Ubiquiti RocketDish RD-5G30 User manual

Dish Reflector Antenna Feed Mount Bracket
Protective Shroud Pole Clamps (Qty. 2) Stabilizer Brackets (Qty. 2)
RF Cables (Qty. 2) Elevation Rod M10x150 Carriage Bolts (Qty.
4)
M10x100 Bolts (Qty. 2) M10x25 Carriage Bolts (Qty.
3)
M4 Screws (Qty. 4)
Package Contents
RD-5G30 Quick Start Guide

Installation Requirements
5 GHz Rocket® radio (sold separately)
Phillips #1 screwdriver
16 mm or 5/8" wrench
24 mm wrench
Shielded Category 5 (or above) cabling with drain wire should be used for all wired
Ethernet connections and should be grounded through the AC ground of the PoE.
We recommend that you protect your networks from harmful outdoor
environments and destructive ESD events with industrial-grade, shielded Ethernet
cable from Ubiquiti. For more details, visit ui.com/toughcable
Hardware Installation
IMPORTANT: Handle the Dish Reflector with care. Deformations in its shape
may reduce the antenna’s effectiveness.
1.
IMPORTANT: The Dish Reflector and Antenna Feed are keyed so the
Antenna Feed can only be installed in a single orientation.
IMPORTANT: Do not handle the antenna by the Antenna Feed once the
feed is connected.
2.
RD-5G30 Quick Start Guide

3.
4.
RD-5G30 Quick Start Guide

5.
6.
7.
RD-5G30 Quick Start Guide

8.
9.
10.
RD-5G30 Quick Start Guide

11.
12.
13.
RD-5G30 Quick Start Guide

14.
RD-5G30 Quick Start Guide

15.
RD-5G30 Quick Start Guide

16.
17.
RD-5G30 Quick Start Guide

Specifications
RocketDish RD-5G30
Dimensions 650 x 650 x 304 mm
(25.59 x 25.59 x 11.97")
Weight 9.8 kg
(21.61 lb)
Frequency 5.1 - 5.9 GHz
Gain 30 dBi
HPOL Beamwidth 5° (3 dB)
VPOL Beamwidth 5° (3 dB)
Front-to-Back Ratio -34 dB
Max. VSWR 1.7:1
Wind Survivability 200 km/h
(125 mph)
Wind Loading 787 N @ 200 km/h
(177 lbf @ 125 mph)
Polarization Dual Linear
RD-5G30 Quick Start Guide

RocketDish RD-5G30
Cross-Pol Isolation 35 dB Min.
Mounting Universal Pole Mount, Rocket Bracket, and
Weatherproof RF Jumpers Included
Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by the manufacturer.
WARNING: Do not use this product in location that can be submerged by water.
WARNING: Avoid using this product during an electrical storm. There may be a remote
risk of electric shock from lightning.
Electrical Safety Information
1. Compliance is required with respect to voltage, frequency, and current requirements
indicated on the manufacturer’s label. Connection to a different power source than those
specified may result in improper operation, damage to the equipment or pose a fire hazard if
the limitations are not followed.
2. There are no operator serviceable parts inside this equipment. Service should be provided
only by a qualified service technician.
Limited Warranty
ui.com/support/warranty
The limited warranty requires the use of arbitration to resolve disputes on an individual basis,
and, where applicable, specify arbitration instead of jury trials or class actions.
Compliance
RF Exposure Warning
The antenna and transmitter must be installed to provide a separation distance from all persons
and must not be located or operating in conjunction with any other antenna or transmitter. For
the specific separation distance, refer to the Quick Start Guide for your Rocket device
(transmitter).
L’antenne et l’émetteur doit être installé pour fournir une distance de séparation de toute les
personnes et ne doit pas être situé ou opérant en conjonction avec une autre antenne ou un
autre émetteur. Pour la distance spécifique de séparation, se référer au Guide de démarrage
rapide pour votre appareil Rocket (l’émetteur).
WEEE Compliance Statement
RD-5G30 Quick Start Guide

Declaration of Conformity
Online Resources
