INTRODUCTION & SPECIFICATIONS
Surface Prep
Division
P: 877-817- 6687 F: 813-621-7125
Visit us at www.ussaws.com
[email protected]
Read this entire operations and maintenance manual before using your new
tool. Pay close attention to the Rules for safer operation,
Dangers, Warnings and Cautions.
The purpose of safety symbols and explanations are to attract your atten-
tion to possible hazards and how to avoid them. The safety symbols and
explanations do not by themselves eliminate any danger. The instructions
or warnings they give are not substitutes for proper accident prevention
measures.
Table of Contents & Introduction ..................................................... 2
Symbols & Decals ................................................................... 3
Safety Instruction ................................................................... 4 - 5
Pre-Operation Checklist ..............................................................6 - 7
Operation ................................................................... 8
Parts Breakdown .............................................................9 - 12
Warranty & Service ............................................................. 13 - 14
1.0 INSTRUCTIONS FOR USE OF MANUAL SECTIONS
Section Page
2.0 SPECIFICATIONS
Foreword/Introduction
DANGER: Indicates an imminently hazardous situation that if not avoided,
will result in death or serious injury. This signal word is limited to the most
extreme situations.
WARNING: Indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation that, if not avoided
may result in minor or moderate injury. It may also be used to alert against
unsafe practices that may cause property damage.
2
The owner’s manual is intended to point out some of the basic safety situa-
tions that maybe encountered during the normal operation & maintenance
of the CC-100 Crack Chaser Machine & to instruct you in safety practices for
dealing with these conditions. Keep all manuals provided with your
machine in a safe place at all times.
The information and specications included in this publication were
in effect at the time of approval for printing. U.S.SAWS reserves the right,
however, to discontinue or change specications or design at any time with-
out notice and without incurring any obligation.
The U.S.SAWS CC-100 is a gas powered crack chasing saw that is designed
to rout out random cracks in concrete and asphalt surfaces prior to lling
with a repair product or sealant. The CC-100 is intended to be used on
parking garages, runways and large open warehouses. The CC-100 will cut
up to 1” deep and up to ½” wide. Always operate this machine in a well
ventilated area, as it emits carbon monoxide fumes, which are colorless
and odorless and can kill. Read this manual in it’s entirety prior to operat-
ing the machine and make sure to follow all safety regulations. Since safety
regulations vary between different countries and states, you must contact
the proper authorities and follow all appropriate regulations.
TO PREVENT SERIOUS INJURY DO NOT OPERATE SAW WITHOUTPROPER TRAINING AND.
UNDERSTANDING OF THE OWNERS MANUAL
WHEN OPERATING THIS MACHINE
ALWAYS WEAR SAFETY APPROVED
HEARING PROTECTION
EYE OR FACE PROTECTION
PROTECTIVE HELMET
PROTECTIVE GLASSES OR FULL FACE PROTECTION
WEAR HAND PROTECTION
WARNING: Improperly maintaining the JS including the Honda engine or failing to correct a problem before
operation could cause a malfunction resulting in a serious injury. Always perform a pre-operation inspection before
each operation and correct any problem. See Honda Engines Owner's Manual.
5.2 Check the condition of the Honda engine. See the section titled "Before operation - is your
engine ready to go?" in the Honda Engines Owner's Manual.
WARNING: Exhaust gas from gasoline engines contains dangerous carbon monoxide. Breathing it can cause
unconsciousness and even kill you. Always operate gasoline engine machines in a well-ventilated area. Do not
operate in areas where exhaust fumes could accumulate without wearing appropriate respiratory protection.
Consult your employer and OSHA regarding use of appropriate respirator for dangerous carbon monoxide
gases. See Figure 7.
EEnnggiinneeeexxhhaauussttccoonnttaaiinnss
ppooiissoonnoouussccaarrbboonn
mmoonnooxxiiddeeggaass..Breathing
it could cause death.
Operate machine in well
ventilated area.
FFiigguurree77--WWaarrnniinnggllaabbeell--eennggiinneeeexxhhaauussttccoonnttaaiinnssccaarrbboonnmmoonnooxxiiddeeggaass1111
Model CC-100
Part Number SX90102
Description Walk-Behind Crack Chaser
Power Source Honda GX270
Max RPM 7,500
Max Cutting Depth 1”
Blade Diameter 6” Dry Diamond
Blade Width .250”, .375”, .500”
Blade Arbor 5/8” with Drive Pin Hole
Weight 150 lb

SYMBOLS & DECALS
WARNING
Read and understand
operator's manualbefore
using this machine.
Failure to follow operating
Instructions could result
in injury or damage to
equipment.
Use only diamond blades (steel
centered diamond cutting-off
wheels) with this machine. RPM
rating on blade must exceed
machine max rpm rating. The use
of any other blade could result in
death or serious injury.
5400 MAX. RPM
Avoid injury.
Do NOT operate with
guard removed.
Replace guard before
operating machine.
C1h azard Comm unication Syw ems. LLLLCCMMOO--774466--00224411
To avoid injury:
Always inspect saw
blades before use.
Replace all cracked or damaged
blades.
Rotating blade
hazard.
Do NOT operate with
guard up.
Keep hands and feet
away.
Engine exhaust
contains poisonous
ccaarrbboonnmmoonnooxxiiddeeggaass..
Breathing it could cause
death.
Operate machine in well
ventilated area.
This product can expose you to chemicals, including NICKEL. When used, serviced, cleaned, or maintained equipment could generate particulates
that contain chemicals, including silica. These chemicals are known to the state of California to cause cancer and birth defects or other
reproductive harm. For more information, visit www.P65Warnings.ca.gov
