Tynetec FM0671-A User manual

Radio Receiver
2
4
13
I
II
III
IV
IV
III
II
I
Hand
Radio
Remote
Control
GadgetRemoteControlledMainsSockets
•Packincludes5mainsswitchersand1remotecontrol
•Operatingfrequency:433.92MHz
•Operatingvoltage:240V50HzAC
•Maximumload:13A/3120W
•Fitsstandard13AUKmainssocket
•Redonindicatorlamp
•CompatiblewithTynetecMK2SensorController
•Remotedimensions:110mmx40mmx16mm(HxWxD)
•Remoteweight:42grams
WhatcanGadgetRemoteControlledMainsSocketsbeusedfor?
Gadgetmainssocketsprovideameansofcontrollingelectricalappliancesatthetouchofa
button.TheTynetecMK2SensorControllercanalsobeusedtoswitchGadgetmainssockets
on/offautomaticallywhenusersgetin/outofbed.
ImportantSafetyInstructions
Gadgetsareintendedforinternaldomesticuseonly
DonotexposeaGadgettorainormoisture
DonotoverloadaGadget–maximumload3120W/13A
resistiveDonotattempttoserviceaGadget
AvoidpluggingGadgetsindirectsunlightorclosetoaheater
HouseCodeSettings
TheHouseCodeonlyneedstobechangedifneighbouringhomeshaveGadgetsinstalled.
Thereare4possibleHouseCodes(I/II/III/IV)whichmustbesetthesameonall
mainssocketsandtheremotecontrol.
1. Setthedialswitch(I/II/III/IV)onALLsocketstoanewsetting.
2. Settheslideswitchontherearoftheremotecontroltomatchthenewsetting.
3. PlugtheGadgetsintheirwallsocketsandtest.
IfyouhaveaTynetecMK2SensorControllerthiswillalsoneedthenewHouseCode
setting‐seethefollowingpage.
ChannelSetting
MultiplesocketscanbesetwiththesameChannelNumberiftheyallwant
tobeoperatedfromasinglebuttonontheremotecontrol.
Thereare4possibleChannelNumbers(1/2/3/4)whichselectswhich
numberbuttonthesocketrespondstofromtheremotecontrol.
1. Setthedialswitch(1/2/3/4)oneachsocketasrequired.
2. PlugtheGadgetsintheirwallsocketsandtest.
Note:theTynetecMK2SensorControllermusthavefirmwareV1.05AonwardstoworkwithGadgets.
ThefirmwareversionisshownontheMainMenuheaderontheMK2SensorControllerdisplay.
HOUSECODE
SWITCH
GADGET
MAINSSOCKET
CHANNELNUMBER
SWITCH
HOUSECODE
SWITCH GADGETREMOTE
CONTROL
tel. [phone] | [email protected] | web. www.telmenow.com
a

+
Control
Remote
Radio
Hand
I
II
III
IV
MK2SensorControllerSet‐up
FromtheMainMenuselectAdvancedSetupandpressENTER
ScrolldownandselectLightsSetupandpressENTER
SelectGadgetsSetupandpressENTER
SelectEnableandpressENTER
SelectGadgetsAddressandpressENTER
UsethekeystoSelectChannelI- II - III - IV(i.e.HouseCode)andpressENTER
Exitallprogrammingmenu’suntilthedisplaygoesblank.
FittingaGadgetSocket
Unplugtheapplianceyouwishtocontrolfromitsexistingsocket
SelectaGadgetandnote/setitschannelnumber(1to4)
PlugtheGadgetintothewallsocket
PlugtheapplianceyouwishtocontrolintotheGadgetsocket
Switchthewallsocketon
Switchtheapplianceonwithitsownon/offswitch
TestingwiththeRemoteControl
PresstheONbutton(channelnumber1to4)ontheremotecontrol
TheREDtransmitlightwillflashandthemainslamp/applianceshouldswitchon
PresstheOFFbutton(channelnumber1to4)ontheremotecontrol
TheREDtransmitlightwillflashandthemainslamp/applianceshouldswitchoff
Asradiosignalsareusedtooperatethemainssocketsthismeansyoucancontrolappliances
indifferentrooms.Typicallya30metrerangecanbeexpected,howevercertainbuilding
structuresmayreducetherangeorcauseblindspots.
TestingwiththeMK2SensorController
PressENTERonthesensorcontroller
FromtheMainMenuselectAdvancedSetupandpressENTER
SelectCalibrateandTestandpressENTER
ScrolldownandselectTestModeandpressENTER
Waituntilthedisplayshows……..NoClient……..
Lieonthebedandthedisplayshouldshow..ClientDetected..
Remainonthebedfor10seconds,theunitwillbeep3timesandthedisplaywillshowUnitissendingstatusINcode
Afterashortdelaythedisplaywillchangetoshow..ClientLoggedIN..
Getoffthebed,thedisplaywillshowUnitissendingstatusOUTcodeandGadgetSocket1willactivate
Afterapprox15secondsthedisplaywillshow..ClientOUT..andGadgetSocket2willactivate
Afterapprox10secondstheunitwillstarttobeepandthedisplaywillshow..Alarm..
Afterapprox10secondsandthedisplaywillshowUnitissendingALARMcode
AfterashortdelaytheunitwillexitTestModeandbothGadgetSockets1&2willdeactivate
TroubleShooting
Iftheappliancefailstooperatecheckthefollowing;
IstheGadgetsocket/appliancecorrectlyplugged‐in?
IsmainswallsocketswitchedON?
IstheapplianceitselfswitchedON?
IsthebatteryintheremotecontrolOK?
Iftheapplianceoperatessporadicallyitspossiblethataneighboursremotecontrolisinterfering
withyours–thiscanbeovercomebychangingtheHouseCodesetting.
RemoteControlBatteryReplacement
IftheREDTRANSMITLIGHTontheremotecontrolfailstoilluminate
whenon/offbuttonsarepresseditislikelythebatteryneedsreplacing.
Removethebatterycoveroffthebackoftheremotecontrol
Replacethebatterywithatype23A‐12V(notecorrectpolarity)
Refitthebatterycover
Note:Gadgetsocketsdonotrequirebatteries.
REPLACEMENT
BATTERY
TYPE23A‐12V
REDTRANSMITLIGHT
REMOVE
BATTERYCOVER
