Ubiquiti PrismAP-5-30 User manual

5GHz,30°Beamwidth
SectorHornAntenna
Model:PrismAP-5-30

Introduction
Thank you for purchasing the Ubiquiti Networks® Prism®AP.
This Quick Start Guide is designed to guide you through
installation and also includes warrantyterms.
The PrismAP is compatible with the following models:
• IsoStation™IS-M5
• IsoStation IS-5AC
• PrismStation™PS-5AC
Package Contents
5GHz, 30°Beamwidth
SectorHorn Antenna
Model:PrismAP-5-30
PrismAP-5-30 Quick Start Guide
TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet
cable and earth grounding must be used as conditions of product warranty. TOUGHCable™is
designed for outdoor installations. It is the customer’s responsibility to follow local country
regulations, including operation within legal frequency channels, output power, and Dynamic
Frequency Selection (DFS) requirements.

Hardware Installation
These instructions show the IsoStation; however, they also
apply to the PrismStation.
1. To remove the default horn, rotate the horn
counterclockwise while depressing the Release Button.
Release
Button
2. As you insert the PrismAP, align the arrow on the PrismAP
with the Release Button.

3. Press down on the PrismAP and rotate it clockwise until
you hear a click.
4. Follow the installation instructions in the Quick Start Guide
of your IsoStation or PrismStation.

Specifications
PrismAP-5-30
Dimensions 221.4 x 221.4 x 184.2 mm
(8.72 x 8.72 x 7.25")
Weight 1.1 kg
(2.43 lb)
Frequency Range 5.15 - 5.85 GHz
Compatible Radios IsoStation/PrismStation
Gain 19 dBi
HPOL Beamwidth 30°
VPOL Beamwidth 30°
Elevation Beamwidth 30°
Electrical Downtilt 0°
Polarization Dual-Linear
Cross-Pol Isolation 17 dB
Max. VSWR 2:1
Wind Loading
(with PrismStation)
56 N @ 200 km/h
(12.59 lbf @ 125 mph)
Wind Survivability 200 km/h
(125 mph)
