Ucl swift Tek-6 User manual

NORTH AMERICA

SWIFT TEST KIT TEK-6

TABLE OF CONTENTS

uclswiftna.com

SECTION ONE:LSSM |LASER LIGHT SOURCE |QUICK START GUIDE

SECTION TWO:LSSM |LASER LIGHT SOURCE |TECHNICAL GUIDE

SECTION THREE:OPM1 |OPTICAL POWER METER |QUICK START GUIDE

SECTION FOUR:OPM1 |OPTICAL POWER METER |REFERENCE & TEST GUIDE

SECTION FIVE:HFM1 |HANDHELD INSPECTION MICROSCOPE |QUICK START GUIDE

SECTION SIX:VFF1 |VISUAL FAULT FINDER |QUICK START GUIDE

TRAINING MANUAL

SECTION ONE

LSSM |LASER LIGHT SOURCE

QUICK START GUIDE

NORTH AMERICA

QUICK START GUIDE

The LSSM dual laser source is a singlemode test laser used for verifying the proper function of ber optic

networks. This document will serve as an overview of the major features and functions of the device and offer

tips for troubleshooting common issues in optical networks.

FEATURES

CONNECTOR ADAPTER

(Interchangeable)

WAVELENGTH INDICATOR

LOW BAT TERY INDICATOR

POWER BUTTON

2 KHZ BUTTON

WAVELENGTH BUTTON

EXTERNAL POWER PORT

NORTH AMERICA

Laser Light Source - SM

LSSM

INTRODUCTION

Connector Adapter

Wavelength Indicator

Power Button

Change Wavelength

Button

Low Battery

Indicator

2kHz Button

External Power

Port

The LSSM comes with an SC screw-on adapter. Additional adapters are

available from SWIFT.

This unit offers 1310nm and 1550nm wavelengths. When the LSSM is

turned on, the red light indicates which wavelength is selected. The red

light blinks to indicate when the 2kHz modulation is turned ON.

A red indicator light appears when the CR2 battery power is low.

Replace or recharge the battery, depending on the battery type, to

return to normal operation of the LSSM.

Use to turn the LSSM ON and OFF. The unit will turn off automatically

after 15 minutes. To bypass auto-shutoff, hold the power button for 5

seconds when turning ON.

Toggles the modulation of currently-selected wavelength output. The

laser ashes at 2000 times per second to provide a recognizable signal

to a companion power meter. Output power of the laser is reduced by

3dB when the modulation is active.

Switches between the 1310nm and 1550nm wavelength.

The port accepts the PSD1 power supply. The power supply is not a

battery charger - just a battery bypass.

PAGE 2 3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 | Ofce: 972.556.0916 | Fax: 972.910.8384

LSSM

WARNING

Read and understand all of the instructions and safety information in this manual before

operating this tool.

LASER HAZARD

Please note that 1310nm and 1550nm wavelengths are not visible to the human eye. Do not look

directly into the output port of the LSSM or directly into any fiber connector that may be live.

Since the laser is invisible to the eye, the eye’s natural blink reflex is suppressed. This can cause

damage to the retina.

FDA 21 CFR 1040.10 & 1040.11

IEC 60825-1: 2007-03

Class 1 Laser Product

The LSSM transmits either the 1310nm or 1550nm wavelength on singlemode ber. It is important to use a

test jumper to mate the LSSM to the ber-under-test.

TRANSMITTING LIGHT

Test Jumper

Signal Propagates Down Fiber

Mate Connectors Appropriately

The LSSM is calibrated to have an output power level of -5dBm. Variations in power level between -5dBm

and -8dBm may be normal depending on the quality and age of the test jumper, the LSSM output port, and

other factors.

Always ensure that the LSSM is transmitting an acceptable power level before performing an insertion loss

test. Simply insert the test jumper (plugged into the LSSM) into a companion power meter set to the dBm

mode. The power meter will indicate the measured output power of the laser.

OUTPUT POWER

OPM1

Test Jumper Plugged

into Power Meter Power Meter Displays

Output Power of Laser

TO CLEAN THE FERRULE:

• Unplug the test jumper

• Unscrew the adapter until it spins freely, then pull

• Inspect the ferrule with an approved microscope,

clean if necessary, and replace adapter

The LSSM utilizes a physical ber connection at the output port. It ensures a steady power level for performing

insertion loss tests.

Ensure that any test jumpers are inspected and cleaned before plugging into the LSSM unit. If soiled or damaged

connectors are inserted, they can cause damage to the LSSM output port and the unit may need to be repaired.

OUTPUT PORT MAINTENANCE

LSSM

When the LSSM’s 2kHz modulation is active, the selected wavelength indicator will blink. The modulation

is recognized by optical power meters further down the ber and indicated by a 2kHz notication on the

screen and a loud beep. The modulated tone can also be recognized through the ber jacket when a Fiber

Identier is used.

USING THE 2KHZ FUNCTION

Test Jumper has physical contact with the

ferrule inside the LSSM

The Fiber Identier introduces a bend into the ber which leaks light from the core onto the detector of the

power meter. When using a Fiber Identier, expect a 30 to 35dB offset in core power.

PAGE 4 3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 | Ofce: 972.556.0916 | Fax: 972.910.8384

Blue connectors (UPC) have a straight ferrule with a domed interface. Green connectors (APC) have an

eight-degree angled ferrule with a domed interface.

UPC and APC connectors are not compatible. NEVER connect UPC and APC connectors together, OR plug

an APC connector into the LSSM unit. This can cause irreparable damage to both connectors.

TESTING NOTES

LSSM

UNPACKING & INSPECTION

The LSSM is supplied with a soft carry case, SC adapter installed on the unit, 3.0V CR2 battery, and an

instruction card. Contact SWIFT immediately if any part of the unit or packaging is damaged, or otherwise

unsatisfactory.

LOW BATTERY

The LSSM provides over 1000 operations under normal conditions. When the LOW BAT LED indicator is

illuminated on the device, the CR2 battery should be replaced or recharged, depending on the battery type.

OPTICAL CONNECTOR INTERFACE

The LSSM is equipped with a SC/UPC connector adapter that is compatible with only SC/UPC optical

connectors. The connector adapter interface should be kept covered and protected from contamination.

Care must be taken to avoid objects that may damage the ber inside the adapter mount. Always inspect

and clean bers before mating them to the device. If scratches or breaks occur on the ber surface, please

contact SWIFT for proper service.

CALIBRATION

All SWIFT brand products include a 2-year warranty. SWIFT recommends recalibration every two years to

ensure adherence to NIST measurement standards. The rst recalibration is free within the warranty period.

MAINTENANCE

3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 | Ofce: 972.556.0916 | Fax: 972.910.8384

SWIFT offers the PSD1 wall plug for users who wish to leave their LSSM turned on for long periods of time.

This is NOT a charger, but rather powers the unit from a wall outlet.

PSD1 BATTERY BYPASS

SPECIFICATIONS

Wavelength

Output Power

Output Stability

Spectral Width

Optical Interface

Tone Output

Power

Battery

Operating Temperature

Storage Temperature

Dimensions

Weight

DUAL SINGLEMODE LASER SOURCE

1310nm & 1550nm

-5.0dBm

±0.05dB (1 hour)

±0.03dB long-term (15 min warm-up)

5nm/5nm

SC/FC/ST/LC interchangeable

2kHz

Push button toggle/auto-off

CR2

-10º to +50ºC

-30º to +60ºC

6.1” x 0.94” x 0.75” (15.5 x 2.83 x 1.9cm)

3oz. (85.4g)

3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 | Ofce: 972.556.0916 | Fax: 972.910.8384 PAGE 5

LSSM

CK-01

Bag, 9x8x3 zippered

Swabs, package of 25

AquaKleen cleaner, 2 ﬂ oz bottle

FiberKleen wipes, pk of 50 wipes

Brush

Screwdriver

Tweezers

Illuminated jeweler’s loupe

Instruction sheet

Zipper pull

Sharpie, medium point

CK-02

Bag, 9x8x3 zippered

Swabs, package of 25

AquaKleen cleaner, 2 ﬂ oz bottle

FiberKleen wipes, pk of 50 wipes

IBC-SC

IBC-LC

Optipop-R

Instruction sheet

Zipper pull

PAGE 6 3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 | Ofce: 972.556.0916 | Fax: 972.910.8384

This product conforms with health, safety, and environmental protection standards for products sold within

the European Economic Area (EEA). This product was tested by an ISO 17025 accredited laboratory and

complies with the following CE directives and standards listed below:

DIRECTIVES: Electromagnetic Compatibilities (2014/30/EU)

STANDARDS: EMC: EN 61326-1:2013 Industrial;

Safety: EN/IEC61010- 1:2010+A1:2016

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter-

ference in a residential installation. This equipment generates, uses and can radiate radio frequency energy,

and if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of

the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CERTIFICATIONS

LSSM

uclswiftna.com

Ofce: 972.556.0916

Fax: 972.910.8384

CONTACT

SECTION TWO

LSSM |LASER LIGHT SOURCE

TECHNICAL GUIDE

NORTH AMERICA

TECHNICAL GUIDE

The LSSM dual laser source provides stabilized optical power levels for accurate loss measurements on

singlemode ber systems. Technicians can utilize each of the wavelengths included in this light source to

reference and test with UCL Swift’s optical power meters and gather measurements to meet international

standards.

The LSSM provides a 2kHz tone output which is recognized by optical power meters; the incoming 2kHz

signal is identied and an audible alert is provided by the power meter. This 2kHz signal will also allow ber

identication when used with non-invasive ber identier devices, such as our FI2K.

Easy removal of the included SC adapter allows the light source ferrule to be cleaned, preventing

contamination of test jumpers. Additional adapters are available.

This device maintains full compliance with all FDA and CFR standards for light-emitting products.

FEATURES

Small form-factor for fast, simple testing in the eld

Single output port ensures faster switching when

testing at multiple wavelengths

NIST-traceable laser output

Long-lasting battery

Combine LSSM with an optical

power meter (OPM1 pictured)

to perform insertion loss tests

on singlemode ber.

The 2kHz tone output of the

LSSM can be recognized

through the ber jacket when

a Fiber Identier is used.

Quick-change adapters allow

users to adjust the LSSM output

to match their testing situation.

NORTH AMERICA

Laser Light Source - SM

LSSM

INTRODUCTION

PAGE 2 3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 | Ofce: 972.556.0916 | 972.910.8384

SPECIFICATIONS

LSSM

Wavelength

Output Power

Output Stability

Spectral Width

Optical Interface

Tone Output

Laser Class

Power

Battery

Operating Temperature

Storage Temperature

Dimensions

Weight

DUAL SINGLEMODE LASER SOURCE

1310nm & 1550nm

-5.0dBm

±0.05dB (1 hour)

±0.03dB long-term (15 min warm-up)

5nm/5nm

SC/FC/ST/LC interchangeable

2kHz

Class 1 (FDA 21 CFR 1040.11)

Push button toggle/auto-off

CR2

-10º to +50ºC

-30º to +60ºC

6.1” x 0.94” x 0.75” (15.5 x 2.83 x 1.9cm)

3oz. (85.4g)

Interchangable Adapter

(SC shown) Low Battery

Indicator

Modulation Control

(2kHz/CW)

Wavelength Indicator

Power Button

Change Wavelength

Button

CK-01

Bag, 9x8x3 zippered

Swabs, package of 25

AquaKleen cleaner, 2 ﬂ oz bottle

FiberKleen wipes, pk of 50 wipes

Brush

Screwdriver

Tweezers

Illuminated jeweler’s loupe

Instruction sheet

Zipper pull

Sharpie, medium point

CK-02

Bag, 9x8x3 zippered

Swabs, package of 25

AquaKleen cleaner, 2 ﬂ oz bottle

FiberKleen wipes, pk of 50 wipes

IBC-SC

IBC-LC

Optipop-R

Instruction sheet

Zipper pull

SECTION THREE

OPM1 |OPTICAL POWER METER

QUICK START GUIDE

NORTH AMERICA

FEATURES

CONNECTOR ADAPTER

(Interchangeable)

LOW BAT TERY INDICATOR

2KHZ TONE INDICATOR

SAVE BUTTON

RCL BUTTON

USB BUTTON

LCD SCREEN

MEASUREMENT MODE

INDICATOR - dB/dBm

The OPM1 comes with a 2.5mm universal adapter. Additional adapters

are available from SWIFT.

“BATT” will appear on the LCD screen when the CR2 3V battery needs

to be recharged or replaced, depending on the battery type.

A beep will sound and show “2 kHz” on the LCD once a 2 kHz modulated

signal is recognized.

Over 4,000 readings may be saved on the OPM1. Each time the save

button is pressed, the current reading will be saved to internal storage. The

display ashes the indexed location where the reading has been saved.

Toggles through the saved readings on the device. The indexed location,

wavelength, and reading will ash on-screen.

When the OPM1 is connected via USB to a computer running SWIFT

brand software, pressing this button will transfer all saved data points

into the software for reporting.

The screen displays the measured value, selected wavelength, and

status indicators.

dB is a loss measurement. dBm is an absolute power measurement.

QUICK START GUIDE

NORTH AMERICA

Optical Power Meter

OPM1

Connector Adapter

LCD Screen

Measurement

Mode Indicator

Wavelength

Button

Low Battery

Indicator

Power

Button

dB/dBm

Button

2kHz Tone

Indicator

Save Button

RCL

Button 6

USB Button

PAGE 2 3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 | Ofce: 972.556.0916 | Fax: 972.910.8384

OPM1

WARNING

Read and understand all of the instructions and safety information in this manual before

operating this tool.

ELECTRIC SHOCK HAZARD

Contact with live circuits could result in severe injury or death. Pay attention to proper battery polarity.

Do not mix battery types or manufacturers. Do not open the unit. Use this unit only for its intended

purpose as outlined in this guide.

WAVELENGTH BUTTON

dB/dBm BUTTON

POWER BUTTON

Hold the button to switch the OPM1 between the 850, 1300, 1310,

1490, 1550, 1611, and 1625nm wavelengths. Press the button once to

immediately display the current wavelength. The selected wavelength

will briey appear on-screen every 8 seconds.

Press the button to toggle between dB and dBm modes. Hold the button

down when in dBm mode to set a reference on the OPM1.

Press the button once to turn the OPM1 on. Press once again to turn the

OPM1 off. The OPM1 will automatically turn off after 5 minutes if inactive.

LASER HAZARD

Avoid eye exposure to open ber connectors and interfaces when working with ber systems. They

may be connected to a live laser source. Do not look into the output port of a laser source. Point

ber endfaces toward non-reective surfaces to prevent reection of laser.

ITEM DAMAGE HAZARD

Do not leave the item in direct sunlight or near heat sources, submerge in water, or subject the unit

to strong impact. Cover the ber interface with the ip-cap when the unit is not in use.

DO NOT THROW THIS PRODUCT AWAY

Contact your local recycling station to dispose of properly.

IMPORTANT SAFETY INFORMATION

AUDIBLE ALERTS

The OPM1 emits an audible beep each time a major function is used. To disable most beeps, ensure that the

unit is OFF. Press and hold the Save button, and turn the unit ON while holding the Save button. Perform the

same procedure to turn the audible beeps back on.

CONTINUOUS USAGE MODE

The OPM1 turns off automatically if no buttons are pressed for 5 minutes. To bypass this feature, hold the

Power button for 3 seconds when powering on. A series of beeps will indicate that the unit is now in

Continuous Mode and will not turn off automatically.

REVIEWING SAVED READINGS

While in the RCL mode, use the Save and Wavelength buttons to navigate through the saved readings on

the device. Each reading has a “location” indicated by a 4-digit number. Note the blue arrows on the Save

and Wavelength buttons. The data cycles at either end. Scrolling “up” from the last data point will cycle back

to the rst location (0001) and vice versa.

DELETING SAVED READINGS

Press and hold the Save and Wavelength buttons simultaneously to delete all saved readings in the OPM1’s

internal memory. The screen ashes 0000 to indicate that the memory is empty.

NON-VOLATILE MEMORY

The OPM1 uses a non-volatile memory system. Data is not lost if the unit is turned off while testing, if the

battery is removed, or if the unit is stored for long periods of time.

FUNCTION TIPS

OPM1

Before transferring data from the OPM1 to the computer, download and install the SWIFT brand software,

available online at uclswiftna.com

• Plug the OPM1 into the computer using the included USB cable. If this is the rst time it has been

plugged in, wait at least ten seconds for the drivers to install.

• Place the SWIFT brand software into Dump/Sync mode by navigating to Settings > Data Mode > Dump Mode.

• Press the USB button on the OPM1 to dump/sync all data points. The data from the OPM1 appears in

the box on the left side of the window.

• Fill out the elds on the right side of the window (Customer, User, Test Site, etc).

• Navigate to Settings > Report Settings to identify a minimum and maximum value for the PASS/FAIL

functionality. Choose a color code scheme from this window, if necessary.

• To create the nal report, click File > Export to Excel.

USB DOWNLOADS

PAGE 4 3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 | Ofce: 972.556.0916 | Fax: 972.910.8384

OPM1

The OPM1 can be used in a live streaming mode with the SWIFT brand software.

• With the OPM1 plugged in via USB, place the SWIFT brand software into Active Mode by navigating to

Settings > Data Mode > Active Mode.

• Click the Save button on-screen to save the live reading displayed in the window. Save as many readings

as needed.

• To create the nal report, click File > Export to Excel.

UNPACKING & INSPECTION

The OPM1 is supplied with a 2.5mm adapter installed on the unit, a LC 1.25mm adapter is also included in

the kit, 3.0V CR2 battery, USB cable, and an instruction card. Contact SWIFT immediately if any part of the

unit or packaging is damaged, or otherwise unsatisfactory.

LOW BATTERY

The OPM1 provides over 1000 operations under normal conditions. When the BATT indicator is shown on

the device screen, the CR2 battery should be recharged or replaced, depending on the battery type.

OPTICAL CONNECTOR INTERFACE

The OPM1 is equipped with a universal connector adapter that is compatible with many popular style connectors.

The connector adapter interface should be kept covered and protected from contamination. Care must be taken to

avoid objects that may damage the glass surface of the detector mount. If scratches or breaks occur on the surface,

please contact UCL Swift NA for proper service.

CALIBRATION

All SWIFT brand products include a 2-year warranty. SWIFT recommends recalibration every two years to

ensure adherence to NIST measurement standards. The rst recalibration is free within the warranty period.

DATA STREAMING

MAINTENANCE

3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 | Ofce: 972.556.0916 | Fax: 972.910.8384

SPECIFICATIONS

Detector Type

Measurement Range

Wavelength Range

Selectable Wavelengths

Resolution

Absolute Accuracy

Optical Interface

Display

Tone ID

Storage

Data Transfer

Power

Operating Temperature

Storage Temperature

Battery

Dimensions

Weight

OPTICAL POWER METER

-02: InGaAs/-04: Filtered InGaAs

-02: +6 to -70dBm/-04: +23 to -45dBm

850nm to 1650nm

850/1300/1310/1490/1550/1611/1625nm

0.01dB

±0.25dB (23ºC +/- 2ºC at 0dBm)

Universal 2.5mm (additional adapters available)

LCD

2kHz

4000+ measurements

Mini-USB (live readings or data dump)

Push button toggle/auto-off

-10º to +55ºC

-30º to +70ºC

CR2

6.1” x 0.94” x 0.75” (15.5 x 2.83 x 1.9cm)

3oz. (85.4g)

3330 Earhart Drive, Suite 208 |Carrollton, TX 75006 | Ofce: 972.556.0916 | Fax: 972.910.8384 PAGE 5

OPM1

CK-01

Bag, 9x8x3 zippered

Swabs, package of 25

AquaKleen cleaner, 2 ﬂ oz bottle

FiberKleen wipes, pk of 50 wipes

Brush

Screwdriver

Tweezers

Illuminated jeweler’s loupe

Instruction sheet

Zipper pull

Sharpie, medium point

CK-02

Bag, 9x8x3 zippered

Swabs, package of 25

AquaKleen cleaner, 2 ﬂ oz bottle

FiberKleen wipes, pk of 50 wipes

IBC-SC

IBC-LC

Optipop-R

Instruction sheet

Zipper pull
