UCL SWIFT SWIFT KF4 User manual

NORTH AMERICA
SWIFT KF4 USER MANUAL
OPTICAL FIBER ARC FUSION SPLICER
Read carefully before running KF4
uclswiftna.com

TABLE OF
CONTENTS
SAFETY INSTRUCTIONS 3
PRODUCT SPECIFICATIONS AND COMPONENTS 6
2.1|PRODUCT SPECIFICATIONS 6
2.2|PRODUCT PACKAGE 6
PRODUCT OUTLINE 7
3.1|FUNCTION BUTTONS 7
3.2|COMPONENT NAME 8
INSTRUCTIONS FOR USE 9
4.1|POWER SUPPLY 9
4.2|HOW TO TURN THE POWER ON/OFF 10
4.3|KF4 SLEEVE HEATER 10
4.4|SPLICE PROCEDURE 11
4.5|REMOVING THE SPLICED FIBER 12
4.6|HEATING PROTECTION SLEEVE 12
4.7|USE OF WORK BELT 13
MAINTENANCE OF SPLICE QUALITY 14
5.1|CLEANING AND INSPECTION BEFORE SPLICE 14
5.2|REGULAR INSPECTION AND CLEANING 15
MENU 17
POPUP MENU 19
6.1|SPLICE 22
6.2|HEATER 26
6.3|HISTORY (SPLICE RESULT) 31
6.4|OPTION 32
6.5|CALIBRATION 35
6.6|ELECTRODES 39
6.7|SETTING 42
6.8|INFORMATION 45
1 2
1
2
3
4
5
6
7
8
9
10
ERROR MESSAGES 48
7.1|TOO DIRTY FIBER 48
7.2|REPLACE FIBER 48
7.3|TOO LONG FIBER 49
7.4|FIBER OVER ANGLE 49
7.5|LOSS LIMIT OVER 50
7.6|FIBER THIN ERROR 50
7.7|FIBER THICK ERROR 50
7.8|BUBBLE ERROR 50
7.9|CLEAVED SURFACE ERROR 50
SPLICING PROBLEM SOLVING 51
8.1|WHEN LOSS IS HIGH 51
8.2|ABNORMAL SPLICING OPERATION 51
PROBLEM OCCURRENCES AND QUESTIONS 52
9.1|POWER 52
9.2|SPLICE 52
9.3|SLEEVE HEATER 53
9.4|OTHERS 53
WARRANTY AND REPAIR RESPONSIBILITY LIMIT 54
10.1|INFORMATION NECESSARY FOR REPAIR 54
10.2|TRANSPORTATION 54
10.3|REPAIR 54

SWIFT KF4-EN, Rev.C 5
WARNINGS
Do not disassemble the AC charger, battery or KF4. Deformation may cause fire, electrical
shock or injury.
Refer to the following when using the battery:
▪ Failure to use batteries and chargers provided by UCLSWIFT may result in smoke,
equipment damage, burn, injury or even death.
▪ Do not incinerate any conductive materials.
▪ Do not charge the battery near flame.
▪ Do not give an excessive shock to the battery.
▪ When the battery does not completely charge in two hours, or when the green LED is
not turned on, stop charging immediately and contact UCLSWIFT.
▪ Do not put anything on the AC charger while charging.
Use only the AC charger provided. Do not use another AC power cord or battery. Excessive
current may result in equipment damage or injury.
Do not use the KF4 where there is harmful gas or flammable liquid. Explosion or fire may
result.
Do not use compressed air or compressed gas when cleaning the KF4.
To inspect, carry case belt before transportation. If fallen the carry case due to damage on the
belt, it may incur equipment damage or injury.
Always follow safety best practices, including the use of safety goggles and protective clothing
when working with fiber optic products, including KF4.
Do not use the KF4 around high temperatures or flame. Injury or equipment damage may
occur.
CAUTION:
HIGH TEMPERATURES DO NOT SPRAY FREON GAS CAUTION:
HIGH VOLTAGE
SAFETY INSTRUCTIONS
3 4
The KF4 is designed for convenient use on indoor and outdoor work sites. Please read all instructions to
prevent accidents and malfunctions. This user guide provides the information necessary for safe operation.
! Keep this user guide with the product at all times.
UCL SWIFT does not take any responsibility for equipment damage and personal or physical loss incurred due
to improper use or alteration.
If any of the following situations occur during use, turn off the power immediately and contact your local UCL
SWIFT offi ce or representative:
• Smoke, abnormal smell, noise or abnormal overheating
• A foreign substance or liquid falls into the equipment
• The splicer is visibly damaged
Use only the power cord and connecting devices provided with or intended for the KF4. Failure to do so may
result in fi re, electrical shock or injury.
Do not touch the electrodes when the power is on. High voltage and high temperatures generated from the
electrodes may result in serious shock or burn.
Connect the provided AC power cord only as directed. Ensure that there is no foreign substance on the
terminal before connecting it to the AC power socket. Improper use may result in smoke, electrical shock, fi re,
equipment damage, serious injury or even death.
Use proper power voltage.
AC power for the charger is AC100-240V, 50~60 Hz.
Test the AC power before use. When the output voltage of AC power is high or abnormal frequency is
generated, the product is damaged thus serious injury or even death may result.
AC output voltage should be measured using a circuit tester before connecting the AC power cable. Regular
inspection should also be conducted.
Do not pull the AC power cord with excessive force, apply heat or transform it.
When a damaged power cord is used, it may cause fi re or injury.
Use a three-plug AC power cord. Never use a two-plug power cord, cable or plug.
Do not touch the AC plug, AC power cord or splicer with wet hands. It may cause electrical shock.
Do not disassemble the AC charger, battery or KF4. Disassembly may cause fi re, electrical shock or injury.
!WARNINGS
Refer to the following when using the battery:
• Failure to use batteries and chargers provided by UCL SWIFT may result in smoke, equipment damage,
burn, injury or even death.
• Do not burn any conductive materials.
• Do not charge the battery near a fl ame.
• Do not give an excessive shock to the battery.
• When the battery does not completely charge in two hours, or when the green LED is not turned on, stop
charging immediately and contact UCL SWIFT.
• Do not put anything on the AC charger while charging.
Use only the AC charger provided. Do not use another AC power cord or battery. Excessive current may result
in equipment damage or injury.
Do not use the KF4 where there is harmful gas or fl ammable liquid. Explosion or fi re may result.
Do not use compressed air or compressed gas when cleaning the KF4.
Inspect the carry case belt before transportation. Equipment damage or injury may occur if the carrying case is
damaged.
Always follow safety best practices, including the use of safety goggles and protective clothing when working
with fi ber optic products, including the KF4.
Do not use the KF4 around high temperatures or fl ame. Injury or equipment damage may occur.
Be aware of and avoid hot surfaces associated with thermal strippers and sleeve heaters. Allow sleeves to cool
before handling.
| CAUTION: HIGH TEMPERATURES
SWIFT KF4-EN, Rev.C 5
WARNINGS
Do not disassemble the AC charger, battery or KF4. Deformation may cause fire, electrical
shock or injury.
Refer to the following when using the battery:
▪ Failure to use batteries and chargers provided by UCLSWIFT may result in smoke,
equipment damage, burn, injury or even death.
▪ Do not incinerate any conductive materials.
▪ Do not charge the battery near flame.
▪ Do not give an excessive shock to the battery.
▪ When the battery does not completely charge in two hours, or when the green LED is
not turned on, stop charging immediately and contact UCLSWIFT.
▪ Do not put anything on the AC charger while charging.
Use only the AC charger provided. Do not use another AC power cord or battery. Excessive
current may result in equipment damage or injury.
Do not use the KF4 where there is harmful gas or flammable liquid. Explosion or fire may
result.
Do not use compressed air or compressed gas when cleaning the KF4.
To inspect, carry case belt before transportation. If fallen the carry case due to damage on the
belt, it may incur equipment damage or injury.
Always follow safety best practices, including the use of safety goggles and protective clothing
when working with fiber optic products, including KF4.
Do not use the KF4 around high temperatures or flame. Injury or equipment damage may
occur.
CAUTION:
HIGH TEMPERATURES DO NOT SPRAY FREON GAS CAUTION:
HIGH VOLTAGE
SWIFT KF4-EN, Rev.C 5
WARNINGS
Do not disassemble the AC charger, battery or KF4. Deformation may cause fire, electrical
shock or injury.
Refer to the following when using the battery:
▪ Failure to use batteries and chargers provided by UCLSWIFT may result in smoke,
equipment damage, burn, injury or even death.
▪ Do not incinerate any conductive materials.
▪ Do not charge the battery near flame.
▪ Do not give an excessive shock to the battery.
▪ When the battery does not completely charge in two hours, or when the green LED is
not turned on, stop charging immediately and contact UCLSWIFT.
▪ Do not put anything on the AC charger while charging.
Use only the AC charger provided. Do not use another AC power cord or battery. Excessive
current may result in equipment damage or injury.
Do not use the KF4 where there is harmful gas or flammable liquid. Explosion or fire may
result.
Do not use compressed air or compressed gas when cleaning the KF4.
To inspect, carry case belt before transportation. If fallen the carry case due to damage on the
belt, it may incur equipment damage or injury.
Always follow safety best practices, including the use of safety goggles and protective clothing
when working with fiber optic products, including KF4.
Do not use the KF4 around high temperatures or flame. Injury or equipment damage may
occur.
CAUTION:
HIGH TEMPERATURES DO NOT SPRAY FREON GAS CAUTION:
HIGH VOLTAGE
| CAUTION: DO NOT SPRAY FREON GAS
| CAUTION: HIGH VOLTAGE

5 6
!CAUTIONS
Use the KF4 only on a stable surface to avoid falls that may cause damage or injury.
The KF4 should be accurately adjusted and treated in alignment. Do not give it a strong shock. Use the
carrying case provided for transporting and storing the KF4 to reduce humidity, vibration and shock.
When replacing the electrodes:
• Always use UCL SWIFT-approved replacements
• Ensure correct positioning
• Always replace in pairs
Failure to follow all warnings and cautions to ensure proper function of the KF4 may result in equipment
damage or a faulty splice.
Use only ethyl alcohol (96% or higher) or other approved cleaning solutions to clean the lens, V-groove, LCD
monitor and main body.
Use the splicer only within the stated operating environmental ranges. Store in a controlled environment to
avoid long-term exposure to damaging temperatures and humidity levels.
The KF4 should receive regular service by a UCL SWIFT-authorized service technician to ensure long-term
functionality and safety.
PRODUCT SPECIFICATIONS AND COMPONENTS
2.1| PRODUCT SPECIFICATIONS
CATEGORY MODEL
Battery
Cleaver blade
Electrode
Transporting case
Work belt
Work table
Sleeve
SOC connector
Alcohol dispenser
External power
Optical fiber holder
KF-3400
BI-07
EI-24
HC-11 (hard case)
WB-01
WK-02
S09-C, S09, S30-C, S30
SC, LC, FC, ST
POM
DC 12V (available for car cigar jack)
HS-250, HS-900, HS-2.5, HS-IN, KF4-SC/FC,
KF4-ST-01, KF4-ILC, LS-900 (choose one)
OPTIONAL ACCESSORIES
STANDARD PACKAGE
* Design, standard/optional package and specification shown above are subject to change with or without notice.
CATEGORY MODEL Q’TY
Arc fusion splicer
Battery
Battery adapter
Instructions for use
Spare electrode
Transporting case
Cooling tray
Screw driver
USB cable
Sleeve clamp
Cleaver
Manual stripper
Alcohol dispenser
SWIFT KF4
KF-3400
FY1701000
—
EI-24
Hard case
CT-01 (40mm(1.5in))
LD-3300
—
SC-01
CS-01BT
CF-02
PP
1
1
1
1
1 pair
1
1
1
1
1
1
1
1
CATEGORY
SPECIFICATIONS
DESCRIPTION
Fiber alignment
Applicable type of fibres
Fiber count
Applicable fiber dimensions
Fiber setting and cleaved length
Splicing modes
Typical splice loss
Return loss
Splicing time
Splice loss estimate
Sleeve heating time
Applicable protection sleeve
Storage of splice result
Tension test
Operating condition
Storage condition
Dimension
Weight
Viewing method and display
Fiber view and magnification
Power supply
No. of splice cycles with battery
Electrode life
Blade life
Terminals
IPAAS, Active V-Groove Alignment
SM (G.652; MM (G.651); DS (G.653); NZDS (G.655); SM (G.657 A1, A2/B2, B3)
Single fiber
Cladding diameter: 125�m; Coating diameter: 150�m-3mm
7mm to 16mm (0.28in to 0.63in)
Splice mode: 300; Heat mode: 100
SM: 0.03dB; MM: 0.01dB; DS:0.05dB; NZDS:0.05dB
>60dB
Typical 7 sec. with SM
Available
Typical 13 sec. with IS-60 mode, IS-60 sleeve
40mm (2.4in); 60mm (1.5in) micro sleeve
Data: up to 5,000 ea; Image: up to 5,000 ea
1.96N to 2.25N
Altitude: 0-5,000m above sea level; Temperature: -10ºC~50ºC (-14ºF~122ºF);
Humidity: 0-95%; Wind: 15m/s, non-condensing, dust proof, water proof, shock proof
Temperature: -40ºC~80ºC (40ºF~176ºF); Humidity: 0-95%
124(W) x 189(L) x 75(H)mm (without rubber protector)
1.1kg (including battery)
2 AXIS Two CMOS cameras with 109mm (4.3in) color LCD monitor
X/Y: 130X; Max: 260X
Li-ion battery (DC 14.8V, 3400mAh); 100~240V AC charger
Typical 200 cycles
Up to 38,000 splices
Up to 77,000 cleaves
USB
4230 LBJ Freeway, Ste.149 | Dallas, TX 75244
2ɝFH_)D[
LQIR#DPHULFDLOVLQWHFKFRP_ZZZDPHULFDLOVLQWHFKFRP
KF4
Active V-Groove Alignment
BENEFITS AND FEATURES
5HPRWH0DLQWHQDQFHYLDΖQWHUQHW
ΖGHDOIRU(QWHUSULVH'DWD&HQWHU%URDGEDQG
DQG)77+QHWZRUNDSSOLFDWLRQ
9HUVDWLOLW\0$;Ζ080
$FWLYH9*URRYH$OLJQPHQW0HWUR$FFHVV
1HWZRUNDQG)77+8QLYHUVDO)LEHU+ROGHUV
6L]H:HLJKW0Ζ1Ζ080
:RUOGȇVPRVWFRPSDFW$FWLYH9*URRYH
)XVLRQ6SOLFHU
(FRQRP\237Ζ080
7KHEHVWTXDOLW\EXGJHWSULFHGPDNH
HYHU\SHQQ\FRXQW
&RPSDWLEOHZLWK)XVLRQ6SOLFH2Q
&RQQHFWRU)62&LQDFFRUGDQFHZLWKWKH
LQGXVWULDOVWDQGDUG
KF4
Fusion Splice-On Connectors
Up to 38,000
ELECTRODE LIFE
Up to 75,000
ROTATING BLADE LIFE
3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 | Office: 972.556.0916 | Fax: [phone] | uclswiftna.com
KF4
Rev. 221004R3
CATEGORY MODEL
Cleaver blade
Electrode
Work belt
Work table
Sleeve
SOC connector
External power
Optical fiber holder
BI-07
EI-24
WB-01
WK-02
S09-C, S09, S30-C, S30
SC, LC, FC, ST
DC 12V (available for car cigar jack)
HS-2.5, HS-IN, KF4-ST-01
OPTIONAL ACCESSORIES
STANDARD PACKAGE
* Design, standard/optional package and specification shown above are subject to change
with or without notice.
CATEGORY MODEL Q’TY
Arc fusion splicer
Battery
Battery adapter
Instructions for use
Spare electrode
Transporting case
Cooling tray
Screw driver
USB cable
Sleeve clamp
Cleaver
Manual stripper
Alcohol dispenser
Cleaning brush
Tweezer
Optical fiber holder
SWIFT KF4
KF-3400
FY1701000
—
EI-24
Hard case
CT-01 (40mm(1.5in))
LD-3300
—
SC-01
CS-01BT
CF-02
POM
—
—
1
1
1
1
1 pair
1
1
1
1
1
1
1
1
1
1
CATEGORY
SPECIFICATIONS
DESCRIPTION
Fiber alignment
Applicable type of fibres
Fiber count
Applicable fiber dimensions
Fiber setting and cleaved length
Splicing modes
Typical splice loss
Return loss
Splicing time
Splice loss estimate
Sleeve heating time
Applicable protection sleeve
Storage of splice result
Tension test
Operating condition
Storage condition
Dimension
Weight
Viewing method and display
Fiber view and magnification
Power supply
No. of splice cycles with battery
Electrode life
Blade life
Terminals
IPAAS, Active V-Groove Alignment
SM (G.652; MM (G.651); DS (G.653); NZDS (G.655); SM (G.657 A1, A2/B2, B3)
Single fiber
Cladding diameter: 125�m; Coating diameter: 150�m-3mm
7mm to 16mm (0.28in to 0.63in)
Splice mode: 300; Heat mode: 100
SM: 0.03dB; MM: 0.01dB; DS:0.05dB; NZDS:0.05dB
>60dB
Typical 7 sec. with SM
Available
Typical 13 sec. with IS-60 mode, IS-60 sleeve
40mm (2.4in); 60mm (1.5in) micro sleeve
Data: up to 5,000 ea; Image: up to 5,000 ea
1.96N to 2.25N
Altitude: 0-5,000m above sea level; Temperature: -10ºC~50ºC (-14ºF~122ºF);
Humidity: 0-95%; Wind: 15m/s, non-condensing, dust proof, water proof, shock proof
Temperature: -40ºC~80ºC (40ºF~176ºF); Humidity: 0-95%
124(W) x 189(L) x 75(H)mm (without rubber protector)
1.1kg (including battery)
2 AXIS Two CMOS cameras with 109mm (4.3in) color LCD monitor
X/Y: 130X; Max: 260X
Li-ion battery (DC 14.8V, 3400mAh); 100~240V AC charger
Typical 200 cycles
Up to 38,000 splices
Up to 77,000 cleaves
USB
4230 LBJ Freeway, Ste.149 | Dallas, TX 75244


KF4
Active V-Groove Alignment
BENEFITS AND FEATURES















KF4
Fusion Splice-On Connectors
Up to 38,000
ELECTRODE LIFE
Up to 75,000
ROTATING BLADE LIFE
3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 |||
KF4
Rev. 221018R4
HS-250(Pair), HS-900(Pair),
LS-900L(Loose tube),
KF4-SC/FC, KF4-ILC
2.1.2| PRODUCT PACKAGE
CATEGORY MODEL
Cleaver blade
Electrode
Work belt
Work table
Sleeve
SOC connector
External power
Optical fiber holder
BI-07
EI-24
WB-01
WK-02
S09-C, S09, S30-C, S30
SC, LC, FC, ST
DC 12V (available for car cigar jack)
HS-2.5, HS-IN, KF4-ST-01
OPTIONAL ACCESSORIES
STANDARD PACKAGE
* Design, standard/optional package and specification shown above are subject to change
with or without notice.
CATEGORY MODEL Q’TY
Arc fusion splicer
Battery
Battery adapter
Instructions for use
Spare electrode
Transporting case
Cooling tray
Screw driver
USB cable
Sleeve clamp
Cleaver
Manual stripper
Alcohol dispenser
Cleaning brush
Tweezer
Optical fiber holder
SWIFT KF4
KF-3400
FY1701000
—
EI-24
Hard case
CT-01 (40mm(1.5in))
LD-3300
—
SC-01
CS-01BT
CF-02
POM
—
—
1
1
1
1
1 pair
1
1
1
1
1
1
1
1
1
1
CATEGORY
SPECIFICATIONS
DESCRIPTION
Fiber alignment
Applicable type of fibres
Fiber count
Applicable fiber dimensions
Fiber setting and cleaved length
Splicing modes
Typical splice loss
Return loss
Splicing time
Splice loss estimate
Sleeve heating time
Applicable protection sleeve
Storage of splice result
Tension test
Operating condition
Storage condition
Dimension
Weight
Viewing method and display
Fiber view and magnification
Power supply
No. of splice cycles with battery
Electrode life
Blade life
Terminals
IPAAS, Active V-Groove Alignment
SM (G.652; MM (G.651); DS (G.653); NZDS (G.655); SM (G.657 A1, A2/B2, B3)
Single fiber
Cladding diameter: 125�m; Coating diameter: 150�m-3mm
7mm to 16mm (0.28in to 0.63in)
Splice mode: 300; Heat mode: 100
SM: 0.03dB; MM: 0.01dB; DS:0.05dB; NZDS:0.05dB
>60dB
Typical 7 sec. with SM
Available
Typical 13 sec. with IS-60 mode, IS-60 sleeve
40mm (2.4in); 60mm (1.5in) micro sleeve
Data: up to 5,000 ea; Image: up to 5,000 ea
1.96N to 2.25N
Altitude: 0-5,000m above sea level; Temperature: -10ºC~50ºC (-14ºF~122ºF);
Humidity: 0-95%; Wind: 15m/s, non-condensing, dust proof, water proof, shock proof
Temperature: -40ºC~80ºC (40ºF~176ºF); Humidity: 0-95%
124(W) x 189(L) x 75(H)mm (without rubber protector)
1.1kg (including battery)
2 AXIS Two CMOS cameras with 109mm (4.3in) color LCD monitor
X/Y: 130X; Max: 260X
Li-ion battery (DC 14.8V, 3400mAh); 100~240V AC charger
Typical 200 cycles
Up to 38,000 splices
Up to 77,000 cleaves
USB
4230 LBJ Freeway, Ste.149 | Dallas, TX 75244


KF4
Active V-Groove Alignment
BENEFITS AND FEATURES















KF4
Fusion Splice-On Connectors
Up to 38,000
ELECTRODE LIFE
Up to 75,000
ROTATING BLADE LIFE
3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 |||
KF4
Rev. 221018R4
HS-250(Pair), HS-900(Pair),
LS-900L(Loose tube),
KF4-SC/FC, KF4-ILC
2.2.2| OPTIONAL ACCESSORIES

SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
PRODUCT OUTLINE
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fi ber to manual mode and adjust the camera’s focus. Stripping popup
menu should load.
Move the cursor to the right.
Move fi ber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode. Splice popup menu should load.
Move the cursor downward. Move each motor to manual mode. Heater
popup menu should load.
Initialize the splice function. Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
7
3.1| FUNCTION BUTTONS
BUTTON DESCRIPTION
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
3.2| COMPONENT NAME
| SLEEVE HEATER
| WIND COVER
| BATTERY
| MONITOR
SWIFT KF4-EN, Rev.C 10
3.2. Component name
Wind cover
Battery
Monitor
Sleeve heater
| OPEN
8
| DC IN/CHARGE-IN
| USB
| HEATER | HEATER COVER

9 10
INSTRUCTIONS FOR USE
The following is the KF4’s initial screen. For accurate splice results, splice mode and heater mode should be
selected. Basic information about the KF4 is displayed on the initial screen. Check that the proper mode is
selected before splicing.
4.1| POWER SUPPLY
The battery pack is built into the battery chamber. Loosen the bottom-cover bolts and exchange the battery.
Please be cautious when you detach the battery from the chamber.
4.1.1 BUILT IN BATTERY
4.1.2 BATTERY CHARGING
Before connecting the AC/DC charter’s DC cable to the DC jack of the battery to charge the battery, make sure
you check the voltage and frequency. When the battery is fully charged, the LED will turn green and power is
disconnected, activating protection circuit to avoid overcharge. The power is turned back on as the battery
needs to be charged. Charging resumes when the charger’s DC cable is connected to the battery’s DC jack.
| BATTERY STATUS INDICATOR
| CURRENT SPLICE MODE
| CURRENT HEATER MODE
SWIFT KF4-EN, Rev.C 13
4. Instructions for Use
The following is the KF4’s initial screen. For accurate splice results, splice mode and heater mode
should be selected. Basic information about the KF4 is displayed on the initial screen. Check that
the proper mode is selected before splicing.
4.1. Power supply
The battery pack is built into the battery chamber. Loosen the bottom-cover bolts and exchange
the battery. Please be cautious when you detach the battery from the chamber.
4.1.1 Built-in battery
Battery status indicator
Current splice mode
Current heater mode
SWIFT KF4-EN, Rev.C 14
4.1.2 Battery charging
Before connecting the AC/DC charter’s DC cable to the DC jack of the battery to charge the
battery, make sure you check the voltage and frequency. When the battery is fully charged, the
LED will turn green and power is disconnected, activating protection circuit to avoid overcharge.
The power is turned back on as the battery needs to be charged; charging resumes when the
charger’s DC cable is connected to the battery’s DC jack.
4.2. How to turn the power on/off
To power on the KF4, press and hold about 1 second with the wind cover closed. After
the functions, including motors, initialize, the screen displays the following. Splice and heater
mode should be selected. The current splice and heater mode are displayed at the bottom of the
screen.
4.2| HOW TO TURN THE POWER ON/OFF
To power on the KF4, press and hold about 1 second with the wind cover closed. After the functions of
motors and initialize, the screen will display the following. Then splice and heater mode should be selected.
The current splice and heater mode are displayed at the bottom of the screen.
4.3| KF4 SLEEVE HEATER
The sleeve heater of the KF4 reinforces the spliced point of the single fi ber.
The quality of fusion splicing on the fi ber should be good.
The fi ber and inserted sleeve tube should be properly aligned and installed on the heater.
Close the heater cover while the heater is on.
1| Choose the heater mode after the confi rmation of the length for the sleeve tube when placing a sleeve tube
on a heater.
2| Place the spliced point in the middle of the sleeve tube fi rst. Then, check the heating part on the heater and
place the sleeve tube on right position.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 14
4.1.2 Battery charging
Before connecting the AC/DC charter’s DC cable to the DC jack of the battery to charge the
battery, make sure you check the voltage and frequency. When the battery is fully charged, the
LED will turn green and power is disconnected, activating protection circuit to avoid overcharge.
The power is turned back on as the battery needs to be charged; charging resumes when the
charger’s DC cable is connected to the battery’s DC jack.
4.2. How to turn the power on/off
To power on the KF4, press and hold about 1 second with the wind cover closed. After
the functions, including motors, initialize, the screen displays the following. Splice and heater
mode should be selected. The current splice and heater mode are displayed at the bottom of the
screen.
ITEM DESCRIPTION
Cable diameter
Sleeve length
Heating time
Temperature range
250µm, 900µm, 2.0mm — 3.0mm
Standard 32mm
10 — 35 seconds
130°C — 200 °C

Choosing the improper mode of the heater for a sleeve tube may not shrink the sleeve tube properly. Specifi cally,
the SOC (Splice-On-Connector) should be placed on the right side edge of the heater in order to line up the
right end of the sleeve tube to the right side edge of the heater as shown on the picture below (Right picture). If
the SOC is placed in the middle or on the left side, the sleeve tube of the SOC does NOT shrink.
3| After settling the fi ber, turn on the heater by pressing . (Heating time 20sec)
4| Remove the sleeve protected fi ber by opening the cover when the cooling is completed.
The appropriate sleeve position helps reduce heating operation time.
4.4| SPLICE PROCEDURE
The status and cleaved quality of the fi ber can be monitored by using a KF4 image processing system.
However, for better splice results, visual inspection is also required.
In auto mode, the splicing procedure begins automatically as the wind cover is closed.
1| Fibers installed on the splicer advance toward each other and stop. The fi bers align once arc cleaning is
done. After that, the splicer checks the cleaved angle of each fi ber, the shape of the end-face contaminations
and so on. When the measured cleaved angle is bigger than the preset value, or damage is detected on the
fi ber, an error message is displayed on the screen. The splice procedure stops as well. Even if there is no error
message displayed, visual inspection of the monitor screen is always recommended.
2|Check that the Wind cover is properly closed at more than 900µm cable (Ø2.0~Ø3.0µm)
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
11 12
!CAUTION
!CAUTION
SWIFT KF4-EN, Rev.C 15
4.3. KF4 Sleeve Heater
The sleeve heater of the KF4 reinforces the spliced point of the single fiber.
The quality of fusion splicing on the fiber should be good.
The fiber and inserted sleeve tube should be properly aligned and installed on the heater.
Close the heater cover while the heater is on.
ITEM
DESCRIPTION
Cable diameter
Φ250 ㎛, Φ 900 ㎛, Φ 2.0 ㎜~ Φ 3.0 ㎜
Sleeve length
standard 32 mm
Heating time
10~35 seconds
Temperature range
130°C ~ 200 °C
i. Choose the heater mode after the confirmation of the length for the sleeve tube when placing a
sleeve tube on a heater.
ii. Place the spliced point in the middle of the sleeve tube first. Then, checking out the heating part
on the heater and place the sleeve tube on right position.
Choosing improper mode of the heater for a sleeve tube may not shrink the sleeve tube
properly. Especially, SOC (Splice-On-Connector) should be placed on the right side edge of the
heater in order to line up the right end of the sleeve tube to the right side edge of the heater as
shown on the picture below (Right picture). If SOC is placed in the middle or on the left side,
sleeve tube of the SOC does NOT shrink.
[Optical Fiber] [SoC Connector]
iii. After settling the fiber, turn on the heater by pressing .
. (Heating time 20sec)
SWIFT KF4-EN, Rev.C 15
4.3. KF4 Sleeve Heater
The sleeve heater of the KF4 reinforces the spliced point of the single fiber.
The quality of fusion splicing on the fiber should be good.
The fiber and inserted sleeve tube should be properly aligned and installed on the heater.
Close the heater cover while the heater is on.
ITEM
DESCRIPTION
Cable diameter
Φ250 ㎛, Φ 900 ㎛, Φ 2.0 ㎜~ Φ 3.0 ㎜
Sleeve length
standard 32 mm
Heating time
10~35 seconds
Temperature range
130°C ~ 200 °C
i. Choose the heater mode after the confirmation of the length for the sleeve tube when placing a
sleeve tube on a heater.
ii. Place the spliced point in the middle of the sleeve tube first. Then, checking out the heating part
on the heater and place the sleeve tube on right position.
Choosing improper mode of the heater for a sleeve tube may not shrink the sleeve tube
properly. Especially, SOC (Splice-On-Connector) should be placed on the right side edge of the
heater in order to line up the right end of the sleeve tube to the right side edge of the heater as
shown on the picture below (Right picture). If SOC is placed in the middle or on the left side,
sleeve tube of the SOC does NOT shrink.
[Optical Fiber] [SoC Connector]
iii. After settling the fiber, turn on the heater by pressing .
. (Heating time 20sec)
| OPTICAL FIBER | SOC CONNECTOR
SWIFT KF4-EN, Rev.C 16
iv. Remove the sleeve protected fiber by opening the cover when the cooling is completed.
The appropriate sleeve position helps reduce heating operation time.
3|Fibers are aligned, cladding to cladding, after inspection. Deviation on clad axis can be displayed on
the screen.
4| After alignment completes, arcing is conducted to splice fi bers.
5|After splicing is completed, the estimated value of the loss is displayed on the screen. The estimated value of
splice loss is subject to various factors related to the error. These factors related to an error affect the estimation
and calculation of estimated loss value as well. Calculation of estimated loss is based on factors such as MFD.
When estimated loss value exceeds the preset value, an error message is displayed on the screen. The error
message is also displayed when the spliced fi bers are too thick or thin, or when bubbles are generated on the
spliced point. If the splice result shown on the screen is not considered good enough, it is recommended that
splicing be conducted again.
6|The splice result is saved as follows.
7|When splice is completed, the splice result is automatically saved.
4.5| REMOVING THE SPLICED FIBER
1|Open the cover of the sleeve heater.
2|Open the wind cover.
3| Hold the fi ber on the left and open the clamp on the left.
4| Open the fi ber clamp on the right.
5| Hold both sides of the spliced fi ber and separate the fi ber from the KF4 with care.
4.6| HEATING PROTECTION SLEEVE
1|Move the spliced point to the center of the protecting sleeve. Place the protected pin face down in the sleeve.
2|Place the protecting sleeve at the center of the sleeve heater.
3| Hold and put down both fi bers as shown in the fi gure. The heater cover will automatically close.
SWIFT KF4-EN, Rev.C 17
4.4. Splice procedure
The status and cleaved quality of the fiber can be monitored by using a KF4 image processing
system. For better splice results, however, visual inspection is also required.
In auto mode, the splicing procedure begins automatically as the wind cover is closed.
i. Fibers installed on the splicer advance toward each other and stop. The fibers align once arc
cleaning is done. After that, the splicer checks the cleaved angle of each fiber, the shape of the
end-face contaminations and so on. When the measured cleaved angle is bigger than the preset
value, or damage is detected on the fiber, an error message is displayed on the screen. The
splice procedure stops as well. Even if there is no error message displayed, visual inspection of
the monitor screen is always recommended.
ii. Check that the Wind cover is properly closed at more than 900um cable (Ø2.0~Ø3.0um)
iii. Fibers are aligned, cladding to cladding, after inspection. Deviation on clad axis can be displayed
on the screen.
iv. After alignment completes, arcing is conducted to splice fibers.
v. After splicing is completed, the estimated value of the loss is displayed on the screen. The
estimated value of splice loss is subject to various factors related to the error. These factors
related to an error affect the estimation and calculation of estimated loss value as well.
Calculation of estimated loss is based on factors such as MFD. When estimated loss value
exceeds the preset value, an error message is displayed on the screen. The error message is also
displayed when the spliced fibers are too thick or thin, or when bubbles are generated on the
spliced point. If the splice result shown on the screen is not considered good enough, it is
recommended that splicing be conducted again.
vi. The splice result is saved as follows.
vii. When splice is completed, the splice result is automatically saved.

13 14
4|Heating starts by pressing .
5|LED turns off when heating is completed.
6| Open the heater cover and take out the fi ber. Do not touch the protecting sleeve or heater at any point
during or right after heating.
7| Conduct a fi nal inspection to check for bubbles, fragments or dust on the sleeve.
4.7| USE OF WORK BELT
The work belt of Swift KF4 is a type of auxiliary equipment that combines with its main body to facilitate
working at a manhole, utility pole, etc.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 19
4.7. Use of Work Belt
The work belt of Swift KF4 is a type of auxiliary equipment that combines with its main body to
facilitate working at a manhole, utility pole, etc.
Work belt components
| WORK BELT COMPONENTS
MAINTENANCE OF SPLICE QUALITY
5.1| CLEANING AND INSPECTION BEFORE SPLICE
5.1.1 V-GROOVE CLEANING
When the inside of the V-groove is contaminated, splice quality may deteriorate. It is important to regularly
inspect and frequently clean the V-groove as follows.
1|Open the wind cover.
2|Clean the V-groove using a cotton swab moistened with alcohol and any proper cleaning agents. Remove
the remaining alcohol from the V-groove using a clean, dry, lint-free cotton swab.
3| When a foreign substance cannot removed with a cotton swab, clean it with the tip of a cleaved fi ber and
repeat the steps above.
5.1.2 PUSHER BLOCK CLEANING
Pusher block contamination causes poor splice quality due to irregular pressure applied to the fi bers. It is
important to frequently inspect and regularly clean it.
SWIFT KF4-EN, Rev.C 19
4.7. Use of Work Belt
The work belt of Swift KF4 is a type of auxiliary equipment that combines with its main body to
facilitate working at a manhole, utility pole, etc.
Work belt components
SWIFT KF4-EN, Rev.C 19
4.7. Use of Work Belt
The work belt of Swift KF4 is a type of auxiliary equipment that combines with its main body to
facilitate working at a manhole, utility pole, etc.
Work belt components
SWIFT KF4-EN, Rev.C 19
4.7. Use of Work Belt
The work belt of Swift KF4 is a type of auxiliary equipment that combines with its main body to
facilitate working at a manhole, utility pole, etc.
Work belt components
SWIFT KF4-EN, Rev.C 21
5. Maintenance of Splice Quality
5.1. Cleaning and inspection before splice
5.1.1 V-groove cleaning
When the inside of the V-groove is contaminated, splice quality may deteriorate. It is important
to regularly inspect and frequently clean the V-groove as follows.
i. Open the wind cover.
ii. Clean the V-groove using a cotton swab moistened with alcohol and any proper cleaning agents.
Remove the remaining alcohol from the V-groove using a clean, dry, lint-free cotton swab.
iii. When a foreign substance cannot removed with a cotton swab, clean it with the tip of a cleaved
fiber and repeat the steps above.
5.1.2 Pusher block cleaning
Pusher block contamination causes poor splice quality due to irregular pressure applied to the
fibers. It is important to frequently inspect and regularly clean it.
SWIFT KF4-EN, Rev.C 21
5. Maintenance of Splice Quality
5.1. Cleaning and inspection before splice
5.1.1 V-groove cleaning
When the inside of the V-groove is contaminated, splice quality may deteriorate. It is important
to regularly inspect and frequently clean the V-groove as follows.
i. Open the wind cover.
ii. Clean the V-groove using a cotton swab moistened with alcohol and any proper cleaning agents.
Remove the remaining alcohol from the V-groove using a clean, dry, lint-free cotton swab.
iii. When a foreign substance cannot removed with a cotton swab, clean it with the tip of a cleaved
fiber and repeat the steps above.
5.1.2 Pusher block cleaning
Pusher block contamination causes poor splice quality due to irregular pressure applied to the
fibers. It is important to frequently inspect and regularly clean it.

15 16
5.2| REGULAR INSPECTION AND CLEANING
To ensure splicing quality, regular inspection and cleaning are required.
5.2.1 OBJECT LENS CLEANING
Contamination on the object lens surface disturbs the identifi cation of fi ber core location and consequently
causes high splice loss. Object lenses should be kept clean at all times. If dust accumulates for a prolonged
period, it may be diffi cult to remove. Clean the lens frequently as follows.
1| Turn the power off before cleaning the object lens.
2|Separate the electrodes.
3|Use a soft cotton swab moistened with alcohol to clean in a circular motion from the center as shown in the
fi gure below. Dry the remaining alcohol using a clean, dry, lint-free cotton swab.
4| The surface of the object lens should be clean without any lines or stains.
5|Reassemble the electrodes.
6|Turn the power on and check for any lines or stains on the monitor. Conduct a self-diagnosis.
5.2.2 ELECTRODES REPLACEMENT
The electrodes should be replaced after being used approximately 4000 times. If the number of arcs exceeds
the replacing cycle, an electrode replacement message is displayed on the screen. If electrodes are not
replaced, splice loss increases and the tensile force at the splicing point weakens.
1|Turn the power off when replacing the electrodes.
2|Open the wind cover and unscrew the clamp screw on the electrodes block.
SWIFT KF4-EN, Rev.C 22
5.2. Regular inspection and cleaning
To ensure splicing quality, regular inspection and cleaning are required.
5.2.1 Object lens cleaning
Contamination on the object lens surface disturbs the identification of fiber core location and
consequently causes high splice loss. Object lenses should be kept clean at all times. If dust
accumulates for a prolonged period, it may be difficult to remove. Clean the lens frequently as
follows.
i. Turn the power off before cleaning the object lens.
ii. Separate the electrodes.
iii. Use a soft cotton swab moistened with alcohol to clean in a circular motion from the center as
shown in the figure below. Dry the remaining alcohol using a clean, dry, lint-free cotton swab.
iv. The surface of the object lens should be clean without any lines or stains.
v. Reassemble the electrodes.
vi. Turn the power on; check for any lines or stains on the monitor; conduct a self-diagnosis.
3|Remove the electrode block and the electrodes.
4|Clean the electrodes carefully by using a soft cotton swab moistened with alcohol, then install.
5|Turn the power on and conduct the electrode stabilization process in the menu.
SWIFT KF4-EN, Rev.C 23
5.2.2 Electrodes replacement
The electrodes should be replaced after being used approximately 4000 times. If the number of
arcs exceeds the replacing cycle, an electrode replacement message is displayed on the screen. If
electrodes are not replaced, splice loss increases and the tensile force at the splicing point
weakens.
i. Turn the power off when replacing the electrodes.
ii. Open the wind cover and unscrew the clamp screw on the electrodes block.
iii. Remove the electrode block and the electrodes.
iv. Clean the electrodes carefully by using a soft cotton swab moistened with alcohol; then install.
v. Turn the power on and conduct the electrode stabilization process in the menu.
SWIFT KF4-EN, Rev.C 23
5.2.2 Electrodes replacement
The electrodes should be replaced after being used approximately 4000 times. If the number of
arcs exceeds the replacing cycle, an electrode replacement message is displayed on the screen. If
electrodes are not replaced, splice loss increases and the tensile force at the splicing point
weakens.
i. Turn the power off when replacing the electrodes.
ii. Open the wind cover and unscrew the clamp screw on the electrodes block.
iii. Remove the electrode block and the electrodes.
iv. Clean the electrodes carefully by using a soft cotton swab moistened with alcohol; then install.
v. Turn the power on and conduct the electrode stabilization process in the menu.

17 18
MENU
The main menu has eight submenus. Press to load the main menu.
The eight submenus can be selected by using , or by pressing the screen. The main menu
screen displays as follows.
SPLICING
• Replace: Selects and replaces a certain splice mode within the database
• Add: Selects and adds a certain splice mode within the database
• Select: Selects a splice mode to run
• Edit: Edits set values of splice mode
• Cancel: Closes the menu window
• Delete: Deletes splice mode
HEATER
• Replace: Selects and replaces a certain heater mode within the database
• Add: Selects and adds a certain heater mode within the database
• Select: Selects a heater mode to run
• Edit: Edits set values of heater mode
• Cancel: Closes the menu window
• Delete: Deletes heater mode
HISTORY (SPLICE RESULTS)
• DISPLAY HISTORY: Displays splice result and image
• CLEAR HISTORY: Deletes all data
OPTION
• DEFAULT: Auto, pause, auto heater
• MENU LOCK: Menu lock setting
• PASSWORD: Password sets upon locking
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 24
6. Menu
The main menu has eight submenus. Press to load the main menu.
The eight submenus can be selected by using , or by pressing
the screen. The main menu screen displays as follows.
n SPLICING
- Replace: Selects and replaces a certain splice mode within the database
- Add: Selects and adds a certain splice mode within the database
- Select: Selects a splice mode to run
- Edit: Edits set values of splice mode
- Cancel: Closes the menu window
- Delete: Deletes splice mode
n HEATER
- Replace: Selects and replaces a certain heater mode within the database
- Add: Selects and adds a certain heater mode within the database
- Select: Selects a heater mode to run
- Edit: Edits set values of heater mode
- Cancel: Closes the menu window
- Delete: Deletes heater mode
CALIBRATION
• ARC CALIBRATION: Adjusts arc calibration intensity
• ARC TEST: Check arc quantity through arc test
• DIAGNOSTIC TEST: Diagnoses equipment state
• MOTOR DRIVE: Operates motor manually
• MOTOR CALIBRATION: Initializes motor speed and location
ELECTRODE
• ELECTRODE STABILIZE: Conducts stabilization of electrodes
• ELECTRODES CAUTION: Sets the number of uses to inform about electrode replacement
• ELECTRODES REPLACE: Explains how to replace the electrodes
• ELECTRODE USED: Displays the electrode-use count
SETTING
• LANGUAGE: Selects a language
• DATE: Sets the present time
• POWER SAVE: Sets sleep mode
• VOLUME: Adjusts the intensity of the buzzer sound
• LCD BRIGHTNESS: Adjusts screen brightness
INFORMATION
• MAINTENANCE INFO: Displays maintenance schedule
• SENSOR VALUE: Indicates temperature and pressure
• VERSION: Shows the current version of the product
• HELP: Consists of:
— NAME OF PARTS
— CLEAN AND INSPECT
— WARNINGS
— A/S CONTACT LIST

2|Select an empty slot by pressing and then press .
3|Select a splice mode to add into the empty slot.
DELETING SPLICE MODE
1|Select a mode to be deleted.
2|Delete it by pressing
19 20
POPUP MENU
The purpose of the popup menu is to facilitate quick, easy access to the splice mode and heater mode. The
user can access the popup menu in various ways.
[Displaying popup menu]
1|Splice popup menu can display the current splice mode by pressing on the initial screen.
2|Heater popup menu can be displayed by pressing on the initial screen.
[Splice popup menu]
ADDING SPLICE MODE
1|Display splice popup menu by pressing on the initial screen.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 26
Popup Menu
The purpose of the popup menu is to facilitate quick, easy access to the splice mode and heater
mode. The user can access the popup menu in various ways.
[Displaying popup menu]
i. Splice popup menu can display the current splice mode by pressing on the initial screen.
ii. Heater popup menu can be displayed by pressing on the initial screen.
SWIFT KF4-EN, Rev.C 26
Popup Menu
The purpose of the popup menu is to facilitate quick, easy access to the splice mode and heater
mode. The user can access the popup menu in various ways.
[Displaying popup menu]
i. Splice popup menu can display the current splice mode by pressing on the initial screen.
ii. Heater popup menu can be displayed by pressing on the initial screen.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 27
[Splice popup menu]
n Adding splice mode
i. Display splice popup menu by pressing on the initial screen.
ii. Select an empty slot by pressing and then press .
iii. Select a splice mode to add into the empty slot.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 27
[Splice popup menu]
n Adding splice mode
i. Display splice popup menu by pressing on the initial screen.
ii. Select an empty slot by pressing and then press .
iii. Select a splice mode to add into the empty slot.
SWIFT KF4-EN, Rev.C 27
[Splice popup menu]
n Adding splice mode
i. Display splice popup menu by pressing on the initial screen.
ii. Select an empty slot by pressing and then press .
iii. Select a splice mode to add into the empty slot.
SWIFT KF4-EN, Rev.C 28
n Deleting splice mode
i. Select a mode to be deleted.
ii. Delete it by pressing .
SWIFT KF4-EN, Rev.C 28
n Deleting splice mode
i. Select a mode to be deleted.
ii. Delete it by pressing .
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.

21 22
[Heater popup menu]
ADDING HEATER MODE
1|Display heater popup menu by pressing on the initial screen.
2|Select an empty slot by pressing and then pressing .
3|Select a heater mode to add into the empty slot.
DELETING HEATER MODE
1|Select a mode to be deleted.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 29
[Heater popup menu]
n Adding heater mode
i. Display heater popup menu by pressing on the initial screen.
ii. Select an empty slot by pressing and then pressing
iii. Select a heater mode to add into the empty slot.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 29
[Heater popup menu]
n Adding heater mode
i. Display heater popup menu by pressing on the initial screen.
ii. Select an empty slot by pressing and then pressing
iii. Select a heater mode to add into the empty slot.
SWIFT KF4-EN, Rev.C 30
n Deleting heater mode
i. Select a mode to be deleted.
ii. Delete it by pressing .
2|Delete it by pressing .
6.1| SPLICE
To display splice mode, press and select “SPLICE” menu with the button. It displays a screen for splice
mode selection as follows. The screen has a list of splice modes to facilitate easy selection. Up to 300 splice
modes can be saved. These splice modes are classifi ed into general modes and user-defi ned modes.
• General splice mode: Nos. 1 — 26
• User-defi ned splice mode: Nos. 27 — 300
[Splice modes summary]
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 30
n Deleting heater mode
i. Select a mode to be deleted.
ii. Delete it by pressing .
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 31
6.1. SPLICE
To display splice mode, press and select “SPLICE” menu with the button. It
displays a screen for splice mode selection as follows. The screen has a list of splice modes to
facilitate easy selection. Up to 300 splice modes can be saved. These splice modes are classified
into general modes and user-defined modes.
n General splice mode: Nos. 1~26
n User-defined splice mode: Nos. 27~300
[Splice modes summary]
SPLICE MODE
DESCRIPTION
SM
For basic SM fiber. MFD of single mode fiber is about 9~10 µm at 1310
nm wavelength.
NZ
For NZDS fiber. MFD of NZDS fiber is about 9~10 µm at 1550 nm
wavelength. WDM fiber can also be spliced on this mode.
DS
For DS fiber. MFD of DS fiber is about 7~9 µm at 1550 nm wavelength.
MM
For MM fiber. The core diameter of MM fiber is about 50~62.5 µm.
Other
Other splice modes are saved in the KF4 database.
New splice modes are currently being updated.
Users should upgrade equipment regularly by contacting UCLSWIFT.
SPLICE MODE DESCRIPTION
SM
NZ
DS
MM
Other
For basic SM fi ber. MFD of single mode fi ber is about 9 — 10µm at 1310nm wavelength.
For NZDS fi ber. MFD of NZDS fi ber is about 9 — 10µm at 1550nm wavelength.
WDM fi ber can also be spliced on this mode.
For DS fi ber. MFD of DS fi ber is about 7 — 9µm at 1550nm wavelength.
For MM fi ber. The core diameter of MM fi ber is about 50 — 62.5µm.
Other splice modes are saved in the KF4 database; New splice modes are currently being updated;
Users should upgrade equipment regularly by contacting UCLSWIFT.

23 24
6.1.1 DELETION
First, select a splice mode by pressing . Then press to delete the selected mode. General modes Nos.
1 — 26 cannot be deleted.
6.1.2 REPLACEMENT
Select a splice mode to replace and press . Splice modes saved in the database are displayed on the screen.
Select a splice mode to replace and press . The mode is replaced with the new mode.
Preset modes Nos. 1 — 26 cannot be replaced.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 32
6.1.1 Deletion
First, select a splice mode by pressing . Then press to delete the selected mode.
General modes Nos. 1~26cannot be deleted.
6.1.2 Replacement
Select a splice mode to replace and press . Splice modes saved in the database are
displayed on the screen. Select a splice mode to replace and press . The mode is
replaced with the new mode.
Preset modes Nos. 1~26 cannot be replaced.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 32
6.1.1 Deletion
First, select a splice mode by pressing . Then press to delete the selected mode.
General modes Nos. 1~26cannot be deleted.
6.1.2 Replacement
Select a splice mode to replace and press . Splice modes saved in the database are
displayed on the screen. Select a splice mode to replace and press . The mode is
replaced with the new mode.
Preset modes Nos. 1~26 cannot be replaced.
6.1.3 ADDITION
Press to display splice modes saved in the database. Select a splice mode to add and press . The newly
added mode is located on the last number.
Additions cannot be made on general modes Nos. 1 — 26.
6.1.4| EDITING SPLICE MODES
Select a splice mode to edit with and press . Different set values of the selected splice mode are
displayed. Press a set value and change it to the proper one.
SWIFT KF4-EN, Rev.C 32
6.1.1 Deletion
First, select a splice mode by pressing . Then press to delete the selected mode.
General modes Nos. 1~26cannot be deleted.
6.1.2 Replacement
Select a splice mode to replace and press . Splice modes saved in the database are
displayed on the screen. Select a splice mode to replace and press . The mode is
replaced with the new mode.
Preset modes Nos. 1~26 cannot be replaced.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.

25 26
[Set values editable within mode]
SET VALUE DESCRIPTION
Fiber Type
Mode Title
Auto Power
Proof Test
Cleaved Limit
Loss Limit
Fiber Angle Limit
Cleaning Power
Cleaning Time
Gap
Gap set Pos
Prefuse Power
Prefuse time
Overlap
Arc1 Power
Arc1 Time
Arc2 Power
Arc2 Time
Arc2 On - Time
Arc2 Off - Time
Rearc Time
Displays the list of splice mode that is saved on the splicer data to facilitate
the selection of a proper mode for use. Among splice modes saved on the
database, it copies a similar splice mode to use an editing function.
Mode title 1 is for indicating splice mode within 11 characters at a maximum.
The closer fi bers are aligned to the core center with a fewer number of
errors, the quicker and better the arcing is done.
Conducts tensile force test after splice.
Sets the cleaved angle’s error limit. When either of the cleaving angles on
both fi bers are outside the limit., an error message is displayed.
Sets the estimated loss value’s error limit. When estimated loss is higher
than the limit, error message is displayed.
When the bending of 2 spliced fi bers exceeds the set limit, an error
message is displayed.
A short arc cleaning is conducted to remove fi ne dust on the fi ber surface
upon initial stage of fi ber alignment. It sets the intensity of the cleaning arc.
It sets the time for the cleaning arc.
Upon fi nal alignment, it sets the clearance of the cross section between
both fi bers.
It sets location of fi ber spliced at the center of arc. When MFD of both
fi bers differs, do the sealing procedure by melting the smaller MFD fi ber
more than the bigger MFD fi ber. To heat the smaller MFD fi ber more,
splice loss can be lowered by moving the clearance location toward the
bigger MFD fi ber at the center of arc.
It sets initial arc amount from the beginning of arc before the fi ber is
advanced. If the value of initial arc amount is too low, the angle of the
fi ber cross section is poor and consequently, an offset can be incurred
on the axis if it is too high, the fi ber can made round or burnt too much
and, consequently, the splice loss value can be big.
It sets the initial time from the beginning of the arc before the fi ber advance.
If [Prefuse time] is long, it means the same that [initial arc amount] gets big.
It sets the duplication of the fi ber on for the fi ber advance amount.
If [Prefuse Power] is weak or [Prefuse time] is short, set the [overlap] to
somewhat small and if the arc amount is strong and the time is long, set it
to somewhat big.
Main arc can be adjusted by 2 levels. The fi rst level of arc is [Arc1 Power]
and the second is [Arc2 Power]. [Arc1 Power] is set in this area.
It sets the time for [Arc1 Power].
[Arc2 Power] is the second level of arc. [Arc2 Power] is set in this area.
It sets the time for [Arc2 Power]. It sets the time for [Arc2 Power].
[Arc time 2] is generally set as “OFF.” It can set the arc time as a very long time
period but when [Arc1 Time] and [Arc2 Time] exceed 30 seconds,
the electrodes can be damaged.
While [Arc2 Power] is on arc, you can set the arc amount as “ON” and “OFF”
in turn. The time period for [Arc2 Power] being “On” is set in this area.
For re-arc, set the arc time as “ON” at all times.
It sets the time period for the arc of [Arc2 Power] when it is turned off.
When [Arc2 Power] is occasionally stopped, re-arc can also be stopped.
When re-arc is continuously required, set as to “OFF.”
It sets re-arc time. Within [splice mode edition], it automatically sets to arc
the re-arc amount with the same intensity as that of [Arc2 Power].
If [Arc2 Power] is set as ON/OFF, re-arc is automatically changed.
GENERAL
MODE
USER
MODE
Editable
Editable
Uneditable
Uneditable
Editable
Editable
Uneditable
Editable
Editable
Uneditable
Uneditable
Uneditable
Uneditable
Unedietable
Unedietable
Unedietable
Unedietable
Unedietable
Unedietable
Unedietable
Editable
Editable
Editable
Editable
Editable
Editable
Editable
Editable
Editable
Editable
Editable
Editable
Editable
Editable
Edietable
Edietable
Edietable
Edietable
Edietable
Edietable
Edietable
Editable
SET VALUE DESCRIPTION
Taper Splice Off
Taper Wait
Taper Speed
Taper Length
Offset
When the fi ber is made thin, the splice loss is sometimes increased.
This pulling function is set to “OFF.” The following 3 parameters decide the
pulling shape.
It designates the time period from the last of the advanced fi ber
amount to the beginning of pulling.
It sets the fi ber pulling speed.
It sets the fi ber pulling time.
It is the sum of the initially measured splice loss value and the increased loss.
When splicing a special fi ber or other fi bers, high loss may be incurred in
spite of optimum arc conditions. To match the estimated splice loss and the
actual splice loss, the minimum value of actual splice loss should be set.
GENERAL
MODE
USER
MODE
Uneditable
Uneditable
Uneditable
Uneditable
Uneditable
Editable
Editable
Editable
Editable
Editable
6.1.5 SELECTION
Press to save the selected splice mode to memory and use upon splicing.
6.1.6 CLOSE
Press to return to the previous stage.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.

6.2| HEATER
To display heater mode, press and then select “HEATER” from the menu using . The selecting screen is
equipped with various heater modes to facilitate easy selection. Heater mode can be expanded and saved for
up to 100 modes. Heater mode Nos. 1—16 cannot be deleted or replaced.
[Outline of heater mode]
Choose the right mode for each sleeve tube type and SOC. Otherwise sleeve tubes do NOT shrink
properly.
For the SOC, operators must use UCLSWIFT standard products. For other sleeves, see manufacturer
specifi cations and adjust manually.
Heater modes specify temperature, time and heating location on the heater plate.
6.2.1 DELETION
First, select a heater mode by pressing . Press to delete. Mode Nos. 1—16 cannot be deleted.
27 28
SET VALUE DESCRIPTION
60mm
40mm
60mm IS-60
45mm IS-45
S09
S09-C
S20
S30
S30-C
LC09/20-C
ST09-C
ST30-C
Standard 60mm micro sleeve
Standard 40mm micro sleeve
60mm micro sleeve
45mm micro sleeve
45mm sleeve for 0.9mm cable
22mm sleeve for SOC (SC-0.9mm)
45mm sleeve for 2.0mm cable
45mm sleeve for 3.0mm cable
32mm sleeve for SOC (SC-3.0mm)
25mm sleeve for SOC (LC-0.9, 2.0mm)
28mm sleeve for SOC(ST-0.9mm)
36mm sleeve for SOC (ST-3.0mm)
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 38
6.2. HEATER
To display heater mode, press and then select “HEATER” from the menu using
. The selecting screen is equipped with various heater modes to facilitate easy selection.
Heater mode can be expanded and saved for up to 100 modes. Heater mode Nos. 1~16 cannot
be deleted or replaced.
[Outline of heater mode]
SET VALUE
DESCRIPTION
60mm
Standard 60mm micro sleeve
40mm
Standard 40mm micro sleeve
60mm IS-60
60mm micro sleeve
45mm IS-45
45mm micro sleeve
S09
45mm sleeve for 0.9mm cable
S09-C
22mm sleeve for SOC(SC-0.9mm)
S20
45mm sleeve for 2.0mm cable
S30
45mm sleeve for 3.0mm cable
S30-C
32mm sleeve for SOC(SC-3.0mm)
LC09/20-C
25mm sleeve for SOC(LC-0.9 , 2.0mm)
ST09-C
28mm sleeve for SOC(ST-0.9mm)
ST30-C
36mm sleeve for SOC(ST-3.0mm)
Choose the right mode for each sleeve tube type and SOC. Otherwise sleeve tubes do NOT shrink
properly.
For the SOC, operators must use UCLSWIFT standard products. For other sleeves, see
manufacturer specifications and adjust manually.
Heater modes specify temperature, time and heating location on the heater plate.
!CAUTIONS
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
6.2.2 REPLACEMENT
Select a heater mode to replace, and press to display heater modes on the screen. Select desired heater
mode and press to replace with the selected mode.
General modes Nos. 1—16 cannot be replaced.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 39
6.2.1 Deletion
First, select a heater mode by pressing . Press to delete. Mode Nos. 1~16 cannot
be deleted.
6.2.2 Replacement
Select a heater mode to replace, and press to display heater modes on the screen. Select
desired heater mode and press to replace with the selected mode.
General modes Nos. 1~16 cannot be replaced.

6.2.4 EDITION
Select a heater mode to edit with and press . Values of the selected heater mode are displayed. Press a
set value to change.
6.2.5 SELECTION
Press to save the selected heater mode to memory.
6.2.6 CLOSE
Press to return to the previous stage.
6.2.3 ADDITION
Press to display heater modes on the screen. Select a heater mode to add and press to add. The newly
added mode is located on the last number.
Additions cannot be made on general modes Nos. 1—16.
29 30
SWIFT KF4-EN, Rev.C 40
6.2.3 Addition
Press to display heater modes on the screen. Select a heater mode to add and press to
add. The newly added mode is located on the last number.
Additions cannot be made on general modes Nos. 1~16.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 41
6.2.4 Edition
Select a heater mode to edit with and press . Values of the selected heater mode are
displayed. Press a set value to change.
6.2.5 Selection
Press to save the selected heater mode to memory.
6.2.6 Close
Press to return to the previous stage.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.

31 32
6.3| HISTORY (SPLICE RESULT)
To display splice mode, press . Select “HISTORY” menu with button to display splice result menu.
6.3.1 SPLICE RESULT DISPLAY
The splicer can save up to 5,000 splice data and images. Each page shows seven splice data and images.
Use to advance screens.
6.3.2 DELETION OF SPLICE RESULT
Data and images can be deleted in a single step.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 42
6.3. HISTORY (Splice result)
To display splice mode, press . Select “HISTORY” menu with button to display
splice result menu.
6.3.1 Splice result display
The splicer can save up to 5,000 splice data and images.
Each page shows seven splice data and images. Use to advance
screens.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 42
6.3. HISTORY (Splice result)
To display splice mode, press . Select “HISTORY” menu with button to display
splice result menu.
6.3.1 Splice result display
The splicer can save up to 5,000 splice data and images.
Each page shows seven splice data and images. Use to advance
screens.
SWIFT KF4-EN, Rev.C 43
6.3.2 Deletion of splice result
Data and images can be deleted in a single step.
6.4| OPTION
To display options menu, press and then select “OPTION” menu with button. This displays options
menu as follows.
6.4.1 SPLICE OPERATION
Splice operation consists of fi ve sub-checkboxes. As the user marks a checkbox, each function is activated.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 44
6.4. OPTION
To display options menu, press and then select “OPTION” menu with button.
This displays options menu as follows.
6.4.1 Splice operation
Splice operation consists of five sub-checkboxes. As the user marks a checkbox, each function is
activated.
SET VALUE
DESCRIPTION
Auto
Splice automatically starts when closing the wind cover.
Pause 1
It temporarily stops after the first alignment is finished.
Press
to advance to the next step.
Pause 2
It temporarily stops after clad alignment is finished.
Press to advance to the next step.
Auto Heat Heater automatically operates after splice is finished.
Auto Heat2
After installing the sleeve, Heater automatically operates
when the heater cover is closed.
SWIFT KF4-EN, Rev.C 44
6.4. OPTION
To display options menu, press and then select “OPTION” menu with button.
This displays options menu as follows.
6.4.1 Splice operation
Splice operation consists of five sub-checkboxes. As the user marks a checkbox, each function is
activated.
SET VALUE
DESCRIPTION
Auto
Splice automatically starts when closing the wind cover.
Pause 1
It temporarily stops after the first alignment is finished.
Press
to advance to the next step.
Pause 2
It temporarily stops after clad alignment is finished.
Press to advance to the next step.
Auto Heat Heater automatically operates after splice is finished.
Auto Heat2
After installing the sleeve, Heater automatically operates
when the heater cover is closed.
SET VALUE DESCRIPTION
Auto
Pause 1
Pause 2
Auto heat
Auto heat 2
Splice automatically starts when closing the wind cover.
It temporarily stops after the fi rst alignment is fi nished. Press to advance to the next step.
It temporarily stops after clad alignment is fi nished. Press to advance to the next step.
Heater automatically operates after splice is fi nished.
After installing the sleeve, Heater automatically operates when the heater cover is closed.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.

33 34
6.4.2 MENU LOCK
This menu includes a function to restrict access to the splice mode and heater mode settings. There is also a
function to disable the deletion of the splice result. After activating this lock function, access to the menu lock
can also be restricted. Password entry is required to release this restriction; memorize the password. If you
forget the password, send the equipment to UCLSWIFT to reset the password.
6.4.3 PASSWORD
The password can be changed as follows.
1|Enter the current password. The initial password is “1234.”
SWIFT KF4-EN, Rev.C 45
6.4.2 Menu lock
This menu includes a function to restrict access to the splice mode and heater mode settings.
There is also a function to disable the deletion of the splice result. After activating this lock
function, access to the menu lock can also be restricted. Password entry is required to release
this restriction; memorize the password. If you forget the password, send the equipment to
UCLSWIFT to reset the password.
TEST ITEM
DESCRIPTION
Splice Lock
Restricts modification on splice mode.
Heat Lock
Restricts modification on heater mode.
Clear Memory Lock
Restricts deletion of splice result.
Password Query
Shows a screen to enter your password.
The initial password is “1234.”
TEST ITEM DESCRIPTION
Splice lock
Heat lock
Clear memory lock
Password query
Restricts modifi cation on splice mode.
Restricts modifi cation on heater mode.
Restricts deletion of splice result.
Shows a screen to enter your password. The initial password is “1234.”
SWIFT KF4-EN, Rev.C 46
6.4.3 Password
The password can be changed as follows.
i. Enter the current password. The initial password is “1234.”
ii. Enter a new password.
SWIFT KF4-EN, Rev.C 46
6.4.3 Password
The password can be changed as follows.
i. Enter the current password. The initial password is “1234.”
ii. Enter a new password.
2|Enter a new password.
3|Enter the new password again.
When the entered password does not match, the following message is shown and it goes back to the
previous stage.
Memorize the password. If you forget the password, the equipment should be returned to UCLSWIFT to reset
the password.
SWIFT KF4-EN, Rev.C 46
6.4.3 Password
The password can be changed as follows.
i. Enter the current password. The initial password is “1234.”
ii. Enter a new password.
SWIFT KF4-EN, Rev.C 47
iii. Enter the new password again.
When the entered password does not match, the following message is shown and it goes back
to the previous stage.
Memorize the password. If you forget the password, the equipment should be returned to
UCLSWIFT to reset the password.
SWIFT KF4-EN, Rev.C 47
iii. Enter the new password again.
When the entered password does not match, the following message is shown and it goes back
to the previous stage.
Memorize the password. If you forget the password, the equipment should be returned to
UCLSWIFT to reset the password.

3|When arc calibration is completed, the following screen is displayed.
4|Press to stop arc before calibration is completed if necessary.
6.5.2 ARC TEST
Swift KF4 measures by ARC TEST menu if arc power is adequate. When arc power is too weak or too strong it is
automatically adjusted by executing ARC CALIBRATION menu.
Only SM fi ber should be used for arc calibration.
1| Prep and insert SM fi ber into the splicer using clamps or proper fi ber holders.
2|Press as follows.
35 36
6.5| CALIBRATION
To display splice mode, press and select the “CALIBRATION” menu with the button. The calibration
menu is equipped with various functions, such as arc amount calibration, motor operation test, etc.
6.5.1 ARC CALIBRATION
The KF4 continuously checks for a change in temperature and air pressure through each sensor. Based on such
data, arc amount is automatically adjusted. However, a change in arc amount due to abrasion of the electrodes
or the fi ber splice, is not automatically adjusted. The central axis of the arc can also be moved toward the left or
right. In this case, arc calibration is required.
When executing arc calibration, arc voltage is automatically changed to a proper value. This value is calculated
internally. The arc voltage cannot arbitrarily be changed.
Only SM fi ber should be used for arc calibration.
1| Prep and insert SM fi ber into the splicer using clamps or proper fi ber holders.
2|Press as follows.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 48
6.5. CALIBRATION
To display splice mode, press and select the “CALIBRATION” menu with the
button. The calibration menu is equipped with various functions, such as arc amount calibration,
motor operation test, etc.
6.5.1 Arc calibration
The KF4 continuously checks for a change in temperature and air pressure through each sensor.
Based on such data, arc amount is automatically adjusted. A change in arc amount due to
abrasion of the electrodes or the fiber splice, however, is not automatically adjusted. The central
axis of the arc can also be moved toward the left or right. In this case, arc calibration is required.
- When executing arc calibration, arc voltage is automatically changed to a proper value. This
value is calculated internally; the arc voltage cannot arbitrarily be changed.
- Only SM fiber should be used for arc calibration.
SWIFT KF4-EN, Rev.C 48
6.5. CALIBRATION
To display splice mode, press and select the “CALIBRATION” menu with the
button. The calibration menu is equipped with various functions, such as arc amount calibration,
motor operation test, etc.
6.5.1 Arc calibration
The KF4 continuously checks for a change in temperature and air pressure through each sensor.
Based on such data, arc amount is automatically adjusted. A change in arc amount due to
abrasion of the electrodes or the fiber splice, however, is not automatically adjusted. The central
axis of the arc can also be moved toward the left or right. In this case, arc calibration is required.
- When executing arc calibration, arc voltage is automatically changed to a proper value. This
value is calculated internally; the arc voltage cannot arbitrarily be changed.
- Only SM fiber should be used for arc calibration.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 49
i. Prep and insert SM fiber into the splicer using clamps or proper fiber holders.
ii. Press as follows.
iii. When arc calibration completes, the following screen is displayed.
iv. Press to stop arc before calibration is completed if necessary.
SWIFT KF4-EN, Rev.C 49
i. Prep and insert SM fiber into the splicer using clamps or proper fiber holders.
ii. Press as follows.
iii. When arc calibration completes, the following screen is displayed.
iv. Press to stop arc before calibration is completed if necessary.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 50
6.5.2 Arc Test
Swift KF4 measures by ARC TEST menu if arc power is proper. When arc power is too weak or too
strong it is automatically adjusted by executing ARC CALIBRATION menu.
l Only SM fiber should be used for arc calibration.
i. Prep and insert SM fiber into the splicer using clamps or proper fiber holders.
ii. Press as follows.
iii. When arc test completes, the following screen is displayed.
!CAUTION
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 50
6.5.2 Arc Test
Swift KF4 measures by ARC TEST menu if arc power is proper. When arc power is too weak or too
strong it is automatically adjusted by executing ARC CALIBRATION menu.
l Only SM fiber should be used for arc calibration.
i. Prep and insert SM fiber into the splicer using clamps or proper fiber holders.
ii. Press as follows.
iii. When arc test completes, the following screen is displayed.

37 38
3|When arc test is completed, the following screen is displayed.
4|Press to stop arc before test is completed if necessary.
5|Arc Test Results
6.5.3 DIAGNOSTIC TEST
The diagnostic test is a function to facilitate dust examination, LED examination, motor test and calibration.
SWIFT KF4-EN, Rev.C 51
iv. Press to stop arc before test is completed if necessary.
v. Arc Test Result
TEST RESULT
DESCRIPTION
Arc Good
The current arc amount is proper
Arc too weak
The current arc power is too weak and needs Arc
Calibration
Arc too strong
The current arc power is too strong and needs Arc
Calibration
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
TEST RESULT DESCRIPTION
Arc good
Arc too weak
Arc too strong
The current arc amount is adequate
The current arc power is too weak and needs Arc Calibration
The current arc power is too strong and needs Arc Calibration
SWIFT KF4-EN, Rev.C 52
6.5.3 Diagnostic test
The diagnostic test is a function to facilitate dust examination, LED examination, motor test and
calibration.
TEST ITEM
DESCRIPTION
Dust Testing
Conducts dust test without fiber
LED Testing
Conducts LED test without fiber
Motor Testing
Conducts motor test
Heater Testing
Conducts heater test
TEST ITEM DESCRIPTION
Dust testing
LED testing
Motor testing
Heater testing
Conducts dust test without fi ber.
Conducts LED test without fi ber.
Conducts motor test.
Conducts heater test.
6.5.4 MOTOR DRIVE
Motor drive checks whether the motor operates normally in manual mode.
1| Remove the fi ber from the splicer.
2|Select “MOTOR DRIVE” with the button.
3|Change the motor selection by pressing . The name of the selected motor is indicated at the top of the screen.
4|Operate the motor in a direction wanted by pressing .
6.5.5 MOTOR CALIBRATION
The motor setting is set on splicer as default, but depending on motor setting location, splice speed may slow
down. If the speed slows down during the splice operation, or any abnormality occurs while in the entering
position, the motor setting can be automatically calibrated through this function.
SWIFT KF4-EN, Rev.C 53
6.5.3 Motor drive
Motor drive checks whether the motor operates normally in manual mode.
i. Remove the fiber from the splicer.
ii. Select “MOTOR DRIVE” with the button.
iii. Change the motor selection by pressing . The name of the selected motor is indicated at
the top of the screen.
iv. Operate the motor in a direction wanted by pressing .
Motor
X/Y Moves fiber down Moves fiber up
ZL Moves right fiber backward Moves right fiber forward
ZR Moves left fiber forward Moves left fiber backward
S Moves step by step upon every press of the button
M Continuously moves upon pressing the button
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
MOTOR
X/Y
ZL
ZR
S
M
Moves fi ber down.
Moves left fi ber backward.
Moves right fi ber forward.
Moves step by step upon every press of the button.
Continuously moves upon pressing the button.
SWIFT KF4-EN, Rev.C 9 3. Product Outline 3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off. Move the cursor to the left. Move fiber to manual mode and adjust the camera’s focus. Stripping popup menu should load. Move the cursor to the right. Move fiber to manual mode and adjust the camera’s focus. Move the cursor upward. Move each motor to manual mode. Splice popup menu should load. Move the cursor downward. Move each motor to manual mode. Heater popup menu should load. Initialize the splice function. Return to the menu screen. Complete a selection. Follow the next step on the menu screen. Splice execution. Return to the initial screen and initialize splice function. Turn on the heater. When it is on, the lamp on the left is in the red. Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
SWIFT KF4-EN, Rev.C 9
3. Product Outline
3.1. Function buttons
BUTTON
DESCRIPTION
Press and hold about 1 second to turn the power on/off.
Move the cursor to the left.
Move fiber to manual mode and adjust the camera’s focus.
Stripping popup menu should load.
Move the cursor to the right.
Move fiber to manual mode and adjust the camera’s focus.
Move the cursor upward.
Move each motor to manual mode.
Splice popup menu should load.
Move the cursor downward.
Move each motor to manual mode.
Heater popup menu should load.
Initialize the splice function.
Return to the menu screen.
Complete a selection.
Follow the next step on the menu screen.
Splice execution.
Return to the initial screen and initialize splice function.
Turn on the heater.
When it is on, the lamp on the left is in the red.
Press once more when it is on, and the heater is turned off.
Moves fi ber up.
Moves left fi ber forward.
Moves right fi ber backward.
Moves step-by-step upon every press of the button.
Continuously moves upon pressing the button.
SWIFT KF4-EN, Rev.C 54
6.5.4 Motor calibration
The motor setting is set on splicer as default, but depending on motor setting location, splice
speed may slow down. If the speed slows down during the splice operation, or any abnormality
is incurred while in the entering position, the motor setting can be automatically calibrated
through this function.
i. Prep and insert SM fiber into the splicer using clamps or proper fiber holders.
ii. Select “MOTOR CALIBRATION” with the button.
iii. If an error message is displayed after testing, immediately contact UCLSWIFT.
iv. End the calibration by pressing .
