SafetyInformation ..... ... .. .3
PackageContentsList .. ..6
Preparation .. ....7
AssemblyInstructions ... .. 8
Installation Instructions ..... ....12
Operating Instructions ..... ..15
Care and Maintenance ..16
Troubleshooting .. ... 18
ReplacementPartsList .... .. ..20
Warranty ... .. .22
TABLEOFCONTENTS
DANGER
Ifyou smell gas:
1.Shutoffgastotheappliance.
2.Extinguishanyopenflame.
3.Openlid.
4.Ifodour continues,keepawayfrom the
applianceand immediatelycallyourgas
supplieroryour firedepartment.
WARNING
1.Donotstoreorusegasolineor other
flammableliquidsorvapoursinthe
vicinity ofthisor anyotherappliance.
2.AnLP cylindernotconnectedfor use
shall notbestoredinthevicinity ofthis
or anyotherappliance.
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn

3
SAFETYINFORMATION
WARNING Hazardsorunsafe
practiceswhichcouldresult insevere
personalinjuryordeath.
CAUTION Hazardsorunsafepractices
whichcouldresultinminorpersonal
injury.
WARNING
CAUTION
WARNING
Donottrylightingthisappliancewithout first reading
the “LIGHTINGINSTRUCTIONS”section ofthis
manual.
WARNING
Donotusethe grill iftheodourofgasispresent. Contactcustomerserviceat1-866-206-0888.
WARNING
Neverattempttousedamagedequipment. Seeyourlocalliquidpropane dealerforrepair.
WARNING
Checkallgassupplyfittingsforleaksbeforeeachuse. Donotusethe grill untilall connectionshavebeen
checkedanddonot leak.Donot smokewhileleaktesting. Neverleaktestwithanopenflame.
WARNING
Donotinstall thisunit intocombustibleenclosures.
Thereshouldbeaminimumclearanceof24 inches
fromallsidestocombustiblematerials.
WARNING
Thisgrill isnot intendedtobe installed inoron
recr
eationalvehiclesand/orboats.
WARNING
Whenlighting,keep yourfaceand handsasfar
awayfromthegrill aspossible.
WARNING
MaximumLP gastanksizeis12inchesindiameter
by18-1/2inchestall.Donot useatankwithoutan
OverfillPreventionDevice(OPD), whichprevents
thetankfrombeingoverfilledandpossibly
damagingyourgrill.
WARNING
Donotstoregrillindoorsunless the cylinderis
disconnected. Donotstorecylinderinabuilding,
garage, oranyotherenclosed area, and keep out
ofreachofchildrenat alltimes.
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn

4
BEFORE LIGHTING
Inspectthegassupplyhosespriortoturning onthegas.Ifthereisevidenceofcuts, wear, orabrasion,it must
bereplaced priortouse.
Onlythepressureregulatorandhoseassemblysuppliedwiththeunitshouldbeused.Neversubstitute
regulatorsforthosesuppliedwiththegrill.Contactcustomerserviceforproperreplacement.
Screwthe regulator(typeQCC1)ontothe cylinder. Leakcheck the hoseandregulatorconnectionswithasoap
and watersolutionbeforeoperating thegrill (See “LeakTesting”instructionson page16).
Donotturnonthe gasattheLPgascylinderunlessthegashoseisproperlyconnected totheside burnergas
pipesystemand allburnervalvesareinthe “OFF”position.
Keepaspraybottleofsoapywaternearthe grilland check the connectionsbeforeeachuse.
WARNING
Donotleavethegrill unattendedwhilecooking.
WARNING
Failuretoproperlyplacethe burneroverthe orifice
couldcauseafiretooccurbehindand beneaththe
valvepanel,therebydamagingthegrill andmaking
it unsafetooperate.
WARNING
Spidersandinsectscan nestinside theburners
ofthe grill anddisrupt gasflow.
Inspect the grillat leasttwiceayear.
CAUTION
Whenusingamatchtolight thegrill,makesureto
usetheattachedlightingrod.
CAUTION
Beforecleaning,makesurethe gassupplyand
controlknobsareinthe “OFF”positionandthe
burnershavecooled.
CAUTION
Thegrill bodyisheavyandwill requiretwoor
morepeopletolift andpositionontogrillcart.
LP GASCYLINDERWARNING
1. Donotstoreorusegasolineorotherflammablevapoursandliquidsinthevicinityof thisoranyother
appliance.
2. Aliquidpropanecylindernotconnectedforuseshouldnot be stored inthevicinityofthisoranyother
appliance.
3. Donotstorespareliquidpropane gascylindersunderornearthisappliance.
4. Neverfillthe cylinderbeyond 80percentcapacity.
5. Liquidpropane cylindersmustbeprovidedwithalistedoverfilling preventiondevice.
6. If theinformationaboveisnot followedexactly,afireresultingindeathorseriousinjurycouldoccur.
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn

5
SAFETYPRACTICES TOAVOIDINJURY
When properlycaredfor,yourgrillwillprovide safe,reliableserviceformanyyears. However, extremecare
mustbe usedasthe grillproducesintenseheatthatcanincreaseaccidentpotential.
When usingthisappliancebasicsafetypracticesmustbefollowed, includingthefollowing:
Donotrepairorreplaceanypart ofthe grill unlessspecificallyrecommended inthismanual.Allotherservice
shouldbereferred toaqualified technician.
The grillisforoutdooruseonly.
The grillisnotintendedtobeinstalledinoron recreationalvehiclesand/orboats.
Childrenshouldnotbeleft alone orunattendedinanareawherethe grillisbeing used.Donotallowchildren
tosit,standorplayonoraround thegrillat anytime.
Donotstoreitemsofinteresttochildrenaroundorbelowthegrillorcart.Donot allowchildrentocrawlinside
the cart.
Neverletclothing, potholdersorotherflammablematerialscomeincontactwithortoo closetoanygrate,
burnerorhotsurfaceuntilit hascooled.The fabriccouldignite, causingseriouspersonalinjury.
Forpersonalsafety,wearproperapparel.Loosefitting garmentsorsleevesshouldneverbewornwhileusing
thisappliance. Somesyntheticfabricsarehighlyflammableandshouldnotbewornwhilecooking.
Onlycertaintypesofglass,ceramic, earthenware,orotherglazedutensilsaresuitableforgrill use.Other
typesofmaterialsmayshatterwithsuddentemperaturechanges.Useonlylowormediumheat settingsin
accordancewiththemanufacturer’sguidelines.
Donotheatunopened foodcontainersasabuild-upofpressuremaycausethecontainerstoburst.
Useacoveredhand when openingthe grill lid. Neverleanoveranopengrill.
When lighting aburner,alwayspaycloseattentiontowhatyou aredoing. Makecertainyouareawareof
whichburneryou arelightingsothat yourbodyandclothingremainclearofopen flames.
When usingthe grill, donottouchthegrill rack, burnergrateorimmediatesurroundingsastheseareas
becomeextremelyhot andcouldcauseburns.Useonlydrypotholders. Moistordamppotholdersonhot
surfacesmaycausesteamburns.Donotuseatowelorbulkyclothinplaceofpotholders. Donotallow
potholderstotouchhotportionsofthegrillrack.
Greaseisflammable.Lethotgreasecoolbeforeattemptingtohandleit.Donot allowgreasedepositsto
collect inthegreasetrayat thebottomofthe grill’sfirebox.Clean the greasetrayoften.
Donotusealuminumfoiltoline thegrill racksorgrillbottom.Thiscanseverelyupsetcombustion airflowor
trapexcessiveheatinthe controlarea.
WARNING
Donottrylightingthisappliancewithout first
readingthe “LIGHTINGINSTRUCTIONS”section
ofthismanual.
CALIFORNIAPROPOSITION65WARNING
Theburningofgasfuelgeneratessomeby-
products, whichareknownbytheStateof
Californiatocausecancerorreproductiveharm.
Tominimizeexposuretothesesubstances,always
operatethisunitaccordingtothecareand use
manual,ensuringyou providegoodventilation
whencookingwithgas.
TESTEDINACCORDANCEWITH
ANSIZ21.58a
LATESTSTANDARDandCGA1.6a-2008
STANDARD FOROUTDOORCOOKINGGAS
APPLIANCES.THIS GRILLISFOROUTDOORUSE
ONLY.
Checkyourlocalbuilding codesforthepropermethod
ofinstallation.Intheabsenceoflocalcodes, follow
eithertheNationalFuelGasCode,ANSI Z223.1/NFPA
54, orCAN/CGA-B149.1,NaturalGasand Propane
Installation Code, ElectricalCode, ANSI/NFPA70
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn

6
WARNING
Donot install thisunitincombustibleenclosures.Thereshouldbeaminimumclearanceof 24inchesfromall
sidestocombustiblematerials.
Forproperlightingandperformanceofthe burners,keep theburnerportsclean. Itisnecessarytoclean them
periodicallyforoptimumperformance. The burnerswillonlyoperateinoneposition andmustbe mounted
correctlyforsafeoperation.
Exercisecautionwhencleaninggrill.Toavoidsteamburns,donotuseawetspongeorclothtoclean thegrill
whileitishot.Somecleanersproducenoxiousfumesorcan igniteifappliedtoahotsurface.
Neveruseadented orrustypropane cylinder.
Turnoffallcontrolknobsandmakecertainthegrilliscoolbeforeusing anytypeof aerosolcleaneron or
aroundit.The chemicalthatproducesthesprayingactioncould,inthe presenceof heat, igniteorcausemetal
partstocorrode.
Donotusethegrilltocookexcessivelyfattymeatsorotherproducts, whichpromoteflare-ups.
Donotoperatethegrillunderunprotectedcombustibleconstructions. Useonlyinwell ventilated areas.Donot
useinbuildings, garages,sheds,breezewaysorothersuchenclosed areas.
Thisunit isintended foroutdooruseonly.
Keepthe areassurrounding the grillfree fromcombustiblematerialsincluding,fluids,trash,and vapourssuch
asgasoline orcharcoallighterfluid.Donot obstructtheflowofcombustion andventilationair. Ifthe unit is
storedindoors,makesureit hascooledbeforemovingitandtheLP-gascylinderhasbeendisconnected.
Thisliquidpropanegasgrillisdesignedforoptimumperformancewithout theuseofbriquettes.Donotplace
briquettesontheflametamersasthiswill blocktheventtothe grillburners. Adding briquettescandamage
ignition components,thusvoidingthewarranty.Donot usebriquettesofanykindinthegrill.
Keepthe backofthecartfree andclearfromdebris. Keepanyelectricalsupplycordand thefuelsupplyhose
awayfromanyheated surface.
Neverusethe grillinextremelywindyconditions.Iflocatedinaconsistentlywindyarea (oceanfront,
mountaintop,etc.),awindbreakwill be required.Alwaysadheretotheclearancespecifications.
PLACEMENTOFTHEGRILL
Outdoorcookingappliancesshouldnotbe usedunderoverheadcombustibleconstruction.
When determiningasuitablelocationtakeintoaccount concernssuchasexposuretowind, proximitytotraffic
paths, andkeepinggassupplylinesasshort aspossible.
Placethe grillinwell-ventilatedareas.Neverplacethe grillinabuilding,garage,breezeway,shedorother
suchenclosedareas.Duringheavyuse,the grillwillproducealotof smoke.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

7
Pack Description Requiredfor
assembly Extra hardware Total
AA5/32-in.x10-mmTruss Head Screw 38 pcs.2pcs.40pcs.
BB5/32-in.LockingWasher36 pcs.2pcs.38pcs.
CC1/4-in.x15-mm TrussHeadScrew 18 pcs.2pcs.20pcs.
DD1/4-in.Locking Washer26 pcs.2pcs.28pcs.
EE TankBolt1pc.--1pc.
FF AllenKey 1pc.--1pc.
GG1/4-in.AxleFlatWasher2pcs.1pc.3pcs.
HH1/4-in. Nut2pcs.1pc.3pcs.
II5/32-in.Nut3pcs.1pc.4pcs.
JJ 1/4-in.x61-mm Truss Head Screw 8pcs.1pcs.9pcs.
KK 1/4-in.FlatWasher14 pcs.2pcs.16pcs.
Beforebeginningassembly,makesureallpartsarepresent. Comparepartswithpackagecontentslist
and diagramabove.Ifanypart ismissingordamaged,do notattempt toassembletheproduct. Contact
customerserviceforreplacementparts.
•Estimatedassemblytime:50 minutes
•Toolsrequired forassembly:
PhillipsScrewdriver(not included)andWrench(not included)
•Note: Therightand left sidesofthegrill aredesignatedasifyouarefacingthefront ofthegrill.
HARDWARECONTENTS
PREPARATION
AA
BB CC DD EE
GG
HH
II
PhillipsScrewdriver
Wrench
JJ
FF
KK
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

8
1. WheelAssembly
Use16pc1/4-20*15(A)screwstolocknutsintoBottompanel(T)
AsshowninFig.1.
2. BottomPanel Assembly
Use5/32-32*10SunkScrewstolock TankBoltcapintotankbolt
AsshowninFig. 2.
3.Use6pcs 1/4-20*10TrussHeadScrewstoattachside panelsintobottompanel 。
AsshowninFig. 3
ASSEMBLYINSTRUCTIONS
Fig. 1
Fig. 2
Fig. 3
A
T
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn

9
4.Use9pcs 1/4-20*10screwstoattachback panelintosidepaneland bottompanel.
AsshowninFig.4
5.Use2pcs 5/32-32*10screwstoattachgastanksupport intobottompanel.AsshowninFig.5.
3.Front panelAssembly
Use16pcs5/32-32*10 sunkscrewstoattachleft-sideand right-side ofdoorwithrightpanelandleftpanel
AsshowinFig.6.
Fig. 4
Fig. 5
Fig. 6
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

10
4. FireboxAssembly
a)RemovetheFireboxAssembly (A)
fromthe cartonand carefullyplace
ontothe grillcart.Lidhandlewill face
frontandbe aboveCondimentTray(T).
AsshowninFig.7.
NOTE:Wesuggest that twopersonslift
thefireboxwhenassembling. Besure
thehoseandregulatorareplacedinside
thecartwhenplacing firebox(A). Be
suretoremoveall packagingmaterial
beforeassembly.
5.LeftSideShelfAssembly
Use4pcs1/4-20step screwstoattachthe left sidepanelintotheleftflange .
AsshowninFig.8.
Fig. 7
Fig. 8
A
T
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn

11
6.Right SideShelfAssembly
Use4pcs1/4-20step screwstolock therightside shelf intotherightflange.
AsshowninFig.9
7. HandleAssembly
Use2pcs5/32-32*10 screwstoattachmaintop handleintohook,AsshowninFig.10.
Fig. 9
Fig.10
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

12
8. LiquidPropaneHook-Up
Attachtheregulatortothe propanecylinderby
turningtheregulatorhandleclockwiseasshown
inFig.11.If theoutdoorcooking applianceisnot
beingused,thegasmustbeturned “OFF”attheLiquid
Propane Cylinder.
Check allgassupplyfittingsforleaksbefore
eachuse.Donotusethegrilluntil all connections
have beencheckedand donot leak (see “LeakTesting”instructionsonpage16).
INSTALLATIONINSTRUCTIONS
GASHOOK-UP
Onlythepressureregulatorandhoseassemblysuppliedwiththegrill shouldbeused.Anyreplacement
pressureregulatorandhoseassemblymustbespecifiedbythegrill manufacturer.
Thisgrill isconfigured forLiquidPropaneonly. DonotuseaNaturalGassupply.
Totalgasconsumption(perhour)withall burnersset on “HIGH”:
Mainburners3x12,000BTU/hr
Searingmainburner12,000BTU/Hr
Total48,000 BTU/Hr.
The installation ofthisappliancemustconformwithlocalcodesor,intheabsenceoflocalcodes, with
eitherthe NationalFuelGasCode, ANSI Z223.1/NFPA54,NationalGasPropaneInstallationCode,CSA
B149.2.
Installation inCanadamustbeinaccordance withtheStandardCAN/CGA-B149.2(installation code
for gasburning appliancesandequipment)andlocalcodes.
LIQUID PROPANECYLINDERREQUIREMENTS
(20-lb.Cylinder)
AdentedorrustyLiquidPropane Cylindermaybehazardousand shouldbechecked byyoursupplier.
Neveruseacylinderwithadamagedvalve.TheLiquidPropane Cylindermustbeconstructedand
marked inaccordancewiththespecificationsforLiquidPropane Cylindersbythe NationalStandardof
Canada,CAN/CSA-B339,Cylinders, SpheresandTubesforTransportation ofDangerousGoods
Commission.
The 20-lb.Cylinder musthaveashutoffvalveterminating inavalveoutletspecified, asapplicable, for
connection typeQCC1inthe standardforcompressedgascylindervalveoutlet andinlet connection
ANSI/CGA-V-1.
Storage ofanoutdoorcookinggasapplianceindoorsispermissibleonlyifthe cylinderisdisconnected
and removedfromtheoutdoorcooking gasappliance. TheCylindersystemmustbearrangedforvapour
withdrawal. ThecylindermustincludeacollartoprotecttheCylindervalve.
Fig. 11
PropaneCylinder
Regulator
TankBolt
Always keep theLPcylinderat
90°(upright)orientation to
providevapour withdraw.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

13
Manifoldpressure:(operating)10incheswatercolumn(W.C.),(non-operating)11.2incheswatercolumn
(W.C.).
LiquidPropane Cylindersmustbeprovidedwithalistedoverfillingprevention device.
Removetheplasticvalve coverfromtheLiquidPropane Cylinder. Makesurethegrillgashosesdonot
contactthegreasepan orgrill fireboxwhentheLiquidPropaneCylinderisplaced intothecart.
CONNECTINGTHELIQUID PROPANECYLINDER
ToconnecttheLiquidPropaneGasSupplyCylinder:
a)Thecylindervalveshouldbeinthe “OFF”position.Ifnot,turnthevalve
clockwiseuntilit stops.
b)Makesurethe cylindervalvehasthepropertype-1externalmalethread
connectionsperANSI Z21.81.
c)Makesurethe burnervalvesareinthe “OFF”position.
d)Inspectthevalveconnections,portand regulatorassembly.Removedebrisandinspectthe hose
fordamage.
e)Whenconnectingtheregulatorassemblytothe valve,useyourhand totighten the nutclockwise
until it stops. Useofawrenchcoulddamagethequickcouplingnutandresultinahazardous
situation.
f)Openthecylindervalve fullybyturningthevalvecounterclockwise.
g)Beforelightingthegrill,useasoapandwatersolutiontocheck alltheconnectionsforleaks.
h)Ifaleakisfound,turnthecylindervalve “OFF”anddonotusethegrilluntilalocalLiquidPropane
dealercan makerepairs.
WARNING
Neverattempttousedamagedorobstructedequipment. SeeyourlocalLiquidPropanedealerforrepair.
DISCONNECTINGTHELIQUID PROPANECYLINDER
1.Turnthegrillburnervalves “OFF”and makesurethegrill iscool.
2.TurntheLiquidPropaneCylindervalve “OFF”byturningclockwiseuntilit stops.
3.Detachthe regulatorassemblyfromthecylindervalvebyturningthequickcoupling nut
counterclockwise.
4.Placedustcaponcylindervalveoutlet wheneverthe cylinderis notinuse.Onlyinstallthetype of
dustcapon the cylindervalveoutletthat isprovided withthecylindervalve. Othertypesofcapsor
plugsmayresultinleakageofpropane.
LEAKTESTING
GENERAL
Although gasconnectionsonthegrill areleaktestedpriortoshipment, acompleteleaktest must be
performedattheinstallationsite.Beforeeachuse,checkallgasconnectionsforleaksusing the
procedureslisted below.
If thesmell ofgasisdetectedatanytime,youshouldimmediatelychecktheentiresystemforleaks.
Pleasemakesurethe cylindervalveconnectiondevice
properlyandsafelymateswiththeconnectiondevice
attachedtotheinletofthepressureregulator.
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn

14
BEFORETESTING
Makesureallpackingmaterialshavebeen removed fromthegrill, includingtheburnertie-downstraps.
WARNING
Checkallgassupplyfittingsforleaksbeforeeachuse. Donot usethe grilluntilall connectionshavebeen
checkedanddonotleak. Donotsmokewhileleaktesting. Neverleaktestwithanopenflame.
Makeasolutionofonepart liquiddetergentandone partwater.Youwill need aspraybottle, brush,or
rag toapplythesolutiontothefittings.Fortheinitialleaktest,makesuretheLiquidPropaneCylinderis
80%full.
TOTEST
1.Turntheburnervalvesoff.
2.TurntheLiquidPropaneCylindervalvecounterclockwisetoopen the valve.
3.Apply the soapsolution toallgasfittings. Soap bubbleswillappearwherealeakispresent.
4.If aleakispresent, immediately turnthegassupply “OFF”andtightenleaky fittings.
5.Turnthegasback “ON”andrecheck.
6.Shouldthegascontinuetoleakfromanyof thefittings,turnthegassupply “OFF”andcontact
customerserviceat 1-866-206-0888
7.If thereisevidenceofexcessive abrasionorwear, orthehoseiscut, itmustbe replacedpriortothe
outdoorcookinggasappliancebeing put intooperation.
Only thosepartsrecommendedbythemanufacturershouldbeusedonthegrill.Substitutionswill void
the warranty.
INSTALLATION FINALCHECK
•Maintainspecifiedclearanceof24inchesfromcombustiblematerialsand construction.
•All internalpackaginghasbeenremoved.
•The hoseandregulatorareproperlyconnectedtotheLiquidPropane Cylinder.
•The unithasbeentested andisfreeofleaks.
•The gassupplyshutoff valvehasbeen located.
•All burnersareinstalled.
•Keeptheinstructionmanualforfuturereference.
OPERATINGINSTRUCTIONS
GeneralUse of theGrill
Eachmainburnerisratedat12,000BTU/Hr. Themaingrillburnersencompass theentirecookingarea
and aresideported tominimizeblockagefromfallinggreaseanddebris.Abovetheburnersareflame
tamers. Theigniterknobsarelocatedon thecenterportionof thevalvepanel.Eachrotaryigniteris
labeled onthecontrolpanel.
UsingtheGrill
Grillingrequireshighheatforsearingandproperbrowning.Mostfoodsarecookedata “HIGH”heat
settingfortheirentirecookingtime.However,when grillinglargepiecesofmeat orpoultry,itmaybe
WARNING
1.Storageofanoutdoorcookinggasapplianceindoorispermissibleonlyifthe cylinderisdisconnected
andremovedfromthe outdoorcookinggasappliance.
2.Cylindermust bestoredoutdoorsout ofthe reachofchildrenand mustnotbe stored inabuilding,
garage oranyotherenclosedarea.
WARNING
1.DonotstorespareLiquidPropaneCylindersunderornearthisappliance.
2.Neverfill thecylinderbeyond 80percent capacity.
3.If theinformation aboveisnot followed exactly,afire,possiblycausing seriousinjuryordeath,may
occur.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

15
WARNING
Whenlighting, keepyourfaceand handsasfar
awayfromthe grillaspossible.
CAUTION
Whenusingamatchtolightthe grillmakesureto
usethe attachedlighting rod.
CAUTION
Removethewarmingrack whenusingamatch
tolightthegrill.
necessarytoturnthe heattoalowersetting aftertheinitialbrowning.Thismethodcooks the food
thoroughly without burningtheoutside.
Food cookedforalong timeorbasted withasugar-based marinademayneedalowerheatsetting near
the end ofitscooking time.
Tobegin:
1.Makesurethegrill hasbeenleaktestedand isproperlyplaced.(Seepage16.)
2.Removeanyremainingpackingmaterials.
3.Lightthe grillburnersusing the LightingInstructionsbelow.
4.Turnthecontrolknob(s)tothe “IGNITE/ HIGH”setting, and preheatthegrill for15 minutes.The grill
lidshouldbe closedduring the pre-heat period.
5.Placethe food on the grill andcooktothedesireddegree ofpreparation.Ifnecessary,adjust theheat
setting. Thecontrolknob maybepositionedatanysetting between “HIGH”and “LOW”.
LIGHTINGINSTRUCTIONS
BeforeLighting
Inspectthegassupplyhosepriortoturningon the gas.Ifthereisevidenceofcuts,wear,orabrasion,it
must bereplacedpriortouse.
Screwtheregulator(typeQCC1)ontothecylinder,and leakcheckthehoseandregulatorconnections
beforeoperating thegrill(seethe “LeakTesting”instructionson page16).
Only thepressureregulatorandhoseassemblysuppliedwiththe unit shouldbeused.Neversubstitute
regulators.If areplacementisnecessary,contactcustomerserviceforproperreplacement.
WARNING
Donotusethe grillif the odourofgasispresent. Contactcustomerserviceat1-866-206-0888.
TOLIGHTTHEMAINBURNERS
1. Open lidduring lighting.
2. Makesureallthe knobsareinthe “OFF”position, and thenturnthe LiquidPropane Cylindervalve
“ON”byslowlyturning counterclockwise.
3. Pushand turnMainBurnercontrolknob toIGNITE/HIGH, at the sametime, pressandhold
electronicignition button tolighttheburner.
4. Oncetheburnerislit, releasetheelectronicignition button andknob.
5. If ignitiondoesnotoccurin5seconds, turntheknob toOFF,wait5minutesandrepeat the lighting
procedureorlight bymatch.
TOMATCHLIGHTTHEGRILL
If aburnerwill notlightafterseveralattemptsusingthecontrolknobs, the burnersmaybelitwithamatch.
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn

16
MainBurner
1.If you have alreadyattemptedtolight the mainburnerwiththeigniter, allow5minutesforany
accumulatedgastodissipate.
2.Insert amatchintothe lighting rodasshownFig.22.
Ignitethe matchandinsertthrough the cookinggridstotheburner.
3.If theburnerdoesnotlightwithinsecondsturntheknobtothe “OFF”position, wait5minutesand try
again.
CAREAND MAINTENANCE
StainlessSteel
Therearemanystainlesssteelcleanersavailable. Alwaysusethemildestcleaningprocessfirst,
scrubbinginthedirection ofthegrain.Donotusesteelwoolasitwillscratchthe surface.Totouchup
noticeablescratchesinthe stainless steel,sandverylightlywithdry100 grit sand paperinthedirection of
the grain.
Greasespecks cangatherand bakeontothesurfacesofthestainlesssteel,givingtheappearanceof rust.
Forremoval,useanabrasivepadwithastainless steelcleaner.
Cooking Grates
The easiest waytoclean the grillisimmediatelyaftercookingiscompleted andthe flameshavebeen
turnedoff.
WearaBBQmitttoprotect yourhandfromheatandsteam.
Scrub the hotcookinggratesbydippingabristledBBQbrushintap water.Cleaningwillbemoredifficult
if thegrilliscooled off.
Grease Pan
The greasepanshouldbeemptied,wiped downandwashedaftereachusewithamilddetergentand
warmwatersolution.Checkthegreasepanfrequentlyanddonotallowexcess greasetoaccumulateand
flowout ofthegreasepan.
Grill Burners
Extremecareshouldbetakenwhen removing aburner.It mustbe correctlycenteredontheorifice
beforeanyattemptismadetorelight the grill.Frequency ofcleaningwill dependonhowoften you use
the grill.
Failuretoproperly placetheburnerovertheorificecouldcauseafiretooccurbehind andbeneaththe
valvepanel,therebydamagingthegrill andmakingit unsafetooperate.
IGNITE/HI
LO
OFF
Fig.12
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

17
Beforecleaning,makesurethegassupplyandcontrolknobsareinthe “OFF”positionand theburners
have cooled.
Toremovethemainburnersforcleaning:
1.Locatetheburnerscrewat the rearofthefirebox.
2.Removethescrewand lifttheburneroutofthefirebox.
Toclean thegrillburners:
1.Cleantheexteriorofthe burnerwithawirebrush.
Useametalscraperforstubbornstainsordebris.
2.Clearcloggedportswithastraightened paperclip.
Neveruseawooden toothpickasit maybreakoff
andclog theport.
3.Check and clean burners/venturetubesforinsects
andinsectnests. Acloggedtubecanleadtoafirebeneath,
andbehindthe maincontrolpanel.
Toreinstallthemainburners:
1. Inserttheburneroverthe mainburnergasvalve.
2. Makesurethe orificestud(A)is inside the burnerventure(B)asshowninFig.23.
3. Align the burnerscrewholewiththefireboxhole,insert screwandtighten.
Fig.13
B
A
CAUTION
1.Keep outdoorcooking gasappliancearea clearand freefromcombustiblematerials,gasoline
andotherflammablevapoursand liquids.
2.Donot obstructtheflowofcombustibleand ventilationair.
3.Keep the ventilationopening(s)of the enclosurefreeandclearfromdebris.
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn

18
TROUBLESHOOTING
ProblemsPossibleSolutions
Grill will not light.
1. Pushandturntheknoband check forsparks.
2.Ifthereisa spark,checktomakesuregasissupplied tothe
burner.
a.Purge the lineofanytrapped air.
b.Check toseeifyoucan match-lightthe burner.
c.Check toseethattheotherburnersoperatenormally.
d.Visuallychecktheelectrode andwirewhilepushing theigniter
knob.Ifasparkoccursanywherebuttheignitertip,the igniter
mustbereplaced.
Burnerflameisyellowand there
is anoticeablegasodour. 1. Check theburnerinletforobstruction, especiallyforspiders
andotherinsects.
2. Check theairshutterforproperadjustment.
3. Check forthe sourceofgasleaks.
Excessiveflare-ups. 1. Keephood upwhen grilling.
2. Keepknobson low.
3. Turnoneburneroffifnecessary.
4. Postheatgrill for10-15minutes, asthiswillburnoffdrippings.
5. Usemeatscontainingless fat.
6. Alwaysgrillchickenonlow,meatsidedownfor20minutesand
turntoskinsideforanother20minutes.Followabovesteps.
7. Ifflareup continues, movemeatstowarmingrackuntilflame
settlesdown.
8. Neverspraywaterongasflames—it will destroyyourgrill.
Burnerblowsout. 1. Checkforanyburnerdefects.
2. Checkforproperburnerinstallation.
3. MakesureonlyaproperLP-gastankisused.
4. Makesurethe gassupplyissufficient.
5. Checkif theLPtankisempty.
Lowheat The propaneregulatorassemblyincorporatesan excessflow
devicedesignedtosupply thegrillwithsufficient gasflowunder
normalconditions,yetcontrolexcessgasflow.
Rapidchangesinpressurecan triggertheexcess flowdevice,
providingalowflameandlowtemperature.Ifthe tankvalveis
turnedopentoallowgasflowwhileaburnervalveis open,the
surge ofpressurewillcausethedevicetoactivate. Thedevicewill
remaincloseduntilthe pressureisequalized.Thisshouldoccur
within5seconds.
Toensurethisdoesnotcausedifficultyinlightingthegrill,
followtheseinstructions:
1. Makesureall burnervalvesare “OFF.”
2. Openthetankvalveandwait5seconds.
3.Lighttheburneroneat atimefollowing thelightinginstructionslisted
onpage15.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

19
TROUBLESHOOTING
Checkforproper burnerflamecharacteristics.Burnerflamesshould beblueandstablewithnoyellow
tips, excessivenoise, orliftingasshowninFig.24. The following stepsshouldbefollowedforcorrecting
the flamecharacteristics:
1.Turnthecontrolknobsand LiquidPropaneCylindervalves “OFF.”
2.Allowthe grillandburnerstocool.
3.If theflameisyellow(not enough air),turntheadjustment screwfoundatthe frontof theburner
counterclockwise.
4.If theflameisnoisyorliftsawayfromthe burner(toomuchair),turntheadjustmentscrew
clockwise.
If theseadjustmentsdo notcorrect the problem, contactcustomerserviceat1-866-206-0888
ProblemsPossibleSolutions
Lowheatgeneratedwithknob
in “HI”position. 1.Makecertaintheproblemisisolatedtoonlyoneburner.Ifit
appearsso,cleantheorificeand burner, clearingportsof any
obstruction.
2.Check forabent orkinked fuelhose.
3.Makesuretheairshutterisproperlyadjusted.
4.Check forpropergassupplyandpressure.
5.Pre-heat the grill forafull 15minutes.
6. Check if LPgastankisempty.
Fig.14
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

20
REPLACEMENTPARTSLIST
Forreplacementparts, callourcustomerservicedepartmentat 1-866-206-0888,8A.M. –8P.M., EST,
Monday –Friday.
REF# DESCRIPTION QTY
REF DESCRIPTIONQTY
01 MainLid1pc29Bottompanel1pc
02 MainLidHandle1pc30Swivelcaster1pc
03 Bowlassembly1pcs 31StiffenerBottompanel. left 1pc
04 MainBurnerValve3pc32Swivelcasterwithbrake1pc
05 Electronicignitermodule1pcs 33Tankbolt1pcs
06 FrontTrimpiece2pcs 34StiffenerBottompanel.Right1pc
07 Woodinsert 2pcs 35Caster2pc
08 Controlpanel1pc36Sidepanel,Right2pcs
09 Logo1pc37Flange,Right1pc
10 Bezel4pc38Backpanel1pc
11 Controlknob 4pcs 39GreaseTrak1pc
12 Regulator.LP1pc40GreaseBox1pc
13 Sideburnergasvalve1pc41Searburnerigniterwire 1pc
14 MainManifold1pc42Searburner 1pc
15 Sideshelf2pcs 43MainburnerIgniterwireA1pc
16 Flange,Left1pc44MainburnerIgniterwireB 1pc
17 Sidepanel.left1pc45MainburnerIgniterwireC 1pc
18 Controlpaneltrim1pc46Mainburner 3pc
19 DoorMagnet Bracket1pc47Flametamer 3pc
20 Doormagnet2pc48Cookinggrid 1pc
21 Condiment tray1pc49Griddle 1pc
22 Leftdoorinsideliner1pc50Backpanel.Top 1PC
23 Rightdoorinsideliner1pc
24 FrontDoor.Left1pc
25 FrontDoor,Right2pcs
26 Doorhinge4pcs
27 Lighting Rod 1pc
28 Gastanksupport1pc
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
