U-Line Wine Captain 1115WC User manual

FEAT URES
8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX [phone] U-LINE.COM
1115 W C
1115 WC 1000 SerieS
• Wine bottle capacity of up to 24 bottles (.75L)
• Touch pad digital control featuring easy view command center and door open alert
• Digital controlled triple temperature zone
• Temperature range 40 to 60°F
• Stable, consistent temperatures provide longer term storage capability
• Sabbath / Blackout mode turns off all lighting and controls display and automatically
resets after 36 hours
• UL residential and commercial listings
• Lighted black interior optimizes elegant display of wines and can be manually turned
on for display with door closed; automatically shuts off after four hours
• Solid beech wood trimmed, 3/4 extension black powder coated wine racks
• Standard commercial stainless steel handle is interchangeable with professional
handle option on stainless steel model
• Stainless steel model has stainless wrap with black caps on top and bottom to make
this unit field
• LowE coated, argon gas filled thermopane glass door provides protection from
potentially harmful UV rays and added insulating energy efficiency
• Black model includes integrated handle and is field reversible
• Black vinyl clad textured cabinet is more resistant to scratching, peeling and flaking
• Solid beech wood trim on wine racks can be stained to match surrounding cabinetry
• Allow a 2-1/2" clearance on hinged side for 90˚ door opening when installed adjacent
to a wall (for stainless steel model)
• Allow 1/4" width overall for proper installation (see backside for details)
• No additional clearance around sides, top or rear of unit is needed for ventilation
• Do not obstruct front grille air flow
• Durable, factory installed level legs provide a more precise undercounter fit
• Product note: with left hand hinge installation, allow for 145º door swing to ensure
extension of wine rack
Black
Stainless
Triple Zone System
f e a t u r e d i n 1115 W C .
For elegant presentation
of your wine collection,
all U-Line Wine
Captain®Models have
an illuminated interior.
INTEGRATION INTERIOR / EXTERIOR PERFORMANCE
WINE CAPTAIN®MODELS

1115WC
Stainless U-1115WCS-00
Black U-1115WCB-00
Please visit www.u-line.com for installation guide.
All specifications are subject to change without notice.
8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX [phone] U-LINE.COM
1115 W C
Height 34-1/8" (86.6)
Width 14 -15/16" (37.8)
Depth 23-1/8" (58.7)
With stainless steel handle 25" (63.5)
Shipping weight:
Black model 102 lbs (46 kg)
Stainless model 102 lbs (46 kg)
Running amps 2.4
Maximum start-up amps 9.8
Amps pertain to voltage rating 110/115 volt, 60 Hz
Capacities:
Wine bottle storage (0.75L) Up to 24
*Note: When installing a black model, allow for 145˚ door swing to
ensure wine racks slide out.
24"
1-1/2"
15-3/16"
7"
34-1/8"
to
35"
34-1/8"
14-15/16"
1115 Refrigerator & Wine Captain®
3-9/16"
23-1/8"
Stainless Refrigerator 1115RS
34-1/8"
14-15/16"
23-1/8"
3-9/16"
Not Including Handle
Stainless Wine Captain® 1115WC
34-1/8"
14-15/16"
23-1/8"
3-5/8"
Not Including Handle
34-1/8"
14-15/16"
1115 Refrigerator & Wine Captain®
3-9/16"
23-1/8"
Stainless Refrigerator 1115RS
34-1/8"
14-15/16"
23-1/8"
3-9/16"
Not Including Handle
Stainless Wine Captain® 1115WC
34-1/8"
14-15/16"
23-1/8"
3-5/8"
Not Including Handle
1115WCS Stainless Model 1115 WC B B l a c k M o d e l
OVERALL DIMENSIONS
DIMENSIONS AND SPECIFICATIONS
WINE CAPTAIN®MODELS
