U-STEP Cueing Module User manual

U-STEP Cueing Module User Guide
In-StepMobility Products
www.Ustep.com
Installing and Replacing the Battery
The battery is installed as shown below. Remove the small screw holding the battery cover on (Figure
1), and slide the cover to the left to remove it. Replace the two “AA” batteries shown in Figure 2 with
Alkaline or Lithiumbatteries. Make surethe two batteries are installed in opposite directions, withthe
“+” and “-“ sides. The unit will beep either three or five times then the batteries are installed correctly.
If the unit beeps three times, the unit is shutting off; if the unit beepsfive times, the unit is turning on
and the LED indicator will start to blink.
Figure 1 Figure 2
Operating the Unit
Operate the unit from the control unit mounted on the right handle barin Figure 3. If the unit is off,
pressing the red ON/OFF button on the control unit and it will go on. The unit will beep 5 times, the
power indicator will begin blinking, andthelaser willturn on.If eitherbutton is pushed again,theunit
will beep three times and turn off.
To activate the sound cueing, turn on the laser and then pressand hold the top black ON button
beneath the AUDIO label on the left of the module (Figure 3). After a few seconds of holding, the
auditory cueingwill engage. When auditory cueing is enabled, pressing the FASTkey will increase the
cadence and pressing the SLOW key will decrease the cadence. The cadence varies from 59 to 130
beats per minute over 15 increments. To turn off auditory cueing, pressand hold the SLOW button.
To adjust the volume, turn on the laser and then press the SLOW button (Figure 3). The volume will
decrease eachtime the button is pushed. When the softest level is reached, the volume then revert to
the loudest level anddecrease again with each button push. The volumelevel selected willremain in
effect for subsequent use.

If auditory cueing is not turned on, the laser will automatically shut off after 4 minutes and the unit will
shut off 4 minutes later. This feature is provided to better manage battery life. Thelaser time-out may
beadjusted from 4to 28 minutes. To adjust the time out,turn the laser on and then press the FAST
button. The unit will beep 1 to 7 times. Each beep indicates 4 minutes of delay. For example, 7 beeps
indicate that the laser will shut off after 28 minutes. If the unit beeps 7 times, the next button push
will rotate back to the beginning and a single beep indicating 4 minutes of delay will be heard. The
selected value will remain in effectforsubsequent use.
Note: The unit will not time out if auditory cueing is enabled.
Figure 3
