

TRACTOR RUNAWAY
1.The tractor can start even if the transmission is engaged position causing Tractor to runaway and
serious injury to the people standing nearby the tractor.
For additional safety keep the pull to stop knob (fuel shut off control) in fully pulled out position.
Transmission in neutral position, Foot brake engaged and PTO lever in disengaged position
while attending to Safety Starter Switch or any other work on Tractor.
1-9
To avoid injury, always engage park brake, ensure HST is in Neutral position
and PTO switch is off when starting or running the engine.

SAFETY DECALS
The following safety decals ARE INSTALLED ON THE MACHINE.
If a decal become damaged,illegible or is on the machine,replace it.The decal part number is listed in
the parts lists.
WARNING
●Before starting and operating know the operating and safety instructions in the operators Manual
and on the tractor
●Clear the area of bystanders.
●Locate and know operation of controls.
●Start engine only from Operator’s seat with depressed clutch pedal, transmission in the neutral,
PTO disengaged and hydraulic control in lower position
●Slow down on turns, rough ground and slopes to avoid upset.
●Do not permit anyone but the operator to ride on the tractor. There is no safe place for rider.
●Lock brakes together, use warning lights and SMV emblem while driving on roads.
●Lower equipment, place gear shift levers in neutral, stop engine, remove the key and apply parking
brake before leaving the tractor seat.
●Air pressures are specified by the manufacturer.
FAILURE TO FOLLOW ANY OF THE INSTRUCTIONS ABOVE CAN CAUSE SERIOUS INJURY
TO THE OPERATOP
1-10

1-11

1-12

1-13
UNIVERSAL SYMBOLS
Some of the universal symbols have been shown below with an indication of their meaning
Engine speed
rev/minX100)
Pressured-
open slowly
Corrosive
substance
Hours,
recorded
Continuous
variable
”Tortoise”
Slow or
minimum Setting
Engine
coolant
temperature
Warning
”Hare” fast or
maximum
setting
Fuel level Hazard
warning
Transmission
oil pressure
Engine
Stop
control
Neutral Turn signal
Lights Fan
Transmission
oil
temperature
Horn Power take
off engaged parking brake
Engine oil
pressure
Power
take off
Disengaged
Head lamp
Air filter Lift arm/raise Differential
lock
Battery charge Lift arm/lower
See
operator’s
manual

SECTION 1. TRACTOR TYPES AND PUNCHED IDENTIFICATION MARKS
The tractor serial number is shown on the left hand side of the tractor as shown in the picture. The engine
number is stamped on the top of the engine block.
1.MODEL NAME PLATE
The plate indicates the model and type of the tractor.
①Model name
②Production I.D No.
The production I.D reference number is as shown
below
T264 M 00001
Production serial No
Production year
Production Model
1-14
Engine type and number on the top of Engine body
Manufacturer’s tractor Sr. No.
Stamped on plate on the L.H.S of Axle bracket
1
2

2. Engine Model Identification and serial number location.
1) Engine identification location
2) Engine EPA decal (A)
This decal represents that this engine is in compliance
with the U.S.EPA exhaust Emission regulation.
3) Engine number (B)
The Engine number is stamped on the cylinder block.
Note : The engine number is necessary information
that is requisite for the warranty registration form.
Engine number assignment standard
4) Assignment standard for engine model
code
Ex) A1100N2
1-15

1-16
SECTION 2. SPECIFICATIONS
Model T264 HST
Engine Maker KM
Model A1100N2
Type Vertical, Water Cooled 4-Cycle Diesel
Horse power , HP (㎾)24.1(18)
Rated Speed 2600
Number of cylinders 3
Displacement,cu in(cc) 71.7(1,175 cc)
Bore and stroke,mm(in) 78X82(3.07X3.23)
Compression ratio 21.5 : 1
Firing Order 1-3-2
Injection Pump -
Lubrication type Force feed (by trochoid pump)
Cooling system Forced cooling
Coolant Capacity (Approximate),
liter(US gal)
3.5(0.92)
Air Cleaner Dry Type with Single element
Muffler Horizontal Round
Fuel Diesel
Fuel tank capacity 6.6 US gal(25L)
Electric Battery 12V50AH
Starting System Electrical with Cell Motor
Starter Capacity 12V,1.4Kw
Alternator 12V,50A
Drive train Transmission HST / 2 Range
Numbers of speed Infinite
MFWD(4 WD) Standard
Differential Lock Mechanical( Foot brake)
Brakes Wet Disk
Steering Hydraulic Power

1-17
MODEL T264 HST
PTO Type Independent
Control Electro-Hydraulic
Clutch Multiple wet Disk
Rear PTO Shaft SAE 1-3/8, 6 spline
Speed 540rpm@Engine 2,600rpm
Hydraulics Control system Open Center
Working pressure 1,813psi( 125bar)
Pump capacity Main 4.4 GPM(16.6 LPM)
Steering 2.632GPM(8.8LPM)
3―Point
Hitch
Type SAE Category Ⅰ
Control Position
Lift Control At lift points 1,543lb(700kg)
At 24 in behind
Lift point 1,102lb(500 kg)
Dimensions Overall length 107.8 in (2,740mm)
Overall Width 52.8 in (1,342mm)
Overall height 89.8 in (2,280mm)
Wheel base 58.3 in (1,480mm)
Min.Ground clearance 7.71 in (196mm)
Tread R1 Front 6-12, 4PR
Rear 9.5-20, 4PR
R3 Front 25X8.50-14, 6PR
Rear 36X12.5-15, 4PR
R4 Front 23X8.50-12, 4PR
Rear 12-16.5, 6PR
R4-1 Front 25X8.5-14,4PR
Rear 14-17.5,10PR
Weight 1,907 lb (865kg)
