F
eatures Benefits
&
8900 North 55th Street • Milwaukee, Wisconsin 53223 • Phone: [phone] • Fax: [phone]
www.u-line.com
WINE CAPTAIN®
MODEL 1115WC
Capacity: Up to 24 bottles (0.75 L)
Defrost Type: Automatic (cycle) Defrost
Colors: Stainless Steel and Black
Feature Benefit
Zones Maintains wine at their proper serving temperature
Top Approximately 55°F (Red)
Middle Approximately 50°F (White)
Bottom Approximately 45°F (Sparkling)
Safely stores three or two types, or a single type, of wine
Stable temperatures Stable, consistent temperatures provide longer-term storage
capability.
Push Button Digital Control • Provides ability to set the middle temperature and see the
temperatures in all three temperature zones
• Manages key model functions and provides user alerts
Adjustable on/off interior light • Automatically illuminates when the door is opened
• May be manually turned on when door is closed for
viewing one’s wines
• Auto shut-off after four hours
• Recessed so as not to interfere with access to wine
Slide-out zinc-coated wine racks Allow for easy access to all wine bottles, especially those
located in the rear of the unit
Maple-trimmed wine racks Wood can be stained or replaced with a solid surface
material to match surrounding décor.
Built-in Provides custom look. No additional clearance around sides,
top or rear of unit for ventilation. Do not obstruct front
grille.
Stainless steel model • Offers a bold commercial-style stainless steel handle,
stainless steel framed glass door with a black “cap” on the
top and bottom of the door
• Black vinyl-clad cabinet and black grille
• Must order right- or left-hand hinged
Black model Offers a black elegant integrated handle and grille with a
black vinyl-clad steel cabinet
Tinted, thermal glass door Protects wine from potentially harmful ultraviolet light rays
Field-reversible doors Flexible installation options. Black model only.
Black vinyl-clad cabinet • Textured look, more resistant to scratching, peeling or
flaking
• Black and stainless steel models
Leveling legs More precise undercounter fit, durable, factory-installed
Flat recessed grille Blends with the other Origins models and integrates with
surrounding cabinetry
Sabbath or “Black Out” mode Easily turn off all lights and control displays. Automatically
resets after 36 hours.

D
imensions Specifications
&
8900 North 55th Street • Milwaukee, Wisconsin 53223
Phone: [phone] • Fax: [phone] • www.u-line.com
04/15/06 © 2006 U-Line Corporation Printed In U.S.A.
Wine Captain Model 1115WC
Specifications Capacities
(1) Amps pertain to a 110/115 volt, 60 Hz electrical environment.
Anchoring device included with unit
Black model: Door must be able to open 145° to extend wine racks
Stainless steel model must be ordered right- or left-hand hinged.
Stainless steel models: Allow 2-1/2" clearance on hinge side for 90° door opening when installed against a wall.
To prevent potential interior liner damage, please consult the Installation Guide if you choose to stain the wood trim on the
wine racks.
Please visit www.U-Line.com for Installation Guide.
All specifications subject to change without notice.
14-15/16
(37.8)
* ON BACK OF UNIT INCHES (CENTIMETERS)
1-9/16
(4)
* POWER
CORD
1-1/2
(3.8)
34
(86.4)
FULL
RETRACT
HEIGHT
35
(88.9)
FULL
EXTEND
HEIGHT
3-1/8
(7.9)
20-5/8
(52.4)
23-1/8
(58.7)
24-5/8
(62.5)
22-13/16
(57.9)
20-5/8
(52.4)
1115WC 1115WC (Stainless Steel)
Shipping Weight:
Black Models
Stainless Steel Models
89 lbs (40 kg)
94 lbs (43 kg)
(1) Running Amps 2.4
(1) Maximum Start-up Amps 9.8
Refrigerator volume N/A
Freezer volume N/A
Approximate daily ice production N/A
Ice storage N/A
Wine bottle storage (0.75 L) Up to 24
