Ubiquiti AM-5AC22-45 User manual

17/09/2020 AM-5AC22-45 Quick Start Guide
https://dl.ubnt.com/qsg/AM-5AC22-45/AM-5AC22-45_EN.html 1/11
Antenna Protective Shroud U-Brackets (Qty. 2)
Pole Brackets (Qty. 2) Pole Clamps (Qty. 2) Carriage Bolts (Qty. 4)
Serrated Flange Bolts (Qty. 4) Serrated Flange Nuts (Qty. 8) Weatherproof RF Cables (Qty.
2)
Package Contents
Installation Requirements
Rocket®5ac PtMP, model R5AC-PTMP (sold separately)
12 mm and 13 mm wrenches
Shielded Category 5 (or above) cabling should be used for all wired Ethernet
connections and should be grounded through the AC ground of the PoE.
We recommend that you protect your networks from harmful outdoor
environments and destructive ESD events with industrial-grade, shielded
Ethernet cable from Ubiquiti. For more details, visit ui.com/toughcable
AM-5AC22-45 Quick Start Guide
×
Click for
Table of Contents

17/09/2020 AM-5AC22-45 Quick Start Guide
https://dl.ubnt.com/qsg/AM-5AC22-45/AM-5AC22-45_EN.html 2/11
Hardware Installation
1.
2.
AM-5AC22-45 Quick Start Guide
×
Click for
Table of Contents

17/09/2020 AM-5AC22-45 Quick Start Guide
https://dl.ubnt.com/qsg/AM-5AC22-45/AM-5AC22-45_EN.html 3/11
3.
4.
AM-5AC22-45 Quick Start Guide
×
Click for
Table of Contents

17/09/2020 AM-5AC22-45 Quick Start Guide
https://dl.ubnt.com/qsg/AM-5AC22-45/AM-5AC22-45_EN.html 4/11
5.
AM-5AC22-45 Quick Start Guide
×
Click for
Table of Contents

17/09/2020 AM-5AC22-45 Quick Start Guide
https://dl.ubnt.com/qsg/AM-5AC22-45/AM-5AC22-45_EN.html 5/11
Note: Orient both U-Brackets as shown.
6.
7.
Note: Hand-tighten the bolts.
8.
AM-5AC22-45 Quick Start Guide
×
Click for
Table of Contents

17/09/2020 AM-5AC22-45 Quick Start Guide
https://dl.ubnt.com/qsg/AM-5AC22-45/AM-5AC22-45_EN.html 6/11
9.
AM-5AC22-45 Quick Start Guide
×
Click for
Table of Contents

17/09/2020 AM-5AC22-45 Quick Start Guide
https://dl.ubnt.com/qsg/AM-5AC22-45/AM-5AC22-45_EN.html 7/11
Note: The antenna has an electrical downtilt of 2°.
10.
AM-5AC22-45 Quick Start Guide
×
Click for
Table of Contents

17/09/2020 AM-5AC22-45 Quick Start Guide
https://dl.ubnt.com/qsg/AM-5AC22-45/AM-5AC22-45_EN.html 8/11
Note: The brackets may slide along the pole, depending on the angle of
the elevation tilt.
11.
AM-5AC22-45 Quick Start Guide
×
Click for
Table of Contents

17/09/2020 AM-5AC22-45 Quick Start Guide
https://dl.ubnt.com/qsg/AM-5AC22-45/AM-5AC22-45_EN.html 9/11
Specications
AM-5AC22-45
Dimensions 750 x 215 x 94 mm
(29.53 x 8.47x 3.70")
Weight (Mount Included) 6 kg
(13.23 lbs)
Frequency 5.15 - 5.85 GHz
Gain 22 dBi
HPOL Beamwidth 45° (6 dB)
VPOL Beamwidth 45° (6 dB)
Elevation Beamwidth 4°
Electrical Downtilt 2°
Max. VSWR 1.5:1
Wind Survivability 200 km/h
(125 mph)
Wind Loading 347 N @ 200 km/h
(78 lbf @ 125 mph)
AM-5AC22-45 Quick Start Guide
×
Click for
Table of Contents

17/09/2020 AM-5AC22-45 Quick Start Guide
https://dl.ubnt.com/qsg/AM-5AC22-45/AM-5AC22-45_EN.html 10/11
AM-5AC22-45
Polarization Dual Linear
Cross-Pol Isolation 30 dB Min.
ETSI Specication EN 302 326 DN2
Mounting Universal Pole Mount, Rocket Mount Bracket, and
Weatherproof RF Cables Included
Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specied by the manufacturer.
WARNING: Do not use this product in location that can be submerged by water.
WARNING: Avoid using this product during an electrical storm. There may be a remote
risk of electric shock from lightning.
Electrical Safety Information
1. Compliance is required with respect to voltage, frequency, and current requirements
indicated on the manufacturer’s label. Connection to a different power source than those
specied may result in improper operation, damage to the equipment or pose a re hazard if
the limitations are not followed.
2. There are no operator serviceable parts inside this equipment. Service should be provided
only by a qualied service technician.
Limited Warranty
ui.com/support/warranty
The limited warranty requires the use of arbitration to resolve disputes on an individual basis,
and, where applicable, specify arbitration instead of jury trials or class actions.
Compliance
RF Exposure Warning
The antenna and transmitter must be installed to provide a separation distance from all persons
and must not be located or operating in conjunction with any other antenna or transmitter. For
the specic separation distance, refer to the Quick Start Guide for your Rocket device
(transmitter).
L’antenne et l’émetteur doit être installé pour fournir une distance de séparation de toute les
personnes et ne doit pas être situé ou opérant en conjonction avec une autre antenne ou un
autre émetteur. Pour la distance spécique de séparation, se référer au Guide de démarrage
rapide pour votre appareil Rocket (l’émetteur).
AM-5AC22-45 Quick Start Guide
×
Click for
Table of Contents

17/09/2020 AM-5AC22-45 Quick Start Guide
https://dl.ubnt.com/qsg/AM-5AC22-45/AM-5AC22-45_EN.html 11/11
