Ubisys J1-R User manual

As per 04/2020Page 1/2
Specifications
The shutter control J1-R is a radio controlled universal shutter actuator with
integrated power consumption measurement. In the current flush mount
version, it is compatible to standard switch boxes and fully integrates into the
rest of your smart home. It is not only suitable for new buildings, but also for
existing buildings, because retrofitting has, due to use of radio technology, no
special requirements to the electrical installation. The system can gradually
be extended by adding new components. The shutter control J1-R offers
full functionality when combined with other components of the ubisys smart
home product line and allows for example:
• Freely configurable assignments between control elements and consu-
mers
• Scenes and group controlling
• Time and event controlled actions
• Continuous metering
• Surveillance
• Control via smartphone and tablet using the ubisys app, or as usual via
buttons or switches
More information about the features of the ubisys smart home product line
can be found at www.ubisys.de.
Installation
The shutter control J1-R meets the requirements of DIN 43880 and is
designed for installation in fuseboxes, mounted on cap rails according to
EN50022.
Leads: Dimensions:
During installation, the general risks of household voltage networks have to
be noted!
Note
Please make sure that you wire the cables for up/down accordingly, so that errors in
operation do not occur later (e.g: you tap on „down“ in the app and the blinds move
up).
Zigbee Initial Commissioning (Brand New Device)
1. Connect the unit to a power source (according to the connections).
2. Open a Zigbee network: when using the ubisys gateway, tap Confi-
guration -> Basic Configuration -> Open for new devices in the
ubisys app (if you are using third-party gateways or apps, follow the
corresponding procedure).
Funkvernetzt mit
Stromverbrauchs-
messung
Universal-
dimmer D1-R
230 V~/50 Hz
500 VA
Funkvernetzt mit
Stromverbrauchs-
messung
Jalousie-
steuerung J1-R
230 V~/50 Hz
500 VA
Funkvernetzt mit
Stromverbrauchs-
messung
Leistungs-
schalter S1-R
230 V~/50 Hz
3.680 VA
Funkvernetzt mit
Stromverbrauchs-
messung
Leistungs-
schalter S2-R
230 V~/50 Hz
2 x 500 VA
90 mm
18 mm
(1 TE)
60,5 mm
90 mm
18 mm
(1 TE)
60,5 mm
90 mm
18 mm
(1 TE)
60,5 mm
90 mm
18 mm
(1 TE)
60,5 mm
3. The Zigbee network is open and the device joins.
4. The device appears in the component list: Configuration -> Basic
Configuration -> Components.
Factory Reset
Power-Cycle Sequencing Factory Reset: It is possible to instigate a factory
reset using a special power-cycle sequence without having access to the
device itself (only to its power supply). The only requirement is a simple on/
off sequence in a 1-second rythm:
1. The device has to be powered up for at least 4 seconds.
2. Power off for a second.
3. Power on for a second.
Repeat steps 2.-3. in the aforementioned 1-second rythm another 3 times,
and with the last sequence keep the device powered up (see illustration).
4. The device will automatically reboot to the original factory settings.
Factory Reset via Button: To reset the device to its factory fresh settings
(e.g. in order to join it to another network afterwards), press the button in the
larger of the two holes on the front for more than 10 seconds until the LED
starts flashing rapidly.*)
Only use the electrically isolated tool provided with the device to press the
button in the hole.
*) If the device has legacy firmware this feature might not be available. In this
case, keep the button pressed for one second, until the LED flashes three
times and then blinks once every second. Then press the button four times
for less than a second, until the LED flashes five times, followed by a pause,
then flashes five times again, followed by a pause, etc. In this state, keep the
button pressed for more than a second until the LED starts flashing rapidly.
Configuration
Upon delivery the factory settings of shutter control J1-R has switching inputs
1 and 2 assigned to the corresponding switching outputs. So it can initially
be operated autonomously without a radio network.
For integration into the smart home radio network, the shutter control J1-R
has to be configured first. Direct access to the shutter control J1-R is not
necessary for configuration. That means that network configuration can also
be done after successful electrical installation. It is best to hold the 16 digit
serial number of the shutter control J1-R in the construction plan during
installation. This allows you to allocate the device at a later point.
When connected to power, the shutter control J1-R automatically logs into
the Zigbee network. After that it can be configured via the electrician’s instal-
lation software (ubisys Network Manager) or the ubisys smartphone app.
More information about adding and configuring ubisys smart home compon-
ents can be found in the ubisys Smart Home app manual.
Technical Information
Rated voltage 230 V ~, 50 Hz
Max. switching power 500 VA
Own consumption 0.3 W
Button
LED
Button
LED
Button
LED
Button
LED
Shutter Control J1-R
Radio linked with power consumption measurement
As per 04/2020Page 2/2
Radio technology Zigbee 3.0 in 2.4 GHz ISM Band,
IEEE 802.15.4 channels 11-26, 0…5dBm
transmitting power *)
Environment temperature -20°C - +45°C
*) More information about radio technology can be found at www.ubisys.de.
Certifications and Environmental Contribution
Caution
Subjecting the inputs with a phase different from the operating voltage’s one (L) will
destroy the device.
Caution
Even unconnected ports can carry threatening voltages.
Caution
Parallel connection of actuators is not permitted and can lead to destruction of the
unit, drive or driven objects (blinds, shutters, doors, windows etc.)!
Hazard notes
Installation should only be performed by a qualified electrician. Wrong wiring from not
following instructions can cause unforeseen behavior, such as fire or destruction of
the device. There is a risk of electric shock. Electrical shock can result in death. Prior
to installation, disable voltage and cover live parts. Opening the unit or other devices
voids the warranty.
Conformity
This device complies with the applicable directives and standards of the EU
match.
Manufacturer
ubisys technologies GmbH
Neumannstr. 10
40235 Düsseldorf
Germany
[email protected]
www.ubisys.de
Shutter Control J1-R
Radio linked with power consumption measurement
