DASH CAMERA INSTALLATION GUIDE
THANK YOU!!
WHAT’S IN THE BOX
AI-12 FEATURES
INSTALL YOUR AI-12
We are excited to introduce you to your new AI-12 Connected Dash Camera. With the AI-12 you can
harness the power of video to connect your fleet vehicle, help protect your drivers on the road and save lives.
WARNING: This type of installation should be performed by a qualified or professional person only.
Working with your vehicles power system can be dangerous for you and your vehicle. In any doubt,
consult a professional.
AI-12 Camera Mounting bracket
Hardwire Kit Proprietary screwdriver
-
Mounting
bracket slot
1080P HD
adjustable 140°
angle camera
Tamper resistant
cover for SIM and
SD card slots
Road-facing camera
HARDWIRE TO THE FUSE BOX
Check the Owner’s manual for the location of the fuse box. It may vary depending on make and model.
Remove the plastic panel to access the fuse box. It may open imply by lifting a tab or pulling it with your
fingers, or use a flat tool that can pinch in between the plastics.
STEP 1. Locate The Fuse Box
Use a circuit tester to test which fuse is constant(typically red) and provides 12v of power. A fuse that is
constant will stay active when the vehicle is off. The camera will automatically enter standby mode when the
vehicle is not moving for 10 minutes.
STEP 2. Which Slot Should I Use?
We recommend using an add-a-fuse kit included in our Essential Install Package, for a more secure, long
lasting installation. The add -a-fuse kit provides a fuse slot for the existing OEM circuit (constant or ignition
switched, #2 in picture below) and another fuse slot for the new circuit for the dashcam device (#1 in picture
below).
STEP 3. Add a Fuse Kit
Add a fuse kitHardwire Kit Fuse tape
Add a fuse kit
1
New fuse tape
Insert the new fuse tap provided in the kit into “slot 1” and the fuse from the fuse box into “slot 2” (Constant
or Ignition Switch). If you set them with the wrong order, it will not feed power to the hardwire kit.
Connect the hardwiring cable with the terminal crimp connector from the add-a-fuse kit. Trim off some of
the rubber tubing to expose the wiring on your hardwiring cable. Then crimp them down together.
You should be able to crimp the fuse kit with a standard needle nose pliers. We recommend using electrical
tape to further secure the wire.
ADJUSTING THE VIEWING ANGLE
The ground wire is usually in a C shape or a ring. To connect the ground wire, slip it under a metal bolt or
screw in your vehicle.
STEP 4. Ground the Hardwire Kit
Plug the power cable to the dashcam. Start your vehicle to test if the dashcam powers up. Once you tested
your dashcam, run the power cable along the headliner of the car along the A-Pillar to the power source for
a clean installation.
STEP 5: Test Your Dash Cam
Place the camera as high as possible on the driver side of the vehicle
Remove the 3M adhesive tape cover and mount the camera to the windshield
STEP 6: Attach Your Camera to the Front Windshield
Connect your Add-a-Fuse Kit to the vehicle fuse slot that you have chosen.
You may need a socket wrench set to loosen the bolt. Loosen the bolt enough to slip it in and tighten it back
up afterwards. A loose ground can result in power issues for your dashcam. We recommend grounding your
wire to an unpainted bare metal bolt.
Remove the AI-12 camera from the mount.
To Adjust the Road-facing camera simply rotate the center mount.
To Adjust Driver Facing Camera, Use the provided screwdriver to loosen the 3 screws onthe round side
of the camera, Do Not Fully Remove them. Next rotate the body near the two inward facing lenses to
adjust. Tighten security screws when finished to lock into place.
CALIBRATING THE AI-12’S SENSORS
The AI-12 contains an internal accelerometer that detects unsafe driving events. The accelerometer is not
calibrated in advance as the installation in every vehicle is different.
*The calibration process takes about a second and once completed. Note: Recalibration is required in case
of transferring the dashcam to another vehicle.
Please follow the following steps to calibrate the accelerometer.
Before you start, make sure that the vehicle is parked on a level surface.
Screws
Power jack
Access the Setting Menu of the AI-12 Camera
Settings Menu
Extremely Important!!!
Press the camera touchscreen.
Enter the default PIN number 3333.
The camera is now unlocked and the Settings menu is now accessible.
Turn on the vehicle’s ignition.
Check that the camera is on.
Press the touchscreen and enter the security PIN.
Enter into the ‘Settings’ menu.
Select ‘Calibrate’.
Calibrating the AI-12’s sensors
WiFi Hotspot
Add APN
Distracted Driver
U.S. Date format
Notify Live Streaming
Calibration
Format SD Card
Video Preset
Driver Camera
In-Cabin Recording
Speed in MPH
Change PIN
Brightness
Power Off
Select APN
Text Overlay
Driver Position
Audio Alarms
Change Driver PIN
Serial Number
THAT’S IT. YOU’VE SUCCESSFULLY INSTALLED YOUR DASHCAM!
VIEW LIVE VIDEO
Enter the ‘Live View’ mode in the main menu.
The live video will be displayed on the screen.
Use the arrow keys below the screen to switch between the road and cabin facing cameras.
Use the arrow back button to return to the main menu.
VIEW RECORDED VIDEOS
Enter the ‘Recordings’ mode in the main menu.
All the recorded videos on the SD card will be displayed in a list, sorted by date and time.
Use the arrow buttons to scroll through the list.
Select the video you would like to view and then click the ‘Play’ button.
DRIVING ALERTS!
A white vehicle icon will be displayed on the screen while driving.
NOW CALL 888-228-4460 ex 2 and our 24 hour support will add the camera to your platform!
Please have the Camera IMEI number ready for them.
In case of a dangerous driving events such as violent turn or unsafe driver behavior, the car icon will turn
red, indicating a visual alert for the driver.
In addition, a noise alert will sound off from the camera.
